Frigidaire FRT16CRH User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT16CRHD5 FRT16CRH R134a almond 115
FRT16CRHW5 FRT16CRH R134a white 115
FRT16CRHY5 FRT16CRH R134a almond/LH 115
FRT16CRHZ5 FRT16CRH R134a white/RH 115
MARKET
North America
Publication No.
5995342382
000815
-EN/SERVICE /DJH
390
REFRIGERATOR
Model No.
FRT16CRH
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218758400
OWNER’S GUIDE - # 218972200
SERVICE DATA SHEET - # 218758400
101 MASTERS BLVD.
ANDERSON, SC 29624

08/00 2
Publication No. FRT16CRH
5995342382
DOOR

# = Fast-moving Parts 3 08/00
* = Non-Illustrated Parts
FRT16CRH Publication No.
5995342382
DOOR
A = FRT16CRH (FRT16CRHD5)
B = FRT16CRH (FRT16CRHW5)
C = FRT16CRH (FRT16CRHY5)
D = FRT16CRH (FRT16CRHZ5)
POS. NO PART NO DESCRIPTION
1 # 215608911 A B C D Gasket-frzr door,white ,magnetic
2 # 218730603 A B C D Gasket-refr door,white ,magnetic
3 218460801 A B C D Panel-inner door,refr
4 218027017 A B C D Rack-door,22.20" x 1.62"
5 215267701 A B C D Support-door rack,"2-liter" ,RH/LH
5A 215473602 A B C D Support-door rack,RH/LH
7 218287801 A B C D Door-dairy,10.71" wide ,white, no graphics
9 218460701 A B C D Panel-inner door,frzr
10 5303001308 A - C - Plug-button,almond ,hinge brg hole
10 5308000134 - B - D Plug-button,white ,hinge brg hole
11 5303917815 A - C - Panel-frzr door,almond ,w/insulation
11 5303917814 - B - D Panel-frzr door,white ,w/insulation
12 218917602 A - C - Label-nameplate,almond
12 218917601 - B - D Label-nameplate,white
13 218800300 A B C D Door Stop,plated
13A 218249002 A - C - Door Stop,almond ,frzr section
13A 218249001 - B - D Door Stop,white ,frzr section
14 218915702 A - C - Plug-button,almond
14 218915701 - B - D Plug-button,white
15 5303917839 A - C - Panel-refr door,almond ,w/insul & brace
15 5303917838 - B - D Panel-refr door,white ,w/insul & brace
18A 218428102 A - C - Handle-door,almond ,w/block & screw
18A 218428101 - B - D Handle-door,white ,w/block & screw
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B C D Bearing-hinge
58 218699800 A B C D Screw,truss head ,8-15A x 0.500
72 218397000 A B C D Button-handle mtg,dovetail
73 218396700 A B C D Block-handle mtg,dovetail
74 215503200 A B C D Screw,cr pan hd ,10-16 x 0.500
* 5303917276 A B C D Insulation-door,fiberglass ,(bulk)

08/00 4
Publication No. FRT16CRH
5995342382
CABINET

# = Fast-moving Parts 5 08/00
* = Non-Illustrated Parts
FRT16CRH Publication No.
5995342382
CABINET
A = FRT16CRH (FRT16CRHD5)
B = FRT16CRH (FRT16CRHW5)
C = FRT16CRH (FRT16CRHY5)
D = FRT16CRH (FRT16CRHZ5)
POS. NO PART NO DESCRIPTION
1 218672501 A B C D Cover-fan
2 5303307351 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 218722200 A B C D Damper-fan cover,black
5 # 218649000 A B C D Fan Blade,black
6 218448302 A - C - Cover,almond ,lwr hinge hole
6 218448301 - B - D Cover,white ,lwr hinge hole
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303205118 A B C D Bracket-motor mtg,front
10 218988902 A B C D Cover-evap coil
10* 5303209814 A B C D Nut,"U" type ,8-15A ,fan mtr mtg
11 5303208309 A B C D Plug-hole,factory test
12 215079000 A B C D Plug-harness hole,round
12 215079100 A B C D Plug-wtr inlet tube,round
13 # 218878901 A B C D Motor-evap fan
14 5303205119 A B C D Bracket-motor mtg,rear
17 218725602 A B C D Trough-drain
18 215245000 A B C D Support-evap cover,(2)
19 5303001198 A B C D Tube,rubber
22 215774911 A - C - Plug-button,almond ,upr hinge holes
22 215774901 - B - D Plug-button,white ,upr hinge holes
23 5303269702 A B C D Tube-drain,w/seal ring
24 5303207353 A B C D Seal Ring,drain tube
25 215774100 A B C D Spout-drain tube,w/mounting pins
29 5308000007 A B C D Washer,.34 x .62 x .05 ,nylon
29* 5308000186 A B C D Washer,.34 x .62 x .10 ,nylon
29* 5308011326 A B C D Washer,.34 x .62 x .02 ,nylon
30 5304409595 A B C D Bracket-lower hinge,zinc plate
30* 215882300 A B C D Tapping Plate,lower hinge ,(2)
32 215217703 A - C - Plug-button,almond ,cabinet base ,(2)
32 215217701 - B - D Plug-button,white ,cabinet base ,(2)
35 218220102 A - C - Bracket-ctr hinge,almond
35 218220101 - B - D Bracket-ctr hinge,light gray
36 218251300 A B C D Pin-center hinge
37 5303321082 A - C - Trim-cabinet corner,almond
37 5303321081 - B - D Trim-cabinet corner,white
38 3206100 A B C D Bracket-upper hinge
40 3206105 A - C - Cover-upper hinge,almond
40 3206101 - B - D Cover-upper hinge,white
41 5303001609 A B C D Grommet,shelf/rod mtg ,RS
41 5308009759 A B C D Grommet,shelf mtg ,LS
42 15880100 A B C D Scr-hinge mtg,hex wash hd,1/4-20 x 0.685,(2)
43 218724000 A B C D Roller Assy,front ,complete
43* 218703002 A B C D Roller
43* 5308009761 A B C D Bolt-roller adj
43* 5308009790 A B C D Spring-roller adj
44 5303283014 A B C D Roller Assy,metal housing
45 5303001343 A B C D Screw,hex washer head ,8-15A x 0.500
56 218220300 A B C D Pin-lower hinge
59 218188000 A B C D Scr,pan hd ,10-32x0.625,hng/mull,thrd form
78 5303274237 A B C D Screw-bracket,hex wshr hd, 8-32CA x 0.500
81 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625, low profile
83 5308000107 A B C D Bracket-connector
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099711 A - C - Plug-button,almond
98 215099701 - B - D Plug-button,white
100 5303288973 A B C D Support-pan cover
* 5303305325 A - C - Paint,touch-up ,almond
* 5303305324 - B - D Paint,touch-up ,white
* 5308016571 A B C D Plug-button,cab liner holes
A = FRT16CRH (FRT16CRHD5)

08/00 6
Publication No. FRT16CRH
5995342382
SHELVES

# = Fast-moving Parts 7 08/00
* = Non-Illustrated Parts
FRT16CRH Publication No.
5995342382
SHELVES
B = FRT16CRH (FRT16CRHW5)
C = FRT16CRH (FRT16CRHY5)
D = FRT16CRH (FRT16CRHZ5)
POS. NO PART NO DESCRIPTION
1 218874411 A - C - Mullion,almond
1 218874401 - B - D Mullion,white
5 # 218781001 A B C D Heater-mullion
6 218845602 A B C D Tapping Plate,mullion mtg ,(2)
7 218865801 A B C D Panel-top,refr cavity
8 218872905 A B C D Divider,styrofoam ,w/foil tape
8* # 218878500 A B C D Wiring Harness,control/divider
9 218865600 A B C D Panel-bottom,frzr cavity
10 215667501 A B C D Tray-ice,plastic
11 5303283280 A B C D Shelf-freezer,"table type"
12 218730000 A B C D Deflector-air
12* 5303001449 A B C D Seal-air deflector,foam plastic ,(2)
13 218631001 A B C D Cover-air deflector
14 # 5309918806 A B C D Switch-light/lamp
15 5303001179 A B C D Light Bulb/Lamp,40 W
16A 218906801 A B C D Socket-light/lamp
17 5304414816 A B C D Control Box
17* 5308016567 A B C D Nut-anchor
18 5303311079 A B C D Knob-temp control
19 # 5303286905 A B C D Switch-energy saver,rocker type
21 5303321453 A B C D Control-temperature
21* 5303001260 A B C D Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B C D Tube,sensor sleeve ,plastic ,clear
22B 218731104 A B C D Tube,PVC ,white ,@ air deflector, insulator
23 # 215846605 A B C D Timer-defrost,60 Hz ,120 V ,10hr/21min
23* 5303001259 A B C D Screw-timer mtg,pan hd ,6-20 x 0.438
24 218272502 A B C D Shelf,sliding ,wire
25 218314101 A B C D Cover-crisper pan,w/support beam
26 3206180 A B C D Pan-crisper
46 5303303588 A B C D Front-crisper pan
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625, hinge/mullion
81 5303001380 A B C D Screw,truss head ,8-10 x 1.625
145 218660800 A B C D Clip,plastic ,temp sensor mtg ,snap-in

08/00 8
Publication No. FRT16CRH
5995342382
SYSTEM

# = Fast-moving Parts 9 08/00
* = Non-Illustrated Parts
FRT16CRH Publication No.
5995342382
SYSTEM
A = FRT16CRH (FRT16CRHD5)
B = FRT16CRH (FRT16CRHW5)
C = FRT16CRH (FRT16CRHY5)
D = FRT16CRH (FRT16CRHZ5)
POS. NO PART NO DESCRIPTION
1 # 218491000 A B C D Condenser
1* 5303208866 A B C D Spacer-cond tube,black
2 5308000296 A B C D Bracket,condenser mtg ,(4)
2* 5308009617 A B C D Washer,ext tooth lock ,#10 ,grounding
4 218944001 A B C D Drier-filter,R134a System
5 # 218878500 A B C D Wiring Harness,control/divider
6 # 215257004 A B C D Wiring Harness,compressor
7 # 5316254901 A B C D Cord-electric power
7* 218843800 A B C D Screw,hex wshr hd ,8-15A x 0.5, wiring clamps
8 5303001197 A B C D Cover-wiring
13 # 218429306 A B C D Heat Exchanger,suction line
14 # 5308009754 A B C D Heater-defrost
15 # 218818701 A B C D Evaporator
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 5316651102 A B C D Insulator-evap,plastic
18 218821301 A B C D Insulation Block,RH
19 5303007287 A B C D Insulation Plug,RH
20 218821201 A B C D Insulation Block,LH
21 # 218969902 A B C D Thermostat-defrost
22 218802500 A B C D Plate-compr mtg,with rail
23 218254500 A B C D Grommet-compr mtg,(4)
24 5308003633 A B C D Washer-compr mtg
25 5308003596 A B C D Clip-compressor mtg
26 215372500 A B C D Pan-defrost drain
27 5303001348 A B C D Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C D Pan Retainer Kit,Service
29 # 218846902 A B C D Compressor,R134a ,w/o electricals
30 # 218721103 A B C D Starter/Overload Assy
32 218740800 A B C D Clamp,elec cont mtg ,compressor
41 5308000039 A B C D Screw,hex wash hd,8-32CA x 0.5,(7),serrat hd
43 5303001199 A B C D Clamp-wiring harness,strain relief, galv steel
44 5308000133 A B C D Clamp,nylon ,.625 ID
45 5303001343 A B C D Screw,hex washer head ,8-15A x 0.500
45* 5300141713 A B C D Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 # 218909901 A B C D Capacitor-run,220 VAC ,15 microfarad
* # 3916557 A B C D Hot Tube Repair Kit,Service
