Frigidaire FRT15B1B User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT15B1BW1 FRT15B3A R134a white 115
MARKET
North America
Publication No.
5995398244
031104
-EN/SERVICE/KHB
390
©2003 Electrolux Home Products, Inc.
All rights reserved
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917

11/03 2
Publication No. FRT15B1BW1
5995398244
DOOR

# = Fast-moving Parts 3 11/03
* = Non-Illustrated Parts
FRT15B1BW1 Publication No.
5995398244
POS. NO PART NO DESCRIPTION
1 # 240554101 Gasket-frzr door,white ,magnetic
2 # 240542102 Gasket,refr door seal ,white ,magnetic
4A 240535301 Rack-door
4B 240535201 Rack-door
8 240535001 Rack-door
10 240381301 Plug-button,white ,hinge brg hole ,(2)
11 240415401 Door,frzr ,white
12 240415201 Label-nameplate,white
13 240312403 Door Stop,white ,ref
13A 240312404 Door Stop,white ,frzr
14 240494001 Plug-button,white
15 240415501 Door,refr ,white
18A 218428101 Handle-door,white ,w/block & screw
21 240383401 Screw,truss hd quad ,#10-16 x .500
21A 240521301 Screw,#10-16 x 1/2
21C 218252200 Screw,#8 truss hd ,10-32CA x 0.500
22 240527101 Bearing-hinge,natural color
73 218396700 Block-handle mtg,dovetail
74 215503200 Screw,cr pan hd ,10-16 x 0.500
DOOR

11/03 4
Publication No. FRT15B1BW1
5995398244
CABINET

# = Fast-moving Parts 5 11/03
* = Non-Illustrated Parts
FRT15B1BW1 Publication No.
5995398244
POS. NO PART NO DESCRIPTION
1 240355401 Cover-fan
2 240367001 Knob-damper control
3 5303001028 Nut,push-on
4 240367401 Damper-fan cover
5 # 5308000010 Fan Blade,red ,evaporator fan
8 5300157666 Bushing-motor mtg,(2)
9 5303292396 Bracket-motor mtg,front
10 240462011 Cover-evap coil
10* 240568601 Seal-coil cover
10* 241520701 Harness-wiring
11 5303208309 Plug-hole,factory test
12 240366801 Plug-ice maker harness,rectangular
12A 240374401 Plug-wtr inlet tube,round ,1"
13 # 240369701 Motor-evap fan
13* 215474201 Washer,"slinger" ,nylon ,evap fan shaft
13* 218931001 Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 Bracket-motor mtg, rear
18 240411901 Support-evap cover, (2)
21C 218252200 Screw,#8 truss hd, 10-32CA x 0.500
22 215774901 Plug-button, white, upr hinge holes
28 240335501 Bolt-roller adj,hex washer head, 1/4-20 x 4.020, (2) ,special
30 240357102 Bracket,bottom hinge ,white
34 240311303 Washer,hinge ,nylon ,(2)
35 240357002 Bracket,center hinge ,white
35A 240336802 Spacer-hinge,center
36 240516401 Pin-center hinge
37 240337601 Trim-cabinet corner,white ,(2)
38 240356901 Bracket,upper hinge
40 240354401 Cover-upper hinge,white
41 5303001609 Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 Grommet,shelf mtg ,1.25" ,LH
42 240578901 Screw-hinge mtg,hex head ,1/4-20 x 5/8
43 240335003 Roller Assy,front ,(2)
56 240516501 Pin-lower hinge
58 5303001343 Screw,hex washer head ,8-15A x 0.500
59 240442702 Screw-#10-32 X 3/4,white
72 240368301 Grille/Kickplate,white
78 240433201 Screw, hex washer head, 8-18 x 0.375
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base ,rear ,(2)
83 5303316859 Rivet, flat head ,1/4 OD x 1-3/4, roller pin
92 5303001479 Screw-hinge mtg,hex hd, 1/4-20 x 0.875
* 218843800 Screw, hex wshr hd, 8-15A x 0.500
* 240479601 Plug, button, cab liner holes ,(2)
* 5303305324 Paint, touch-up ,white
CABINET

11/03 6
Publication No. FRT15B1BW1
5995398244
SHELVES

# = Fast-moving Parts 7 11/03
* = Non-Illustrated Parts
FRT15B1BW1 Publication No.
5995398244
POS. NO PART NO DESCRIPTION
12 240545001 Diffuser,air ,top
13 240362601 Diffuser,air ,bottom
14 240505801 Switch,light/lamp
15 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V,miniature
16 # 241500701 Socket-light/lamp
17 240368001 Control Box
17*# 240388701 Wiring Harness, control box
18 240360801 Knob, temp control
21 # 5304421256 Control, temperature
22A 240468201 Tube, sensor sleeve, 31 inch, plastic, white
23 # 215846606 Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hr/30 min
23* 5303001259 Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240360902 Shelf, sliding, wire
38 240369601 Trivet
81 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
SHELVES

11/03 8
Publication No. FRT15B1BW1
5995398244
SYSTEM
20
20
17
45
1
2
21
15
14
16
83
83
44
41
82
82
87
N05CBBBAB0
22
23
23
85
4
6
29
57
25
25
26
84
45
30 56
31

# = Fast-moving Parts 9 11/03
* = Non-Illustrated Parts
FRT15B1BW1 Publication No.
5995398244
POS. NO PART NO DESCRIPTION
1 # 240406405 Condenser,static
1* 240405201 Grommet, rubber, black, cond tube/wire
1* 5303208866 Spacer, condenser tube, black
2 5308000296 Bracket, condenser mtg, (4)
4 # 218944001 Drier-filter, R134a System
6 # 240581601 Harness-wiring, machine compt
6* 241520701 Harness-wiring
6* # 240388701 Wiring Harness, control box
6* # 240581801 Harness-wiring, compressor
14 # 5303918203 Defrost Heater Kit
15 5303918275 Evaporator Kit
16 5308000110 Strap-evap/heater, aluminum, (2)
17 240434003 Trough-drain
20 240518402 Insulation, evap block, foam, LH/RH
21 # 5303918202 Thermostat-defrost,kit
22 240330005 Base-compressor
22* 218252200 Screw,#8 truss hd, 10-32CA x 0.500
23 218513300 Grommet-compr mtg, (4)
25 240491501 Screw-compressor mtg,1/4-28 x 1.16, shoulder, typ CF
26 240332605 Pan-defrost drain
29 # 5303918297 Compressor, w/electricals
30 # 5304433579 Relay
31 # 5304433578 Overload Protector
41 240433202 Screw, hex washer head, 8-18 x 5/16
44 5303001199 Clamp-wiring harness, strain relief, galv steel
45 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile
56 240582001 Cover-terminal
57 240542601 Clip-wiring harness
82 5304418225 Roller,compressor base ,rear ,(2)
83 5303316859 Rivet,flat head ,1/4 OD x 1-3/4, roller pin
84 240500801 Tube-drain, rubber, lower
85 241504201 Tube-connector, suction
87 240533004 Tube-Condensate
* 240396801 Clamp, tube/wiring, nylon, black/natural
* 5303918263 Heat Exchanger Kit, suction line
* # 5303918234 Hot Tube Repair Kit, Service
SYSTEM

11/03 10
Publication No. FRT15B1BW1
5995398244
WIRING SCHEMATIC

# = Fast-moving Parts 11 11/03
* = Non-Illustrated Parts
FRT15B1BW1 Publication No.
5995398244
WIRING DIAGRAM
