Frigidaire FES368D User manual

4
"
"
31 5/16"
Product No. FES368DQA FES368DSA
37954334H4041 37954337H4011
Series 30" slide-in 30" slide-in
Color bisque white
Market North America North America
Wiring Diagram 318045089 318045089
Owner's Guide 318200840 318200840
Installation Instructions 318201606 316201606
Timer Guide 318200191 318200191
FES368D.eps la20bg0025.eps LA20B0002.eps LA20CT0014.eps LA00D07396-3F.eps
318045089.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995402954
04/01/30
(EN/SERVICE/ECL)
377
30-INCH SLIDE-IN
ELECTRIC RANGE
Model No.
FES368D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995402954 FES368D
01/04 2
BACKGUARD
42
8.8.
8.8.
46
54A
54
54
54A
14
20
19A
19
24
35
35
35
16
LA20BG0025
69
35
69
46
69
99A
69
69
69
14
36
36

FES368D Publication No: 5995402954
# Functional Parts 3 01/04
* Non-Ilustrated Parts
BACKGUARD
Model Index: AFES368D (FES368DSA)
BFES368D (FES368DQA)
POS. NO PART NO. DESCRIPTION
14 # 318044825 A B Light, indicator, 125v, (2)
16 318235000 A - Console, assy., white, w/ end caps
16 318235002 - B Console, assy., bisque, w/ end caps
19 318235144 A - Panel, control, white
19 318235146 - B Panel, control, bisque
19A 318224401 A B Panel, control mtg.
20 # 318185446 A - Clock/Timer, electronic, white, ES300
20 # 318185448 - B Clock/Timer, electronic, bisque, ES300
20* 316220804 A - Overlay, clock, white, ES300
20* 316220806 - B Overlay, clock, bisque
24 # 316005607 A - Switch, rocker, white
24 # 318037520 - B Switch, rocker, bisque, oven light
35 318183101 A - Support, glass, white, (4)
35 318183102 - B Support, glass, bisque, (4)
36 318229300 A - Knob, control, white
36 318229302 - B Knob, control, bisque
42 318224301 A B Trim, vent, black, bottom
46 318228300 A B Lens, indicator light
54 # 318220020 A B Switch, surface unit, single
54A# 318220021 A B Switch, surface unit, large
69 5303323134 A B Screw, switch mtg., 8-32 x 0.188
99A 318223900 A B Gasket, dark grey
* 3201861 A B Screw, 6 x 0.375, (4)
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303211311 A B Screw, 8 x 0.500

Publication No: 5995402954 FES368D
01/04 4
BODY

FES368D Publication No: 5995402954
# Functional Parts 5 01/04
* Non-Ilustrated Parts
BODY
Model Index: AFES368D (FES368DSA)
BFES368D (FES368DQA)
POS. NO PART NO. DESCRIPTION
1 318066402 A B Panel, main back
1A 318225100 A B Panel, main back, upper
2A 318227600 A B Shield, oven top
3 318225200 A B Panel, bodyside, upper RH
3A 318225201 A B Panel, bodyside, upper LH
3B 318160010 A B Panel, body side, lower RH
3C 318160011 A B Panel, body side, lower LH
5 318175503 A B Screw, leveling
6 318025308 A B Rack, oven
9 5303317977 A B Pan, broiler
10 5303317976 A B Insert, broiler pan
12 # 318089913 A B Switch, light
14 318224000 A B Receptacle, oven light
15 5303013071 A B Bulb/Lamp, oven light
16 3201911 A B Cover, oven light, glass
17 5304400195 A B Retainer, light cover
25 318179107 A B Panel, heat shield, sm oven bottom
37 # 316217002 A B Probe, oven temp
41 5303310526 A B Cover, hinge cutout
54 318222400 A B Housing, oven light
56 318225901 A - Trim, oven, white
56 318225903 - B Trim, oven, bisque
58A 318133783 A B Insulation, oven wrapper
58B 318133785 A B Insulation, oven back
59 318072534 A B Tube, vent, oven
62 5303935061 A B Terminal Block Kit
62* 5303323144 A B Nut, 10-32
63 316208500 A B Plate, grounding strap
66 # 318255600 A B Element, broil, 2750W
67 # 318255000 A B Element, bake, 3000W
68 5304403015 A B Support, element hanger
70 318194400 A B Shield, insulation
71 5303310515 A B Panel, wiring cover, rear
76 318225302 A B Front, oven
80 5303324473 A B Bracket, oven mounting
80* 318014110 A B Spacer
81 318192400 A B Spring, oven
83 318089613 A B Liner, oven
86 5303310524 A B Receptacle, hinge
87 318111803 A B Plate, mounting
88 318118904 A B Rod, latch
89 # 318095937 A B Motor, latch assy, w/brkt & switch
89* 318120711 A B Switch
102 5303311142 A B Support, oven front
108# 318073016 A B Motor, blower
112# 318112701 A B Relay
127 5303310542 A B Adapter, vent tube, with converter
128 5303311163 A B Bushing
129 5303311164 A B Spring

Publication No: 5995402954 FES368D
01/04 6
BODY

FES368D Publication No: 5995402954
# Functional Parts 7 01/04
* Non-Ilustrated Parts
BODY
Model Index: AFES368D (FES368DSA)
BFES368D (FES368DQA)
POS. NO PART NO. DESCRIPTION
141# 318005201 A B Switch, thermal cutout
141B 318003607 A B Thermostat, safety
142 318123901 A B Deflector
170 5304405244 A B Anti-tip & accessories
191 5303304030 A B Bracket, angle, corner
284 318226600 A B Box, vent tube
285 318236200 A B Shield, hidden wires
* 318235300 A B Connector assy., w/3 lugs, & instructions
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303211311 A B Screw, 8 x 0.500
* 5303307980 A B Screw, 8-32 x 0.437

Publication No: 5995402954 FES368D
01/04 8
TOP/DRAWER

FES368D Publication No: 5995402954
# Functional Parts 9 01/04
* Non-Ilustrated Parts
TOP/DRAWER
Model Index: AFES368D (FES368DSA)
BFES368D (FES368DQA)
POS. NO PART NO. DESCRIPTION
1 318107104 A B Drawer
4 318134011 A - Panel, drawer, white, front
4 318134013 - B Panel, drawer, bisque, front
11 5303311125 A B Bracket, drawer
13 5303311129 A B Channel, drawer, RH
13A 5303311130 A B Channel, drawer, LH
15 # 318198810 A B Element, surface, 6", 1200 W
15A# 318198812 A B Element, surface, 8", 2200 W
15B# 316224200 A B Element, surface, 9", 2500W, radiant
16 318223630 A - Main Top, glass assy., black/white
16 318223631 - B Main Top, glass assy., black/bisque
46 318225401 A B Box, burner
51 # 318044820 A - Light, indicator, red
51 # 318044822 - B Light, indicator, clear
52 318122007 A B Spring, element mtg, large
52A 318122006 A B Spring, element mtg, small
52B 318122010 A B Spring, element mtg, 1000W/2500W
70 5303311143 A B Bracket, slide, rear
71 5303311144 A B Magnet & spring assy
72 5303311145 A B Bracket & wheel assy
165 318227500 A B Plate, mounting
193 5303325173 A B Cap, plug
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303211311 A B Screw, 8 x 0.500

Publication No: 5995402954 FES368D
01/04 10
DOOR

FES368D Publication No: 5995402954
# Functional Parts 11 01/04
* Non-Ilustrated Parts
DOOR
Model Index: AFES368D (FES368DSA)
BFES368D (FES368DQA)
POS. NO PART NO. DESCRIPTION
1 318180310 A B Bracket, trim mtg
2 318180312 A B Bracket, upper trim mtg
3 318187810 A - Trim, door, white, RH side
3 318187812 - B Trim, door, bisque, RH side
3A 318187811 A - Trim, door, white, LH side
3A 318187813 - B Trim, door, bisque, LH side
3B 318176646 A - Trim, door, white, top
3B 318176648 - B Trim, door, bisque, top
4 318187715 A - Panel, door front assy, glass, white, with lower trim
4 318187716 - B Panel, door front assy, glass, bisque, with lower trim
6 318056802 A B Shield, insulation
7 318133781 A B Insulation, oven door
9 318157011 A B Liner, door
10 5303311174 A B Screw, 10-24 x 3/8
12 318053103 A B Gasket, oven door seal
16 318041603 A B Panel, glass, inner oven door
17 318042102 A B Spacer, glass
18 318053001 A B Seal, window
23 318024700 A B Hinge, oven door
31 5303310536 A B Latch, oven door
39 316203001 A - Handle, door, white
39 316203003 - B Handle, door, bisque
54 5303300265 A B Screw, 8-18 x 0.500, chrome, (3)
64 5304417120 A B Tape, 0.762 m, Neoprene
77 318043100 A - Bracket, trim, handle, (2)
* 316221001 A B Label, anti-tip
* 08016432 A B Screw, truss head, 8-18 x 0.375
* 5303211311 A B Screw, 8 x 0.500
* 5303307980 A B Screw, 8-32 x 0.437

Publication No: 5995402954 FES368D
01/04 12
WIRING DIAGRAM
