Frigidaire FRT18HS8K Instruction Manual

Product No. FRT18HS8KS0
Series R134a
Color stainless
Volts 115
Wiring Diagram 241582401
Owner's Guide 241857201
Market North America
Energy Guide 241935594
Service Data Sheet 241588203
Installation Instructions 240568303
N05L00011.eps N05DFDBBA5.eps N05BBAABA33.eps N05SADAFI13.eps
N05CAABAD4.eps W241582401.eps S241582801.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995535969
09/03/23
(EN/SERVICE/KHB)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18HS8K
Copyright ©All rights reserved.

Publication No: 5995535969 FRT18HS8KS0
03/09 2
DOOR
22
11
12
22
22
13A
13
48A
48A
48A
21C
21C
22
1
7
2
N05DFDBBA5
15
48
49
49
18
79
79
80
80
18
79
79
80
80

FRT18HS8KS0 Publication No: 5995535969
# Functional Parts 3 03/09
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 # 241872509 Gasket-frzr door, black, magnetic
2 # 241872512 Gasket-refr door, black, magnetic
7 240338313 Door, dairy, clear
11 241623301 Door, frzr, stainless steel, RH
12 241808601 Label-nameplate
13 240312405 Door Stop, black, refr
13A 240312406 Door Stop, black, frzr
15 241623401 Door, refr, stainless steel, RH
18 240536819 Handle-door, stainless steel
18* 241601001 Wrench, allen
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 240527102 Bearing-hinge, black
48 240338101 Bin-door, pseudo, bottom
48A 240338202 Bin-door, gallon
49 240495804 Bin-door, pseudo, frzr
79 218755402 Screw-set, 10-32 x 0.375
80 218755504 Screw-shoulder, #10 AB, handle mounting

Publication No: 5995535969 FRT18HS8KS0
03/09 4
CABINET
83
82
11
10
1
12
12A
81
4
58
2
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABA33
43 21C
41
41
41
8
8
9
14
81
34
22
21C
40
89
28

FRT18HS8KS0 Publication No: 5995535969
# Functional Parts 5 03/09
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 241652301 Cover-fan
2 240367001 Knob-damper control
4 241523701 Damper-fan cover
5 # 5308000010 Fan Blade, red, evaporator fan
8 5300157666 Bushing-motor mtg, (2)
9 5303292396 Bracket-motor mtg, front
10 241652214 Cover-evap coil
10* 240568601 Seal-coil cover
10* 241520701 Harness-wiring, freezer
11 5303208309 Plug-hole, factory test
12 241557601 Plug-ice maker harness, rectangular
12A 240374401 Plug-wtr inlet tube, round, 1"
12A* 241586701 Plug-foam-wtr-inlet, round
13 # 241854301 Motor-fan
13* 215474201 Washer, "slinger", nylon, evap fan shaft
13* 218931001 Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 Bracket-motor mtg, rear
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 215774918 Plug-button, black, upr hinge holes
28 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314003 Bracket-lower hinge, black
34 240311303 Washer, hinge, nylon, (2)
35 240313803 Bracket-ctr hinge, black
35A 240336803 Spacer-hinge, center, black
36 240516402 Pin-center hinge
37 241611303 Trim-cabinet corner, black, (2)
38 240313701 Bracket-upper hinge
40 240354404 Cover-upper hinge, black
41 5308009759 Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 Screw, hex head, 1/4-20 x 5/8
43 240335005 Roller Assy, adjustable, front, (2)
56 240516502 Pin-lower hinge
58 240433204 Screw, hex washer head, 8-18 x 5/16
59 240442707 Screw-#10-32 X 3/4, black
72 241839407 Grille/Kickplate, black
81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241733907 Cover-access, with label
89* 241500304 Screw, hex washer head, 8-18AB x 0.625
92 241710601 Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 240479601 Plug, button, cab liner holes
* 5303321321 Paint, touch-up, black

Publication No: 5995535969 FRT18HS8KS0
03/09 6
SHELVES
11
24A
24
25
47
26
26
23
21
22A
13
12
14
18
17
15
16
58
58
31
25B
25C
N05SADAFI13

FRT18HS8KS0 Publication No: 5995535969
# Functional Parts 7 03/09
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
11 240358005 Shelf, freezer, full-width, wire
12 241542001 Diffuser, air, top
13 240362601 Diffuser, air, bottom
14 # 241554901 Switch-light/lamp
15 241555401 Light Bulb
16 241559801 Socket-light
17 240352702 Control Box
17* 240568607 Seal
17*# 240388701 Wiring Harness, control box
18 240360801 Knob, temp control
21 # 5304421256 Control, temperature
22A 240468201 Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 Timer-defrost
23* 5304455649 Screw, pan hd, 6-20 x 0.438
24 240358905 Shelf-"Spill-Safe", sliding
24A 240358906 Shelf-"Spill-Safe", sliding, w/pan hanger
25 240364714 Cover-crisper pan
25B 241613501 Control-humidity, RH
25C 241613502 Control-humidity, LH
26 240337103 Pan-crisper, clear, (2), no graphics
31 240530811 Pan-meat, w/o graphics, clear
47 241711219 Insert-pan cover, glass
58 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
* 241935594 Energy Guide

Publication No: 5995535969 FRT18HS8KS0
03/09 8
SYSTEM
17 21
15
20
14
20
16
1
34
34
83
44
41
82
83
82
N05CAABAD4
22
23
23
30
32
85
55
4
6
29
25
25
24
24 25
24
26
84
45
57
59
61
60
59B
59B
59A
59A
59A 58
86

FRT18HS8KS0 Publication No: 5995535969
# Functional Parts 9 03/09
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 241873404 Condenser
4 218944002 Drier-filter, R134a System
6 # 241607001 Harness-wiring, machine compt
6*# 240388701 Wiring Harness, control box
14 # 240356221 Heater-defrost
15 # 5303918274 Evaporator Kit
16 5308000110 Strap-evap/heater, aluminum, (2)
17 241801301 Trough-drain
20 241551902 Insulation Block
21 # 5303918202 Thermostat-defrost, kit
22 241665606 Base-compressor
22* 218252201 Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 Grommet-compr mtg, (4)
24 241812301 Washer-compr mtg
25 216056401 Clip-compressor mtg
26 241683601 Pan-defrost
29 # 5303918380 Compressor Kit
30 # 241941001 Starter
32 297030500 Clip, controller
34 240405201 Grommet, rubber, black, cond tube/wire
41 240433204 Screw, hex washer head, 8-18 x 5/16
44 5304456288 Clamp-wiring harness, strain relief, galv steel
45 241500304 Screw, hex washer head, 8-18AB x 0.625
55 216985003 Capacitor-run
57 240542601 Clip-wiring harness
58 240569201 Screw, 8-18 x 0.500
59 240315505 Shroud-cond fan
59* 240346701 Tape-foam seal, shroud
59* 240359403 Screw-fan shroud, (2)
59A 240346501 Bracket-support, cond mtr, (3)
59B 240346601 Grommet-bracket, (3)
60 241584301 Motor-condenser fan
61 241639501 Blade-condenser fan
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 Tube-drain, rubber, lower
85 241871501 Tube-connector, suction
86 240409302 Spacer-cond tube, black
* 240396801 Clamp, tube/wiring, nylon, black/natural
* 5303918263 Heat Exchanger Kit, suction line
* 5303918222 Hot Tube Repair Kit, service

Publication No: 5995535969 FRT18HS8KS0
03/09 10
WIRING SCHEMATIC

FRT18HS8KS0 Publication No: 5995535969
# Functional Parts 11 03/09
* Non-Illustrated Parts
WIRING DIAGRAM
