Frigidaire FFHN2750TS Owner's manual

TABLE OF CONTENTS
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352
All about the
Use &Care
of your Refrigerator
Important Safety Instructions......................2
Features at a Glance...................................4
Installation ................................................5
Door Removal Instructions ..........................8
Installing Door Handles.............................10
Connecting Water Supply..........................12
Controls...................................................14
Automatic Ice & Water Dispenser ..............22
A05947001 (October 2016)
Automatic Ice Maker - Freezer...................24
Storage Features ......................................25
Storing Food and Saving Energy................29
Normal Operating Sounds and Sights.........30
Changing the Filter...................................31
Care and Cleaning....................................34
Before you Call.........................................36
Major Appliance Warranty .........................41

WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result
in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, operation
or maintenance information which is
important but not hazard-related.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
Doors
Handles are secure and tight
Door seals completely to cabinet on all sides
Leveling
Refrigerator is level side-to-side and
slightly elevated in front to assist with
door and drawer closing (front should be
higher than back)
Toe grille is properly attached to refrigerator
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected to
refrigerator
No water leaks present at all connections
- recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser operates correctly
Final Checks
Shipping material removed
Fresh food and freezer temperatures set
Crisper humidity controls set
Registration card sent in
Installation Checklist
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.

Denitions
This is the safety alert symbol. It is
used to alert you to potential personal injury
hazards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
2
IMPORTANT SAFETY INSTRUCTIONS
For your Safety
• DO NOT store or use gasoline, or other
ammable liquids in the vicinity of this or
any other appliance. Read product labels
for warnings regarding ammability and
other hazards.
• DO NOT operate the refrigerator in the
presence of explosive fumes.
• Avoid contact with any moving parts of
automatic ice maker.
• Remove all staples from the carton. Staples
can cause severe cuts, and also destroy
nishes if they come in contact with other
appliances or furniture.
WARNING
Please read all instructions before using this
refrigerator.
Child Safety
Destroy or recycle the carton, plastic bags, and
any exterior wrapping material immediately
after the refrigerator is unpacked. Children
should NEVER use these items to play.
Cartons covered with rugs, bedspreads, plastic
sheets or stretch wrap may become airtight
chambers, and can quickly cause suffocation.
Proper Disposal of your Refrigerator
or Freezer
Risk of child entrapment
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators or freezers are still dangerous
– even if they will sit for “just a few days”. If

3
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT
CFC/HCFC Disposal
Your old refrigerator may have a cooling system
that used CFCs or HCFCs (chlorouorocarbons
or hydrochlorouorocarbons). CFCs and HCFCs
are believed to harm stratospheric ozone if
released to the atmosphere. Other refrigerants
may also cause harm to the environment if
released to the atmosphere.
If you are throwing away your old
refrigerator, make sure the refrigerant is
removed for proper disposal by a qualied
technician. If you intentionally release
refrigerant, you may be subject to nes
and imprisonment under provisions of
environmental legislation.
Electrical information
• The refrigerator must be plugged into its
own dedicated 115 Volt, 60 Hz., 15 Amp,
AC only electrical outlet. The power cord of
the appliance is equipped with a three-
prong grounding plug for your protection
against electrical shock hazards. It must be
plugged directly into a properly grounded
three prong receptacle. The receptacle
must be installed in accordance with local
codes and ordinances. Consult a qualied
electrician. Avoid connecting refrigerator to
a Ground Fault Interrupter (GFI) circuit. Do
not use an extension cord or adapter plug.
you are getting rid of your old refrigerator or
freezer, please follow the instructions below to
help prevent accidents.
Proper Disposal of Refrigerators/Freezers
We strongly encourage responsible appliance
recycling/disposal methods. Check with your utility
company or visit www.energystar.gov/recycle for
more information on recycling your old refrigerator.
Before you throw away your old
refrigerator/freezer:
• Remove doors.
• Leave shelves
in place so
children may
not easily climb
inside.
• Have refrigerant
removed by a
qualied service
technician. IMPORTANT
Pressing and holding the On/Off button for
three seconds, located on the temperature
control panel, will disable your refrigerator’s
cooling system but does not disconnect the
power to the light bulb and other electrical
components. To turn off power to your
refrigerator you must unplug the power cord
from the electrical outlet.
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden
temperature change.
• If the power cord is damaged, it should
be replaced by an authorized service
technician to prevent any risk.
• Never unplug the refrigerator by pulling on
the power cord. Always grip the plug rmly,
and pull straight out from the receptacle to
prevent damaging the power cord.
• Unplug the refrigerator before cleaning
and before replacing a light bulb to avoid
electrical shock.
• Performance may be affected if the voltage
varies by 10% or more. Operating the
refrigerator with insufcient power can
damage the compressor. Such damage is
not covered under your warranty.
• Do not plug the unit into an electrical outlet
controlled by a wall switch or pull cord to
prevent the refrigerator from being turned
off accidentally.

IMPORTANT
Features not purchased with your refrigerator can be purchased at www.frigidaire.com
or by calling 1-800-944-9044.
4
FEATURES AT A GLANCE
*Features may vary according to model
*Flip Shelf
Deli
Drawer
*Water
Filter
*Removable
Ice Bin
*Freezer Ice
Maker
Adjustable Hinges
Freezer Baskets
*Toe Grille
*Door Bin
Spillsafe®
Shelves
Flipper
Mullion
*Air
Filter
Flipper
Guide
*Fresh Food
Ice Maker
*Ice Bin
Crisper
Drawer
*Dairy
Compartment
*LED
Cluster Lights
*Slide-Under
Shelf
*Can Rack
*LED
Cluster
Light

NOTE
If your refrigerator is placed with the door
hinge side against a wall, you may have to
allow additional space so the door can be
opened wider.
5
INSTALLATION
CAUTION
Do Not install the refrigerator where the
temperature will drop below 55°F (13°C) or
rise above 110°F (43°C). The compressor
will not be able to maintain proper
temperatures inside the refrigerator.
Do Not block the toe grille on the lower front
of your refrigerator. Sufcient air circulation
is essential for the proper operation of your
refrigerator.
This Use & Care Guide provides general
installation and operating instructions for
your model. We recommend using a service
or kitchen contracting professional to install
your refrigerator. Use the refrigerator only as
instructed in this Use & Care Guide. Before
starting the refrigerator, follow these
important rst steps.
Location
• Choose a place that is near a grounded,
non-GFCI, electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the refrigerator out of
direct sunlight and away from the range,
dishwasher, or other heat sources.
• The refrigerator must be installed on a oor
that is level and strong enough to support
a fully loaded refrigerator.
• Consider water supply availability for
models equipped with an automatic ice
maker.
Installation
Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides & Top ⅜ inch (9.5 mm)
Back 1 inch (25.4 mm)
Door opening
Your refrigerator should be positioned to allow
easy access to a counter when removing
food. For best use of refrigerator drawers and
freezer baskets, the refrigerator should be in a
position where both can be fully opened.
Top Hinge
Cover Front
Screw
Top Hinge
Cover Rear
Screw
Lower
Hinge
Screw
Top
Hinge
Screw
Components Provided:
Tools Necessary:
Phillips Head
or
Quadrex Head
Screwdriver
(OR) OR
⅜" and ¼"
Socket
Wrench
Adjustable
Wrench
OR
⅜"
Fixed
Wrench
ANDAND
6mm
Allen Wrench

6
INSTALLATION
Toe Grille Must
Fit in Slot on
Anti-tip Bracket
Screw/Washer
Assembly
(2) Retaining Clips
Cabinet Leveling & Refrigerator
Door Alignment (if necessary)
Guidelines for nal positioning of your
refrigerator:
• All four corners of the cabinet must rest
rmly on the oor.
• The front should be slightly elevated to
ensure that doors close and seal properly.
• Doors should align with each other and be
level.
Most of these conditions can be met by raising
or lowering the adjustable front rollers.
To level the cabinet using the front rollers:
1 Slightly open freezer drawer if the toe grill
is installed. Lift the toe grille and gently
pull forward.
2 Make initial cabinet adjustments by using
the front roller height adjusting screws.
Use a 3/8 inch socket wrench to turn the
adjustment screws (1 per side).
To raise: turn adjustment screw clockwise.
To lower: turn adjustment screw
counterclockwise.
3 Ensure both doors are bind-free with their
seals touching the cabinet on all four sides
and that cabinet is stable.
4 After unit is leveled, lower anti-tip leg
using a 3/8 inch socket wrench until it
rmly contacts the oor.
Raise
Lower
Anti-tip
Leg
Door
Door
5 Install the toe grille by tting into place.
DO NOT
Loosen
or
Remove
These 3
Hex
Screws
CAUTION
Do Not loosen or remove these 3 hex screws.
Raise
To make nal door height adjustments:
1. Open freezer drawer to make lower hinge
visible.
2. Insert 6mm Allen wrench into the shaft of
the lower hinge.
3. Adjust the height by turning clockwise or
counterclockwise. Turning clockwise will
lower the door. Turning counterclockwise
will raise the door. Default setting is to
the lowest height when you receive your
appliance.

7
Flipper
Mullion
Screw
Flipper
Mullion
Hinge
Adjusting Flipper Mullion Screw
2 Adjust ipper mullion height. For proper
connection with the ipper mullion guide,
there should be a separation about the
thickness of a coin (0.060 inches, or
1.5 mm) between the guide and ipper
mullion.
3 Re-tighten screw.
To adjust the ipper mullion:
1 Loosen the screw located on the ipper
mullion hinge.
Flipper
Mullion
Mullion
Guide
Thickness
of a Coin
Adjusting Flipper Mullion Height
INSTALLATION

8
DOOR REMOVAL INSTRUCTIONS
2 Disconnect the harness by grasping both
sides of the connector rmly, depress the
latch, and pull apart. Remove the two
screws from the top hinge. Lift the door
off of the bottom hinge and set it aside.
3 Detach the water tube from the connector
located behind the refrigerator and pull the
tube back out to the front of the unit. The
connector releases when you press inward
on the outer sleeve while pushing the tube
toward the connector then while continuing
to hold in the sleeve, pull the tube away.
Getting through narrow spaces
If your refrigerator will not t through an
entrance area, you can remove the doors.
Check rst by measuring the entrance.
To prepare for removing the doors:
1 Make sure the electrical power cord is
unplugged from the wall outlet.
2 Open the freezer drawer and remove the
toe grille (see Installation section).
3 Remove any food from the door shelves
and close the doors.
To remove the top hinge covers:
1 Remove the two screws from each cover
over the top door hinges.
2 Lift inside edge of hinge cover and tilt back.
Rear
Cover
Screw
Ground
Screw
Top
Hinge
Top Hinge
Cover
Hinge
Screws
Multi-wire
Cables
Leave
Hinge
With
Door
Front
Cover Screw
Water
Line
Rear
Cover
Screw
Top
Hinge
Ground
Screw
Front
Cover Screw
Top Hinge
Cover
Hinge
Screws
Leave
Hinge
With
Door
To remove the refrigerator doors
1 Trace lightly around the door’s top hinges
with a pencil. This makes reinstallation easier.
NOTE
DO NOT remove the ground screw from hinge.
NOTE
Use care while pulling the water tube from the
unit to be sure that you do not kink the tube.
Press
Press
Approximately
5 feet
Water
Line

9
DOOR REMOVAL INSTRUCTIONS
Lower Hinge Removal
4 Unscrew the three lower hinge screws and
slide the hinge inwards.
CAUTION
Be sure doors are set aside in a secure position
where they cannot fall and cause personal
injury, or damage to the doors or handles.
NOTE
You will be pulling approximately ve feet of
water tube from the back of the refrigerator.
Once both doors are in place, ensure they are
aligned with each other and level (Please see
the Installation section for more details), and
replace the top hinge cover.
NOTE
When reinserting the water tube and
replacing the top hinge cover, use care to be
sure you do not kink the tube.
Press
Press
Approximately
5 feet
Water
Line
Insert tube
up to the
marking
line
NOTE
Upon replacement, the tube needs to be
fully inserted up to the marking line.
To reinstall the refrigerator doors:
Reverse the above steps.
CAUTION
Drawer is heavy. Use caution when lifting.
Remove
Hex Head
Drawer Screw
DO NOT
Remove
Other
Screws
DO NOT
Loosen
or
Remove
These 3
Hex
Screws
1 Remove 4 hex head drawer screws.
2 Lift up drawer to remove.
Removing Freezer Drawer
Re-installing Freezer Drawer
1 Lower drawer back into place.
2 Replace 4 hex head drawer screws and
tighten.

10
INSTALLING DOOR HANDLES
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
NOTE
All set screws should be tightened so the screw is below the surface of the handle. The
handles should be drawn tight to freezer and refrigerator doors with no gaps. Opening the
opposite door while tightening the Allen screw makes installation easier.
The door handle may loosen over time or if it was installed improperly. If this happens,
tighten the set screws on the handles.
Door Handle Mounting
Instructions for Frigidaire
& Frigidaire Gallery
1 Remove handles from carton
and any other protective
packaging.
2 Position fresh food handle
end caps over upper and
lower pre-installed shoulder
bolts (A) that are fastened
into door, ensuring the holes
for the set screws are facing
towards the opposite door.
3 While holding handle rmly
against door, fasten upper and
lower Allen set screws (B) with
supplied Allen wrench.
4 Repeat steps 2 and 3 to
install opposite handle.
Ensure the holes for the set
screws are facing towards the
rst door.
5 Position freezer handle end
caps over left and right pre-
installed shoulder bolts (A)
that are fastened to the door,
ensuring the holes for the set
screws are facing down.
6 While holding handle rmly
against door, loosely tighten
right Allen set screw (B) with
supplied Allen wrench until
there is no gap between
handle and door.
7 Still holding the handle rmly
to the door, rmly tighten
left Allen set screw (B) with
supplied Allen wrench.
8 Return to the right Allen set
screw (B) and rmly tighten
with supplied Allen wrench.
Mounting Freezer Handle
Mounting Refrigerator Handles
NOTE
When tightening the Allen set screws, it is imperative that
force be applied to the longer arm of the Allen wrench
supplied in the handle packaging.

11
INSTALLING DOOR HANDLES
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
Door Handle Mounting
Instructions for
Frigidaire Professional®
1Remove handles from carton and
any other protective packaging.
2Position fresh food handle end
over upper and lower pre-
installed shoulder bolts (A) that
are fastened into door, ensuring
the holes for the set screws are
facing towards the opposite door.
3 While holding handle rmly
against door, fasten further
most upper and further most
lower Allen set screws (B) with
supplied Allen wrench.
4Repeat steps 2 and 3 to install
opposite handle. Ensure the
holes for the set screws are
facing towards the rst door.
5Firmly tighten the inside Allen
set screws.
6Position freezer handle end
over left and right pre-installed
handle shoulder bolts (A)
that are fastened to the door,
ensuring the holes for the set
screws are facing down.
7 While holding handle rmly
against door, loosely tighten
far right Allen set screw (B)
with supplied Allen wrench
until there is no gap between
handle and door.
8 Still holding the handle rmly
to the door, rmly tighten far
left Allen set screw (B) with
supplied Allen wrench.
9Return to the far right Allen set
screw (B) and rmly tighten
with supplied Allen wrench.
10 Firmly tighten the inside Allen
set screws.
NOTE
All set screws should be tightened so the screw is below the surface of the handle. The
handles should be drawn tight to freezer and refrigerator doors with no gaps. Opening the
opposite door while tightening the Allen screw makes installation easier.
The door handle may loosen over time or if it was installed improperly. If this happens,
tighten the set screws on the handles.
A
B
A
B
B
A
B
A
Mounting Refrigerator Handles
Mounting Freezer Handle
NOTE
When tightening the Allen set screws, it is imperative that
force be applied to the longer arm of the Allen wrench
supplied in the handle packaging.

12
CONNECTING THE WATER SUPPLY
WARNING
To avoid electric shock, which can cause
death or severe personal injury, disconnect
the refrigerator from electrical power before
connecting a water supply line to the
refrigerator.
NOTE
Check with your local building authority
for recommendations on water lines and
associated materials prior to installing your
new refrigerator. Depending on your local/
state building codes, Frigidaire recommends
for homes with existing valves its Smart
Choice®water line kit 5305513409 with a 6 ft.
(1.8 meters) Stainless Steel Water Line, and
for homes without an existing valve Frigidaire
recommends its Smart Choice®water line kit
5305510264 with a 20 ft. (6 meters) Copper
Water Line with self-tapping saddle valve.
Please refer to www.frigidaire.com/store for
more information.
CAUTION
To Avoid Property Damage:
• Copper or Stainless Steel braided tubing
is recommended for the water supply
line. Water supply tubing made of ¼
inch plastic is not recommended to be
used. Plastic tubing greatly increases
the potential for water leaks, and the
manufacturer will not be responsible for
any damage if plastic tubing is used for
the supply line.
• DO NOT install water supply tubing in
areas where temperatures fall below
freezing.
• Chemicals from a malfunctioning water
softener can damage the ice maker. If
your home has a water softening system,
ensure the softener is maintained and
working properly.
IMPORTANT
Ensure that your water supply line
connections comply with all local plumbing
codes.
Before Installing The Water
Supply Line, You Will Need:
• Basic Tools: adjustable wrench, at-blade
screwdriver, and PhillipsTM screwdriver
• Access to a household cold water line with
water pressure between 30 and 100 psi.
• A water supply line made of ¼ inch
(6.4 mm) OD, copper or stainless steel
tubing. To determine the length of tubing
needed, measure the distance from the
ice maker inlet valve at the back of the
refrigerator to your cold water pipe. Then
add approximately 7 feet (2.1 meters),
so the refrigerator can be moved out for
cleaning (as shown).
• A shutoff valve to connect the water supply
line to your household water system. DO
NOT use a self-piercing type shutoff valve.
• Do not re-use compression tting or use
thread seal tape.
• A compression nut and ferrule (sleeve) for
connecting a copper water supply line to
the ice maker inlet valve.

13
IMPORTANT
Your refrigerator’s water supply system includes
several tubing lines, a water lter, and a water
valve. To ensure that your water dispenser
works properly, this system must be completely
lled with water when your refrigerator is rst
connected to the household water supply line.
CONNECTING THE WATER SUPPLY
To Connect Water Supply Line To
Ice Maker Inlet Valve
1 Disconnect refrigerator from electric power
source.
2 Place end of water supply line into sink or
bucket. Turn ON water supply and ush
supply line until water is clear. Turn OFF
water supply at shutoff valve.
3 Remove plastic cap from water valve inlet
and discard cap.
4 If you use copper tubing - Slide brass
compression nut, then ferrule (sleeve)
onto water supply line. Push water supply
line into water valve inlet as far as it
will go (¼ inch/6.4 mm). Slide ferrule
(sleeve) into valve inlet and nger tighten
compression nut onto valve. Tighten
another half turn with a wrench; DO NOT
over tighten. See Figure 1.
If you use braided exible stainless steel
tubing - The nut is already assembled on
the tubing. Slide nut onto valve inlet and
nger tighten nut onto valve. Tighten
another half turn with a wrench; DO NOT
over tighten. See Figure 2.
5 With steel clamp and screw, secure water
supply line to rear panel of refrigerator as
shown.
6 Coil excess water supply line (copper
tubing only), about 2½ turns, behind
refrigerator as shown and arrange coils so
they do not vibrate or wear against any
other surface. Do not kink tubing.
7 Turn ON water supply at shutoff valve and
tighten any connections that leak.
8 Reconnect refrigerator to electrical power
source.
9 To turn ice maker on, lower wire signal
arm (freezer ice maker) or set the ice
maker’s On/Off power switch to the “On”
position (fresh food ice maker).
NOTE
These instructions do not cover after market
ice maker installation. Instructions in after
market ice maker kit should be used.
Figure 1
Plastic Water
Tubing to Ice
Maker Fill
Tube
Steel
Clamp
Brass
Compression
Nut
Ferrule
(Sleeve)
Copper
water line
Water Valve
Bracket
Valve Inlet
Water Valve
Copper water line
from household
water supply
(Include enough tubing in loop to allow
moving refrigerator out for cleaning.)
Steel
Clamp
Stainless
Steel
water Line
Water Valve
Bracket
Valve Inlet
Water Valve
6 ft (1.8 Meters) Stainless Steel
water line from household
water supply
Plastic Water Tubing
to Ice Maker
Fill Tube
(Include enough tubing in loop to allow
moving refrigerator out for cleaning.)
Figure 2

14
CONTROLS
Enlarged view of user interface display menu (options may vary)
User Interface (options may vary)
FRIGIDAIRE & FRIGIDAIRE
GALLERY DISPENSER

15
options
(∧or ∨)
Used to enter and exit the
options menu and make
selections.
exit Toggles the options and run
modes.
control
locked
While in the locked state, you
will not be able to change any
settings on the display nor
dispense ice and water. The
“Control Locked” indicator will
ash and an audible warning
tone is played.
quick
freeze on
off
Activates a faster rate for
freezing food and increases
ice production in the freezer.
Deactivates after 12 hours.
ice maker
on off
Toggles the ice maker in the
refrigerator compartment
“ON” or “OFF”. In the “Off”
state, the indicator will blink
when ice is dispensed.
display
on off
Toggles the display of the
temperature settings On and Off.
refrigerator
temp
Allows the temperature set-
points to be adjusted. Control
temperatures range from
+33°F / +1°C to +47°F / +8°C.
freezer
temp
Allows the temperature set-
points to be adjusted. Control
temperatures range from -6°F
/ -21°C to +6°F / -15°C.
mode
°F °C
Toggles display from
Fahrenheit to Celsius.
light Toggles dispenser light On
and Off.
power off Press and hold for three seconds
to turn off the cooling system.
It also turns off the ice maker
and all dispenser functions. The
display will read “power off”.
water lter Displays the current status of
the water lter (Good, Order,
or Replace). To reset the lter
status to “Good”, press and hold
the “set” key for three seconds.
air lter Displays the current status of
the air lter (Good, Order, or
Replace). To reset the lter
status to “Good”, press and hold
the “set” key for three seconds.
default
settings
While in the default option,
press and hold the “set” key
for three seconds to reset all
refrigerator settings to their
factory default settings.
set (+ or -) Selects the current menu
selection option.
water Press the “water” key to
select water. An indicator
light will be illuminated
above the active feature.
cube Press the “cube” key to
select cubed ice. An indicator
light will be illuminated
above the active feature.
crush Press the “crush” key to select
crushed ice. An indicator light
will be illuminated above the
active feature.
CONTROLS
Setting cooling temperatures
(options may vary)
Options May Vary
FRIGIDAIRE & FRIGIDAIRE
GALLERY DISPENSER
NOTE
The recommended settings for a product
installed in a kitchen is 37˚F for the fresh
food compartment and 0˚F for the freezer.
IMPORTANT
If your product has food freezing in the fresh
food compartment, increase the temperature
setting 1 or 2 degrees.
IMPORTANT
If you place food within 1 inch in front of
the air ports, there may be the chance of
freezing food.
Air Port

16
CONTROLS
Alarms
Power Failure
In the event of a power failure, the power fail
alert will be illuminated. Press set to acknowl-
edge the alarm. Other modes may be turned
off until the alarm is acknowledged. While
a power fail alert is displayed on the control
panel, the unit will continue normal operation.
The power fail alert on the control panel will
be removed once in the user acknowledges
the power fail condition by pressing any key on
the control panel. The high temp alarm may
also be illuminated until a safe operating range
temperature has been reached.
Freezer Temp
If the freezer temperature reaches 26°F or
greater, the alarm will sound and the tem-
perature will ash. You can disable the alarm
by pressing the set key but the “High Temp”
indicator will illuminate until the temperature
goes below 26°F.
Fresh Food Temp
If the fresh food temperature reaches 55°F or
greater, the alarm will sound and the tem-
perature will ash. You can disable the alarm
by pressing the set key but the “High Temp”
indicator will illuminate until the temperature
goes below 55°F.
Door Ajar
If the freezer or fresh food doors have been
left open for ve minutes or more, an alarm
will sound and the door ajar indicator will
illuminate on the display. Press the set key to
reset any system alarms.
Flapper
When “Cube” or “Crush” is selected, if the ap-
per (or ice chute door) is being held open by a
jammed ice cube, an alarm will sound for two
minutes. The alarm will reset after two minutes
or when the ice cube is removed and the set
key is pressed to reset.
Sabbath Mode
The Sabbath Mode is a feature that disables
portions of the refrigerator and its controls
in accordance with observance of the weekly
Sabbath and religious holidays within the
Orthodox Jewish community.
Sabbath Mode is turned ON and OFF by
simultaneously pressing and holding both the
“∨” and “+” for ve seconds. The display shows
“Sb” while in Sabbath mode.
In the Sabbath Mode, the High Temp alarm
is active for health reasons. For example,
if the door is left ajar the High Temp alarm
is activated. The refrigerator will function
normally once the door is closed, without
any violation of the Sabbath/Holidays. The
High Temp alarm is permitted when cabinet
temperature is outside the safe zone for 20
minutes. The alarm silences itself after 10
minutes while the High Temp icon stays lit until
the Sabbath mode is exited.
For further assistance, guidelines for proper
usage and a complete list of models
with the Sabbath feature, please visit
the web at
http:\\www.star-k.org.
NOTE
While in Sabbath Mode, neither the lights,
dispenser, nor the control panel will work
until Sabbath Mode is deactivated.
Refrigerator stays in Sabbath Mode
after power failure recovery. It must be
deactivated with the buttons on the control
panel.
NOTE
Although you have entered the Sabbath
Mode, the ice maker will complete the
cycle it had already initiated. The ice cube
compartment will remain cold and new ice
cubes can be made with standard trays.
FRIGIDAIRE &
FRIGIDAIRE GALLERY
NOTE
Control features and alarms may vary by
model.

17
CONTROLS - NON-DISPENSER MODELS
Setting cooling temperatures
Press the ^or v indicator to adjust the temperature to the desired
setting.
The temperature setting will begin to blink with the rst touch. The
display will time out after 10 seconds and return to the basic display.
IMPORTANT
Pressing the system on/off icon does not turn off power to your refrigerator.
You must unplug the power cord from the wall outlet.
An indicator light will be illuminated above most active features.
Touch the icon to activate the options below.
quick freeze Activates a faster rate for freezing food.
quick ice Temporarily increases cooling for freezer to increase
the production of ice
water lter Press and hold for three seconds to reset after lter
change.
air lter Filter condition status is always displayed when door
is open. Press and hold for three seconds to reset
after lter change.
C/F Touch to toggle display from Fahrenheit to Celsius.
alert reset Tones emitted by each key press can be turned off
based on user preference. The sounds are muted
when the red indicator is lit. Warning signals will
stay active.
default
settings
Resets all refrigerator settings such as temp, temp
display and tones to their factory default settings.
power Press and hold for three seconds to turn off the
cooling system to clean the refrigerator. The digital
displays will read OFF.
NOTE
The recommended settings for a product installed in a kitchen is
37˚F for the fresh food compartment and 0˚F for the freezer.

18
CONTROLS - NON-DISPENSER MODELS
“Sabbath Mode”
The Sabbath Mode is a feature that disables
portions of the refrigerator and its controls for,
in accordance with observance of the weekly
Sabbath and religious holidays within the
Orthodox Jewish community.
Sabbath Mode is turned ON and OFF by
simultaneously pressing and holding the
freezer temp “-” and the refrigerator temp “+”
indicators for ve seconds. The display shows
“Sb” while in Sabbath mode.
In the Sabbath Mode, the High Temp alarm
is active for health reasons. For example,
if the door is left ajar the High Temp alarm
is activated. The refrigerator will function
normally once the door is closed, without
any violation of the Sabbath/Holidays. The
NOTE
During Sabbath Mode, the freezer ice maker
will continue to work and must be manually
turned off to be compliant with the Sabbath
observances.
NOTE
While in Sabbath Mode, neither the lights
nor the control panel will work until Sabbath
Mode is deactivated.
Refrigerator stays in Sabbath Mode after power
failure recovery. It must be deactivated with the
buttons on the control panel.
Alarms
Door
Ajar
If the door has been left open for an
extended period of time, an alarm will
sound and the door ajar indicator will
display on the bottom display of the
control panel. The alarm is turned off
by closing the door. The alert reset key
will blink to prompt the reset of any
active alarms. Press this key to reset
any system alarms.
High
Temp
In the event of a high temperature
condition, the temperature display
will blink and display “HI”. After 20
minutes, the alarm will sound and the
high temp indicator will be red on the
bottom of the control panel. Upon
acknowledging the alarm, the highest
temperature reached will be displayed
and the refrigerator will resume normal
operation. In case the high temp alarm
is not acknowledged at the rst alarm
sound time out, when the door is
rst opened, the alarm sound will be
repeated.
Power
Fail
In the event of a power failure, the
power fail alert will be displayed and
the temperature display will blink
until the alert reset icon is pressed,
acknowledging the alarm. Other
modes may be turned off until the
alarm is acknowledged. The power fail
alert is turned off and the refrigerator
will resume normal operation.
The high temp alarm may also be
illuminated until a safe operating range
temperature has been reached.
High Temp alarm is permitted when cabinet
temperature is outside the safe zone for 20
minutes. The alarm silences itself after 10
minutes while the High Temp icon stays lit until
the Sabbath mode is exited.
For further assistance, guidelines for proper
usage and a complete list of models
with the Sabbath feature, please visit
the web at http:\\www.star-k.org.

19
User Interface In-Door Controls (options may vary)
CONTROLS
FRIGIDAIRE
PROFESSIONAL
POWER
ON-OFF
Press and hold for three seconds
to turn off the cooling system. It
also turns off the ice maker and all
dispenser functions. The display will
read “OFF”.
DEFAULT
SETTINGS
Press and hold for three seconds to
reset all refrigerator settings to their
factory default settings.
ICE MAKER
ON-OFF
The Ice Maker is on if the LED
above the Icon is illuminated. Ice
dispensing will still function. Press
and hold the button for 3 seconds to
toggle the Ice Maker on and off.
POWERPLUS
FREEZE
Activates a faster rate for freezing
food and increases ice production
in the freezer. Deactivates after 12
hours.
AIR FILTER Displays the current status of the air
lter (GOOD, ORDER, or REPLACE).
To reset the lter status to “GOOD”,
press and hold for three seconds.
WATER FILTER Displays the current status of the
water lter (GOOD, ORDER, or
REPLACE). To reset the lter status
to “GOOD”, press and hold for three
seconds.
MUTE ALARM Tones emitted by each key press
can be turned off based on user
preference. The sounds are muted
when the red indicator is lit. Warning
signals will stay active.
REFRIGERATOR
TEMP
Allows the temperature set-
points to be adjusted. Press the
“-” or “+” indicator to adjust the
temperature to the desired setting.
Control temperatures range from
+33°F / +1°C to +47°F / +8°C.
FREEZER TEMP Allows the temperature set-
points to be adjusted. Press the
“-” or “+” indicator to adjust the
temperature to the desired setting.
Control temperatures range from
-6°F / -21°C to +6°F / -15°C.
C/F Toggles display between Clesius and
Fahrenheit.

20
CONTROLS
Alarms
Power Failure
In the event of a power failure, the power fail
alert will be illuminated. Press “mute alarm”
to acknowledge the alarm. Other modes may
be turned off until the alarm is acknowledged.
While a power failure alert is displayed on the
control panel, the unit will continue normal
operation. The power fail alert on the control
panel will be removed once the user acknowl-
edges the power fail condition by pressing any
key on the control panel. The high temp alarm
may also be illuminated until a safe operating
range temperature has been reached.
Freezer Temp
If the freezer temperature reaches 26°F or
greater, the alarm will sound and the tem-
perature will ash and the dispenser control
will display “HIGH TEMP DETECTED”. You can
disable the alarm by pressing “mute alarm” but
the “HIGH TEMP DETECTED” indicator will illu-
minate until the temperature goes below 26°F.
Fresh Food Temp
If the fresh food temperature reaches 55°F or
greater, the alarm will sound and the tem-
perature will ash and the dispenser control
will display “HIGH TEMP DETECTED”. You can
disable the alarm by pressing “mute alarm” but
the “HIGH TEMP DETECTED” indicator will illu-
minate until the temperature goes below 55°F.
Door Ajar
If the freezer or fresh food doors have been
left open for ve minutes or more, an alarm
will sound and the door ajar indicator will il-
luminate on the display. Press “mute alarm” to
reset any system alarms.
Flapper
When “CUBES” or “CRUSHED” is selected, if
the apper (or ice chute door) is being held
open by a jammed ice cube, an alarm will
sound for two minutes and the current selec-
tion will blink on the dispenser control. The
alarm will reset after two minutes or when the
ice cube is removed.
FRIGIDAIRE
PROFESSIONAL
Dispenser Controls
(options may vary)
WATER Press the “WATER” key to
select water.
CUBES Press the “CUBES” key to
select cubed ice.
CRUSHED Press the “CRUSHED” key to
select crushed ice.
light Toggles dispenser light on
and off.
