Frigidaire FFTR1835VW Owner's manual

Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352
use &care
REFRIGERATOR
A13110304 (October 2019)
Introduction.......................................................2
Important Safety information.....................3
Features (Frigidaire)......................................5
Features (Frigidaire Gallery/Professional)... 7
Installation .........................................................8
Door Removal.................................................10
Door Handle Installation (some models).. 13
Water Supply Connection.......................... 16
Ice Maker .......................................................... 18
Controls and Settings ................................. 19
Storage Features.......................................... 22
Normal Operating Sounds........................ 24
Filter replacement........................................ 25
Care and Cleaning ....................................... 26
Troubleshooting .......................................... 28
Limited Warranty ......................................... 29

2INTRODUCTION
Doors
Handles are secure and tight
(some models)
Refrigerator door seals completely
to cabinet on all sides
Freezer door is level from side to
side across the top
Leveling
Refrigerator is level side-to-side and
tilted ¼" (6 mm) front-to-back
Cabinet is set solid on all corners
Anti-tip bracket set in front (both sides)
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker (some models)
House water supply connected
to refrigerator
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Final Checks
Shipping material removed
Refrigerator and freezer tempera-
tures set to recommended setting
Crisper humidity controls set
Registration card sent in
Installation Checklist

Welcome to our family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at www.frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it ocial! Be sure to register
your product.
Keep your product info here so it’s easy
to find.
Model Number ____________________
Serial Number ____________________
Purchase Date ____________________
FPO
Serial location
Serial Number Location
Serial Plate

3
WARNING
WARNING indicates a potentially haz-
ardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently haz-
ardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially haz-
ardous situation which, if not avoided,
may result in minor or moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
Safety Instructions
• DO NOT store or use gasoline, or
other flammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regarding
flammability and other hazards.
• DO NOT operate the refrigerator in
the presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts, and also
destroy finishes if they come in contact
with other appliances or furniture.
WARNING
Please read all instructions before using
this appliance.
Child Safety
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after you unpack the
refrigerator. Children should NEVER use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause suocation.
IMPORTANT SAFETY INFORMATION
WARNING
WARNING! CALIFORNIA RESIDENTS
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
DANGER
DANGER Risk of fire or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigera-
tor. Do not puncture refrigerant tubing.
DANGER Risk of fire or explosion.
Flammable refrigerant used. To be re-
paired only by trained service person-
nel. Do not puncture refrigerant tubing.
CAUTION
CAUTION Risk of fire or explosion.
Flammable refrigerant used. Consult
repair manual/owner’s guide before
attempting to service this product. All
safety precautions must be followed.
CAUTION Risk of fire or explosion.
Dispose of property in accordance with
federal or local regulations. Flammable
refrigerant used.
CAUTION Risk of fire or explosion
due to puncture of refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.

4IMPORTANT SAFETY INFORMATION
Proper Disposal of your Appliance
Risk of child entrapment
Child entrapment and suocation are not
problems of the past. Junked or aban-
doned appliances are still dangerous –
even if they will sit for “just a few days”. If
you are getting rid of your old unit, please
follow the instructions below to help pre-
vent accidents.
We strongly encourage responsible appli-
ance recycling/disposal methods. Check
with your utility company or visit www.
energystar.gov/recycle for more informa-
tion on recycling your old appliance.
Before you throw
away your old unit:
• Remove doors.
• Leave shelves in
place so children
may not easily
climb inside.
• Have refrigerant re-
moved by a qualified service technician.
WARNING
Follow these guidelines to ensure
safety mechanisms in this appliance will
operate properly.
Electrical information
• Plug the unit into its own dedi-
cated 115 Volt, 60 Hz., 15 Amp, AC
only electrical outlet. The power
cord of the appliance is equipped
with a 3-prong grounding plug for
your protection against electrical
shock hazards. Plug it directly into a
properly grounded 3-prong recep-
tacle. You must install the recepta-
cle in accordance with local codes
and ordinances. Consult a qualified
electrician. Avoid connecting the unit
to a Ground Fault Interrupter (GFI)
circuit. Do not use an extension cord
or adapter plug.
• If the power cord is damaged, an
authorized service technician should
replace it to prevent any risk.
• Never unplug the refrigerator by pull-
ing on the power cord. Always grip
the plug firmly, and pull it straight
out from the receptacle to prevent
damaging the power cord.
• Unplug the appliance before clean-
ing and before replacing the AC LED
light bulb to avoid electrical shock.
Use only a 5-watt or less AC LED
light bulb.
• Performance may be aected if the
voltage varies by 10% or more. Oper-
ating the refrigerator with insucient
power can damage the compressor.
Such damage is not covered under
your warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or
pull cord to prevent the unit from
being turned o accidentally.
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
IMPORTANT
Turning the Refrigerator controls to
“OFF” will disable your refrigerator’s
cooling system, but does not disconnect
the power to the light bulb and other
electrical components. To turn o power
to your refrigerator you must unplug the
power cord from the electrical outlet.
IMPORTANT
CFC/HCFC Disposal
Your old refrigerator may have a cooling
system that used CFCs or HCFCs (chlo-
rofluorocarbons or hydrochlorofluoro-
carbons). CFCs and HCFCs are believed
to harm stratospheric ozone if released
to the atmosphere. Other refrigerants
may also cause harm to the environment
if released to the atmosphere.
If you are throwing away your old refrig-
erator, make sure the refrigerant is re-
moved for proper disposal by a qualified
technician. If you intentionally release
refrigerant, you may be subject to fines
and imprisonment under provisions of
environmental legislation.

5
FEATURES (FRIGIDAIRE)
*Features may vary according to model
A
B
C
D
E
F
G
H
I
J
J
ACrisper Drawers
BCrisper Cover
CDeli Drawer*
DFull Shelves
ERefrigerator Control
FFreezer Shelf
GIce Bucket*
HFreezer Control
IIce Maker*
JFixed Door Bins
IMPORTANT
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in
Canada) or from an authorized seller.

6FEATURES (FRIGIDAIRE)
*Features may vary according to model
A
B
C
D
E
F
G
H
I
J
J
ACrisper Drawers
BCrisper Cover
CDeli Drawer*
DFull Shelves
ERefrigerator Control
FFreezer Shelf
GIce Bucket*
HFreezer Control
IIce Maker*
JFixed Door Bins
IMPORTANT
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in
Canada) or from an authorized seller.

7
FEATURES (FRIGIDAIRE GALLERY/PROFESSIONAL)
*Features may vary according to model
ACrisper Drawers
BCrisper Cover
CAuto Humidity Control Membrane
DFull Width Deli Drawer
EFull Shelves
FRefrigerator Control
GFreezer Shelf
HIce Bucket*
IFreezer Control
JIce Maker*
KFixed Door Bins
LAdjustable Door Bins
IMPORTANT
Accessories are available for your appliance and may be purchased at
Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in
Canada) or from an authorized seller.
A
B
D
E
F
G
H
K
Temp Recommended
Cold Coldest
Replace
Holdto Reset
Air
Filter
L
I
J
C

8INSTALLATION
IMPORTANT
Cleaning your Refrigerator
Remove tape and glue residue from
surfaces before turning the refriger-
ator on. Rub a small amount of liquid
dish soap over the adhesive with your
fingers. Rinse with warm water and dry
with a soft cloth.
Do not use sharp instruments, rubbing
alcohol, flammable fluids, or abrasive
cleaners to remove tape or glue. These
products can damage the surface of
your refrigerator.
After you remove all of the package ma-
terials, clean the inside of your refriger-
ator before using it. See the CARE AND
CLEANING section in this manual.
IMPORTANT
Moving your Refrigerator
Your refrigerator is heavy. When moving
the refrigerator for cleaning or service,
raise the anti-tip bracket (see “Setting
the Anti-tip Brackets”). Also be sure to
cover the floor with cardboard or hard-
board to avoid floor damage. Always
pull the refrigerator straight out when
moving it. Do not wiggle or “walk” the
refrigerator when trying to move it as
you could damage the floor.
NOTE
If your refrigerator is placed with the
door hinge side against a wall, you may
have to allow additional space for the
handle so the door can be opened wider.
This Use & Care Guide provides general
operating instructions for your model.
Use the appliance only as instructed in
this Use & Care Guide. Before starting the
unit, follow these important first steps.
Installation
Installation clearances
• Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides & Top ⅜"
Back 1"
CAUTION
Do not block the lower front of your
refrigerator. Sucient air circulation is
essential for the proper operation of
your refrigerator.
Location
• Choose a place that is near a ground-
ed electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the refrigerator out of
direct sunlight and away from the range,
dishwasher or other heat sources.
• The refrigerator must be installed on
a floor that is level and strong enough
to support a fully loaded refrigerator.
• Consider water supply availability for
Guidelines for final positioning of
your refrigerator:
• All 4 corners of the cabinet must rest
firmly on the floor.
• The cabinet should be level at the
front and rear.
• The sides should tilt ¼" (6 mm) from
front to back (to ensure that doors
close and seal properly).
• Doors should align with each other
and be level.
models equipped with an automat-
ic ice maker. If you do not hook up
water to the refrigerator, remember
to turn the ice maker o.
CAUTION
Do not install the refrigerator where the
temperature will drop below 50°F (10°C)
or rise above 110°F (43°C). The compres-
sor will not be able to maintain proper
temperatures inside the refrigerator.
Do not block the toe grille on the lower
front of your refrigerator. Sucient air
circulation is essential for the proper
operation of your refrigerator.

9
INSTALLATION
Setting the Anti-tip Brackets
The anti-tip brackets are located on the
lower front corners of the cabinet. Lower
the anti-tip brackets on each side clock-
wise until they contact the floor. Do not
raise the cabinet.
Lower
Anti-Tip Bracket
AVERTISSEMENT
The anti-tip bracket must
be installed according to
the instructions in your
Use & Care Manual. Failure
to do so will result in injury.

10 DOOR REMOVAL
NOTE
The direction in which your refriger-
ator doors open (door swing) can be
reversed, from left to right or right to
left, by moving the door hinges from
one side to the other. Reversing the
door swing should be performed by a
qualified person.
IMPORTANT
Before you begin, turn the refrigerator tem-
perature control to OFF and remove the
electrical power cord from the wall outlet.
Remove any food from door shelves.
or
or
Tools Necessary:
Socket
Wrench Set Adjustable
Wrench
5/16"
(8mm)
Fixed
Wrench
Pan Head
Quadrex
MSX12
Top Hinge
Screw
MSX16
Quadrex
Center
Hinge
Phillips™
Head and
Flat Head
Screwdriver
Hammer
Door Removal/Reversal
(some models)
1. Unplug
your refrig-
erator.
2. Remove the
top hinge
cover (some
models--see
Figure 1A).
For models
without the
hinge cover,
go to step 3.
CAUTION
Be sure the doors are set aside in a
secure position where they cannot fall
and cause personal injury.
3. Using a 5/16 in. socket, loosen the
3 screws from the top hinge (see
Figure 2).
Figure 1
A
B
Figure 2
4. Carefully open the freezer door. Lift
the loosened the top hinge and lift
the door o of center hinge pin. Set
the door aside.
NOTE
* We do not recommend to using an
electric tool to unscrew and screw parts
because it may damage the screw threads
or cause screw heads to be stripped o.
However, if you have an electric tool with
torque control, the torque cannot be larg-
er than 6 N·m (53 in.lb).
NOTE
Keep the screws so they can be used
on the opposite side.

11
DOOR REMOVAL
Hinge
Pin
Center
Hinge
Screws
Hinge
Hole
Plug
Figure 3
Figure 4
Door
Stopper
Door
Stopper
Screw
Bottom Hinge
Pin
Figure 5
Figure 6
Door Bearing Reversal For
Freezer and Refrigerator Doors
1. With a flathead screwdriver, pry out
the center hinge bearing from the
top of the refrigerator door (see
Figure 7A).
2. With a flathead screwdriver, pry out
the center hinge bearing plug from
the opposite side of the refrigerator
door (see Figure 7B).
5. Unscrew the center hinge pin using
an adjustable wrench and set it
aside (see Figure 3).
6. Open the refrigerator door and lift
the door o of the bottom hinge pin.
Set the door aside.
7. Remove the 3 center hinge screws
using a Phillips screwdriver and set
the center hinge aside (see Figure 3).
8. Remove the 3 pan head screws on
the opposite side of the center hinge
(Figure 4) and install them in the holes
where the center hinge was attached.
9. Remove both lower hinge covers.
10. Remove the screw from the door
stopper with a Phillips screwdriver
(see Figure 5).
11. Unscrew the bottom hinge pin from
the right-hand position using an ad-
justable wrench (see Figure 5).
12. Install the bottom hinge pin in the
left-hand hole of the left-hand lower
hinge (see Figure 6).
13. Flip the door stopper. Reinstall the
door stopper on top of the bottom
hinge with the screw (see Figure 6).
3. Install the hinge bearing on the
opposite side by tapping it with a
hammer until it is flush with the end
cap. Repeat the process for the plug.
4. Reverse the door handle (see
DOOR HANDLE INSTALLATION
section if applicable).
5. Flip the refrigerator door over and
remove the screw from the door
closer using a Phillips screwdriver
and set it aside (see Figure 8A).
6. Pry out the hinge bearing from the
door with a straight screwdriver (see
Figure 8B).
Figure 7
A
B
IMPORTANT
Place the door on a padded surface to
avoid damage.

12 DOOR REMOVAL
Door Bottom
AB
C
Door Closer
Figure 8
Figure 11
7. Install the bottom hinge bearing on
the opposite side of the door (see
Figure 8C).
8. Flip the door closer over and install
on the opposite side of the door
(see Figure 8C).
11. Screw in and tighten the center hinge
pin using an adjustable wrench.
12. Lower the freezer door in the opened
position over the center hinge pin
and close the door (see Figure 10).
Place the lower hinge cover between
the freezer door and refrigerator
door to keep it level while attaching
the top hinge (see Figure 11).
Figure 12
13. Attach the top hinge using a 5/16 in.
socket, and then place the top hinge
cover (some models) on the unit
(see Figure 12).
Figure 13
14. For models without the hinge cover,
flip the hinge cover over and attach it
using a 5/16 in. socket (see Figure 13).
9. Repeat steps 1-8 for the freezer door.
10. Lower the refrigerator door in the
opened position on the bottom
hinge pin and close the door (see
Figure 9).
1
2
Figure 9
1
2
Figure 10
15. Replace the lower hinge covers.

13
DOOR HANDLE INSTALLATION (SOME MODELS)
To attach the metal refrigerator handle
(Stainless steel, Black Stainless steel,
Stainless Steel EZCare):
1. Place the rounded part of the handle
onto the shoulder screw on the face
of the door and align the 2 holes in
top of handle with the 2 holes in top
of the door. Do not tighten the set
screw yet.
2. Install the 2 screws into the top of
the handle.
3. Tighten the set screw on the rounded
part of the handle until the handle
is flush with the door; then tighten
another ½turn.
Screw
Handle
Button
Plug
Set
Screw
Shoulder
Screw
Shoulder
Screw
Nameplate
Handle
Set Screw
Screw
Rounded Doors
To attach the metal freezer handle
(Stainless steel, Black Stainless steel,
Stainless Steel EZCare):
1. Place the rounded part of the handle
onto the shoulder screw on the face
of the door and align the 2 holes in
bottom of handle with the 2 holes in
bottom of door. Do not tighten the
set screw yet.
2. Install the 2 screws into the bottom
of the handle.
3. Tighten the set screw on the
rounded part of the handle until the
handle is flush with the door; then
tighten another ½ turn.
Flat Doors

14 DOOR HANDLE INSTALLATION (SOME MODELS)
To attach the plastic refrigerator handle
(Smooth white/black):
1. With the door open, place the
end of the handle on the dove tail
mounting screw and pull it down to
secure it in place.
2. Align the handle base with the holes
in top of the door.
3. Install screws packaged with
the handle.
CAUTION
Do not use an electric screwdriver to attach the handles; overtightening the handles
may crack them. Use a handheld screwdriver only.
To attach the plastic freezer handle
(Smooth white/black):
1. With the door open, place the
end of the handle on the dove tail
mounting screw and push it up to
secure it in place.
2. Align the handle base with holes in
the bottom of the door.
3. Install screws packaged with
the handle.
Handle
Screws
Handle Base Mounting Screw
Handle Base
Screws
Handle

15
DOOR HANDLE INSTALLATION (SOME MODELS)
To reverse the door handles:
2. Remove
the name
plate on the
freezer door.
3. Remove the
shoulder
screw on
the opposite
side of the
freezer door
and install
the shoulder
screw where
the name
plate was
removed
using an adjustable wrench or
Phillips head screwdriver.
4. Install the
name plate
on the
opposite
side of the
freezer door.
CAUTION
Be sure the doors are set aside in a
secure position where they cannot fall
and cause personal injury.
The handles may be easier to reverse
while the doors are o.
1. Unscrew
and remove
the handles
5. Remove the
button plugs
from the
front and
top of the
refrigerator
door.
6. Remove the
shoulder
screw on
the left side,
and install
the shoulder
screw on
the opposite
side of the
door using an adjustable wrench or
Phillips head screwdriver.
7. Install the
button
plugs on the
opposite side
of the front
and top of the
refrigerator
door
8. Reverse and
attach the
freezer and
refrigerator
handles as
shown.

16 WATER SUPPLY CONNECTION
WARNING
To avoid electric shock, which can cause
death or severe personal injury, dis-
connect the refrigerator from electrical
power before connecting a water supply
line to the refrigerator.
CAUTION
To Avoid Property Damage:
• Use stainless steel braided tubing
for the water supply line. Do not
use water supply tubing made of
¼in. plastic. Plastic tubing greatly
increases the potential for water
leaks, and the manufacturer will not
be responsible for any damage if you
use plastic tubing for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
softener can damage the ice maker.
If the ice maker is connected to soft
water, ensure that the softener is
maintained and working properly.
IMPORTANT
Ensure that your water supply line connec-
tions comply with all local plumbing codes.
NOTE
Check with your local building authority
for recommendations on water lines and
associated materials prior to installing
your new refrigerator. Depending on
your local/state building codes, Frigid-
aire recommends for homes with exist-
ing valves its Smart Choice®water line
kit 5304437642 (with a 6 ft. Stainless
Steel Water Line) and for homes without
an existing valve, Frigidaire recom-
mends its Smart Choice®water line kit
5304493869 (with a 6’ Polyline Water-
line). Please refer to www.frigidaire.com
for more information.
Before Installing The Water Supply Line,
You Will Need:
• Basic Tools: adjustable wrench, flat-blade
screwdriver, and Phillips screwdriver
• Access to a household cold water line
with water pressure between 30 and
100 psi.
• A water supply line made of stainless
steel tubing. To determine the length
of tubing needed, measure the dis-
tance from the ice maker inlet valve
at the back of the refrigerator to your
cold water pipe, so the refrigerator
can be moved out for cleaning.
• A shuto valve to connect the water
supply line to your household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fitting or
use thread seal tape.
Ice Maker Models Only
NOTE
Automatic ice makers are optional acces-
sories that you may install in most models
at any time. Visit www.frigidaire.com for
information about Ice Maker Kit 117000.

17
To Connect the Water Supply Line To the
Ice Maker Inlet Valve
1. Disconnect the refrigerator from the
electrical power source.
2. Place the end of water supply line
into a sink or bucket. Turn ON the
water supply and flush the supply
line until the water is clear. Turn OFF
the water supply at the shuto valve.
3. Remove the plastic cap from the wa-
ter valve inlet and discard the cap.
4. If you use copper tubing, slide brass
compression nut, and then the fer-
rule (sleeve) onto the water supply
line. Push the water supply line into
the water valve inlet as far as it will
go (¼" / 6.4 mm). Slide the ferrule
(sleeve) into valve inlet and finger
tighten the compression nut onto
the valve. Tighten another ½ turn
with a wrench; DO NOT overtighten.
See below.
If you use braided flexible stain-
less steel tubing, the nut is already
assembled on the tubing. Slide the
nut onto the valve inlet and finger
tighten the nut onto valve. Tighten
another ½turn with a wrench; DO
NOT overtighten. See below.
5. With the steel clamp and screw,
secure the water supply line (copper
tubing only) to the rear panel of
refrigerator as shown.
6. Coil the excess water supply line
(copper tubing only), about 2½
turns, behind the refrigerator as
shown and arrange the coils so they
do not vibrate or wear against any
other surface.
7. To turn the ice maker on, press the
ice maker’s On/O power switch so
the LED is illuminated.
Plastic Water
Tubing to Ice
Maker Fill Tube
Brass
Compression
Nut
Ferrule
Sleeve
Copper
Line
Water
Valve
Bracket
Water
Valve Inlet
Water
Valve
Copper water line
from household water supply
Clamp
(Include enough tubing in loop to allow
moving refrigerator out for cleaning.)
Units with copper tubing
service
mode
8. Turn ON the water supply at the
shuto valve and tighten any con-
nections that leak.
9. Reconnect the refrigerator to the
electrical power source.
Brass
Compression
Nut
Water Line
Water Valve
Bracket
Valve Inlet
Water Valve
6 ft minimum (1.8 m)
braided flexible stainless steel
water line from household water supply
Plastic Water
Tubing to Ice
Maker Fill Tube
(Include enough tubing in to allow
moving refrigerator out for cleaning.)
Units with braided flexible
stainless steel tubing
WATER SUPPLY CONNECTION

18
IMPORTANT
The ice maker is shipped in the On posi-
tion. To ensure proper function for your
ice maker, hook up the water supply
immediately or turn the ice maker O. If
the ice maker is on and the water supply
is not connected, the water valve will
make a loud chattering noise.
ICE PRODUCTION: WHAT
TO EXPECT
The ice maker will produce 2 to 2.5
pounds of ice every 24 hours depending
on usage conditions. Ice is produced at a
rate of 10 cubes every 100 to 160 minutes.
CAUTION
Do Not place the ice container in
your dishwasher.
ICE MAKER
If your refrigerator has an automatic ice
maker, it will produce minimal ice during
the first 24 hours of operation. Air in new
plumbing lines may cause the ice maker to
cycle 2 or 3 times before making a full tray
of ice. With no usage, it will take approxi-
mately 1 to 2 days to fill the ice container.
New plumbing connections may cause
the first production of ice cubes to be
discolored or have an odd flavor. Discard
ice made during the first 24 hours.
Turning your Ice Maker On
After completely connecting the
plumbing, you must open the water
supply valve. Place the ice container
under the ice maker, pushing it as far back
as possible. Press the ice maker’s On/O
button.
Turning your Ice Maker O
To stop the ice maker, press the ice
maker’s On/O button. The ice maker
regulates the ice production and stops
making ice when full and starts again
when ice is low in the ice container.
NOTE
Automatic ice makers are optional acces-
sories that you may install in most models
at any time. Visit www.frigidaire.com for
information about Ice Maker Kit 117000.

19
CONTROLS AND SETTINGS
NOTE
When first turning the refrigerator on, adjust the control to Recommended. After 24
hours, adjust the controls as needed.
IMPORTANT
Adjusting the refrigerator temperature
control to OFF turns o the compressor
and prevents the refrigerator from cool-
ing, but does not disconnect the power
to the light bulb and other electrical
components. To turn o power to your
refrigerator, you must unplug the power
cord from the wall outlet.
NOTE
If your unit is in a garage or area where
the temperature is below 50° F, adjust
the freezer control to the coldest setting
to improve performance.
Cool Down Period
To ensure safe food storage, allow the refrigerator to operate with the doors closed
for at least 8 hours before loading it with food.
Temperature Adjustment
Adjust the temperature gradually: adjust the knob in small increments, allowing the
temperature to stabilize.
• For colder temperatures, adjust the control toward Coldest.
• For warmer temperatures, adjust the control toward Cold.
Adjusting the refrigerator control will change temperatures in both compartments. The
freezer control can be left at the factory preset (*Recommended) or adjusted as desired.
To maintain temperature, a fan circulates air in the refrigerator and freezer
compartments. For good circulation, do not block cold air vents with food items.
Frigidaire
Freezer Control
Refrigerator Controls
All Models

20
Frigidaire Gallery and Professional
CONTROLS AND SETTINGS
Temperature Adjustment
Adjust the temperature gradually: adjust in small increments, allowing the
temperature to stabilize.
• For colder temperatures, press the Temp button to change the temperature
setting toward Coldest.
• For warmer temperatures, press the Temp button to change the temperature
setting toward Cold.
Air Filter
The filter status light on the control panel will prompt you to replace the filter after 6
months. After replacing the air filter, the air filter status on the control panel should be
reset. To reset, Press and hold for 3 seconds.
Door Alarm
If the door is left open for 5 or more minutes, the door alarm will sound. Clear the
alarm by closing the door or by pressing any button.
NOTE
Pressing the Temp button will scroll through the 5 temperature settings toward the
coldest setting, and then loop back to the least coldest setting.
Adjusting the refrigerator control will change temperature in both compartments. The
freezer control can be left at the factory preset (*Recommended) or adjusted as desired.
To maintain temperatures, a fan circulates air in the refrigerator and freezer
compartments. For good circulation, do not block cold air vents with food items.
Cold
Colder 1
Recommended
Colder 2
Coldest
