PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC07M5HW0 FFC07M5H 134A white 115
FFC09M5HW0 FFC09M5H 134A white 115
MARKET
North America
Publication No.
5995320271
990330
-EN/SERVICE /GS
365
FREEZER
Model No.
FFC07M5HW0
FFC09M5HW0
©1999White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216372500
OWNER’S GUIDE - # 216657700
SERVICE DATA SHEET - # 216487327/216372500
101 Masters Blvd.
Anderson, SC 29624
03/99 2
Publication No. FFC07/09M5H
5995320271
DOOR
# = Fast-moving Parts 3 03/99
* = Non-Illustrated Parts
FFC07/09M5H Publication No.
5995320271
DOOR
A = FFC07M5HW (FFC07M5HW0)
B = FFC09M5HW (FFC09M5HW0)
POS. NO PART NO DESCRIPTION
1 216480901 A - Gasket-door,white
1 216481001 - B Gasket-door,white
2 # 5303925107 A B Lock Assy
5 # 216388700 A B Key,lock
9 216061600 A - Panel-inner door/lid,white
9 216061800 - B Panel-inner door/lid,white
10 216141101 A B Plug button,white
11 216113122 A - Panel-outer door/lid,white
11 216117921 - B Panel-outer door/lid,white
12 216373000 A B Frame-nameplate
12A 316095402 A B Label-nameplate
18 216205004 A B Handle,white
23 216212700 A B Light-signal,amber
27 5303212828 A B Clip,panel
31 08009392 A B Gasket,white
35 5303297015 A B Washer,signal light
44 # 5303017178 A B Switch-rocker
46 08037851 A B Screw,PH type AB ,8-32x1/2 ,
wiring harness
47 216552700 A B Harness,electrical
53 # 5303208483 A B Buzzer,alarm
55 216164000 A B Housing,switch
56 5308037857 A B Sealing cap
61 5309948955 - B Clip-panel
93 5303161215 A B Screw
* 5303917276 A B Insulation-door,fiberglass ,(bulk)
03/99 4
Publication No. FFC07/09M5H
5995320271
CABINET
# = Fast-moving Parts 5 03/99
* = Non-Illustrated Parts
FFC07/09M5H Publication No.
5995320271
A = FFC07M5HW (FFC07M5HW0)
B = FFC09M5HW (FFC09M5HW0)
POS. NO PART NO DESCRIPTION
1 216117700 A B Support lock
2 216269500 A B Adapter-drain
3 216502600 A B Plug-drain,exterior
4 216073900 A B Plug-drain,interior
6 216112800 A - Breaker-hinge,white
6 216117500 - B Breaker-hinge side,white
7 216112900 A - Breaker-lock side
7 216117600 - B Breaker-lock side
11 216105600 A B Breaker-ends,white
18 216591602 A B Knob,temp control
21 # 216375500 A B Control-temperature
27 216629600 A B Screw-hinge
28 216478800 A B Hinge Assy
30 216105500 A B Breaker-corners,white
59 216078600 A B Basket
71 131168200 A B Screw,8-18 x 0.31
75 216329402 A B Panel-access,white
* 5303305324 A B Paint,touch-up ,white
CABINET
03/99 6
Publication No. FFC07/09M5H
5995320271
SYSTEM
# = Fast-moving Parts 7 03/99
* = Non-Illustrated Parts
FFC07/09M5H Publication No.
5995320271
SYSTEM
A = FFC07M5HW (FFC07M5HW0)
B = FFC09M5HW (FFC09M5HW0)
POS. NO PART NO DESCRIPTION
1 # 5300120780 A - Condenser
1 # 5300120781 - B Condenser
4 216634500 A B Drier-filter
5 216552700 A B Harness,electrical
22 216056400 A B Clip-spring mtg
25 216022800 A B Screw,washer head ,8-18 X 1/2
27 5308002681 A B Grommet,compressor
29 # 5303925442 A B Compressor,w/electricals
29 216510900 A B Compressor,R134a ,w/ electricals
30 216511200 A B Starter-PTC
31 216100113 A B Overload Protector
46 08037851 A B Screw,PH type AB ,8-32x1/2 ,
wiring harness
53 216347800 A B Cover,compressor
* 216478900 A B Fastener,energy guide
