Frigidaire 218954901 User manual

P/N218954901(0101)
READ AND SAVE THESE INSTRUCTIONS

2
Product Registration ThisOwner'sGuidewillinstructyouonhowtoproperly operate and careforyour
product.Inaddition,pleasereadthroughtheinformationcontainedinyourliterature
pack to learn more about your new appliance.
Record Your Model and Serial Numbers
RecordtheModelNo.andSerialNo.ofthisrefrigeratorinthespaceprovidedbelow.
Thesenumbersarefoundontheserialplatelocatedontheceilingoftherefrigerator
compartment.
Model No. __________________________________________________
Serial No. ___________________________________________________
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD (shown left) should be filled in
completely, signed and returned to Electrolux Home Products.
2 ProductRegistration
2 Versión en español
3 ImportantSafetyInstructions
3 For Your Safety
3 Child Safety
3 ElectricalInformation
3 OtherPrecautions
4 First Steps
4 Location
4 Installation
4 DoorOpening
4 Leveling
4 Cleaning
5 Connecting Ice Maker to Water Supply
6 EnergySavingIdeas
6 Setting the Controls
6 Cool Down Period
6 RefrigeratorControl
6 FreezerControl
7 Fresh Food Storage
8-9 Automatic Ice and Water Dispenser
10-11 Care and Cleaning
10 Inside
10 Outside
10 Replacingthe LightBulb
10 Vacation and Moving Tips
11-12 Removing Handles and Doors
11 To Remove Handles
12 To Remove Freezer Door
12 ToRemoveRefrigerator Door
12 To Reinstall Freezer Door
12 ToReinstallRefrigeratorDoor
13-15 AvoidServiceChecklist
15 NormalOperatingSounds
16 Warranty
17 Service Information in Canada
Versión en español
Sideseaobtenerunacopiaenespañolde
esteManualdelUsuario,sírvaseescribira
ladirecciónqueseincluyeacontinuación.
Solicite la P/N 218955000.
SpanishOwner'sGuides
ElectroluxHomeProducts
P.O. Box 212378
Augusta, GA 30917
Contents
© 2001 White Consolidated Industries, Inc.
All rights reserved.
This Owner's Guide provides specific
operating instructions for your model.
Use the refrigerator only as instructed
in this Owner's Guide.

3
Important Safety
Instructions Read all instructions before using this refrigerator.
For Your Safety
Do not store, or use gasoline or other flammable vapors and liquids in the vicinity
ofthisoranyotherappliance.Readproductlabelsforflammabilityandotherwarnings.
• Destroy carton, plastic bags, and any exterior wrapping material immediately
after refrigerator is unpacked. Children should never use these items for play.
Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may
become airtight chambers, and can quickly cause suffocation.
• Remove all staples from carton. Staples can cause severe cuts, and destroy
finishes if they come in contact with other appliances or furniture.
• Anempty,discardedicebox,refrigerator,orfreezerisaverydangerousattraction
to children. Remove door of any appliance that is not in use, even if it is
being discarded.
•Refrigerator must be plugged into its own 115 Volt, 60 Hz, AC only
electrical outlet. The power cord of the appliance is equipped with a three-
prong grounding plug for your protection against shock hazards. It must be
pluggeddirectlyintoaproperlygroundedthree-prongreceptacle.Thereceptacle
must be installed in accordance with local codes and ordinances. Consult a
qualified electrician. Do Not Use An Extension Cord Or Adapter Plug.
• Ifvoltagevariesby10percent ormore,performanceofyourrefrigeratormaybe
affected.Operatingrefrigeratorwithinsufficientpowercandamagecompressor.
Suchdamage isnotcovered underyour warranty. Ifyou suspectyour voltage is
highor low, consultyour power companyfor testing.
• Topreventrefrigeratorfrombeingturnedoff accidentally, donotplugunitinto
an outlet controlled by a wall switch or pull cord.
• Do not pinch, knot, or bend power cord in any manner.
• Neverunplugrefrigeratorbypullingonpowercord.Alwaysgripplugfirmly,and
pullstraight outfrom receptacle.
• Toavoid electricalshock, unplugrefrigerator beforecleaning andbefore replacing
a light bulb. NOTE: Turning control to OFF turns off compressor, but does not
disconnectpowertolightbulborother electrical components.
• Do not operate refrigerator in the presence of explosive fumes.
• Avoid contact with any moving parts of automatic ice maker.
Child Safety
Avoid fire hazard or
electric shock. Do not use an extension
cord or an adapter plug. Do not remove
any prong from the power cord.
Theseguidelinesmustbefollowedtoensurethatsafetymechanismsinthe
design of this refrigerator will operate properly.
Electrical Information
Other Precautions
Proper Disposal of
Your Refrigerator/Freezer
Risk of child entrapment.
Child entrapment and suffocation are
not problems of the past. Junked or
abandoned refrigerators or freezers are
still dangerous — even if they will sit for
"just a few days." If you are getting rid
ofyouroldrefrigeratororfreezer,please
follow the instructions below to help
prevent accidents.
BEFORE YOU THROW AWAY YOUR
OLD REFRIGERATOR/FREEZER:
Remove
doors.
Leave shelves
in place so
children may
not easily
climb inside.

4
First Steps This Owner’s Guide provides specific operating instructions for your model. Use
refrigeratoronlyasinstructedinthisOwner’sGuide. Beforestartingrefrigerator,
follow these important first steps:
Location
Installrefrigerator:
• nearagroundedelectrical outlet. DO NOT useanextensioncordoranadapter plug.
• outofdirectsunlightandawayfromrange,dishwasher,orotherheatsources,
if possible.
• onafloorthatislevelandstrongenoughtosupportafullyloadedrefrigerator.
• where a water supply is available for automatic ice maker.
Installation
• Donotinstallrefrigeratorwheretemperaturewilldropbelow60°F(15°C),orrise
above110°F(43°C). Compressorwillnotbeabletomaintainpropertemperatures.
• In a recessed installation, allow an extra 1/2 inch (10-15 mm) on each side for
ease of installation.
• If the hinge side of the unit will be placed against a wall, allow a 1-3/4 inch (44
mm) space between wall and refrigerator to permit proper door swing.
Door Opening
Forbestuseofdrawersandfreezerbasket,refrigeratorshouldbeinapositionwhere
both the refrigerator and freezer doors can be opened about 135°.
Leveling
• Refrigeratormustbeleveledwithallbottomcornersrestingfirmlyonasolidfloor.
Adjust front rollers to level cabinet both front-to-rear and side-to-side. Keep
cabinetaslowaspossibleforstability. Neveradjustcabinetrollerssofrontislower
than rear.
•Toadjustfrontrollers: Openrefrigeratorandfreezerdoors.Removetoegrille
bypullingitstraightout.Adjustrollersbyturningeachrolleradjustingboltwithan
adjustablewrench, a socketwrench, oranutdriver until refrigeratorislevel and
stable. Rear rollers are not adjustable.
• Check both doors to be sure seals touch cabinet evenly on all four sides.
• Iffreezerdoorishigherthanrefrigeratordoor,raiserightcornerand/orlowerleft
corner until doors align across top of cabinet.
• Ifrefrigeratordoorishigherthanfreezerdoor,raiseleftcornerand/orlowerright
corner until doors align across top of cabinet.
•To replace toe grille: Line up tabs with holes, and push grille straight on.
Cleaning
• Wash the inside, all removable parts, and the outside with mild detergent and
warm water. Wipe dry. Do not use harsh cleaners on these surfaces.
• Do not use razor blades or other sharp instruments that can scratch appliance
surface, when removing adhesive labels. Any glue left from the tape or energy
labelcanberemovedwithamixtureofwarmwaterandmilddetergent,ortouch
glue with sticky side of tape already removed.
•Do Not Remove Serial Plate.
ReplacingToeGrille

5
First Steps
(continued) Connecting Ice Maker to Water Supply
Do Not Install Ice Maker Tubing Where Temperature May
Fall Below Freezing.
Check to be sure your water connection will comply with local plumbing codes.
Water quality determines your ice quality. It is best to connect the ice maker to
water that is not softened. Chemicals from a malfunctioning softener can
damage the ice maker. If the ice maker is connected to soft water, ensure that
the softener is maintained and working properly.
The ice maker requires a 1/4 inch (6.4 mm) copper water supply line (with
shutoff)from your householdwater system.Allowenough tubingbehindyour
refrigeratortopermit moving out to cleanfloor.
A water line kit is available through your dealer at extra charge. This kit includes
1/4 inch diameter copper tubing, plus parts to connect to your cold water line.
You will need to purchase a 1/4 inch brass compression nut and ferrule from
yourlocal hardwareor plumbingstore.
1. Turn ON water supply and flush out copper tubing. Turn off water supply.
2. Unplugrefrigerator.
3. Install WATER SUPPLY LINE as follows (figure 2):
• Slide brass nut, then ferrule, onto copper tubing.
• Push end of copper tubing as far into the metal water valve fitting as it will
go (1/4 inch). Slide ferrule into fitting and thread brass nut onto inlet,
tightenfinger tightplus1/2 turnwith wrench.
NOTE: Some models may have a cap on the valve. Unscrew the cap and
discard.
4. Secure copper tubing with STEEL CLAMP and screw to rear panel at location
shown (Figure 3).
5. Coil water supply tubing as shown (figure 3).
NOTE: To prevent vibration noise and wear, leave a space between all
tubingand other surfaces.
6. Turn on water supply and check all connections for leaks (figure 3).
7. Plugrefrigerator cordintowall outlet.
8. To begin ice production, lower the Wire Signal Arm to the “down” or “ON”
position(Figure 4).
IMPORTANT
Ice production will begin when freezer reaches normal operating temperature.
Air in new plumbing lines may cause ice maker to cycle two or three times
before making a full tray of ice.
New plumbing may cause ice to be discolored or have poor flavor. Discard ice
made during the first 24 hours. After installation, if you wish to shut the ice
maker off, lift the Wire Signal Arm until it clicks and locks in the “UP” position.
Figure1
Figure2
Figure3
Figure4

6
• Locate the refrigerator in the coolest part of the room, out of direct sunlight and
away from heating ducts or registers. Do not place the refrigerator next to heat-
producing appliances such as a range, oven or dishwasher. If this is not possible,
asectionofcabinetryoranaddedlayerofinsulationbetweenthetwoappliances
will help the refrigerator operate more efficiently.
• Level the refrigerator so the doors close tightly.
• Refer to this Owner's Guide for the suggested refrigerator settings.
• Periodic cleaning of the condenser will help the refrigerator run more efficiently.
See Outside in the "Care and Cleaning" section.
• Do not overcrowd the refrigerator or block cold air vents. Doing so causes the
refrigeratorto runlonger anduse moreenergy. Shelvesshould not be lined with
aluminum foil, wax paper or paper toweling. Liners interfere with cold air
circulation, making the refrigerator less efficient, which could cause food
spoilage.
• Coverfoodsandwipecontainersdrybeforeplacingthemintherefrigerator.This
cuts down on moisture build-up inside the unit.
• Organize the refrigerator to reduce door openings. Remove as many items as
needed at one time and close the door as soon as possible.
Setting the Controls Cool Down Period
Toensuresafefoodstorage,allowtherefrigeratortooperatewiththedoorsclosed
for at least 8 to 12 hours before loading with food.
Refrigerator Control
• Therefrigeratorcontrolshouldbesetatthemidpoint(-)ofthedialforatrialperiod
of24hours.
• After 24 hours, adjust the control as needed. For colder temperatures, turn the
dial a notch toward COLDEST. For warmer temperatures, turn the dial a notch
toward COLD. Adjust temperatures by one increment at a time.
Freezer Control
• The freezer control should be set at the midpoint (-) of the dial for a trial period
of24hours.
• After 24 hours, adjust the control as needed. For colder temperatures, turn the
dial a notch toward COLDEST. For warmer temperatures, turn the dial a notch
toward COLD. Adjust temperatures by one increment at a time.
NOTE: Whenfirstsettingthecontrolsorwhenchangingasetting,wait24hoursfor
the temperature to stabilize before making additional changes.
Turning the freezer control may change temperatures in both compartments. For
example,ifthefreezercontrolisturned to acoldersetting,therefrigeratorcontrol
may have to be adjusted to a warmer one. Turning the refrigerator control will
changeonly therefrigerator temperature.
IMPORTANT: If the freezer control is turned to OFF, cooling stops in both
compartments.
Youmayhearthe"FrostFree"systemworking.Afancirculatesairintherefrigerator
andfreezercompartments.Forgoodcirculationandmaintenanceofpropercooling
temperatures,donot blockcoldair vents withfooditems. Water drainingintothe
defrostwaterpanandhissingsoundsarenormalduringtheautomatic"FrostFree"
cycle.
Energy Saving Ideas
G05C0090
Refrigerator Control
G05C0091
Freezer Control

7
Fresh Food Storage Shelf Adjustment
Refrigerator shelves are easily adjusted to suit individual needs. Before adjusting
shelves,removeallfood.Theshippingclipswhichstabilizetheshelvesforshipping
may be removed and discarded.
To adjust the cantilever shelves (shelves supported at the rear of the refrigerator),
liftthebackoftheshelfupandout.Replaceshelfbyinsertinghooksatrearintoslots.
Lower and lock into position. Some models have Spillfree glass shelves, which
catch and hold accidental spills.
Door Storage
Doorbinsandshelvesareprovidedforconvenientstorageofjars,bottlesandcans.
Items used often are available for quick selection.
Thedoorbinscanbemovedtosuitindividualneeds.Removebinsbyliftingstraight
up. Place bins in the desired position and lower over the supports.
The Dairy compartment is warmer than the general food storage section and is
intended for short term storage of cheese, spreads, or butter.
Crisper
TheCrisperdrawer,locatedunderthebottomrefrigeratorshelf,isforstoringfruits
andvegetables.Mostproduceshouldbewashedinclearwateranddrainedbefore
placinginthisdrawer.Itemswithstrongodorsorhighmoistureshouldbewrapped
beforestoring.
The Humidity Control (some models) allows you to adjust the humidity within the
Crisperdrawer.Thiscanextendthelifeoffreshvegetableswhichkeepbestinhigh
humidity. Leafy vegetables, however, keep best when stored with the Humidity
Control set on HIGHER, or in a drawer without a Humidity Control. This keeps
incoming air to a minimum and maintains maximum moisture content.
Meat Keeper
The Meat Keeper is located at the bottom of the refrigerator. The temperature in
thiscompartmentcanbemadecolderthantherestoftherefrigeratorcompartment
byslidingthe Chilled AirControlknob within theCOLDESTorCOLD range.Meat
willbepartiallyfrozenandmaybekeptfreshlongerthanifstoredonarefrigerator
shelf.
BeforeplacingitemsintheMeatKeeper,followthesestepstokeepthemeatfresh:
1. Carefully handle meat with clean hands and always keep the compartment
clean.
2. Store meat in its original wrapper. If necessary, overwrap in plastic wrap or foil
topreventdrying. Wrapfishtightly to preventodortransfer to otherfoods.
3. If spoilage ever occurs, disinfect the compartment with liquid chlorine bleach
followinglabel directions.Then rinsewith asolution ofbaking sodaand water.
Rinse with clear water and dry.
Freezer Basket
A slide-out wire basket (some models have two) hangs below the bottom freezer
shelf. This basket provides easy access to frozen food packages.
Tall Storage Compartment(some models)
A shelf is attached to the freezer wall just below the ice server. This allows for
convenient storage of tall items placed vertically between the ice server and the
freezer wall.
Remove Shipping Clips
Lift up
and out
Cantilever Shelf
FRESH FRUITS & VEGETABLES
LOWER
FRUITS
HIGHER
HUMIDITY CONTROL
VEGETABLES
Humidity Control
Chilled Air Control
Tall Storage
Compartment

8
Automatic Ice and
Water Dispenser The ice and water dispenser on the freezer door conveniently dispenses chilled
waterandicecubes.Tooperatethedispenser,slidetheknobtotheselectionofyour
choice and press a glass against the dispensing arm, as shown. Be sure to hold the
glassasfarupaspossibletocatchallcubes. Tostopdispensing,pullglassawayfrom
dispensing arm. Release dispensing arm before the glass is full, but do not remove
the glass until the ice has completely dispensed.
Asmallheatedareabeneaththedispenserfloorcatchesandevaporatessmallspills.
Do not pour water or excess cubes into this area because there is no drain.
Light
The dispenser has a light that can be turned on and off by sliding the knob to the
desired position. The light also turns on automatically when ice and/or water is
dispensed. Replace light bulb with an appliance bulb of the same wattage.
How the Water Dispenser Works
The water tank is located behind the drawers in the refrigerator compartment. As
thewaterisdispensed,thetankisautomaticallyrefilled.Forproperoperationofthe
dispenser, the supply water pressure must fall between 30 psi and 120 psi.
After the refrigerator is installed and the plumbing connections are complete, the
water tank should be filled by drawing one glass of water.This will take about 1-
1/2 minutes. Then, draw and discard 7 more glasses to be sure that the tank and
plumbing connections are rinsed of any impurities.
To ensure fresh-tasting water, plan to use the dispenser every day. If the water
dispenser has not been used for a week or more, draw and discard 7-8 glasses to
freshen the tank supply.
How the Ice Dispenser Works
The ice maker and ice storage bin are located in the top left corner of the freezer
compartment. After the refrigerator is installed properly and has cooled for several
hours,the ice makercan begin makingice. To beginice production, lowerthewire
signalarmtothe"down"or ONposition.Ascubesaremade,theyarestoredinthe
storagebin.Withnousageitwilltakeapproximately2daystofillthebin.However,
the dispenser may be used after the first batch of ice is made. The ice maker turns
off automatically when the ice storage bin is full.
Because of new plumbing connections, the first production of ice cubes may be
discolored or have an odd flavor. These should be discarded until the cubes made
arefreeofdiscolorationandtaste. Remember,waterqualitydetermines
your ice quality. It is best to connect the ice maker to water that is not softened.
Chemicalsfrom a malfunctioning softener can damage the ice maker. Ifice maker
isconnectedtosoftwater,ensurethesoftenerismaintainedandworkingproperly.
To stop the ice maker, lift the wire signal arm until it clicks and locks in the "up"
or OFF position.
Ice Maker
Wire
Signal Arm
Dispenser Selector
Press glass against dispensing arm.
go5c0092

9
Ice Dispenser Tips
1. Ice cubes stored too long may develop an odd flavor. Empty the container and
return it to the proper position. The ice maker will then produce more ice.
2. Occasionally shake the container to keep ice separated.
3. Ifthedispensingarmispushedinformorethan4minutes,thedispensermotor
may overload and stop. The overload protector will reset automatically after 3
or4minutes.If a large quantityoficeisneeded at onetime,itisbestto remove
cubes directly from the ice storage bin.
4. Certain sounds are normal when the ice maker is operating. They are:
• Motor operation
• Ice being loosened from the tray
• Ice dropping into the storage bin
• Running water
• Water valve opening or closing
For more information on these operations, see "Normal Operating Sounds."
5. Stop the ice maker when cleaning the freezer or for long vacations.
6. Iftheicemakeristobeturnedoffforalongperiodoftime,turnthewatersupply
valve to the closed position.
Cleaning the Ice Dispenser
Clean the dispenser and ice storage bin at regular intervals, particularly before you
take a vacation or move, or if the ice dispenser sticks.
1. Stop ice production by lifting the wire signal arm to the "up" or OFF position.
2. Remove ice storage bin by lifting up and out. Empty and carefully clean the bin
with mild detergent.Do notsubmerge thebin whilecleaning. Rinsewith clear
water. Do not use harsh or abrasive cleaners. Allow ice bin to dry completely
before replacing in the freezer.
3. Remove ice chips and clean the shelf and chute that supports the ice storage
bin.
4. Replace the ice storage bin. Lower the wire signal arm on the ice maker to the
"down" or ON position and the ice maker will resume production.
IMPORTANT: Whenremovingorreplacingtheicebin,donotrotatetheaugerin
theicebin.Iftheaugerisaccidentallyturned,youmustrealigntheaugerbyturning
it in 90° turns until the ice bin fits into place with the drive mechanism. For further
instruction, see the label on the ice bucket.
Remove and empty the ice storage bin if:
1. Anextendedpowerfailure(onehourorlonger)causesicecubesintheicestorage
bin to melt and freeze together and jam the dispenser mechanism.
2. Theicedispenserisnotusedfrequently.Icecubeswillfreezetogetherinthebin
and jam the dispenser mechanism. Remove the ice storage bin and shake to
loosen the cubes.
NEVER use an ice pick or similar sharp instrument to break up the ice. This could
damage the ice storage bin and dispenser mechanism.
Do not use the ice
chute as a handle when removing
or replacing the ice storage bin.
Surfaces there may be sharp.
WARNING
Automatic Ice and
Water Dispenser
(continued)
Repositioning the Auger
AUGER
DRIVER
MECHANISM
DO NOT PUT FINGERS UP ICE CHUTE.
SURFACES THERE MAY BE SHARP.

10
Care and Cleaning Keepyourrefrigeratorandfreezercleantopreventodorbuild-up.Wipeupanyspills
immediatelyandcleanbothsectionsatleasttwiceayear.Neverusemetallicscouring
pads, brushes,abrasivecleaners orstrongalkalinesolutions onanysurface. Donot
wash any removable parts in a dishwasher.
Always unplug the power cord from the wall outlet before cleaning.
NOTE:TurningthecontroltoOFFdoesnotdisconnectpowertothecontrols,lightbulb,
orotherelectricalcomponents.
Inside
Washinsidesurfacesoftherefrigeratorandfreezerwithasolutionof2tablespoons
baking soda in 1 quart warm water. Rinse and dry thoroughly. Be sure to wring
excesswateroutofspongeorclothbeforecleaningaroundthecontrols,light
bulb, or any electrical parts.
Washremovablepartssuchasshelvesanddrawerswithbakingsodasolutionormild
detergent and warm water. Do not use harsh cleaners on these surfaces. Rinse
anddrythoroughly.Cleanthedoorgasketswithmildsuds,rinsewithclearwaterand
wipe dry. Do not use razor blades or other sharp instruments which can scratch the
appliance surface when removing adhesive labels. Any glue left from the tape or
energy label can be removed with a mixture of warm water and mild detergent, or,
touch the glue with the sticky side of tape already removed. Do not remove the
serial plate.
Outside
Washthecabinetandhandleswithwarmwaterandmildliquiddetergent.Rinsewell
and wipe dry with a clean soft cloth. Do not use commercial household cleaners,
ammonia, or alcohol to clean handles.
Removeanydust ordirtfrom the frontofthe toe grilleusinga vacuum cleanerwith
itsdustingtoolattachment.Removethetoegrillebypullingitstraightout.Whilethe
grille is removed, vacuum the backside of the grille and wipe with a sudsy cloth or
sponge. Periodically clean the condenser (black tubes and wires beneath the
refrigerator,behindthetoegrille).Donotallowlintordusttoaccumulateonthecoils.
Insertalonghandledbrushorvacuumattachmentbetweenthetwocoilstobringthe
lintforward.Toreplace the toe grille,lineuptabswith holes andpushgrillestraight
on. Use caution when cleaning in the area of the coils. Surfaces
there may be sharp.
Theairventsontheloweraccesspanelattherearoftherefrigeratorshouldbecleaned
periodically. Clean the vents by using a vacuum cleaner with its dusting tool
attachment. When moving the refrigerator, pull straight out. Do not shift the
refrigeratorfromsidetosideas thismaytearorgougethefloorcovering.Becareful
nottomovethe refrigeratorbeyondplumbingconnections.
Damp objects stick to cold
metalsurfaces. Donottouch refrigerated
surfaces with wet or damp hands.
To avoid damage and help
the refrigerator run as efficiently as
possible, clean the condenser and air
vents periodically.
Air Vents on Lower Access Panel
Replacing the Light Bulb
To replace the light bulb in either compartment:
1. Unplugtherefrigerator.
2. Wear gloves as protection against possible broken glass.
3. Replace old bulb with an appliance bulb of the same wattage.
4. Remember to plug the refrigerator back in.
Vacation and Moving Tips
Shortvacations:
• Leave refrigerator operating during vacations of 3 weeks or less.
• Use up all perishable items in refrigerator section.
• Wrap and store other items in the freezer.
• Turn off automatic ice maker, even if you will be gone just a few days.
