Frigidaire GLFU1767F User manual

P08F0078.eps P08D0473.eps P08C0878.eps P08S0397.eps
Product No. GLFU1767FW2
Series 134A
Color white
Volts 115
Wiring Diagram 297079600
Owner's Guide 297079200
Market North America
Energy Guide 216795410
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995461992
06/02/24
(EN/SERVICE/MLR)
365
UPRIGHT FREEZER
Model No.
GLFU1767FW
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995461992 GLFU1767FW2
02/06 2
DOOR

GLFU1767FW2 Publication No: 5995461992
# Functional Parts 3 02/06
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216522309 Gasket-door, white
2 5303925107 Lock Assy
5 # 216702900 Key, lock
9 216527816 Panel-inner door, frzr
11 216526565 Panel-outer door, white
13 5303271076 Door Stop
18 216921200 Handle, white
* 216932500 Nut, flange locking, handle
* 297048000 Screw, anchor, #8, white
21A 5303271077 Screw, flat head, #1/4-20, door stop/hng
22 216970800 Bearing, hinge w/o'ring, top
26 216524200 Gasket, secondary
27 5303212828 Clip, panel mtg
27* 5304406520 Clip, panel mtg kit, (40)
28 216806100 Rack-door, contour, (3)
32 5309950074 Valve, breather, door base
57 297072601 Overlay
59 216974500 Bearing, door closer
64 216403700 Plug-button, hole filler, door base
72 216514100 Shelf, tilt out, wire, (2)
73 216513900 End Cap, shelf, LH, (2), tilt-out
74 216514000 End Cap, shelf, RH, (2), tilt-out
77 297072500 Bezel
79 # 216944300 Control Board, digital
93 5303161215 Screw, ph truss head, 8-18AB x 0.500
133 216905300 Screw, control board, #3-24 x .25, (3)

Publication No: 5995461992 GLFU1767FW2
02/06 4
CABINET

GLFU1767FW2 Publication No: 5995461992
# Functional Parts 5 02/06
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
3 216503100 Screen-drain
5 # 216325600 Fan Blade
6 216604200 Breaker Kit w/corners
7 216603700 Breaker Kit w/corners, lock catch
9 216603300 Breaker Kit w/corners, 32", top or bottom
13 216934100 Motor, fan, 115 V
* 216912400 Screw, hex washer head, #8-32 x .500, bracket fan mtr, (2)
14 216472300 Switch-light plunger
15 216988100 Light Bulb/Lamp, long, blue tint, 40 W, 120V, (2)
16 216817601 Socket, light/lamp, 25 W
19 216204900 Gasket, evap cover
25 216820201 Cover-evaporator
29 216313501 Hose-drain
32 5308005500 Drain
34 216816221 Shield-light
35 216629700 Clip
38 216939100 Hinge-upper
40 216809000 Cover-hinge
41 216936800 Screw-hinge, 12-24x.700 HWH
47 216661600 Plate, baffle, snap fit
50 216394000 Bracket, fan motor mount
59 297093100 Basket, (2)
60 297013500 Slide, basket, (4)
62 131420300 Screw, cr truss head, 8-18AB x 0.750
63 216396900 Screw, leveling foot, plastic, adjustable
69 5305878546 Bumper-basket, (4)
71A 5304416289 Screw, ph truss head, 8-18AB x 0.47, EVAP PANEL
72 297036900 Grille/Kickplate, 32", white
79 3017666 Nut-insert
93 5303161215 Screw, ph truss head, 8-18AB x 0.500
93A 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
132 5303283898 Screw, 6-20AB x 3/8
144 216922300 Shelf-assy, fixed, glass, complete
144A 216922301 Shelf-assy, fixed, glass, complete
* 216502400 Grommet-shelf mtg
156 297071800 Divider, basket, (2)
157 297071900 Shelf, small items
* 216795410 Energy Guide
* 5303305324 Paint, touch-up, white
* 297001704 Insulation, 24", drain tube
* 297088700 Guide-Electronic control

Publication No: 5995461992 GLFU1767FW2
02/06 6
SYSTEM
FRONT
BACK
1
35
34
29
27
5
4
86
93
54
43A
19
20
2
14
130
18
15
15A
P08S0397
30
32
31A

GLFU1767FW2 Publication No: 5995461992
# Functional Parts 7 02/06
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5300083897 Condenser
2 5308000110 Strap-evap/heater, aluminum, (2)
4 # 216938600 Drier-filter
5 # 297025900 Harness-main
14 # 216730700 Heater-defrost
15 # 216997300 Evaporator
15A# 216783200 Heat Exchanger, suct/cap tube
18 216727600 Insulator-evap, styrofoam
19 216727700 Insulator-evap, styrofoam
20 216872200 Thermostat, defrost
27 5308002681 Grommet, compressor
29 # 297048100 Compressor, kit w/grommets, & welded clip
30 297051000 Controller, compressor
31A 216994100 Pan-drain
32 297051100 Clamp, elec cont mtg, compressor
34 5306594529 Sleeve-compressor
35 5303272328 Screw, Ind hex sems, 1/4-28 unfx, compressor
43A 216629700 Clip
54 # 216979700 Electronics, high voltage
86 5303161215 Screw, ph truss head, 8-18AB x 0.500
93 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
130 216486800 Support, evaporator mtg
* 216502500 Sleeve, suction line
* 297014500 Plug-suction line
* 5303298960 Spacer-tube, 0.237" ID
