Frigidaire FFHT10F2LW Installation instructions

10 Cu. Ft. Top Mount
Signature Features
frigidaire.com
SpaceWise® Adjustable
Wire Shelves
Easily adjust shelves up and down to
create more space for taller items.
Store-More™ Freezer
Easy-to-access freezer includes a shelf
and door rack.
Store-More™ Clear
Crisper Drawers
Keep your fruits and vegetables fresh
in our crisper drawers.
Store-More™ Door Bins
Door bins provide ample storage.
Product Dimensions
A – Height 59-3/4"
B – Width 23-3/4"
C – Depth (Including Door) 26-3/4"
D – Depth with Door Opened 90° 48-1/32"
More Easy-To-Use Features
Ready-Select® Controls
Store-More™ Built-In
Can Dispenser
Convenient in-door can storage.
Bright Lighting
Our bright lighting makes it easy to see
what’s inside.
Square Door Design
Color-Coordinated Door Handle
(Recessed)
Color-Coordinated Smooth
Cabinet Finish
Color-Coordinated Door
Hinge Covers
Reversible Door-Swing Option
Door can be installed to open left or right
based on your needs.
ENERGY STAR®
Available in:
White
(W)
Apartment Refrigerator
FFHT10F2L W

Specifications
subject to change.
Product Dimensions
A - Height
B - Width
C - Depth (Incl. Door)
D - Depth with Door Open 90˚
NOTE: For planning purposes only. Always consult local and national
electric codes. Refer to Product Installation Guide for detailed
installation instructions on the web at frigidaire.com.
Accessories information available
on the web at frigidaire.com
Apartment Refrigerator (No Handle)
Frigidaire Baseline
A
D
CB
WALL
Minimum
clearances
required around
unit for adequate
air circulation:
Back - 2"
Sides - 1"
Above - 12"
Apartment Refrigerator (No Handle)
Frigidaire Baseline
A
D
CB
WALL
Minimum
clearances
required around
unit for adequate
air circulation:
Back - 2"
Sides - 1"
Above - 12"
Features
Cubic Feet (Cu. Ft.)
Exterior
Door Color
Cabinet Color
Door Handle
Door Stops
Reversible Door
Interior
Controls
Lighting
Refrigerator Shelves
Store-More™ Crisper Drawers
Door Bins
Door Racks
Tall Bottle Storage
Can Rack
Freezer Racks
Freezer Shelves
Cabinet Liner
Certifications
ENERGY STAR®
Specifications
Total Capacity (Cu. Ft.)
Refrigerator Capacity (Cu. Ft.)
Freezer Capacity (Cu. Ft.)
Power Supply Connection Location
Voltage Rating
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Installation Type
59-3/4"
23-3/4"
26-3/4"
48-1/32"
10
Color-Coordinated
Color-Coordinated
Integrated
Yes
Yes
Ready-Select®
Bright LED
2 SpaceWise®
Adjustable Wire
2 Clear
1 Full-Width Clear
3 Half-Width Clear
Yes
Yes
3-Can Capacity
2 Full-Width Clear
1 SpaceWise®
Adjustable Wire
White
Yes
10
7.09
2.88
Right Bottom Rear
120V / 60Hz / 15 or 20A
15
154 Lbs.
Freestanding
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFHT10F2L 07/11 © 2011 Electrolux Home Products, Inc. Printed in the U.S.A.
Apartment Refrigerator
FFHT10F2L W 10 Cu. Ft.

Specifications
subject to change.
Apartment Refrigerator - 10 Cu. Ft.
Baseline (Model FFHT10F2L)
Apartment Refrigerator Specifications
•Product Shipping Weight (approx.) – 154 Lbs.
•Voltage Rating – 120V / 60 Hz / 15 or 20 Amps
•Always consult local and national electric codes.
•For adequate air circulation, allow 2" minimum clearance at rear,
1" on sides and 12" on top.
•Locate where surrounding air temperature will not exceed 110° F or
drop below 10° F, to ensure optimum performance.
•All bottom corners of unit MUST rest firmly on solid level surface
of hard material, same height as flooring. Surface must be strong
and stable enough to support unit when fully loaded.
•Equipped with adjustable leveling legs to ensure unit is level,
which is required in order to function properly.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at frigidaire.com for detailed instructions.
