Frigidaire FCS388CG User manual

PRODUCT NO. FACTORY NO. COLOR MARKET
FCS388CGSC 37956393H8313 WHITE U.S.A.
FCS388CGBC 37956393H8363 BLACK U.S.A.
ELECTRIC - RANGE
Model No.
FCS388CG
©1998 White Consolidated Industries,
Inc.
FACTORY PARTS CATALOG
SLIDE-IN RANGE
WIRING DIAGRAM # - 318045030
OWNER’S GUIDE # - 318200808
TIMER INSTRUCTION GUIDE # - 318130805
INSTALLATION INSTR. # - 318104605
FRIGIDAIRE HOME PRODUCTS
7075 ORDAN DRIVE
MISSISSAUGA, ONTARIO
CANADA, L5T 1K6
TEL: [phone] Publication No.
5995315560
981203
-EN/SERVICE
377

Publication No. FCS388CGS/B
5995315560
12/98 2
BACKGUARD
20
LAP22G0017
13A
14
23
69
18A
21
18
19
64
42
2424
46
36A

FCS388CGS/B Publication No.
5995315560
# = Functional Part 312/98
* = Non-Illustrated Part
BACKGUARD
POS. NO PART NO DESCRIPTION
13A 316095500 AB Switch-warmer infinite
14 5303051533 AB Light/Lamp
18 5303304668 AEnd Cap white RH
18 5303300160 B End Cap black RH
18A 5303304671 AEnd Cap white LH
18A 5303300161 B End Cap black LH
19 318005539 APanel-control
19 318005541 B Panel-control
20 # 318012901 AClock/Timer
20# 318012900 B Clock/Timer
21 318027804 ATrim-backguard
21 318027803 B Trim-backguard
23 318015020 AB Bracket-clock mtg
24 # 316005607 ASwitch-rocker white
24# 316005612 B Switch-rocker almond
36A 318165101 AKnob-warmer white
36A 318165103 B Knob-warmer grey
42 318106904 A Trim-vent
42 318106903 B Trim-vent
46 5308006417 AB Lens-light/lamp
64 318112200 AB Plate
69 5303323134 AB Screw mtg 8-32 X 3/16
*5303211311 AB Screw, #8 X ½
*08016432 AB Screw, 8-18 X 3/8
*5303323145 AB Nut
*5303311124 A B Screw 6-20 X 1/2
A= FCS388CG (FCS388CGSC)
B= FCS388CG (FCS388CGBC)

Publication No. FCS388CGS/B
5995315560
12/98 4
BURNER
72
10B
10
10
10A
35
35
35
3
2
14
15
73
222A
1
8
13
6
4
7
5
77
33
33
77
76
76
74
74
74
74
75
75
75
75 76
76A
77
77A
333
35
LAP22B0030

FCS388CGS/B Publication No.
5995315560
# = Functional Part 512/98
* = Non-Illustrated Part
BURNER
POS. NO PART NO DESCRIPTION
1318177301 AB Manifold pipe
2# 5303935042 AB Valve-top burner
2A# 318087001 AB Valve-top burner
3# 316032002 AB Switch-ignitor (4)
4# 318167703 AB Tube-burner
5# 318167700 AB Tube-burner
6# 318167702 A B Tube-burner
7# 318167701 A B Tube-burner
8# 5303280394 AB Spark module
10# 318148001 AB Burner mid.
10A# 318148002 AB Burner large
10B# 318148000 A B Burner small
13 318054503 AB Connector, manifold tube
14# 318122700 AB Regulator, pressure
15 318122900 AB Bracket
33 318171500 AB Bracket burner
35 5303307978 AB Bushing insulation
72 5303323141 AB Screw 1/4-20 X 5/16
73 318080100 AB Plate
74# 318148700 A B Ignitor
75 318148800 A B Clip (ignitor mtg)
76# 318167801 A B Mid & large mixing tube
76A 318167800 A B Small mixing tube
77 318112010 A B Bracket burner
77A 318112000 A B Bracket burner
*316048200 AB Screw
*318127701 A B Lp kit
A= FCS388CG (FCS388CGSC)
B= FCS388CG (FCS388CGBC)

FCS388CGS/B Publication No.
5995315560
12/98 6
BODY
141
219
68
170
170A
5
3B
102
191
62
71
87
80
LAP22V0012A
6
67
25
83
58B
142
58A
2A
88
89 108
59
141
10
9
127
37
12
129
128
70
3
70
114
114
1A
62
14
54 15 16
17
81
81
125
1
56
56
41
86
86
76 41
217
6A
107
66
3A
5
102
5
177
63
4223
222
59A

FCS388CGS/B Publication No.
5995315560
# = Functional Part 712/98
* = Non-Illustrated Part
BODY
POS. NO PART NO DESCRIPTION
1 318066400 AB Back-main
1A 5303311161 AB Panel-back
2A 318108600 AB Shield-oven top
3 5303300143 AB Panel-bodyside
3A 5303280349 AB Panel-bodyside RH
3B 5303280351 AB Panel-bodyside LH
4318073900 AB Panel-subtop
5 318175500 AB Screw-leveling
6 5303310522 AB Rack-oven
6A 5303311206 AB Rack, broiler pan
9 5303317977 AB Pan-broiler
10 5303317976 AB Insert-broiler pan
12 # 318089910 AB Switch-light
14 5308011085 AB Socket-light/lamp
15 3201908 AB Lamp-oven light
16 3201911 AB Glass-oven light lens
17 5304400195 AB Retainer-lens
25 318121303 AB Shield-heat
37 # 316111201 AB Probe-oven temp
41 5303310526 AB Cover-hinge cutout
54 5303310514 AB Housing-oven light
56 318002602 ATrim-oven front white
56 318002601 B Trim-oven front black
58A 5303310539 AB Insulation
58B 5303310538 AB Insulation oven back
59 318072519 AB Tube-oven vent
59A 318072520 AB Tube-oven vent
62 # 5303310518 AB Terminal Block
63 5303310517 AB Plate-ground strap
66 # 5303310513 AB Element-broil
67 # 5303310512 AB Element-bake
68 5304403015 AB Support-element
70 5303300142 AB Shield-insulation
71 5303310515 AB Cover-wiring
76 318124100 AB Front-oven
80 5303320846 AB Plate oven
81 5303301261 AB Spring-oven
83 318089609 AB Liner-oven
86 5303310524 AB Channel-hinge
87 318111800 AB Plate-mounting
88 5303311160 AB Rod-latch
89 # 5304404899 AB Motor-latch
89 * 318120702 AB Switch latch
102 5303311142 AB Support-oven front
107 318119600 AB Cover-fan
108# 318073001 AB Motor-fan
109 5303311203 AB Fan blade
111 5303311205 AB Nut-fan retainer
111* 5303322885 AB Spacer
114 3051827 AB Plate-filler
125# 5303311202 AB Motor-convection
127 5303310542 AB Adapter assy
128 5303311163 AB Bushing
129 5303311164 AB Spring
141 # 5303284446 AB Switch thermal cutout
142 318123901 AB Air Deflector
170 3203576 AB Anti-tip bracket right
170A 3203575 AB Anti-tip bracket left
177 5303324040 AB Gasket-vent
191 5303304030 AB Bracket
217 316042300 AB Warning plate
219# 318003400 AB Thermostat safety
222 318080000 AB Covering plate
223 318038400 AB Cover tube
* 5303211311 AB Screw #8 X ½
*5303300265 A B Screw, 8-18 X 1/2
A= FCS388CG (FCS388CGSC)
B= FCS388CG (FCS388CGBC)

FCS388CGS/B Publication No.
5995315560
12/98 8
TOP/DRAWER
43
43 43 43
45
45
45
45
22
22B
22
22A
19
19A
19
19B
31A
31A
31A 31A
20
20
20
20
105
16
60
2
193
124
85
1
80
4
87
39
86
81
1A
1B
1C
124A 13A
13
84
LAP22T0021B
72
72
95

FCS388CGS/B Publication No.
5995315230
# = Functional Part 912/98
* = Non-Illustrated Part
TOP/DRAWER
POS.NO PART NO DESCRIPTION
1 318142500 AB Drawer-warmer
1A 318143307 AB Deflector-warmer side
1B 318143306 AB Deflector-warmer side
1C 318143201 AB Deflector-warmer rear
2318108013 AB Inner-Panel-drawer
4 5303300149 APanel-drawer white
45303300151 B Panel-drawer black
13 316094900 AB Rail-drawer RH outer
13A 316094901 AB Rail-drawer LH outer
16 318079200 AMain Top glass white
16 318079201 B Main Top glass black
19 318168116 ABurner pan, medium white
19 318168114 B Burner pan, medium black
19A 318168126 ABurner pan, large white
19A 318168124 B Burner pan. large black
19B 318168106 ABurner pan, small white
19B# 318168104 BBurner pan, small black
20 318120104 AGrate
20 318120103 B Grate
22 318076411 ACap-burner mid greyl
22 318076410 B Cap-burner mid black
22A 318076421 ACap-burner large grey
22A 318076420 B Cap-burner large black
22B 318076401 ACap-burner small grey
22B 318076400 BCap-burner small black
31A 5303307931 AB Gasket pan
39 316026103 AHandle-drawer white
39 5303300154 B Handle-drawer black
43 318016500 AKnob, top valve (4)
43 318016501 B Knob, top valve (4)
45 5303307933 AB Bushing, top burner
60 5303300155 A B Screw handle
72 318113401 AB Bracket-slide (2)/ Support latéral
80 318052700 AB Seal-door, warmer drawer
81# 316093100 AB Element warmer drawer
84# 318005101 AB Thermostat
85 316093600 AB Rack, warmer drawer
86 316095800 AB Clip hold down
87 318121501 AB Base-warmer
95 318143701 AB Cover-wire/ Couvercle
105 318171600 A B Glass support/ Support vitre
124 316096500 AB Channel-drawer RH, inner
124A 316096501 AB Channel-drawer LH, inner
193 5304400796 A B Plug
*5303211311 AB Screw, #8 X ½
*08011955 A B Screw, 10-24 X 3/8
*5304403558 A B Screw, 10-16 X ¼
*08002868 A B Screw, 10-24 X 1/2
A= FCS388CG (FCS388CGSC)
B= FCS388CG (FCS388CGBC)

Publication No. FCS388CGS/B
5995315560
12/98 10
DOOR
3
23
17
23
9
6
3A
3B
54
1
39
42
18
12
4
10
A23CD018
29
29
16
20
20
31
16
7

FCS388CGS/B Publication No.
5995315560
# = Functional Part 11 12/98
* = Non-Illustrated Part
DOOR
POS. NO PART NO DESCRIPTION
1 318043100 AB Bracket-trim
3 318049206 ATrim-oven door white
3318049205 B Trim-oven door black
3A 318028900 AB Trim-oven door
3B 318049020 ATrim-oven door white
3B 318049019 B Trim-oven door black
4 318041102 AGlass-oven door white
4318041105 B Glass-oven door black
6 318056802 AB Shield-wool
7 318106001 AB Insulation-door
9 318048802 AB Liner-oven door
10 5303324305 AB Screw 10-24 X 5/8
12 318053103 AB Seal-oven door
16 318041603 AB Glass-oven door
17 318042102 AB Spacer-glass
18 318053001 AB Seal-window
20 318014301 ASpacer-handle white
20 318014300 B Spacer-handle black
23 5303311215 AB Hinge-oven door assy.
23* 3201899 AB Washer
29 5303310535 AB Bumper base
31 5303310536 AB Latch-door
39 316091119 AHandle-door white
39 316091121 B Handle-door black
42 5303311194 ATrim-oven door white
42 5303311200 B Trim-oven door black
54 5303317175 AScrew 8-18 X ½ white
54 5303308456 B Screw, 8-18 X ½ black
*08016432 AB Screw, 8-18 X 3/8
*5303211311 AB Screw, #8 X ½
A= FCS388CG (FCS388CGSC)
B= FCS388CG (FCS388CGBC)

Publication No. FCS388CGS/B
5995315560
12/98 12
WIRING DIAGRAM
