Frigidaire FFC05C4CW0 User manual

CHEST FREEZER
Base Model:
FFC05C4CW
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216787900
OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 216793807
SERVICE DATA SHEET - # 216787900
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC05C4CW0 FFC05C4CW 134A white 115
MARKET
North America
Publication No.
5995392783
030715
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

07/03 2
Publication No FFC05C4CW0
5995392783
DOOR

# = Fast-moving Parts 3 07/03
* = Non-Illustrated Parts
FFC05C4CW0 Publication No.
5995392783
DOOR
POS. NO PART NO DESCRIPTION
1 216480801 Gasket-door,white
2 # 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216061500 Panel-inner door\lid,white
10 216141101 Plug button,white
11 216106003 Panel-outer door\lid,white
12A 216816801 Insert-nameplate
18 216446600 Handle
27 5303212828 Clip,panel mtg
40 5309948647 Fastener,handle

07/03 4
Publication No FFC05C4CW0
5995392783
CABINET

# = Fast-moving Parts 5 07/03
* = Non-Illustrated Parts
FFC05C4CW0 Publication No.
5995392783
POS. NO PART NO DESCRIPTION
1 216117700 Catch-lock
3 216502600 Plug,drain ,interior
4 216073905 Plug-drain,exterior
6 216105700 Breaker-hinge\front,white
7 216105800 Breaker-lock side
11 216105600 Breaker-ends,white
18 216707200 Knob,temp control
21 # 216787700 Control-temperature
27 216337700 Screw,hex washer head ,10-24 x 0.500
28 216478800 Hinge Assy
30 216105500 Breaker-corners,white
59 216848200 Basket,(2)
71 131168200 Screw,pan head ,8-18B x 0.31
75 216782000 Panel-access,white
* 216793807 Energy Guide
* 5303305324 Paint,touch-up ,white
CABINET

07/03 6
Publication No FFC05C4CW0
5995392783
SYSTEM

# = Fast-moving Parts 7 07/03
* = Non-Illustrated Parts
FFC05C4CW0 Publication No.
5995392783
SYSTEM
POS. NO PART NO DESCRIPTION
1 5300120779 Condenser
4 216634500 Drier-filter
5 # 216711500 Harness-main
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
29 # 216784800 Compressor,w/o electricals
30 216649304 Controller
32 216694500 Clip,controller
55 # 216696700 Capacitor-run,180 VAC ,15 microfarad
85 216818300 Wire-ground
86 216707700 Screw,8-18 X 1/2
