Frigidaire FFU21C3AW1 User manual

FREEZER
Model number
FFU21C3AW1
©2002 Electrolux Home Products, Inc
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216803200
SERVICE DATA SHEET - # 216803200
ENERGY GUIDE - # 216795101 OWNER’S GUIDE - # 216802800
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFU21C3AW1 FFU21C3AW 134A white 115
MARKET
North America
Publication No.
5995368064
020312
-EN/SERVICE /BLT
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

03/02 2
Publication No FFU21C3AW1
5995368064
DOOR

# = Fast-moving Parts 3 03/02
* = Non-Illustrated Parts
FFU21C3AW1 Publication No.
5995368064
DOOR
POS. NO PART NO DESCRIPTION
1 216522312 Gasket-door,white
2 5303925107 Lock Assy
5 # 216702900 Key,lock
6 5300158222 Screw-anchor,8-18
9 216528107 Panel-inner door,white
11 5303925476 Panel-outer door,white
12 216817100 Nameplate
12* 216817001 Insert-nameplate
13 08016354 Door Stop
14 5303313518 Washer,sealing
18 216446900 Handle,white
21A 08005520 Screw-door stop mtg,flat hd metric ,4.0 x 0.7-19.7
22 5303925197 Bearing
22A 216503200 Bearing-hinge,btm
26 216524200 Gasket,secondary
27 5303212828 Clip,panel
28 216807700 Rack-door,wide
32 5309950074 Valve-breather
57 3017682 Insert-handle
64 216403700 Plug-button,door base
93 5303161215 Screw

03/02 4
Publication No FFU21C3AW1
5995368064
CABINET

# = Fast-moving Parts 5 03/02
* = Non-Illustrated Parts
FFU21C3AW1 Publication No.
5995368064
POS. NO PART NO DESCRIPTION
3 216502600 Plug-drain,interior ,interior
6 216604100 Breaker Kit w/corners
7 216603600 Breaker Kit w/corners,lock catch
9 216603300 Breaker Kit w/corners,32" ,top or bottom
18 216707200 Knob-control cold
20 216707300 Cover-control housing
21 # 216788100 Control-temperature
22 216823500 Clamp,cap tube ,cold control
23 06594648 Light-signal,amber
24 5300052943 Screw-clamp,truss hd cr ,control
26 216503300 Ramp,closer ,door
27 5303205738 Screw-hinge,cr ,1/4-20 x 1.000 ,btm
28 216247400 Hinge-bottom
29 216313502 Hose-drain
32 5308005500 Drain
33 216831100 Bracket,signal light
35 216273000 Clip,drain hose
38 216808900 Hinge-upper
39 5303294372 Nut-insert,hinge
40 216809000 Cover-hinge
41 5303001479 Screw-hinge mtg,hex hd ,1/4-20 x 0.875
46 08037851 Screw,PH type AB ,8-32x1/2 ,wiring harness
62 131420300 Screw,cr truss head ,8-18AB x 0.750
63 216396900 Foot-adjustable
65 216443500 Drop front
72 216591110 Grille/Kickplate
81 216571000 Support-drop front,top
83 216571100 Support-drop front,btm
86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2
101 216835200 Kit-top hinge
* 09948773 Insulation,drain tube
* 216802800 Owners guide
* 5303305324 Paint,touch-up ,white
CABINET

03/02 6
Publication No FFU21C3AW1
5995368064
SYSTEM

FFU21C3AW1 Publication No.
5995368064
# = Fast-moving Parts 7 02/02
* = Non-Illustrated Parts
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5300083897 Condenser
3 216847805 Trim-shelf,decorated ,evap
4 216634500 Drier-filter
5 216806700 Harness-main
6 3091418 Support-shelf,front LH
7 08037928 Support-shelf,front RH
11 216474600 Support-rear shelf
12 216225700 Grommet-spacer
13 216138900 Screw,hex sems ,8-18AB x 1.00 ,evap
15A# 216401500 Heat Exchanger
27 218513300 Grommet-compr mtg,(4)
29 216836600 Compressor,w/o electricals
30 # 216649316 Controller
32 5309950074 Valve-breather
34 5306594529 Sleeve-compressor
35 240491501 Screw-compressor mtg,1/4-28 x 1.16,shoulder,typ CF
36 # 216070900 Grid-top evaporator
37 # 216071000 Shelf-top evaporator
38 # 216071100 Shelf-middle evaporator
39 # 216071200 Shelf-third evaporator
40 216071300 Shelf-bottom evaporator
55 # 218909901 Capacitor-run,220 VAC ,15 microfarad
86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2
* 216502500 Sleeve-tube insert
* 5303298960 Spacer-tube,.75"
