Frigidaire FGEW2765P W Installation and operation manual

frigidaire.com
Signature Features
Product Dimensions
Height 29"
Width 27"
Depth 24-3/4"
More Easy-To-Use Features
Steam Cleaning
A light oven cleaning that’s chemical-free,
odor-free, and fast.
Eortless™ Convection
Takes the guesswork out of convection
cooking — our oven automatically
adjust standard baking temperatures to
convection temperatures for consistent
results.
Even Baking Technology
Our Even Baking Technology ensures even
baking every time.
Express-Select® Controls
Easily set cooking temperature or choose
one-touch cooking options.
Temperature Probe
Take the guesswork out of cooking with
our temperature probe that ensures your
food is at the right internal temperature.
One-Touch Keep Warm Setting
Just one touch of a button keeps food
warm until everything —
and everyone — is ready.
Auto Oven Shut-O
As an extra safety measure, the oven will
automatically shut off after six hours.
A.D.A. Compliant
When properly installed, this model is
A.D.A.-qualified based on the United
States Access Board’s A.D.A./A.B.A.
Accessibility Guidelines and the
Department of Justice’s 2010 A.D.A.
Standards for Accessible Design.
Sabbath Mode (Star-K® Certified)
Available in:
1Based on single rack cooking performance, not set
temperature, using Quick Preheat.
2Select models only.
27" Electric
Single Wall Ovens
FGEW2765P F/ W/ B
Stainless
(F)
White
(W)
Black
(B)
Power Broil
Added power means you can broil
food faster.
Quick Preheat
Preheat in less than six minutes.1
True Convection
Single convection fan circulates hot
air throughout the oven for faster and
more even multi-rack baking.
Smudge-Proof™ Stainless Steel2
Reduces fingerprints and smudges so
it’s easy to clean.

Specifications
subject to change.
Accessories information available
on the web at frigidaire.com
Features
Oven Control / Timing System
Window
Exterior Door Finish
Handle Design
Oven Cleaning System
Oven Controls
Bake / Broil
Eortless™ Convection Conversion
Convection Bake / Broil / Roast
Oven Preheat
My Favorite
Slow Cook
Eortless™ Temperature Probe
Chicken Nugget Button
Pizza Button
Keep Warm
Add-a-Minute
Delay Start
Self-Clean / Clean Options
Steam Clean
Delay Clean
Kitchen Timer
Timed Cook Option
Control Lock
Auto Oven Shut-O
Oven Lock-Out
Oven Features
Capacity (Cu. Ft.)
Convection System
Oven Light
Hidden Bake Element
Rack Configuration
Baking System
Broiling System
Bake / Broil Element (Watts)
Optional Accessories
3"-High Bottom Trim – Stainless
Steel (F) / White (W) /Black (B)
10'-Long Armored Power Cable
Certifications
A.D.A. Compliant1
Sabbath Mode (Star-K® Certified)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating)
@ 240 / 208 Volts2
Amps @ 240 / 208 Volts
Minimum Circuit Required (Amps)
Approved for
Under-Counter Installation
Shipping Weight (Approx.)
Single Wall Ovens
FGEW2765P F / W / B 27" Electric
E
D
B
C
A
Spacer
Single Electric Wall Ovens
Frigidaire Baseline
Express-Select®
Extra-Large
Smudge-Proof™
Stainless Steel (F),
Color-Coordinated (W/B)
Stainless Steel (F),
Color-Coordinated (W/B)
Self-Clean w/ Steam Clean
Option
Yes / Variable (400 - 550 °F)
Yes
Yes / Yes / Yes
Quick
Yes
Yes
Yes
Yes / 2, 3, 4 Hours
Yes
Yes
Yes
Yes
Yes
Yes
Yes
3.8
True Convection
2 Halogen
Yes
2 Heavy Duty, 1 Oset Rack
Even Baking Technology
Power Broil
1,450 / 3,400
(F) PN # 903114-901S
(W) PN # 903114-9011
(B) PN # 903114-9010
PN # 903056-9010
Yes
Yes
17" x 20-1/2" x 18-3/4"
Left Bottom Rear
240V / 208V / 60Hz
3.7 /2.8
15.4 / 13.5
20
Yes
146 Lbs.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGEW2765P 10/13 © 2013 Electrolux Home Products, Inc.
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
Cutout Dimensions
Height (Min.) / (Max.)
Width (Min.) / (Max.)
Depth (Min.)
27-1/4" / 28-5/8"
24-7/8" / 25-1/4"
23-1/2"
Product Dimensions
A - Height
B - Width
C - Depth
D - Height (Wrapper)
E - Width (Wrapper)
Depth with Door Open 90˚
29"
27"
24-3/4"
27-3/16"
24-5/8"
45-3/4"
1When properly installed, this model is A.D.A.-qualified based on the
United States Access Board’s A.D.A./A.B.A. Accessibility Guidelines and
the Department of Justice’s 2010 A.D.A. Standards for Accessible Design.
2Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz AC
only electrical supply with ground required on separate circuit fused on
both sides of line.

Accessories information available
on the web at frigidaire.com
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE •frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FGEW2765P 10/13 © 2013 Electrolux Home Products, Inc.
Specifications
subject to change.
Single Wall Ovens
FGEW2765P F / W / B 27" Electric
27" Single Electric Wall Oven
Gallery
Single Wall Oven Specifications
• Product Shipping Weight (approx.) – 146 Lbs.
• Single phase 3- or 4-wire cable, 120 / 240 or 120 / 208 Volt, 60 Hertz
AC only electrical supply with ground required on separate circuit
fused on both sides of line.
• Connected Load (kW Rating) @ 240 / 208 Volts = 3.7 / 2.8 kW
• Amps @ 240 / 208 Volts = 15.4 / 13.5 Amps
• Recommended Circuit Breaker – 20 Amps
• Always consult local and national electric codes.
• Minimum 21" clearance for oven door depth when open.
• Suggested distance from floor is 31". Minimum required distance
is 4-1/2".
• Minimum 23-1/2" deep cutout dimension is critical for proper
installation, to ensure that oven’s faceplate will fit flush against
cabinet front.
• To adapt oven to fit cutout height greater than 28-1/8", add one
2"-wide wood shim of appropriate height to each side of opening
under oven side rails. Lifting oven will hide larger cutout opening
at top and oven’s 1"-high bottom trim will hide shims at bottom.
(Standard 1"-High Bottom Trim included.)
• To adapt oven to fit cutout height greater than 28-5/8", optional
3"-High Bottom Trim available.
• Full oven base of solid plywood or similar material required,
capable of supporting 150 Lbs.
• Base must be level and cabinet front must be square.
• Single Wall Ovens are NOT approved to be used in stackable or
side-by-side installation.
• Single Wall Ovens are approved to be used alone in under-counter
installation or beneath any approved Frigidaire® gas or electric
cooktop. (Refer to Gas or Electric Cooktop Installation Over 30" / 27"
Electric Single Wall Oven Specifications pages on web.)
• Single Wall Ovens are approved to be used in combination with any
Frigidaire® Warmer Drawer. (Refer to model-specific Warmer Drawer
product page for Combination Installation Specifications.)
• Single Wall Ovens are approved to be used in combination with
any Frigidaire® Built-In Microwave Oven.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
Optional Accessories
• 3"-High Stainless Steel Bottom Trim – (PN # 903114-901S).
• 3"-High White Bottom Trim – (PN # 903114-9011).
• 3"-High Black Bottom Trim – (PN # 903114-9010).
• 10'-Long Armored Power Cable – (PN # 903056-9010).

USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_SSR FR 04/13 © 2013 Electrolux Home Products, Inc.
General Installation Guidelines
with Side-by-Side Refrigerator
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Specifications
subject to change.

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_TMR FR 04/13 © 2013 Electrolux Home Products, Inc.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with Top Mount Refrigerator

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_FDR FR 04/13 © 2013 Electrolux Home Products, Inc.
Top
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
General Installation Guidelines
with French Door Refrigerator

Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
INSTGDLNS_ARAF FR 04/13 © 2013 Electrolux Home Products, Inc.
Use these dimensions and clearance instructions for planning purposes only. For detailed installation
instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.
Front
Top
Front
Top
General Installation Guidelines
with All Refrigerator or All Freezer
