Frigidaire FRT21KG3C User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21KG3CQ2 FRT21KG3C R134a bisque 115
FRT21KG3CW1 FRT21KG3C R134a white 115
FRT21KG3CW2 FRT21KG3C R134a white 115
MARKET
North America
Publication No.
5995399267
031125
-EN/SERVICE/KHB
357
TOP MOUNT
REFRIGERATOR
Model No.
FRT21KG3C
©2003 Electrolux Home Products, Inc.
All rights reserved
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - 240379012
OWNER’S GUIDE - 1 = 240400109 & 2 = 240400110
SERVICE DATA SHEET - 240379012

11/03 2
Publication No. FRT21KG3C
5995399267
DOOR

# = Fast-moving Parts 3 11/03
* = Non-Illustrated Parts
FRT21KG3C Publication No.
5995399267
A = FRT21KG3C (FRT21KG3CQ2)
B = FRT21KG3C (FRT21KG3CW1)
C = FRT21KG3C (FRT21KG3CW2)
POS. NO PART NO DESCRIPTION
1 # 240514607 A B C Gasket,seal ,white ,frzr door ,magnetic
2 # 240514608 A B C Gasket,seal ,white ,refr door ,magnetic
4 240534901 A B C Rack-door
4B 240534701 A B C Rack-door,4B
7 240337701 A B C Door-dairy,w/o graphics ,white
8 240534801 A B C Rack-door
10 240381302 A - - Plug-button,bisque ,hinge brg hole ,(2)
10 240381301 - B C Plug-button,white ,hinge brg hole ,(2)
11 240450305 A - - Door,frzr ,bisque
11 240450301 - B C Door,frzr ,white
12 240415203 A - - Label-nameplate,bisque
12 240415201 - B C Label-nameplate,white
13 240312407 A - - Door Stop,bisque ,ref
13 240312403 - B C Door Stop,white ,ref
13A 240312408 A - - Door Stop,bisque ,frzr
13A 240312404 - B C Door Stop,white ,frzr
14 240494002 A - - Plug-button,bisque
14 240494001 - B C Plug-button,white
15 240450405 A - - Door,refr ,bisque
15 240450401 - B C Door,refr ,white
18A 218428119 A - - Handle-door,bisque ,w/block & screw
18A 218428101 - B C Handle-door,white ,w/block & screw
21 240383401 A B C Screw,truss hd quad ,#10-16 x .500
21A 240521301 A B C Screw,#10-16 x 1/2
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
22 240527101 A B C Bearing-hinge,natural color
73 218396700 A B C Block-handle mtg,dovetail
74 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
DOOR

11/03 4
Publication No. FRT21KG3C
5995399267
CABINET

# = Fast-moving Parts 5 11/03
* = Non-Illustrated Parts
FRT21KG3C Publication No.
5995399267
FRT21KG3C
A = FRT21KG3C (FRT21KG3CQ2)
B = FRT21KG3C (FRT21KG3CW1)
C = FRT21KG3C (FRT21KG3CW2)
POS. NO PART NO DESCRIPTION
1 240355402 A B C Cover-fan
2 240367001 A B C Knob-damper control
3 5303001028 A B C Nut,push-on
4 240367401 A B C Damper-fan cover
5 # 5308000010 A B C Fan Blade,red ,evaporator fan
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303292396 A B C Bracket-motor mtg,front
10 240313610 A B C Cover-evap coil,w/o light
10* 240568606 A B C Seal-coil cover
10*# 240524701 A B C Wiring Harness,freezer section
11 5303208309 A B C Plug-hole,factory test
12 240366801 A B C Plug-ice maker harness,rectangular
12A 240374401 A B C Plug-wtr inlet tube, round ,1"
13 # 240369701 A B C Motor-evap fan
13* 218931001 A B C Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C Bracket-motor mtg, rear
14* 240433201 A B C Screw, hex washer head, 8-18 x 0.375
18 240411901 A B C Support-evap cover, (2)
21C 218252200 A B C Screw, #8 truss hd ,10-32CA x 0.500
22 215774919 A - - Plug-button, bisque, upr hinge holes
22 215774901 - B C Plug-button, white, upr hinge holes
28 240335501 A B C Bolt-roller adj,hex washer head, 1/4-20 x 4.020, (2), special
30 240314004 A - - Bracket-lower hinge,bisque
30 240314002 - B C Bracket-lower hinge,white
34 240311303 A B C Washer,hinge ,nylon ,(2)
35 240313804 A - - Bracket-ctr hinge,bisque
35 240313802 - B C Bracket-ctr hinge,white
35A 240336802 A B C Spacer-hinge,center
36 240516401 A B C Pin-center hinge
37 240337604 A - - Trim-cabinet corner,bisque ,(2)
37 240337601 - B C Trim-cabinet corner,white ,(2)
38 240313701 A B C Bracket-upper hinge
40 240354403 A - - Cover-upper hinge,bisque
40 240354401 - B C Cover-upper hinge,white
41 5303001609 A B C Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C Grommet,shelf mtg ,1.25" ,LH
42 240578901 A B C Screw-hinge mtg,hex head ,1/4-20 x 5/8
43 240335003 A B C Roller Assy,front ,(2)
56 240516501 A B C Pin-lower hinge
58 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
59 240442704 A - - Screw-#10-32 X 3/4,bisque
59 240442702 - B C Screw-#10-32 X 3/4,white
72 240368206 A - - Grille/Kickplate,bisque
72 240368205 - B C Grille/Kickplate,white
81 5308016566 A B C Screw,hex washer head ,8-15A x 0.625, low profile
82 5304418225 A B C Roller,compressor base ,rear ,(2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326115 A B C Cover-access,with label
92 216850900 A B C Screw,hex washer hd ,1/4 x 7/8, hinge mtg
* 218990901 A B C Clip-wire
* 240479601 A B C Plug,button ,cab liner holes ,(2)
* 5304414035 A - - Paint,touch-up ,bisque
* 5303305324 - B C Paint,touch-up ,white
CABINET

11/03 6
Publication No. FRT21KG3C
5995399267
SHELVES
25 47
26
26
N05SAAADF11
23
21
22A
13
12
14
18
17
15
16
81
81
41
29
40
24A
42
31
42
123
41
29
40
24
10
10
11

# = Fast-moving Parts 7 11/03
* = Non-Illustrated Parts
FRT21KG3C Publication No.
5995399267
A = FRT21KG3C (FRT21KG3CQ2)
B = FRT21KG3C (FRT21KG3CW1)
C = FRT21KG3C (FRT21KG3CW2)
POS. NO PART NO DESCRIPTION
10 215667501 A B C Tray,ice cube ,plastic
11 240358003 A B C Shelf,freezer ,full-width ,wire
11* 5303299664 A B C Spacer,shelf
12 240545901 A B C Diffuser-air,top
13 240362601 A B C Diffuser,air ,bottom
14 # 240505801 A B C Switch,light/lamp
15 240436702 A B C Light Bulb, A-15, clear, 40 W, 120 V, miniature
16 241500701 A B C Socket-light/lamp
17 240368101 A B C Control Box
17*# 240388701 A B C Wiring Harness,control box
18 240360801 A B C Knob,temp control
21 # 5304421256 A B C Control,temperature
22A 5303916855 A B C Tube,sensor sleeve ,plastic ,clear
23 # 215846606 A B C Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min
23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240372407 A B C Frame-shelf, sliding, full width
24A 240372408 A B C Frame-shelf, sliding, full width, w/hanger tabs
25 240364756 A B C Cover-crisper pan
26 240343801 A B C Pan-crisper,(2)
29 240357704 A B C Trim-shelf,front
31 240530901 A B C Pan-meat
40 240443310 A B C Glass-shelf,full shelf
41 240561502 A B C Trim-shelf,rear
42 240530601 A B C Track,meat pan hanger ,LH
42 240530701 A B C Track,meat pan hanger ,RH
47 240350609 A B C Insert-pan cover,glass
81 5308016566 A B C Screw,hex washer head, 8-15A x 0.625, low profile
123 215005100 A B C Screw,hanger/rlr mtg ,8-10 x 0.438
* 3205266 A B C Edge Protector,wiring harness
SHELVES

11/03 8
Publication No. FRT21KG3C
5995399267
SYSTEM

# = Fast-moving Parts 9 11/03
* = Non-Illustrated Parts
FRT21KG3C Publication No.
5995399267
A = FRT21KG3C (FRT21KG3CQ2)
B = FRT21KG3C (FRT21KG3CW1)
C = FRT21KG3C (FRT21KG3CW2)
POS. NO PART NO DESCRIPTION
1 # 240444401 A B C Condenser,dynamic
4 # 218944001 A B C Drier-filter,R134a System
6 # 240581701 A B C Harness-wiring,machine compt
6* # 240388701 A B C Wiring Harness,control box
6* # 240524701 A B C Wiring Harness,freezer section
6* # 240581801 A B C Harness-wiring,compressor
14 # 5303918247 A B C Defrost Heater Kit
15 # 5303918274 A B C Evaporator Kit
16 5308000110 A B C Strap-evap/heater,aluminum ,(2)
17 240434004 A B C Trough-drain
20 240518402 A B C Insulation,evap block ,foam ,LH/RH
21 # 5303918202 A B C Thermostat-defrost,kit
22 240330001 A B C Plate-compr mtg
22* 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B C Grommet-compr mtg,(4)
25 240491501 A B C Screw-compressor mtg,1/4-28 x 1.16, shoulder,typ CF
26 240332602 A B C Pan-defrost drain
29 # 5303918297 A B C Compressor,w/electricals
30 # 5304433579 A B C Relay
31 # 5304433578 A B C Overload Protector
34 240405201 A B C Grommet,rubber ,black ,cond tube/wire
41 240555001 A B C Screw-#8-32 X 3/8
44 215174700 A B C Clamp-service cord, strain relief, galv steel
45 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
56 240582001 A B C Cover-terminal
57 240542601 A B C Clip-wiring harness
58 215004600 A B C Screw,hx serr wshr hd ,8-36 x 7/16, cond fan motor, (2)
59 240315501 A B C Shroud-cond fan
59* 240346701 A B C Tape-foam seal,shroud
59* 240359401 A B C Screw-fan shroud,(2)
59A 240346501 A B C Bracket-support,cond mtr ,(3)
59B 240346601 A B C Grommet-bracket,(3)
60 # 240334001 A B C Motor,condenser fan
61 # 240315401 A B C Fan Blade,galv steel ,condenser fan
61A 215004700 A B C Nut,speed
61B 215004800 A B C Grommet-silencer
82 5304418225 A B C Roller,compressor base ,rear ,(2)
83 5303316859 A B C Rivet,flat head ,1/4 OD x 1-3/4, roller pin
84 240500801 - B - Tube-drain,rubber ,lower
85 240493101 A B C Tube-connector,suction
86 240409302 A B C Spacer-cond tube,black
* # 5303918210 A B C Heat Exchanger Kit,suction line
* # 5304421289 A B C Hot Tube Repair Kit,Service
SYSTEM

11/03 10
Publication No. FRT21KG3C
5995399267
WIRING SCHEMATIC

# = Fast-moving Parts 11 11/03
* = Non-Illustrated Parts
FRT21KG3C Publication No.
5995399267
WIRING DIAGRAM
