Frigidaire FFU17FC4AW User manual

FREEZER
Model number
FFU17FC4AW
FFU20FC4AW
©2002 Electrolux Home Products, Inc
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - 216857700 OWNER’S GUIDE - 216802800
SERVICE DATA SHEET - 216857700
ENERGY GUIDE - 17’ - 216795401, 20’ - 216795501
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFU17FC4AW2 FFU17FC4AW 134A white 115
FFU20FC4AW2 FFU20FC4AW 134A white 115
MARKET
North America
Publication No.
5995373122
020530
-EN/SERVICE /BLT
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

05/02 2
Publication No FFU17FC4AW, FFU20FC4AW
5995373122
DOOR

# = Fast-moving Parts 3 05/02
* = Non-Illustrated Parts
FFU17FC4AW, FFU20FC4AW Publication No.
5995373122
DOOR
A = FFU17FC4A (FFU17FC4AW2)
B = FFU20FC4A (FFU20FC4AW2)
POS. NO PART NO DESCRIPTION
1 216522309 A - Gasket-door,white
1 216522312 - B Gasket-door,white
2 5303925107 A B Lock Assy
5 # 216702900 A B Key,lock
6 5300158222 A B Screw-anchor,8-18
9 216527803 A - Panel-inner door,white ,frzr
9 216528103 - B Panel-inner door,white
11 5303925474 A - Panel-outer door,white
11 5303925476 - B Panel-outer door,white
12 216816901 A B Nameplate
12A* 216817100 A B Nameplate,insert
13 08016354 A B Door Stop
14 5303313518 A B Washer,sealing
18 216446900 A B Handle,white
21A 08005520 A B Screw-door stop mtg,flat hd metric ,4.0 x 0.7-19.7
22 5303925197 A B Bearing
22A 216503200 A B Bearing-hinge,btm
26 216524200 A B Gasket,secondary
27 5303212828 A B Clip,panel
28 216807700 A B Rack-door,wide
32 5309950074 A B Valve-breather
57 3017682 A B Insert-handle
64 216403700 A B Plug-button,door base
93 5303161215 A B Screw
* 5303925098 A - Insulation

05/02 4
Publication No FFU17FC4AW, FFU20FC4AW
5995373122
CABINET

# = Fast-moving Parts 5 05/02
* = Non-Illustrated Parts
FFU17FC4AW, FFU20FC4AW Publication No.
5995373122
A = FFU17FC4A (FFU17FC4AW2)
B = FFU20FC4A (FFU20FC4AW2)
POS. NO PART NO DESCRIPTION
3 216503100 A B Screen-drain
5 # 216325600 A B Fan Blade
6 216604200 A - Breaker Kit w/corners
6 216604100 - B Breaker Kit w/corners
7 216603700 A - Breaker Kit w/corners,lock catch
7 216603600 - B Breaker Kit w/corners,lock catch
9 216603300 A B Breaker Kit w/corners,32" ,top or bottom
13 216822500 A B Motor-fan
18 216707200 A B Knob-control cold
19 216204900 A - Gasket,evap cover
19 216204901 - B Gasket-cover evap
20 216230300 A B Cover,temp control
21 216715200 A B Control-temperature
22 216823500 A B Clamp,cap tube ,cold control
22A 5303916855 A B Tube,sensor sleeve ,plastic ,clear
23 06594648 A B Light-signal,amber
24 5300052943 A B Screw-clamp,truss hd cr ,control
25 216737100 A - Cover-evaporator
25 216737200 - B Cover-evaporator
26 216503300 A B Ramp,closer ,door
27 5303205738 A B Screw-hinge,cr ,1/4-20 x 1.000 ,btm
28 216247400 A B Hinge-bottom
29 216313500 A B Hose-drain
32 5308005500 A B Drain
33 216831100 A B Bracket,signal light
34 216816203 A B Shield-light
35 216273000 A B Clip,drain hose
38 216808900 A B Hinge-upper
39 5303294372 A B Nut-insert,hinge
40 216809000 A B Cover-hinge
41 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
42 216458500 - B Shelf,wire ,16.69x26.88 ,white ,(3)
42A 216458400 A B Shelf,14.50x27.88 ,WH
42B 216458200 A - Shelf,12.50x27.88 ,white
42B 216546000 - B Shelf-fixed w/frame,white
47 216661600 A B Baffle-plate
49 216278900 A - Trivet
49 216279000 - B Trivet
50 216394000 A B Bracket-motor mtg fan
63 216396900 A B Foot-adjustable
71A 216347500 A B Screw,quadrex
72 216591110 A B Grille/Kickplate
80 06594601 A B Bracket,control
93 5303161215 A B Screw
93A 5303302760 A B Screw
101 216835200 A B Kit-top hinge
132 5303283898 A B Screw,6-20AB x 3/8
* 09948773 A B Insulation,drain tube
* 216502400 A B Grommet-shelf mtg
* 5303305324 A B Paint,touch-up ,white
* 216802800 A B Owners guide
CABINET

05/02 6
Publication No FFU17FC4AW, FFU20FC4AW
5995373122
SYSTEM

FFU17FC4AW, FFU20FC4AW Publication No.
5995373122
# = Fast-moving Parts 7 05/02
* = Non-Illustrated Parts
SYSTEM
A = FFU17FC4A (FFU17FC4AW2)
B = FFU20FC4A (FFU20FC4AW2)
POS. NO PART NO DESCRIPTION
1 # 5300083897 A B Condenser
2 5308000110 A B Strap-evap/heater,aluminum ,(2)
4 216634500 A B Drier-filter
5 # 216823900 A B Harness-main
14 # 216730700 A B Heater-defrost
15 # 216737300 A B Evaporator
15A 216783200 A B Heat Exchanger
18 216727600 A B Insulator-evap,styrofoam
19 216727700 A B Insulator-evap,styrofoam
20 216731000 A B Thermostat-defrost
23 # 216744500 A B Timer-defrost
24 08016580 A B Bracket
27 5308002681 A B Grommet,compressor
29 216851700 A - Compressor,w/o electricals
29 216851800 - B Compressor,w/o electricals
30 216649318 A B Controller
32 216649100 A B Clamp,elec cont mtg ,compressor
34 5306594529 A B Sleeve-compressor
35 5303272328 A B Screw,Ind hex sems ,1/4-28 unfx ,compressor
43A 216629700 A B Clip-harness
55 # 216787800 A B Capacitor-run
86 216036600 A B Screw,rwhd (gx-ca) ,8-32 x 1/2
87 08037849 A B Screw
105 216854001 A - Cup-drain
105 216854000 - B Cup-drain
130 216486800 A B Support-evaporator
* 5303298960 A B Spacer-tube,.75"
