Frigidaire FRT18DRH User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18DRHD0 FRT18DRH R134a System almond 115
FRT18DRHW0 FRT18DRH R134a System white 115
FRT18DRHY0 FRT18DRH R134a System almond 115
FRT18DRHZ0 FRT18DRH R134a System white 115
MARKET
North American
Publication No.
5995323671
990524
-EN/SERVICE /ECL
390
REFRIGERATOR
Model No.
FRT18DRH
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218758400
OWNER’S GUIDE - # 218942600
SERVICE DATA SHEET - # 218758400
101 MASTERS BLVD.
ANDERSON, SC 29624

05/99 2
Publication No. FRT18DRH
5995323671
DOOR

# = Fast-moving Parts 3 05/99
* = Non-Illustrated Parts
FRT18DRH Publication No.
5995323671
DOOR
A = FRT18DRH (FRT18DRHD0)
B = FRT18DRH (FRT18DRHW0)
C = FRT18DRH (FRT18DRHY0)
D = FRT18DRH (FRT18DRHZ0)
POS. NO PART NO DESCRIPTION
1 # 215608906 A - C - Gasket-frzr door,almond ,magnetic
1 # 215608916 - B - D Gasket-frzr door,white ,magnetic
2 # 218730606 A - C - Gasket-refr door,almond ,magnetic
2 # 218730605 - B - D Gasket-refr door,white ,magnetic
3 218360001 A B C D Panel-inner door,refr
4 218027022 A B C D Rack-door,23.81" x 1.62"
5 215267701 A B C D Support-door rack,"2-liter" ,RH/LH
5A 215473602 A B C D Support-door rack,RH/LH
7 218287801 A B C D Door-dairy,10.71" wide
9 218360101 A B C D Panel-inner door,frzr
10 5303001308 A - C - Plug-button,almond ,hinge brg hole
10 5308000134 - B - D Plug-button,white ,hinge brg hole
11 5303917807 A - C - Panel-frzr door,almond ,w/insulation
11 5303917805 - B - D Panel-frzr door,white ,w/insulation
12 218917602 A - C - Label-nameplate,almond
12 218917601 - B - D Label-nameplate,white
13 218800300 A B C D Door Stop,plated
13A 218249002 A - C - Door Stop,almond ,frzr section
13A 218249001 - B - D Door Stop,white ,frzr section
14 218915702 A - C - Plug-button,almond
14 218915701 - B - D Plug-button,white
15 5303917808 A - C - Panel-refr door,almond ,w/insul & brace
15 5303917806 - B - D Panel-refr door,white ,w/insul & brace
18A 218428102 A - C - Handle-door,almond ,w/block & screw
18A 218428101 - B - D Handle-door,white ,w/block & screw
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B C D Bearing-hinge
58 218699800 A B C D Screw,truss head ,8-15A x 0.500
72 218397000 A B C D Button-handle mtg,dovetail
73 218396700 A B C D Block-handle mtg,dovetail
74 215503200 A B C D Screw,cr pan hd ,10-16 x 0.500 ,spec/hi-lo
* 5303917276 A B C D Insulation-door,fiberglass ,(bulk)

05/99 4
Publication No. FRT18DRH
5995323671
CABINET

# = Fast-moving Parts 5 05/99
* = Non-Illustrated Parts
FRT18DRH Publication No.
5995323671
CABINET
A = FRT18DRH (FRT18DRHD0)
B = FRT18DRH (FRT18DRHW0)
C = FRT18DRH (FRT18DRHY0)
D = FRT18DRH (FRT18DRHZ0)
POS. NO PART NO DESCRIPTION
1 218672501 A B C D Cover-fan
2 5303307351 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 218722200 A B C D Damper-fan cover,black
5 # 218649000 A B C D Fan Blade,black
6 218448302 A - C - Cover,almond ,lwr hinge hole
6 218448301 - B - D Cover,white ,lwr hinge hole
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303205118 A B C D Bracket-motor mtg,front
10 3206451 A B C D Cover-evap coil
10* 5303209814 A B C D Nut,"U" type ,8-15(A) ,fan mtr mtg
11 5303208309 A B C D Plug-hole,factory test
12 215079000 A B C D Plug-harness hole,round
12 215079100 A B C D Plug-wtr inlet tube,round
13 # 218878701 A B C D Motor-evap fan
14 5303205119 A B C D Bracket-motor mtg,rear
17 218725700 A B C D Trough-drain
18 215245000 A B C D Support-evap cover,(2)
19 5303001198 A B C D Tube,rubber
22 215774911 A - C - Plug-button,almond ,upr hinge holes
22 215774901 - B - D Plug-button,white ,upr hinge holes
23 5303269702 A B C D Tube-drain,w/seal ring
24 5303207353 A B C D • Seal Ring,drain tube
25 215774100 A B C D Spout-drain tube,w/mounting pins
29 5308000007 A B C D Washer,.34 x .62 x .05 ,nylon
29 5308011326 A B C D Washer,.34 x .62 x .02 ,nylon
30 5304409595 A B C D Bracket-lower hinge
30* 215882300 A B C D Tapping Plate,lower hinge ,(2)
32 215217703 A - C - Plug-button,almond ,cabinet base ,(2)
32 215217701 - B - D Plug-button,white ,cabinet base ,(2)
35 218220102 A - C - Bracket-ctr hinge,almond
35 218220101 - B - D Bracket-ctr hinge,light grey
36 218251300 A B C D Pin-center hinge
37 5303321082 A - C - Trim-cabinet corner,almond
37 5303321081 - B - D Trim-cabinet corner,white
38 3206100 A B C D Bracket-upper hinge
40 3206105 A - C - Cover-upper hinge,almond
40 3206101 - B - D Cover-upper hinge,white
41 5303001609 A B C D Grommet,shelf/rod mtg ,RH
41* 5308009759 A B C D Grommet,shelf mtg ,LH
42 215880100 A B C D Screw-hinge mtg,hex wshr hd ,1/4-20 x 0.685,(2)
43 218724000 A B C D Roller Assy,front ,complete
43* 218703002 A B C D • Roller
43* 5308009790 A B C D • Spring-roller adj
43* 5308000186 A B C D • Washer,.34 x .62 x .10 ,nylon
43* 5308009761 A B C D • Bolt-roller adj
43* 3051070 A B C D Screw 10-24 X 7/16,hex washer hd ,10-24 x 7/16
44 5303283014 A B C D Roller Assy,metal housing
45 5303001343 A B C D Screw,hex wshr hd ,8-15A x .5 ,spec
56 218220300 A B C D Pin-lower hinge
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625 ,hng/mlln,thrd form
78 5308000039 A B C D Screw,hex wshr hd ,8-32CA x 0.500 ,serrated hd
81 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C D Bracket-connector
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875 ,(6)
98 215099711 A - C - Plug-button,almond
98 215099701 - B - D Plug-button,white
* 5308016571 A B C D Plug-button,cabinet liner ,icemaker holes
* 5303305325 A - C - Paint,touch-up ,almond
* 5303305324 - B - D Paint,touch-up ,white

05/99 6
Publication No. FRT18DRH
5995323671
SHELVES

# = Fast-moving Parts 7 05/99
* = Non-Illustrated Parts
FRT18DRH Publication No.
5995323671
SHELVES
A = FRT18DRH (FRT18DRHD0)
B = FRT18DRH (FRT18DRHW0)
C = FRT18DRH (FRT18DRHY0)
D = FRT18DRH (FRT18DRHZ0)
POS. NO PART NO DESCRIPTION
1 218874311 A - C - Mullion,almond
1 218874301 - B - D Mullion,white
5 # 218781003 A B C D Heater-mullion
6 218845602 A B C D Tapping Plate,mullion mtg ,(2)
7 218814800 A B C D Panel-top,refr cavity
8 218872903 A B C D Divider,styrofoam ,w/foil tape
8* # 218878500 A B C D Harness-wiring,control/divider
9 218814700 A B C D Panel-bottom,frzr cavity
10 215667501 A B C D Tray-ice,plastic
11 5303288242 A B C D Shelf-freezer,fixed/flat ,full width ,wire
11* 5303299664 A B C D Spacer-shelf
12 218730000 A B C D Deflector-air
12* 5303001449 A B C D Seal-air deflector,foam plastic ,(2)
13 218631001 A B C D Cover-air deflector
14 # 5309918806 A B C D Switch-light/lamp
15 5303001179 A B C D Light Bulb/Lamp,40 W
16A 218906801 A B C D Socket-light/lamp
17 5303321455 A B C D Control Box
18 5303311079 A B C D Knob-temp control
19 # 5303286905 A B C D Switch-energy saver,rocker type
21 # 5304404821 A B C D Control-temperature
21* 5303001260 A B C D Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B C D Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B C D Tube,PVC ,white ,@ air deflector ,insulator
23 # 215846605 A B C D Timer-defrost
23* 5303001259 A B C D Screw-timer mtg,pan hd ,6-20 x 0.438
24 5303307451 A B C D Shelf,sliding ,wire ,refr section
25 5303207340 A B C D Cover-crisper pan,with beam ,less insert
26 3206438 A B C D Pan-crisper
28 3201150 A B C D End Cap-shelf,protector ,frzr shelf
30 5303285319 A B C D Cover-meat pan
31 3206209 A B C D Pan-meat
46 5303304709 A B C D Front-crisper pan
47 5303281398 A B C D Insert-pan cover,glass
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625 ,hng/mlln,thrd form
67 5303309966 A B C D Front-meat pan
81 5303001380 A B C D Screw,truss head ,8-10 x 1.625
145 218660800 A B C D Clip,plastic ,temp sensor mtg ,snap-in

05/99 8
Publication No. FRT18DRH
5995323671
SYSTEM

# = Fast-moving Parts 9 05/99
* = Non-Illustrated Parts
FRT18DRH Publication No.
5995323671
SYSTEM
A = FRT18DRH (FRT18DRHD0)
B = FRT18DRH (FRT18DRHW0)
C = FRT18DRH (FRT18DRHY0)
D = FRT18DRH (FRT18DRHZ0)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B C D Condenser
1* 5303208866 A B C D Spacer-cond tube,black
2 5308000296 A B C D Bracket,condenser mtg ,(4)
2* 5308009617 A B C D Washer,ext tooth lock ,#10 ,grounding
4 # 218541000 A B C D Drier-filter,R134a System
5 # 218878500 A B C D Harness-wiring,control/divider
6 # 215257004 A B C D Harness-wiring,compressor
7 # 5316254901 A B C D Cord-electric power
8 5303001197 A B C D Cover-wiring
13 # 218429306 A B C D Heat Exchanger,suction line
14 # 3206453 A B C D Heater-defrost
15 # 3206452 A B C D Evaporator
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 5303207493 A B C D Insulator-evap,plastic
18 5308013648 A B C D Insulation Block,RH
19 5303007287 A B C D Insulation Plug,RH
20 5308017227 A B C D Insulation Block,LH
21 # 5316269001 A B C D Thermostat-defrost
22 218802500 A B C D Plate-compr mtg,with rail
23 218254500 A B C D Grommet-compr mtg,(4)
24 5308003633 A B C D Washer-compr mtg
25 5308003596 A B C D Clip-compressor mtg
26 215372500 A B C D Pan-defrost drain
27 5303001348 A B C D Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C D Pan Retainer Kit,Service
29 # 218846902 A B C D Compressor,R134a ,w/o electricals
30 # 218721103 A B C D Starter/Overload Assy
32 218740800 A B C D Wire-bale
41 5308000039 A B C D Screw,hex wshr hd ,8-32CA x 0.500 ,srratd head
43 5303001199 A B C D Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B C D Clamp,nylon ,.75 OD tube
45 218843800 A B C D Screw,hex wshr hd ,#8 14 x 1/2 ,wiring clamps
45 5300141713 A B C D Screw,hex wshr hd ,8-32 x .625 ,spec
45 5303001343 A B C D Screw,hex wshr hd ,8-15A x .5 ,spec
55 # 216236200 A B C D Capacitor-run,180-200 VAC ,15 microfarad
* # 3916557 A B C D Hot Tube Repair Kit,Service
