Frigidaire FEB30T6F User manual

FEB30T6FC.tif CPLEB30T9FCA.eps BUFEB30T6DSD.eps BLFEB30T6DSC.eps
DCFEB30S5GC2.eps 318046123.eps
Product No. FEB30T6FCC
37054383E60S3
Series 30" double
Color stainless
Market North America
Wiring Diagram 318046123
Owner's Guide 318205119
Installation Instructions 318201514
Service Data Sheet 318047309
Timer Guide 318200129
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995493805
07/06/27
(EN/SERVICE/BJH)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB30T6F
Copyright ©2007 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995493805 FEB30T6FCC
06/07 2
CONTROL PANEL

FEB30T6FCC Publication No: 5995493805
# Functional Parts 3 06/07
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
2A 318257300 Shield, oven top
2B 318260100 Cover, box
19 318271533 Control Panel Assembly, steel/glass, stainless/black, w/touch pad
20 # 316443834 Control, electronic, ES610W2, dual oven
77 316247900 Spacer, power board, (4)
77A 316114100 Spacer, (2)
97 316443912 Board, relay, dual oven
* 5303211311 Screw, 8 x 0.500

Publication No: 5995493805 FEB30T6FCC
06/07 4
UPPER OVEN
119
108
108A
70
185
71
81
163
163
81
1
80
58B
264
99
37
76
29
29 127
86
86
41
41
58A
82
BUFEB30T6DSD
99
185
70
2
12
83
59
59A
131
132
89
58D
143
67
66
68
54
14
15
16
17
142
310
311
312
6
6
272
107
111
109
263
125

FEB30T6FCC Publication No: 5995493805
# Functional Parts 5 06/07
* Non-Illustrated Parts
UPPER OVEN
POS. NO PART NO. DESCRIPTION
1 318259205 Back, main
2 318258902 Shield, insulation, upper
6 318262502 Rack, oven
12 316445501 Switch, oven light, door frame
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
* 5303325980 Screw, 10-32 x 0.437
54 318222400 Housing, oven light
58A 318285055 Insulation, oven wrapper
58B 318285056 Insulation, oven back
58D 318285058 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
71* 318340201 Bracket, insul. panel
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258707 Shield, insulation, lower
83 318261404 Liner, oven assy
86 318342400 Receptacle, hinge
89 # 318261211 Motor, latch assy
* # 318231750 Harness, wiring, main, latch
* # 318199744 Wiring Harness, latch, BAS
* 318199746 Wiring Harness, latch, NO BAS
99 318252800 Support, side
* 5303300265 Screw, 8-18 X 1/2, (2)
107 318219401 Cover, fan
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
109 316136400 Blade, fan
111 316136600 Nut, fan retainer
119# 318004900 Switch, thermal
125* 5303316994 Insulation, 3.81 x 3.13
125# 316415800 Motor, fan
127 318317100 Adapter Assembly, vent tube, w/converter
131 318272900 Box, vent
132 318003000 Plate, shield
142 318123910 Deflector
143 318172904 Support, wire

Publication No: 5995493805 FEB30T6FCC
06/07 6
UPPER OVEN
119
108
108A
70
185
71
81
163
163
81
1
80
58B
264
99
37
76
29
29 127
86
86
41
41
58A
82
BUFEB30T6DSD
99
185
70
2
12
83
59
59A
131
132
89
58D
143
67
66
68
54
14
15
16
17
142
310
311
312
6
6
272
107
111
109
263
125

FEB30T6FCC Publication No: 5995493805
# Functional Parts 7 06/07
* Non-Illustrated Parts
UPPER OVEN
POS. NO PART NO. DESCRIPTION
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
263 316136500 Washer, flat
264 318257701 Trim, oven, black, front
272 318249401 Tube, protector
310 5304440067 Cabinet Mounting Kit
311 318246010 Bracket, cabinet mtg, (2)
311* 5304438005 Screw, 6 x 1, black
312 318246702 Tool, cabinet bracket, RH
312 318246703 Tool, cabinet bracket, LH
* 318165800 Spacer
* 5303211311 Screw, 8 x 0.500
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995493805 FEB30T6FCC
06/07 8
LOWER OVEN
143
119
108
108A
70
185
71
81
163
163
81
87
1
62
80
142
58B
264
99
56A
76
29
29 127
86 56
86
41
41
90
58A
82 BLFEB30T6DSC
99
185
70
2
12
83
59
59A
37
89
58D
67
66
68
54
14
15
16
17
6
6
272
107
111
109
263
125

FEB30T6FCC Publication No: 5995493805
# Functional Parts 9 06/07
* Non-Illustrated Parts
LOWER OVEN
POS. NO PART NO. DESCRIPTION
1 318259205 Back, main
2 318258902 Shield, insulation, upper
6 318345207 Rack, oven
12 316445501 Switch, oven light, door frame
14 318224000 Receptacle, oven light
14* 318268099 Insulation, oven light
15 5303013071 Bulb/Lamp, light
16 08011086 Lens, oven light, glass
17 5304400195 Retainer, light cover
29 318147411 Bumper, (2)
37 # 316217002 Probe, oven temp
41 5303310526 Cover, hinge cutout
* 5303325980 Screw, 10-32 x 0.437
54 318222400 Housing, oven light
56 318903604 Trim, side filler, black, RH
56A 318903605 Trim, side filler, black, LH
58A 318285055 Insulation, oven wrapper
58B 318285056 Insulation, oven back
58D 318285058 Insulation, 1/2" thick, 43 x 9.5
59 318072560 Duct, oven vent
59A 318261600 Bracket, vent tube
62 316056000 Terminal Block
62* 5303323139 Screw, 10-24 x 0.906
62* 5303323144 Nut, 10-32
66 # 318255600 Element, broil, 2750W
67 # 318255401 Element, bake, 3400W
68 5304403015 Support, hanger, (2), broil element
70 318259100 Shield, insulation, sides, (2)
71 318260007 Panel, rear box
71* 318340201 Bracket, insul. panel
76 318056217 Front, oven
80 5303320846 Plate, oven mtg
81 318192400 Spring, oven
82 318258707 Shield, insulation, lower
83 318261404 Liner, oven assy
86 318342400 Receptacle, hinge
87 318260600 Bracket, cable mtg.
89 # 318261211 Motor, latch assy
* # 318231750 Harness, wiring, main, latch
* # 318199744 Wiring Harness, latch, BAS
* # 318199746 Wiring Harness, latch, NO BAS
90 318259701 Trim, oven front, black, bottom
99 318256200 Bracket, side, bottom, (2)
107 318219401 Cover, fan
108# 318073018 Motor, blower
* 08016432 Screw, truss head, 8-18 x 0.375
108A 318251300 Bracket, fan support
109 316136400 Blade, fan
111 316136600 Nut, fan retainer
119# 318004900 Switch, thermal
125* 5303316994 Insulation, 3.81 x 3.13

Publication No: 5995493805 FEB30T6FCC
06/07 10
LOWER OVEN
143
119
108
108A
70
185
71
81
163
163
81
87
1
62
80
142
58B
264
99
56A
76
29
29 127
86 56
86
41
41
90
58A
82 BLFEB30T6DSC
99
185
70
2
12
83
59
59A
37
89
58D
67
66
68
54
14
15
16
17
6
6
272
107
111
109
263
125

FEB30T6FCC Publication No: 5995493805
# Functional Parts 11 06/07
* Non-Illustrated Parts
LOWER OVEN
POS. NO PART NO. DESCRIPTION
125# 316415800 Motor, fan
127 318317100 Adapter Assembly, vent tube, w/converter
142 318123910 Deflector
143 318172904 Support, wire
163 318014111 Spacer
185 318014700 Spacer, oven shield, (4)
263 316136500 Washer, flat
264 318257801 Trim, oven, black, front
272 318249401 Tube, protector
* # 318078543 Box & wires assy
* # 318370312 Wriring Harness, main
* 5303211311 Screw, 8 x 0.500
* 318165800 Spacer
* 5303323136 Screw ground
* 5303323277 Screw, 8-18 X 13/32
* 5304436875 Screw, 8-18 X 1/2, black

Publication No: 5995493805 FEB30T6FCC
06/07 12
DOORS
4142
56
56
56
56
3A
3A
24
13
6
3B
3B
7
7
7A
7A
9
64
12
17
17
23
23
39
40
40
64
8
8
16
DCFEB30S5GC2
56
10
10

FEB30T6FCC Publication No: 5995493805
# Functional Parts 13 06/07
* Non-Illustrated Parts
DOORS
POS. NO PART NO. DESCRIPTION
3A 318260401 Trim, oven door, side, (2)
3B 318262101 Cover, rear door, black, (2)
6 318260520 Baffle, door
7 318372000 Insulation, door, (2)
7A 318372002 Insulation, door, (2)
8 316117500 Glass, oven door, heat barrier
9 318259605 Liner, door
10 5304452028 Screw, handle mtg, 10-14 x 1/2, (2)
12 318053130 Seal, oven door, upper
13 318272188 Door Assy, glass, stainless steel, outer
16 318212210 Glass, oven door, heat barrier
17 316402403 Spacer, door glass, (2)
23 318024714 Hinge, door, (2)
24 318260301 Trim, door, black, lower
39 316270200 Handle, door, black
40 318242702 Bracket, glass holder, upper door, (2)
41 318370600 Bracket, glass retainer, (2)
42 318382301 Bracket, glass retainer, (4)
56 5304436875 Screw, 8-18 X 1/2, black
64 318165800 Spacer
* 08016432 Screw, truss head, 8-18 x 0.375
* 5303211311 Screw, 8 x 0.500
* 5303300265 Screw, 8-18 X 1/2, (2)
* 5303323277 Screw, 8-18 X 13/32

Publication No: 5995493805 FEB30T6FCC
06/07 14
WIRING DIAGRAM
