Frigidaire FEF352F Manual

FEFB65A.eps T20G5642.eps T20V0037.eps T20T0047.eps T20D0021.eps
316417700d.eps 316417700s.eps
Product No. FEF352FSA FEF352FUA FEF352FWA
Series 30" f/s elec 30" f/s elec 30" f/s elec
Color white black/bisque black/white
Market North America North America North America
Wiring Diagram 316417700 316417700 316417700
Owner's Guide 316417007 316417007 316417007
Installation Instructions 316454901 316454901 316454901
Service Data Sheet 316417613 316417613 316417613
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995460010
06/02/01
(EN/SERVICE/ECL)
369
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FEF352F
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995460010 FEF352F
02/06 2
BACKGUARD
8.8.
8.8.
24
14
54
54A
46
69
31
31
54
54A 14
T20G5642
56
1
15A
15
19
20A
20
23
23

FEF352F Publication No: 5995460010
# Functional Parts 3 02/06
* Non-Illustrated Parts
BACKGUARD
Model Index: AFEF352F (FEF352FSA)
BFEF352F (FEF352FWA)
CFEF352F (FEF352FUA)
POS. NO PART NO. DESCRIPTION
1 316416100 A B C Shield, backguard, rear wall
14 316022500 A B C Light/Lamp, indicator, 125 V
15 316411403 A - - Support, backguard, white, RH
15 316411405 - B C Support, backguard, black, RH
15A 316411402 A - - Support, backguard, white, LH
15A 316411404 - B C Support, backguard, black, LH
19 316445207 A - - Panel-backguard, white
19 316445206 - B C Panel-backguard, black
20 # 316418204 A B C Clock/Timer, electronic, ES200
20A 316419101 A - - Overlay, clock, white, ES200
20A 316419100 - B C Overlay, clock, black, ES200
23 316441600 A B C Bracket-clock mtg, black
24 # 316448701 A - - Switch, rocker, white, oven light
24 # 316448700 - B C Switch, rocker, black, oven light
31 316223000 A - - Knob, control, white
31 316223002 - B C Knob, control, black
46 316040201 A B C Lens, indicator light, red
54 # 316436000 A B C Switch, infinite, small element
54A# 316436001 A B C Switch, infinite, large element
56 316234012 A - - Shield, backguard, white, inner
56 316234013 - B C Shield, backguard, black, inner
69 5303288565 A B C Screw, truss sqdr, 8-32 x 3/16, switch mtg
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021109 A B C Screw, 8-18 x 0.5, chrome
* 316021110 A B C Screw, 8-18 x 0.5, black

Publication No: 5995460010 FEF352F
02/06 4
BODY
25
12
ANTI-TIP
BRACKET
ANTI-TIP
BRACKET
NOTE: Oven Liner N/A
Ass. du four N/A
21
3
5
170
5A
151
87
57
71
89
88
1
86
58A
58B
18
86
17
16
15
14
68
37
8
58
6
6
42
5
5A
170
T20V0037
3
151
66
67
4
59
29
28
62
63
44

FEF352F Publication No: 5995460010
# Functional Parts 5 02/06
* Non-Illustrated Parts
BODY
Model Index: AFEF352F (FEF352FSA)
BFEF352F (FEF352FWA)
CFEF352F (FEF352FUA)
POS. NO PART NO. DESCRIPTION
1 316401800 A B C Panel, main back
3 316400116 A B - Panel, bodyside, white, RH
3 316400117 A B - Panel, bodyside, white, LH
3 316400120 - - C Panel, bodyside, bisque, RH
3 316400121 - - C Panel, bodyside, bisque, LH
4 316201401 A B C Burner Box
5 316272900 A B C Screw, leveling, plastic, rear, (2)
5A 316407201 A B C Leveling Leg Assy, metal, front, (2), bracket & leg
6 316404500 A B C Rack, oven
8 316400601 A B C Panel, oven bottom
12 316445501 A B C Switch, oven light, door frame
14 316116400 A B C Receptacle, oven light
15 5303013071 A B C Bulb/Lamp, light
16 08011086 A B C Lens, oven light, glass
17 316087500 A B C Retainer, lens
18 # 316405800 A B C Latch Assembly, oven door
21 316408000 A B C Clip, bodyside
25 316406200 A B C Shield, heat, lower
28 316045000 A B C Clip, wiring harness, green, main top
29 316407301 A B C Glide, drawer, front
37 # 316217001 A B C Probe, oven temp
42 316407700 A B C Shield, wool, lower
44 316246501 A B C Spacer, oven door
57 316457800 A B C Cover, access
58 316403800 A B C Insulation, oven bottom
58A 316406600 A B C Insulation, oven wrapper
58B 316406500 A B C Insulation, oven back
59 316073606 A B C Tube, oven vent
62 5304409888 A B C Terminal Block Kit
62* 316085600 A B C Insulator
62* 316205500 A B C Nut, hex flange, 3/8 10-32
63 316278800 A B C Plate, grounding strap
66 # 316203200 A B C Element, broil
67 316075103 A B C Element, bake
68 316404000 A B C Support, element, broil
71 316422304 A B C Shield, rear wall
86 316441300 A B C Receptacle, hinge
86* 316418901 A B C Screw, trilobe, 10-32 x 5/16"
87 316081200 A B C Bracket, cable mtg
88 316203500 A B C Rod, auto latch
89 # 316415400 A B C Motor, latch/lock
151 316404600 A B C Shield, bodyside
170 5303935180 A B C Anti-tip Kit, w/bracket, screw
170* 316107200 A B C Bracket, anti-tip
170* 316112500 A B C Template, anti-tip
170* 316116000 A B C Screw, concrete, 1.75", anti-tip brkt
* # 316416401 A B C Harness, wiring, main
* 3203550 A B C Plug, button, oven bottom
* 5303321319 A B - Paint, touch-up, white
* 5303305345 - B C Paint, touch-up, black
* 5304414035 - - C Paint, touch-up, bisque
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021110 A B C Screw, 8-18 x 0.5, black
* 316089500 A B C Screw, 10-16 x .486
* 5303271648 A B C Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B C Screw, wafer head, 8-32T x 0.500, black
* 5308014215 A B C Screw, 6-20 x 0.312

Publication No: 5995460010 FEF352F
02/06 6
TOP/DRAWER

FEF352F Publication No: 5995460010
# Functional Parts 7 02/06
* Non-Illustrated Parts
TOP/DRAWER
Model Index: AFEF352F (FEF352FSA)
BFEF352F (FEF352FWA)
CFEF352F (FEF352FUA)
POS. NO PART NO. DESCRIPTION
1 316408701 A B C Drawer, utility
2 316403300 A B C Liner, drawer
4 316403501 A B - Panel, drawer front, white
4 316403503 - - C Panel, drawer front, bisque
7 316407400 A B C Glide, drawer, rear
15 # 3051450 A B C Element, surface, 8" large
15A# 3051449 A B C Element, surface, 6" small
16 316202363 A B - Main Top, white
16 316202364 - - C Main Top, bisque
17 316057601 A B C Rod, support, main top
18 316436600 A B C Hinge Bracket, maintop, (2)
19 # 316048413 A B C Pan-surface element, chrome, large/8 inch, (2)
19A# 316048414 A B C Pan-surface element, chrome, small/6 inch, (2)
27 # 5303912666 A B C Terminal Block Kit, surface element
28 5303017715 A B C Medallion, 1 1/2"dia, black, surface element
* # 316253501 A B C Wiring Harness, surface element
* # 316045000 A B C Clip, wiring harness, green, main top
* 316021105 A B C Screw, hex head cup pt, 8-18 x 0.375, black
* 316021109 A B C Screw, 8-18 x 0.5, chrome
* 316021110 A B C Screw, 8-18 x 0.5, black
* 5308014215 A B C Screw, 6-20 x 0.312

Publication No: 5995460010 FEF352F
02/06 8
DOOR
60B
10B
10
3
4
52
7
6
T20D0021
17
17
23
23
8
8
9
12
39
20
20

FEF352F Publication No: 5995460010
# Functional Parts 9 02/06
* Non-Illustrated Parts
DOOR
Model Index: AFEF352F (FEF352FSA)
BFEF352F (FEF352FWA)
CFEF352F (FEF352FUA)
POS. NO PART NO. DESCRIPTION
3 5303935243 A - - Trim kit-door, 3 sided, white, w/tape
3 5303935245 - B C Trim kit-door, 3 sided, black, w/tape
4 316406403 A - - Glass, oven door, white, outer
4 316406404 - B C Glass, oven door, black, outer
6 316406309 A B C Shield, wool
7 316405601 A B C Insulation, oven door
8 316427701 A B C Glass, oven door, inner
9 316423703 A B C Liner, oven door
10 316001009 A B C Screw, waf hd sq, 10-24 x 1.88, (2), handle mtg
10B 316008401 A B C Washer, 3/4 OD x 1/4 ID, steel
12 316405000 A B C Seal, oven door
17 316408803 A B C Spacer, door glass, (2)
20 316248401 A - - Spacer, handle, white, (2)
20 316248400 - B C Spacer, handle, black, (2)
23 316456307 A B C Hinge, oven door, purple titan, (2)
23* 316418900 A B C Screw, sims lp, #8-32 x 5/16", black
39 316248301 A - - Handle, oven door, white
39 316248300 - B C Handle, oven door, black
52 316405100 A - - Cap, door trim, white
52 316405101 - B C Cap, door trim, black
60B 316021110 A B C Screw, 8-18 x 0.5, black
* 316433603 A B C Label, anti-tip
* 316021109 A B C Screw, 8-18 x 0.5, chrome
* 5303271648 A B C Screw, wafer hd sq dr, 8-18AB x 0.5
* 5303285179 A B C Screw, wafer head, 8-32T x 0.500, black

Publication No: 5995460010 FEF352F
02/06 10
WIRING SCHEMATIC

FEF352F Publication No: 5995460010
# Functional Parts 11 02/06
* Non-Illustrated Parts
WIRING DIAGRAM
