Frigidaire FFC07K0CW User manual

CHEST FREEZER
Model numbers:
FFC07K0CW
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216787900
OWNER’S GUIDE - # 216802800 ENERGY GUIDE - # 216793908
SERVICE DATA SHEET - # 216787900
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC07K0CW0 FFC07K0CW 134A white 115
MARKET
North America
Publication No.
5995385746
030212
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

10/02 2
Publication No FFC07K0CW0
5995385746
DOOR

# = Fast-moving Parts 3 10/02
* = Non-Illustrated Parts
FFC07K0CW0 Publication No.
5995385746
DOOR
POS. NO PART NO DESCRIPTION
1 216480901 Gasket,door seal ,white
9 216061602 Panel-inner lid,white
10 216141101 Plug button,white
11 216113114 Panel-outer door,white
27 5303212828 Clip,panel mtg
* 5303917276 Insulation-door,fiberglass ,(bulk)

10/02 4
Publication No FFC07K0CW0
5995385746
CABINET

# = Fast-moving Parts 5 10/02
* = Non-Illustrated Parts
FFC07K0CW0 Publication No.
5995385746
POS. NO PART NO DESCRIPTION
3 216502600 Plug,drain ,interior
4 216073900 Plug,drain ,exterior
6 216112800 Breaker-hinge,white
11 216105600 Breaker-ends,white
12 216892800 Nameplate
18 216707200 Knob,temp control
21 # 216787700 Control-temperature
27 216337700 Screw,hex washer head ,10-24 x 0.500
28 216478800 Hinge Assy
30 216105500 Breaker-corners,white
59 216848200 Basket
71 131168200 Screw,pan head ,8-18B x 0.31
75 216782000 Panel-access,white
* 5303305324 Paint,touch-up ,white
CABINET

10/02 6
Publication No FFC07K0CW0
5995385746
SYSTEM

# = Fast-moving Parts 7 10/02
* = Non-Illustrated Parts
FFC07K0CW0 Publication No.
5995385746
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5300120780 Condenser
4 216634500 Drier-filter
5 # 216711500 Harness-main
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
29 # 216820500 Compressor,w/o electricals
30 216649305 Controller
32 216694500 Clip,controller
42 216232700 Washer,flat ,1"OD x 0.531"ID
55 216696700 Capacitor-run,180 VAC ,15 microfarad
85 216818300 Wire-ground
86 216707700 Screw,8-18 X 1/2
