Frigidaire 131956700A User manual

P/N131956700A(0407)

2
For your safety, the information in this manual must be followed to minimize the risk of
fire or explosion or to prevent property damage, personal injury or loss of life.
-Donotstoreorusegasolineorotherflammablevaporsandliquidsinthevicinityofthisoranyother
appliance.
- WHATTODOIFYOUSMELLGAS:
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
•Clear the room, building or area of all occupants.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
•Ifyoucannotreachyourgassupplier,callthefiredepartment.
Installationandservicemustbeperformedbyaqualifiedinstaller,serviceagencyorthegassupplier.
PrintedinU.S.A.
ImportantSafetyInstructions
Readallinstructionsbeforeusingthisdryer.
Toreducetheriskoffire,electricalshock,orinjurytopersonswhen
usingthisdryer,complywiththebasicwarningslistedbelow.
Failuretocomplywiththesewarningscouldresultinseriouspersonalinjuries.
PreventFire
Donotdryitemsthathavebeenpreviouslycleanedin,soakedin,or
spottedwithgasoline,cleaningsolvents,kerosene,waxes,etc.Donotstorethese
items on or near the dryer. These substances give off vapors that could ignite or
explode.
Topreventfire,donotuseheattodryitemscontainingplastic,foam
rubberor similarlytexturedrubber-like materials,oritems containingfeathersor
down.UseAirFluff(NoHeat)only.
Clean the lint screen before or after each load. The interior of the
dryer,lintscreenhousingandexhaustductshouldbecleanedapproximatelyevery
18monthsbyqualifiedservicepersonnel.Anexcessiveamountoflintbuild-upin
these areas could result in inefficient drying and possible fire. See Care and
Cleaning,page6.
Do not operate the dryer if the lint screen is blocked, damaged or
missing.Firehazard,overheatinganddamagetofabricscanoccur.Ifyourdryerhas
adryingrack,alwaysreplacethelintscreenwhenfinishedusingthedryingrack.
Keepareaaroundtheexhaustopeningandsurroundingareasfree
fromthe accumulationoflint, dustand dirt.
Do not obstruct the flow of ventilating air. Do not stack or place
laundryorthrowrugsagainstthefrontorbackofthedryer.
Donotsprayanytypeofaerosolinto,onorneardryeratanytime.
Do not use fabric softeners or products to eliminate static unless
recommendedbythemanufacturerofthefabricsoftenerorproduct.
Do not place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical reaction that could
causea loadtocatchfire.
Failuretocomplywiththesewarningscouldresultinfire,explosion,seriousbodily
injuryand/ordamagetotherubberorplasticpartsofthedryer.
©2000 White Consolidated Industries, Inc.
Allrightsreserved.
ProductRegistration
Thank you for choosing this dryer.
Thisowner'sguidewillexplainproper
operationandcare.
RecordYourModelandSerial
Numbers
Record below the model and serial
numbersfoundonthedryerserialplate
located on the left side of the door
opening.Keepthesenumbersforfuture
reference.
ModelNumber _________________
SerialNumber _________________
DateofPurchase _______________
RegisterYourProduct
Theself-addressedPRODUCT
REGISTRATIONCARDshouldbefilled
incompletely,signedandreturned.
Contents
ProductRegistration ........................ 2
ImportantSafetyInstructions ........ 2-3
DryingProcedures ........................... 4
Features.......................................... 5
CommonDryingProblems .............. 5
CareandCleaning ......................... 6
AvoidServiceChecklist................... 7

3
ProtectChildren
Donotallowchildrentoplayonorinthedryer.Closesupervisionof
childrenisnecessarywhenthedryerisusednearchildren.Aschildrengrow,teach
themtheproper,safeuseofallappliances.
Destroythecarton,plasticbagandotherpackingmaterialsafterthe
dryer is unpacked. Children might use them for play. Cartons covered with rugs,
bedspreadsorplasticsheetscanbecomeairtightchambers.
Keeplaundryproductsoutofchildren'sreach.Topreventpersonal
injury,observeallwarningsonproductlabels.
Beforethedryerisremovedfromserviceordiscarded,removethe
dryerdoortopreventaccidentalentrapment.
Failuretocomplywiththesewarningscouldresultinseriouspersonalinjuries.
PreventInjury
Topreventshockhazardandassurestabilityduringoperation,the
dryermust beinstalled andelectrically groundedby aqualified serviceperson in
accordancewithlocalcodes.Installationinstructionsarepackedinthedryerforthe
installer'sreference.RefertoINSTALLATIONINSTRUCTIONSfordetailedgrounding
procedures.Ifthedryerismovedtoanewlocation,haveitcheckedandreinstalled
byaqualifiedserviceperson.
To prevent personal injury or damage to the dryer, the electrical
powercordofagasdryermustbepluggedintoaproperlygroundedandpolarized
3-prong outlet. The third grounding prong must never be removed. Never
ground the dryer to a gas pipe. Do not use an extension cord or an adaptor
plug.
ALWAYS disconnect the dryer from the electrical supply before
attemptinganyserviceorcleaning.Failuretodosocanresultinelectricalshockor
injury.
Do not use any type spray cleanser when cleaning dryer interior.
Hazardousfumesorelectricalshockcouldoccur.
Topreventinjury,donotreachintothedryerifthedrumismoving.
Waituntilthedryerhasstoppedcompletelybeforereachingintothedrum.
Topreventinjuryanddamagetothedryer:
• All repairs and servicing must be performed by an authorized servicer
unlessspecificallyrecommendedinthisOwner'sGuide.Useonlyauthorized
factoryparts.
• Do not tamperwith controls.
• Do not installor store the dryer where it will be exposed to the weather.
Athermallimiterswitch automatically turnsoffthemotor in theunlikelyevent
ofanoverheatedsituation(electricdryersonly).Aservicetechnicianmustreplacethe
thermallimiterswitchaftercorrectingthefault.
Failuretocomplywiththesewarningscouldresultinseriouspersonalinjuries.
SAVETHESEINSTRUCTIONS
Note:Theinstructionsappearinginthis
Owner's Guide are not meant to cover
every possible condition and situation
that may occur. Common sense and
cautionmustbepracticedwheninstalling,
operatingandmaintaininganyappliance.
ThisOwner'sGuideprovidesgeneral
operatinginstructionsforyourdryer.It
alsocontainsinformationaboutfeatures
for several other models. Your dryer
maynothaveeveryfeatureincluded.
Usethedryeronlyasinstructedinthis
Owner's Guide and the Operating
Instructions cardincluded withyour
dryer.
Avoid fire hazard or
electricalshock.Donotuseanadaptor
plug or extension cord or remove
groundingprongfromelectricalpower
cord.Failuretofollowthiswarningcan
causeseriousinjury,fireordeath.
CORRECT
Use this way ONLY
ELECTRICDRYERS:
DRYER
FUSED30AMP
120/240VOR
120/208 V
WALL
RECEPTACLE DRYER
SERVICECORD
14-30R
GASDRYERS:
CORRECT
Use this way ONLY
Grounding type
w
all receptacle
Power supply
cord with 3-prong
grounding plug
Do not under
any circumstances
cut, remove,
or bypass
the grounding prong
from this plug.

4
•Followtheguidelinesbelowforpreparingtheloadfordrying.
•ReadtheOperatingInstructionscardforoperatingyourspecificmodel.
• Always read and follow fabric care labels and laundry product labels.
Toreducetheriskoffire,electricalshock,orinjurytopersons,read
ImportantSafetyInstructions,pages2-3,beforeoperatingthisdryer.
1. Prepare itemsfor drying.
•Dryitemsofsimilarfabric,weightandconstructioninthesameload.
•Separatedarkitemsfromlight-coloreditems.Separateitemsthatshedlint
from those that attract lint. If an item sheds lint, turn it inside out.
•Besurebuckles,buttonsandtrimareheatproofandwon'tdamagethedrum
finish.Closezippers,fastenhooksandVelcro®-likefasteners.Tiestringsand
sashestopreventsnaggingandtangling.
•Ifpossible,turnpocketsinsideoutforevendrying.
•Checkforstainswhichmaynothavebeenremovedinwashing.Dryerheat
maypermanentlysetsomestains.Repeatstainremovalprocessbefore
drying.
•Placesmallitemsinameshbagtopreventtanglingandforeasyremoval.
2. Checkthatlintscreeniscleanandinplace.
3. Load the dryer.
• Theaverageloadwillfillthedrum1/3to1/2full.Itemsneedroomtotumble
freelyforevendryingandlesswrinkling.Donotoverloaddryer.
• Whendryinglargeitems,dryonly2or3atatime.Fillouttheloadwithsmall
andmediumsizeditems.
• Fordelicateorverysmallloads,add2lint-freetowelsforbetterdrying,less
wrinkling,andtopreventgreasestainscausedbyfabricsoftenersheets.
• Donotoverdryitems.Overdryingcancausewrinkling,shrinkage,harshness,
andabuild-upofstaticelectricity,whichcanproducemorelint.
• Ifdesired,addadryerfabricsoftenersheet.
4. Closethedryerdoorandsetdryercontrols(somemodels).
SeeOperatingInstructionscardforyourspecificmodelcontrols.
5. Turncycleselectorclockwisetothedesiredsetting.
6. Start the dryer.
• PushStartButtonfor2secondsorturntheSTARTknobclockwisetoON,hold
for1-2secondsandrelease.
• Toaddorremoveitemswhenthedryerisrunning,openthedoor.Thedryer
will always stop when the door is opened. Allow the drum to come to a
completestopbeforereachinginside.
• Torestartdryer,closethedoorthenpushtheStartButtonfor2secondsor
turntheSTARTknobclockwisetoON,holdfor1-2secondsandrelease.
• ThedryerwillnotstartifthecycleselectorisintheOFFposition.
7. When the cycle ends, remove items immediately and hang
orfold.Ifloadisremovedbeforethecycleends,turncycleselectortoOFF.
DryingProcedures
Followfabriccarelabelinstructions.
Placesmallitemsinameshbag.
Fill dryer drum 1/3 to 1/2 full.

5
Features
PROBLEM • Add a few bath towels to small loads for
proper tumbling.
• Some "silk-like" fabrics should be air dried.
• Use proper drying temperature.
• Place fabric softener sheet on top of load
before starting the dryer.
• Do not overload dryer.
• Use fabric softener in washer or dryer to
reducestaticelectricity.
• Removeitems when they are slightly damp
to avoid overdrying.
• Checkthat lint screen is clean and in place.
• Use fabric softener to lubricate fibers.
• When ironing, use spray starch or fabric
finish on collars and cuffs.
• Turn items inside out to reduce abrasion.
• Followfabriccarelabeldirections.
• If shrinking is a concern, check load often.
• Removeitemswhileslightly dampand
hang or lay flat to complete drying.
• Blockknits intoshape.
• Do not overload dryer.
• Removeitemsassoonascycleends.
PREVENTIVEMEASURES
Manydryingproblemsinvolvepoorcleaningresults,poorsoilandstainremoval,residuesoflintandscum,andfabricdamage.
Forsatisfactorydryingresults,followthesesuggestionsprovidedbyTheSoapandDetergentAssociation.
CommonDryingProblems
Greasy, oily
stains
Lint
Pilling
(Fibersbreak
off, ball up and
cling to fabric.)
Shrinking
Wrinkling
POSSIBLECAUSES
• Fabricsoftenersheet.
• Overloading.
• Overdryingcausesstatic
electricity.
• Lintscreennotclean
whencyclebegan.
• Lint is attached to "pills."
• Pilling is normal with
synthetic and permanent
pressfabrics.Thisisdue
to abrasion from normal
wear.
• Overdrying.
• Overloading.
• Leavingitemsindryer
aftercycleends.
SOLUTIONS
• Rub fabric softener stains with bar soap.
Rinseandrewash.
• Reduceloadsizeandrewashusingliquid
fabric softener in the final rinse.
• Or, add a fabric softener sheet and
tumble without heat.
• Use lint brush or roller to remove lint.
• Use a lint brush or shaver to remove pills.
• Irreversiblecondition.
• Reduceload size and tumble atmedium
or low heat for 5-10 minutes.
• Removeitems immediately. Hang or fold.
Place the front bar under
the lip of the lint screen opening.
CycleSignalControl (some models)
WhentheCycleSignalControlisON,asignalwillsoundattheendofeachcycle
andduringthePressSaversetting(somemodels).Thevolumeisadjustableon
somemodels.
Drum Light(some models)
A drum light will come on whenever the door is opened to illuminate the dryer
drum during loading and unloading. Closing the door turns off the light.
ReversibleDryerDoor
Yourdryerisequippedwithareversibledoor.Thedoorcanbehingedontheright
orleftside.RefertotheINSTALLATIONINSTRUCTIONSfordirectionsonchanging
the door.
DryingRack(somemodels)
Use the drying rack to dry items which should not be tumble dried.
1. Openthe dryer door and remove the lint screen.
2. Insertdryingrackinto thedryerdrum. Place thefrontbar underthelipof the
lintscreenopening.
3. Placeitems to be dried on top of the rack. Weight shouldnot exceed 10 lbs.
Leavespacebetweenitems,butdonotletitemshangoverthesidesorthrough
the grids. Do not tumble other items when using the drying rack.
4. Selectatimeddrysettingbestsuitedforitemsbeingdried.UseonlytheAirFluff
(no heat) temperature setting for items containing plastic, foam rubber,
rubber-likematerials,feathersordown.
5. Whenitemsaredry,removetherackandreplacethelintscreen.Iflintscreen
is not in place, tumbling items could enter the exhaust system and cause
damage to the dryer.

6
Care and Cleaning To reduce risk of fire or serious injury to persons or property,
comply with the basic warnings listed in Important Safety Instructions,
pages 2-3, and those listed below.
• Before cleaning the dryer interior, unplug the electrical power cord to
avoid electrical shock hazards.
• Do not use any type spray cleanser when cleaning dryer interior.
Hazardous fumes or electrical shock could occur.
Inside
• Clean the lint screen after every load. Lint build-up in the screen restricts
air flow, which causes longer drying times. The screen is located at the
bottom of the door opening. Remove by pulling straight up. Remove the
lint and replace the screen.
• Occasionally a waxy build-up may form on the lint screen from using
dryer-added fabric softener sheets. To remove this build-up, wash the
lint screen in warm, soapy water. Dry thoroughly and replace. Do not
operate the dryer without the lint screen in place.
• If the dryer drum becomes stained from noncolorfast fabrics, clean the
drum with a damp cloth and a mild liquid household cleanser. Remove
cleanser residue before drying the next load.
• Every 18 months an authorized servicer should clean the dryer cabinet
interior and exhaust duct. These areas can collect lint and dust over time.
An excessive amount of lint build-up could result in inefficient drying
and possible fire hazard.
Outside
• Clean the cabinet with mild soap and water. Never use harsh, gritty or
abrasivecleansers.
• If the cabinet becomes stained, clean with diluted chlorine bleach [1/2
cup
(120 ml) in 1 quart (.95 liter) water]. Rinse several times with clear water.
• Remove glue residue from tape or labels with a mixture of warm water
and mild detergent. Or, touch residue with the sticky side of the tape or
label.
•Before moving the dryer, place a strip of cardboard or thin fiberboard
under the front leveling legs to prevent damage to floor.
Cleanlintscreen afterevery load.
Do not store or place laundry products
on top of dryer at any time. They can
damage the finish or controls.

7
AvoidService
Checklist
Beforecalling forservice, review thislist. It maysave both timeand expense. The list includes
commonoccurrencesthatarenottheresultofdefectiveworkmanshipormaterialsinthisdryer.
OCCURRENCE SOLUTION
Make sure the plug fits tightly in wall outlet.
Resetcircuitbreakerorreplacefuse.
Makesure electrical line is not overloadedandthe dryer is
ona separate circuit.
Callauthorizedservicepersonforreplacement.
Replacefuse.
Checktomakesuresupplyvalveisopen.SeeINSTALLATION
INSTRUCTIONSforprocedure.
SeeINSTALLATIONINSTRUCTIONS.
Refillorreplace tank.
Dryershould heat when utility service isrestored.
Make sure all lint has been removed from the dryer lint
screenbeforestartingeachcycle.
Exhaustductmustbeatleast4inchesindiameterandmade
of rigid or flexible metal.
When in place, the duct must have no more than two 90°
bendsandmustnotexceedlengthlistedinINSTALLATION
INSTRUCTIONS.
Drying time will be 20% longer than drying on a 240 volt
circuit.
SeeDryingProcedures,page4.
Clean out any obstruction.
Use a dehumidifier near the dryer.
Do notoverload. See Drying Procedures,page 4.
Removeitemsassoonascycleends.
SeeDryingProcedures,page4.
Followfabriccarelabelinstructions.
Always remove foreign objects from pockets before
laundering. Remove objects from drum and restart dryer.
It may be necessary to baste a scrap of material securely
aroundornamentsbeforedryingtopreventscratchingand
damage to the dryer.
Drum damage caused by foreign objects or
permanently attached items is not covered by the
warranty.
POSSIBLECAUSE
Electricalpowercordisnotsecurelyplugged
in or plug may be loose.
Housefuseblownorcircuitbreakertripped.
Thermal limiter tripped.
Thereare2 housefuses inthedryercircuit.
If 1 of the 2 fuses is blown, the drum may
turn but the heater will not operate.
Gassupplyvalveisnotopen(gasmodels).
Dryer does not have anough air supply to
support the burner flame (gas models).
LPgassupplytankisemptyortherehasbeen
a utility interruption of natural gas (gas
models).
Lint screen is clogged with lint.
Exhaust duct requirements have not been
met.
Electric dryer is connected to a 208 volt
circuit.
Dryingprocedures havenot been followed.
Outside exhaust hood or exhaust duct may
be clogged or restricted.
High humidity.
Dryerisoverloaded.
Items left in dryer too long.
Insufficient sorting of items.
Drying temperature too high.
Foreignobjectssuchascoins,pins,clipsor
buttons are inside the dryer.
Permanently attached items such as belt
buckles,zippersandfastenersmaybehitting
the inside of the drum.
Dryer does not start.
Dryer runs but won't heat.
Drying cycle takes too long,
outside of the dryer feels
too hot or smells hot.
Excessivewrinkling.
Scratchingorchippingofthe
drum finish.

THE CONSUMER WILL BE
RESPONSIBLE FOR:
Costs of service calls that are listed under
IMPORTANT RESPONSIBILITIES OF THE
CONSUMER.*
Costs of the technician's travel to the home and any
costs for pick up and delivery of the appliance
required because of service.
WARRANTY
PERIOD
One year from original
purchase date.
Time period listed above.
FRIGIDAIRE, THROUGH ITS AUTHORIZED
SERVICERS, WILL:
Pay all costs for repairing or replacing any parts of this
appliance which prove to be defective in materials or
workmanship.
All of the provisions of the full warranty above and the
exclusions listed below apply.
FULL ONE-YEAR
WARRANTY
LIMITED WARRANTY
(Applicable to the
State of Alaska)
*IMPORTANT
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED
SERVICE
This warranty applies only to products in ordinary household use, and the consumer is responsible for the items
listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in
accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose
connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are
not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING
FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation
or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in ordinary
household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by servicers other than Frigidaire or its authorized servicers; use of parts other
than genuine Frigidaire Home Products parts; obtained from persons other than such servicers; or external causes such
as abuse, misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily determined.
Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the bill establishes the warranty
period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This written
warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under this
warranty must be obtained by contacting Frigidaire Home Products:
800 • 944 • 9044
Frigidaire Home Products
P.O. Box 212378
Augusta, GA 30917
Product features or specifications as described or illustrated are subject to change without notice. All warranties are made
by White Consolidated Industries, Inc. This warranty applies only in the 50 states of the U.S.A. and Puerto Rico.
Your appliance is warranted by Frigidaire Home Products, a division of White Consolidated Industries, Inc. We authorize no person to change or add
to any of our obligations under this warranty. Our obligations for service and parts under this warranty must be performed by Frigidaire or an
authorized Frigidaire servicer.
FRIGIDAIRE DRFRIGIDAIRE DR
FRIGIDAIRE DRFRIGIDAIRE DR
FRIGIDAIRE DRYER WYER W
YER WYER W
YER WARRANTYARRANTY
ARRANTYARRANTY
ARRANTY
YourFrigidaireproductisprotectedbythiswarranty
