Frigidaire FFC15M6C User manual

FREEZER
Model No.
FFC15M6C
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216700200
OWNER’S GUIDE - # 216657700
SERVICE DATA SHEET - #216700200
ELECTROLUX HOME PRODUCTS NORTH AMERICA.
P.O.Box 212378, Augusta, GA 30917
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC15M6CW5 FFC15M6CW 134A white 115
MARKET
North America
Publication No.
5995345062
001017
-EN/SERVICE /GS
365

10/00 2
Publication No. FFC15M6CW5
5995345062
DOOR

# = Fast-moving Parts 3 10/00
* = Non-Illustrated Parts
FFC15M6CW5 Publication No.
5995345062
DOOR
POS. NO PART NO DESCRIPTION
1 216481201 Gasket-door,white
2 5303925107 Lock Assy
5 # 216388700 Key,lock
9 216687004 Panel-inner lid,white
10 216141101 Plug button,white
11 216129924 Lid,white
12 216208100 Bezel-nameplate
12A 216683000 Insert-bezel
14 216472300 Switch-light plunger
15 216608600 Bulb-light,40W ,130V
16 216684000 Socket-light/lamp
18 216140200 Handle,recessed ,white
23 3200895 Light-signal,round ,amber
27 5303212828 Clip,panel
31 08009392 Gasket,white
34 216087902 Shield-light
35 5303297015 Washer,signal light
36 5306599968 Plate,backup ,light switch
44 5303017178 Switch-rocker
46 08037851 Screw,PH type AB ,8-32x1/2, wiring harness
47 # 216756100 Harness-lid
53 # 5303208483 Buzzer,alarm
55 216164000 Housing,switch
56 216694200 Sealing cap
61 5309948955 Clip-panel
93 5303161215 Screw
* 5303925098 Insulation

10/00 4
Publication No. FFC15M6CW5
5995345062
CABINET

# = Fast-moving Parts 5 10/00
* = Non-Illustrated Parts
FFC15M6CW5 Publication No.
5995345062
CABINET
POS. NO PART NO DESCRIPTION
1 5303208488 Latch-door
1A 216080800 Support,lock
2 216269500 Adapter-drain
3 216502600 Plug-drain,interior
4 216073900 Plug-drain,exterior
6 216111000 Breaker,hinge side
7 216111600 Breaker,lock side
11 216110800 Breaker,white ,ends
18 216591602 Knob,temp control
21 216562400 Control-temperature
27 216629600 Screw-hinge
28 216035200 Hinge
30 216110700 Breaker,white ,corners
59 216080600 Basket,upper ,(2)
70 216375100 Handle-basket,teal
71 5303302714 Screw,8-18x3/4 ,(2)
73 216128200 Divider/drain pan
74 5306594584 Support-shelf
75 216034301 Panel-access,white
* 5303305324 Paint,touch-up ,white

10/00 6
Publication No. FFC15M6CW5
5995345062
SYSTEM

# = Fast-moving Parts 7 10/00
* = Non-Illustrated Parts
FFC15M6CW5 Publication No.
5995345062
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5303925238 Condenser
4 216634500 Drier-filter
5 216676800 Wiring Harness
22 216056400 Clip-spring mtg
27 5308002681 Grommet,compressor
28 5303212615 Support-compressor
29# 216511100 Compressor,w/o electricals
30 216649301 Controller
32 216649200 Clip,controller
42 216232700 Washer-flat
43A 5303212614 Clip-harness
47 216629600 Screw-hinge
55 218909901 Capacitor-run,220 VAC ,15 microfarad
86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2
* 216478900 Fastener,energy guide
