Frigidaire FRS20ZGJ User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRS20ZGJB0 FRS20ZGJ R134a System black 115
FRS20ZGJD0 FRS20ZGJ R134a almond 115
FRS20ZGJW0 FRS20ZGJ R134a System white 115
MARKET
North America
Publication No.
5995334553
000310
-EN/SERVICE /DJH
357
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS20ZGJ
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
SIDE BY SIDE
REFRIGERATOR
WIRING DIAGRAM - # 218903201
OWNER’S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909500
101 Masters Blvd.
Anderson, SC 29624

03/00 2
Publication No. FRS20ZGJ
5995334553
FREEZER DOOR

# = Fast-moving Parts 3 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
FREEZER DOOR
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
1 # 215734311 A B - Gasket-frzr door,white ,magnetic
1 # 215734321 - - C Gasket-frzr door,black ,magnetic
5 5303288950 A B C Support-door rack,RH/LH
6 5303323484 A B C Support-door rack,white ,LH
6A 5303323485 A B C Support-door rack,white ,RH
8 218807017 A B C Rack-door,w/end caps
8A 215474047 A B C Rack-door
9 218748601 A B C Panel-inner door,frzr
11 5303917896 A - - Panel-frzr door,white ,w/foam insulatn
11 5303917897 - B - Panel-frzr door,almond ,w/foam insulatn
11 5303917898 - - C Panel-frzr door,black ,w/foam insulatn
13 5303289522 A B C Door Stop
18 218025201 A - - Handle-door,white ,soft grip
18 218025204 - B - Handle-door,almond ,soft grip
18 218025205 - - C Handle-door,metallic gray ,soft grip
21 218886801 A B C Screw-8-32 X 1/2 #10 Truss ca,8 32 x 1/2 #10
21A 218578600 A B C Screw-door stop mtg,phl truss hd ,10-16 x 3/4
22A 215615300 A B C Bushing-door,bronze
23 5303001020 A B C Screw,cr flat head ,8-32D x 1/2
23* 215598900 A B C Washer-flat,.691x1x.05,zinc ,I&W hinge brkt
37 215867064 A - - Trim-handle,white ,upper ,w/dec gold band,and snap lock
37 215867065 - B - Trim-handle,almd ,upper ,w/dec gold band,and snap lock
37 218811610 - - C Trim-handle,metl gray ,w/dec gold band,& snap-on lock
37A 215867061 A - - Trim-handle,white ,low ,w/dec gold band,and snap locks
37A 215867062 - B - Trim-handle,almd ,low ,w/dec gold band,and snap locks
37A 218811609 - - C Trim-handle,metl gray ,w/dec gold band,& snap-on lock
37A* 215782300 A B C Lock-handle trim,snap-in
37A* 215940700 A B C Lock-handle trim,stick-on
37A* 218676003 A B C Band-decorative,gold
47 218922901 A B C Wiring Harness,frzr door
58 218781100 A B C Screw,pan head ,8-18 x 0.625
68 218020600 A B C Chute-ice
140 218922801 A B C Elbow-water tube
141 218929601 A B C Tool-Push Connector
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)

03/00 4
Publication No. FRS20ZGJ
5995334553
REFRIGERATOR DOOR

# = Fast-moving Parts 5 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
2 # 215734312 A B - Gasket-refr door,white ,magnetic
2 # 215734322 - - C Gasket-refr door,black ,magnetic
3 218749301 A B C Panel-inner door,refr
4 218807016 A B C Rack-door,(2)
5 5303288950 A B C Support-door rack,RH/LH
7 5303308347 A B C Door-dairy,12.96" wide
12 218364004 A - - Frame-nameplate,white
12 218364005 - B - Frame-nameplate,almond
12 218364006 - - C Frame-nameplate,black
12* 215008604 A - - Label-nameplate,white
12* 215008605 - B - Label-nameplate,almond
12* 215008606 - - C Label-nameplate,black
12* 5315340712 A B C Tape,adhesive ,12" long ,foam ,double-faced
13 5303289522 A B C Door Stop
15 5303917893 A - - Panel-refr door,white ,w/foam insulatn
15 5303917894 - B - Panel-refr door,almond ,w/foam insulatn
15 5303917895 - - C Panel-refr door,black ,w/foam insulatn
18 218025201 A - - Handle-door,white ,soft grip
18 218025204 - B - Handle-door,almond ,soft grip
18 218025205 - - C Handle-door,metallic gray ,soft grip
21 218886801 A B C Screw-8-32 X 1/2 #10 Truss ca,8 32 x 1/2 #10
21A 218578600 A B C Screw-door stop mtg,phl truss hd ,10-16 x 3/4
22 5303289320 A B C Bearing-hinge
26 215817806 A B C Tray-egg
37 215867064 A - - Trim-handle,white ,upper ,w/dec gold band,and snap lock
37 215867065 - B - Trim-handle,almd ,upper ,w/dec gold band,and snap lock
37 218811610 - - C Trim-handle,metl gray ,w/dec gold band,& snap-on lock
37A 215867061 A - - Trim-handle,white ,low ,w/dec gold band,and snap locks
37A 215867062 - B - Trim-handle,almd ,lower ,w/dec gold band,and snap locks
37A 218811609 - - C Trim-handle,metl gray ,w/dec gold band,& snap-on lock
37A* 215782300 A B C Lock-handle trim,snap-in
37A* 215940700 A B C Lock-handle trim,stick-on
37A* 218676003 A B C Band-decorative,gold
49 218592305 A B C Bin-door,gallon ,with trim
58 218781100 A B C Screw,pan head ,8-18 x 0.625
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)
REFRIGERATOR DOOR

03/00 6
Publication No. FRS20ZGJ
5995334553
CABINET

# = Fast-moving Parts 7 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
10 218748901 A B C Cover-air duct
10* 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg
10A 218751301 A B C Cover-evap coil,lower
11 5303208309 A B C Plug-hole,factory test
12 215230400 A B C Plug-harness hole
18 5303289043 A B C Support-air duct cvr,2.55" long
18* 5303289044 A B C Support-air duct cvr,1.83" long
28 5303289062 A B C Bolt-roller adj,hex head ,5/16-24 x 7/8
29 215003200 A B C Washer,.40 x .63 x .16 ,nylon
29* 215314301 A B C Washer,.40 x .75 x .06 ,nylon
29* 218871201 A B C Washer,nylon ,0.363 ID w/nibs
30 5303289060 A B C Bracket-lower hinge,RH/LH ,w/hinge pin
30* 218730800 A B C Tapping Plate,RH
30A 215009000 A B C Bracket-lower hinge,LH ,w/hinge pin
30A* 218730700 A B C Tapping Plate,LH
37 5303321081 A - - Trim-cabinet corner,white
37 5303321082 - B - Trim-cabinet corner,almond
37 5303321083 - - C Trim-cabinet corner,black
38 218215241 A - - Bracket-upper hinge,with closer ,white
38 218215243 A - - Bracket-upper hinge,with closer ,white ,LH
38 218215249 - B - Bracket-upper hinge,with closer ,almond
38 218215251 - B - Bracket-upper hinge,with closer ,almond
38 218215242 - - C Bracket-upper hinge,with closer ,black ,RH
38 218215244 - - C Bracket-upper hinge,with closer ,black ,LH
40 5303318773 A - - Cover-upper hinge,white
40 5303318774 - B - Cover-upper hinge,almond
40 5303323268 - - C Cover-upper hinge,black
41 5303001609 A B C Grommet,shelf/rod mtg ,RH
41* 5308009759 A B C Grommet,shelf mtg ,LH
43 218615300 A B C Roller Assy,front ,(2)
43* 5308017044 A B C Screw-roller mtg,spcl ind hex hd ,5/16-18(23)x7/8
44 218738300 A B C Roller Assy,rear ,(2)
47 218659500 A B C Channel-shelf mtg,side ,(2)
52 215454600 A B C Tube-water,ice mold fill ,elbow
58 5308002748 A B C Screw,hex wshr hd ,8-15A x 0.500 ,special
66 215050201 A B C Damper-meat keeper
66A 218171301 A B C Cover-meat kpr dmpr
71 218515401 A B C Clip-grille
72 218359613 A - - Grille/Kickplate,white
72 218359614 - B - Grille/Kickplate,almond
72 218359615 - - C Grille/Kickplate,black
77 5303001216 A B C Washer-nylon,3/16 x 5/8 OD
78 5303274237 A B C Screw-bracket,hex wshr hd ,8-32CA x 0.500
78* 5308009617 A B C Washer,ext tooth lock ,#10 ,grounding
80 218249802 A B C Seal-coil cover,(2)
80* 218154003 A B C Gasket-air duct cvr
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
85 218922701 A - - Cover-lower hinge,white
85 218922703 - B - Cover-lower hinge,almond
85 218922705 - - C Cover-lower hinge,black
89 215741407 A B C Cover-machine compt,w/caution label
90 215022602 A B C Seal-foam
90* 5303322647 A B C Tape-foam
91 218964701 A B C Deflector-air,air duct cover
92 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875
101 215305701 A B C Seal-foam
* 5303305324 A - - Paint,touch-up ,white
* 5303305325 - B - Paint,touch-up ,almond
* 5303305345 - - C Paint,touch-up ,black
* 5308016571 A B C Plug-button,cab liner holes
CABINET

03/00 8
Publication No. FRS20ZGJ
5995334553
SHELVES

# = Fast-moving Parts 9 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
2 5303300707 A B C Trim-basket
11 218298005 A B C Shelf-freezer,sliding ,wire
11B 5304405990 A B C Shelf-freezer,fixed wire
11* 218159700 A B C Spacer-shelf
24 218746001 A B C Shelf-"Spill-Safe",sliding ,(3)
25A 218015301 A B C Trim-storage pan cvr,snap-on ,front
25C 218015401 A B C Trim-storage pan cvr,snap-on ,rear
26 5303306579 A B C Pan-storage,upper
26A 5303288968 A B C Pan-storage,lower
28 08013638 A B C End Cap-shelf,protector ,lower fzr shelf
39 215217562 A B C Trim-frzr shelf
39A 215217563 A B C Trim-frzr shelf
46 218278301 A B C Front-storage pan,upper
46A 218278302 A B C Front-storage pan,lower
47 218498118 A B C Insert-pan cover,glass ,w/graphics
47A 215723551 A B C Insert-pan cover,14.61" x 17.32" ,glass
49 5303288957 A B C Basket-sliding
51 5303288960 A B C Hanger-basket,RH
52 215162501 A B C Hanger-basket,LH,with/spring
57 5303271653 A B C Ferrule-inner
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
96 215192600 A B C Support-water tank
97 218942701 A B C Water Tank
100A 218015501 A B C Support-pan cover,LH
100B 218015601 A B C Support-pan cover,RH
101 215005000 A B C Screw,hex wshr hd ,8-18AB x 0.750 ,gusset/hanger
126 218867401 A B C Channel,auger mtg ,LH
126 218867402 A B C Channel,auger mtg ,RH
* 215328300 A B C Clip-shelf
* 5303001038 A B C Washer,.28 x .62 x .19 ,nylon
SHELVES

03/00 10
Publication No. FRS20ZGJ
5995334553
CONTROLS

# = Fast-moving Parts 11 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
2 5303307883 A B C Knob-damper control,white/teal line
5 # 5308000010 A B C Fan Blade,red
7 5308000124 A B C Ring-fan orifice
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303205118 A B C Bracket-motor mtg,front
12 215809600 A B C Diffuser-air
13 # 215426200 A B C Motor-evap fan
13* 215474201 A B C Washer,"slinger" ,nylon ,evap fan shaft
14 5303205119 A B C Bracket-motor mtg,rear
15 5303001179 A B C Light Bulb/Lamp,40 W
16 5303289050 A B C Socket-light/lamp
17 218468702 A B C Control Box,refr ,w/light tunnel
17A 5303321928 A B C Control Box,frzr
18 5303307882 A B C Knob-temp control
20 5303321927 A B C Label-control box,refr
20A 5303322426 A B C Label-control box,frzr
21 # 5303300027 A B C Control-temperature
22 5303319683 A B C Housing-temp sensor,plastic
22* 218731102 A B C Tube,insulator ,PVC ,white ,on temp sensor
23 # 215846602 A B C Timer-defrost,60 Hz ,120 V ,8 hour/30 min
23* 215277000 A B C Cover-defrost timer,top
23* 5303001259 A B C Screw-timer mtg,pan hd ,6-20 x 0.438
23* 5303289058 A B C Shield-defrost timr,btm
41 5308000039 A B C Screw,hex washer head ,8-32CA x 0.500 ,serrated head
41* 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg
53 215809511 A B C Box-damper control
65 5303001361 A B C Pin-mounting,push-in ,plastic
75 218465101 A B C Shield-light,refr
76 218225800 A B C Cover-light socket
78 5303274237 A B C Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C Bracket-connector
111 5303289024 A B C Wireway,frzr
114# 5303289051 A B C Switch-light/lamp,white
115 215011503 A B C Damper Assy,w/seal
116 215011400 A B C Seal-damper,foam
125 215334201 A B C Switch-auger kill,white
137 218904602 A B C Filter-water,carbon ,with o’ ring
138 218893301 A B C Cup-water filter
139 218893201 A B C Housing-wtr filter
140 218518700 A B C Elbow-water tube
141 218832401 A B C Valve-water,dual solenoid ,115 V ,w/nut
141* 215290100 A B C Screw-solenoid valve,hx hd-slot wshr ,12-24 x 3/4
142 218657701 A B C Knob-indicator,filter replment
143 218696700 A B C Heater-water filter
143* 218646000 A B C Wiring Harness,filter heater
CONTROLS

03/00 12
Publication No. FRS20ZGJ
5995334553
SYSTEM

# = Fast-moving Parts 13 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
1 218787700 A B C Condenser
1* 5303208866 A B C Spacer-cond tube,black
1* 5303289026 A B C Spacer-tube
1* 5304406721 A B C Spacer-cond tube,round ,5/8 OD x .81"lg
2 5303289029 A B C Clip-cond mtg,(4)
3 218679603 A B C Block-evap coil,styrofoam ,(2)
4# 218944001 A B C Drier-filter,R134a System
5# 218959901 A B C Wiring Harness,main
5* 215005200 A B C Wiring Harness,refr controls
5* 218646000 A B C Wiring Harness,filter heater
5* 218815101 A B C Wiring Harness,frzr controls
6 # 218960301 A B C Wiring Harness,machine compt
7 # 215459201 A B C Cord-electric power
8 218803400 A B C Cover-wiring
13 # 215006701 A B C Heat Exchanger,suction line
14 # 218169801 A B C Heater-defrost
15 # 218691302 A B C Evaporator,R134a System
15* 3206414 A B C Tube-inlet
16 5308000110 A B C Strap-evap/heater,aluminum ,(2)
17 5303289042 A B C Insulator-evap
19 218631200 A B C Tube,rubber
21 # 218969901 A B C Thermostat-defrost
22 218811100 A B C Base-compressor mtg,(drain pan)
23 218513300 A B C Grommet-compr mtg,(4)
25 218773500 A B C Screw-compressor mtg,hex washer head ,10Bx11/4
29 # 218894801 A B C Compressor,R134a ,w/o electricals
30 # 218721105 A B C Starter-PTC
32 218888601 A B C Clamp,elec cont mtg ,compressor
41 5308000039 A B C Screw,hex washer head ,8-32CA x 0.500 ,srratd head
43 215174700 A B C Clamp-service cord,strain relief ,galv steel
43* 5308000133 A B C Clamp,nylon ,.625 ID
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
45* 5300141713 A B C Screw,hex wshr hd ,8-32 x 0.625 ,spec
49 215506900 A B C Bracket-evap mtg
54 5303289027 A B C Rail-cabinet base,rear
54A 5303289311 A B C Rail-compr support
54B 5303289292 A B C Rail-cabinet base,front
55 # 218909902 A B C Capacitor-run,180 VAC ,20 microfarad
56 218769300 A B C Insert-compressor mtg
57 218247300 A B C Clip-wiring harness
58 215004600 A B C Screw-cond fan mtr,hx serr wshr hd ,8-36 x 7/16,(2)
59 5303289031 A B C Shroud-cond fan mtr
60 # 215501901 A B C Motor-condenser fan
61 5303289032 A B C Blade-cond fan
61* 215004700 A B C Nut,speed
61* 215004800 A B C Grommet-silencer
62 215048201 A B C Trough-drain,w/shield assy ,& #17 insulator
64 5303289063 A B C Tube-drain
65 5303289301 A B C Spacer-tube
70 5303289041 A B C Bracket-evap/cvr mtg
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
* 5303917166 A B C Hot Tube Repair Kit,Service
SYSTEM

03/00 14
Publication No. FRS20ZGJ
5995334553
DISPENSER

# = Fast-moving Parts 15 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
1 5318582501 A B C Tube-water inlet,93" ,plastic ,cut-to-size
1* 218832302 A B C Tube-water inlet,inlet valve ,to filter
1* 218859901 A B C Tube-water inlet,inlet valve ,to filter
1* 218949201 A B C Tube-water inlet,formed ,plastic ,dispenser
2 218505301 A - - Deflector-ice disp,white
2 218505302 - B - Deflector-ice disp,almond
2 218505303 - - C Deflector-ice disp,black
3 # 215484300 A B C Heater-door housing
4 218852401 A - - Housing-dispenser,white
4 218852402 - B - Housing-dispenser,almond
4 218852403 - - C Housing-dispenser,black
7 218284800 A B C Switch-actuator,micro
8 218874901 A B C Module-dispenser
10 218209800 A B C Spring,dispenser door
14 218903704 A - - Label-module cover,white
14 218903705 - B - Label-module cover,almond
14 218903706 - - C Label-module cover,black
15 218284900 A B C Light Bulb/Lamp,4 W ,115 V
16 215284900 A B C Socket-light/lamp
17 215794400 A B C Screw,#6 x 1/4
17A 215840700 A B C Screw,truss head ,6-20 x 3/8
17A* 215923400 A B C Washer-flat
23 5303297844 A - - Drip Tray,white
23 5303297845 - B - Drip Tray,almond
23 5303299660 - - C Drip Tray,black
24 218921301 A - - Actuator,white
24 218921302 - B - Actuator,almond
24 218921303 - - C Actuator,black
26 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
28 218891401 A - - Cover-selector,white
28 218891402 - B - Cover-selector,almond
28 218891403 - - C Cover-selector,black
30 215753600 A B C Door Assy-ice chute,w/gasket,insul
33 218870201 A B C Heater-disp throat
35 218740004 A B C Heat Motor,115 V
36 218891301 A B C Cover-module
38 # 218906601 A B C PC Board-power
38C 218881801 A B C PC Board-control
39 218284600 A B C Wire-ice door
40 218284500 A B C Yoke-heat motor
41 215917800 A B C Spring-actuator
43 215760300 A B C Screw,#4 x 3/8
49 215794000 A B C Bracket-heat motor
56 218434300 A B C Screw-micro switch,pan head ,4-24 x 9/16
82 215296300 A B C Screw,plask h/l ,#6 x 3/8
83 5304412136 A B C Fuse,7A ,125v
* 5308010366 A B C Tube-water inlet,0.25 OD x 93" ,plastic
DISPENSER

03/00 16
Publication No. FRS20ZGJ
5995334553
ICE CONTAINER

# = Fast-moving Parts 17 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
2 5304404344 A B C Auger-ice
3 5304404343 A B C Cam-drive
4 218815300 A B C Container-ice
6 5304404346 A B C Drum-ice disp
7 218815400 A B C Front-ice container
10 5304404337 A B C Bar-drive
13 5304404359 A B C Gate
15 5303001179 A B C Light Bulb/Lamp,40 W
16 5303289050 A B C Socket-light/lamp
17 5304404345 A B C Drive Blade
18 # 5304404330 A B C Motor-auger
18* 5304404335 A B C Wiring Harness,auger motor
20 5304404332 A B C Cover-motor
21 215285100 A B C Nut-drive
23 5304404347 A B C Plate-front
25 5304404362 A B C Screw,hex washer head ,8-32T x 0.375
26 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
33 5304404351 A B C Spacer
34 5304404349 A B C Spacer
35A 5304404353 A B C Fixed Blade,round
35B 5304404352 A B C Fixed Blade,square
37A 5304404348 A B C Blade-crusher,#1
37B 5304404350 A B C Blade-crusher,#2
37C 5304404356 A B C Blade-crusher,#3
39 5304404365 A B C Screw
41 5304404358 A B C Housing-crusher
44 218359200 A B C Screw,pan head ,8-32 x 0.250
45 # 5304404333 A B C Solenoid Assy
45A 5304406816 A B C Spring-solenoid
45B 5304406817 A B C E-Ring-solenoid
45C 5304406818 A B C Actuator-solenoid
45D 5304406819 A B C Solenoid
46 5304404341 A B C Control Rod
47 5304404342 A B C Spring-control rod
48 5304404340 A B C Bracket-control rod
48* 5304404364 A B C Screw-bracket
49 5304404329 A B C Rail Assy
50 5304404334 A B C Guide-solenoid
51 5304404336 A B C Rotation Stop
52 5304404354 A B C Spacer-fixed blades
53 5304404355 A B C Pin-spiral,fixed blades
54 5304404357 A B C Nut-auger
55 5304404360 A B C Washer
56 5304404361 A B C E-ring
57 5304404363 A B C Door-access
58 5304404331 A B C Screw-solenoid
* 218842802 A B C Ice Container Assy
ICE CONTAINER

03/00 18
Publication No. FRS20ZGJ
5995334553
ICE MAKER

# = Fast-moving Parts 19 03/00
* = Non-Illustrated Parts
FRS20ZGJ Publication No.
5995334553
A = FRS20ZGJ (FRS20ZGJW0)
B = FRS20ZGJ (FRS20ZGJD0)
C = FRS20ZGJ (FRS20ZGJB0)
POS. NO PART NO DESCRIPTION
1 5308010366 A B C Tube-water inlet,0.25 OD x 93" ,plastic
1* 218832302 A B C Tube-water inlet,inlet valve ,to filter
1* 218859901 A B C Tube-water inlet,inlet valve ,to filter
1* 218949201 A B C Tube-water inlet,formed ,plastic ,dispenser
2 3206348 A B C Spring,shut-off arm
3 3206299 A B C Label,ID plate
4 3206301 A B C Gear
5 3206303 A B C Plate-mounting
6 3206305 A B C Screw-ground wire,8-32 x 0.250
7 # 3206306 A B C Motor-ice maker
8 3206312 A B C Spacer-hold switch
9 3206313 A B C Cam
10 3206315 A B C Clamp
11 # 3206319 A B C Thermal Cutoff,ice maker ,complete assy
12 # 3206349 A B C Wiring Harness,ice maker ,internal ,with plug
12*# 3206321 A B C * Connector Plug,wiring harness
13 # 3206322 A B C Thermostat Assy,ice maker
15 # 3206324 A B C Switch,(3)
16 3206326 A B C Support,phenolic
17 # 5303320545 A B C Mold-ice maker,Radius Cube ,with heater
18 3206328 A B C Ejector-ice
19 3206330 A B C Bearing & Inlet
20 5304408581 A B C Screw,8-32 x 0.375
21 3206332 A B C Ice Stripper
22 3206333 A B C Shut-off Arm
23 5304408582 A B C Screw,8-32 x 0.875 ,mold-to-support ,(3)
24 3206335 A B C Lever Arm
25 3206336 A B C Screw,8-18 x 0.562 ,lever arm/sprt
26 3206337 A B C Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B C Screw,4-40 x 1.000 ,hold switch mtg ,(2)
28 3206339 A B C Screw-timing stop,4-40 x 0.375
29 3206323 A B C Screw,4-24 x 0.750 ,(6)
30 3206341 A B C Screw-timing adj,8-32 x 1.000
31 3206342 A B C Insulator
32 3206343 A B C Plate-valve switch
33 3206344 A B C Spring
33 5304408583 A B C Spring-timing adj
34 5304408584 A B C Screw,plascrew ,#6 ,(3)
35 5304408585 A B C Screw
36 3206347 A B C Cover-ice maker
44 5308000133 A B C Clamp,nylon ,.625 ID
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
46 5303001193 A B C Clamp,.50 ID ,steel ,water tube
51 215811600 A B C Tube-water,ice mold fill ,extension
55 # 218859701 A B C Valve-water,single solenoid ,115 V ,w/nut
55* 218873001 A B C Cap-water valve
59 5303001191 A B C Sleeve-tube insert
60 5303207328 A B C Screw,hex washer head ,8-15A x 1.000 ,(2)
61 218721500 A B C Bracket-leveling,ice maker
62 218737900 A B C Screw-IM brkt mtg,hex washer head ,8-32D x 0.375
64 5303001549 A B C Clamp,0.31 ID ,steel ,copper wtr line
141 218832401 A B C Valve-water,dual solenoid ,115 V ,w/nut
141* 215290100 A B C Screw-solenoid valve,hx hd-slot wshr ,12-24 x 3/4
* 218699501 A B C Ice Maker,Radius Cube ,115 V ,no instl parts
ICE MAKER

03/00 20
Publication No. FRS20ZGJ
5995334553
WIRING SCHEMATIC
