Frigidaire FFU17D7HW User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFU17D7HW3 FFU17D7HW 134A white 115
MARKET
North America
Publication No.
5995350245
010222
-EN/SERVICE /GS
365
FREEZER
Model number
FFU17D7HW
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216751800
OWNER’S GUIDE - # 216768600
SERVICE DATA SHEET - # 216751800
ELECTROLUX HOME PRODUCTS N. AMERICA
P.O BOX 212378, AUGUSTA , GA 30917

03/01 2
Publication No. FFU17D7HW
5995350245
DOOR

# = Fast-moving Parts 3 03/01
* = Non-Illustrated Parts
FFU17D7HW Publication No.
5995350245
DOOR
POS. NO PART NO DESCRIPTION
1 216522309 Gasket-door,white
2 # 5303925107 Lock Assy
5 # 216702900 Key,lock
6 5300158222 Screw-anchor,8-18
9 216527812 Panel-inner door,frzr
11 5303925474 Panel-outer door,white
12 316095402 Label-nameplate,Frigidaire ,white
12A 216373000 Frame-nameplate
13 08016354 Door Stop
14 5303313518 Washer,sealing
18 216446900 Handle,white
21A 08005520 Screw-dr stop mtg,flat hd metric , 4.0 x 0.7-19.7
22 216443600 Bearing
22A 216503200 Bearing-hinge,btm
26 216524200 Gasket,secondary
27 5303212828 Clip,panel
28 216523102 Rack-shelf,wide ,white
32 5309950074 Valve-breather
57 3017682 Insert-handle
64 216403700 Plug-button,base door
93 5303161215 Screw
* 216205400 Washer,signal light
* 5303925098 Insulation

03/01 4
Publication No. FFU17D7HW
5995350245
CABINET

# = Fast-moving Parts 5 03/01
* = Non-Illustrated Parts
FFU17D7HW Publication No.
5995350245
POS. NO PART NO DESCRIPTION
2 216269500 Adapter-drain
3 216502600 Plug-drain,interior ,interior
6 216604200 Breaker Kit w/corners
7 216603700 Breaker Kit w/corners,lock catch
9 216603300 Breaker Kit w/corners,32" , top or bottom
14 216472300 Switch-light plunger
15 216608600 Bulb-light,40W ,130V
16 5300136117 Socket-light/lamp
18 216707200 Knob-control
20 216707300 Cover-control housing
21 # 216715800 Control-temperature
22 08037931 Clamp,cap tube ,cold control
23 216511700 Light-signal
24 5300052943 Screw-clamp,truss hd cr ,control
26 216503300 Ramp,closer ,door
27 5303205738 Screw-hinge,cr ,1/4-20 x 1.000 ,btm
28 216247400 Hinge-bottom
29 216313502 Hose-drain
32 5308005500 Drain
33 216511601 Bracket,signal light
34 216557600 Shield-light
35 216273000 Clip,drain hose
38 5303925086 Hinge-upper
39 5303294372 Nut-insert,hinge
40 5303212912 Cover-hinge
41 5303212937 Screw-top hinge
59 216154400 Basket
59A 09948791 Stop-basket
62 131420300 Screw,cr truss head ,8-18AB x 0.750
63 216396900 Foot-adjustable
64 216009200 Bracket-dfr switch
65 216443500 Drop front
66 # 216713800 Buzzer,alarm
67 # 5303212703 Switch-rocker,SPST
68 08009560 Glide-basket
69 5305878546 Bumper-basket
72 216511500 Grille/Kickplate
81 216571000 Support-drop front,top
83 216571100 Support-drop front,btm
86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2
87 09950853 Screw-control knob,phillips ,4-40 x 3/8
88 # 216380500 Switch-defrost
89 216206200 Bezel-nameplate,defrost
90 5303297123 Screw,th ,8-32 x 2-1/2
91 216372000 Insert-bezel
93 5303161215 Screw
132 5303283898 Screw,6-20AB x 3/8
* 09948773 Insulation,drain tube
* 216205400 Washer,signal light
* 5303305324 Paint,touch-up ,white
* 5303311565 Clip-cable
CABINET

03/01 6
Publication No. FFU17D7HW
5995350245
SYSTEM

# = Fast-moving Parts 7 03/01
* = Non-Illustrated Parts
FFU17D7HW Publication No.
5995350245
POS. NO PART NO DESCRIPTION
1 # 5300083897 Condenser
3 216444800 Trim-shelf,decorated
4 216634500 Drier-filter
5 # 216762500 Harness-ext,main
6 3091418 Support-shelf,front LH
7 08037928 Support-shelf,front RH
11 216474600 Support-rear shelf
12 216225700 Grommet-spacer
13 216138900 Screw,hex sems ,8-18AB x 1.00 ,evap
15A 216468200 Heat Exchanger
26 216511900 Spacer tube,(3)
27 216498900 Grommet,compressor
29 # 216639700 Compressor,Service
30 216649308 Controller-regulator LP
32 216731900 Clip-controller
34 5306594529 Sleeve-compressor
35 5303272328 Screw,Ind hex sems ,1/4-28 unfx , compressor
36 # 216070500 Grid-top evaporator
37 # 216211800 Shelf-top evaporator,evaporator
38 # 216070700 Shelf-middle evaporator
40 # 216070800 Shelf-bottom evaporator
43 09950610 Clip,cord
43A 216629700 Clip-harness
48 # 3201514 Solenoid
49 3201513 Clip,valve
50 216533400 Wire-ground,solenoid
51 # 5303210219 Valve-formed
86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2
* 216502500 Sleeve-tube insert
* 5303208622 Clip,grounding
* 216762300 Harness,int
SYSTEM
