Frigidaire GLFC2027F User manual

P08F0085.eps P08D0405.eps P08C0883.eps P08S0354.eps
Product No. GLFC2027FW3
Series Gallery
Color white
Volts 115
Wiring Diagram 297010501
Owner's Guide 297079200
Market North America
Energy Guide 216794407
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995475166
06/09/27
(EN/SERVICE/MLR)
365
FREEZER CHEST
Model No.
GLFC2027FW
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995475166 GLFC2027FW3
09/06 2
DOOR
5
2
47
27
34
16
15
9
1
10
11
P08D0405
40
40
23
18
57
14

GLFC2027FW3 Publication No: 5995475166
# Functional Parts 3 09/06
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216481401 Gasket, lid seal, white
2 5303925107 Lock Assy
* 5300114366 Washer-sealing
5 # 216702900 Key, lock
9 216829504 Panel-inner door, frzr
10 216923001 Plug button, 1/4", white
11 216130127 Lid, white
* 216858000 Screw, TH#8-18x.500AB, #10
14 216822900 Switch, light/lamp, ramp
15 297048600 Light Bulb/Lamp, short
16 216817600 Socket, light/lamp, 25 W
18 216897600 Handle, white
23 216212700 Light-signal, amber
27 5303212828 Clip, panel mtg
27* 5304406520 Clip, panel mtg kit, (40)
34 297013900 Shield, light
40 216922700 Fastener, .330 dia stud, handle, (2)
47 # 216908000 Harness-lid
57 216899514 Overlay
* 5303917276 Insulation-door, fiberglass, (bulk)

Publication No: 5995475166 GLFC2027FW3
09/06 4
CABINET

GLFC2027FW3 Publication No: 5995475166
# Functional Parts 5 09/06
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 216909800 Catch-lock, white
1A 216818900 Support, lock catch clip
3 216502600 Plug, drain, interior
4 297013600 Plug, drain, exterior
6 216955513 Breaker, hinge side
7 216955512 Breaker, lock side
11 216955500 Breaker, chest end, (2)
18 216707200 Knob, temp control
21 # 216714600 Control-temperature
27 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
28 216035300 Hinge
30 216110700 Breaker, corners
59 216916203 Basket, blue/gray, upper, (3)
71 131420300 Screw, cr truss head, 8-18AB x 0.750
74 216486700 Support, divider, (4)
75 216034301 Panel, access, white
173A 297063000 Divider, chest, step
173B 297063100 Divider, small chest, (2)
173C 297063300 Divider, chest, step
* 5303321319 Paint, touch-up, white
* 216794407 Energy Guide

Publication No: 5995475166 GLFC2027FW3
09/06 6
SYSTEM

GLFC2027FW3 Publication No: 5995475166
# Functional Parts 7 09/06
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 5303280307 Condenser
4 # 216938600 Drier-filter
5 # 216987300 Harness-main
22 216056400 Clip, compressor mtg, SPRING
27 5308002681 Grommet, compressor
28 5303212615 Support, compressor
29 # 216967000 Compressor, w/o electricals
30 216954203 Controller
32 216649100 Clamp, elec cont mtg, compressor
42 216232700 Washer, flat, 1"OD x 0.531"ID
43A 5303212614 Clip, harness mount
47 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
55 218909913 Capacitor, run, 220 VAC, 15 microfarad
86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
* 297102800 Spacer-tube
