Frigidaire FRT18IL6D User manual

Product No. FRT18IL6DBL FRT18IL6DKL FRT18IL6DML FRT18IL6DQL FRT18IL6DSL FRT18IL6DWL
Series R134a R134a R134a R134a R134a R134a
Color black stainless-LH silver/mist bisque stainless-RH white
Volts 115 115 115 115 115 115
Wiring Diagram 240398801 240398801 240398801 240398801 240398801 240398801
Owner's Guide 241694400 241694400 241694400 241694400 241694400 241694400
Market North America North America North America North America North America North America
Energy Guide 240598682 240598682 240598682 240598682 240598682 240598682
Service Data Sheet 240379018 240379018 240379018 240379018 240379018 240379018
Installation Instructions 240568301 240568301 240568301 240568301 240568301 240568301
N05L00003.eps N05DCDBBA8.eps N05BBAAAA9.eps N05SACAFI17.eps
N05CAAAAA21.eps 115-1.eps 240398801.eps 240398601.eps
u x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995469276
06/06/30
(EN/SERVICE/WC)
390
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT18IL6D
Copyright ©2006 Home Pr oducts, Inc.
All rights reserved.

Publication No: 5995469276 FRT18IL6D
06/06 2
DOOR
22
11
12
21 14B
21
14B
18
21
14
14
22
22
13A
13
48A
48A
48A
21C
21C
18A
14
22
1
7
2
N05DCDBBA8
15
48
49
49
10
22
22
10
22
22

FRT18IL6D Publication No: 5995469276
# Functional Parts 3 06/06
* Non-Illustrated Parts
DOOR
Model Index: AFRT18IL6D (FRT18IL6DBL)
BFRT18IL6D (FRT18IL6DKL)
CFRT18IL6D (FRT18IL6DML)
DFRT18IL6D (FRT18IL6DQL)
EFRT18IL6D (FRT18IL6DSL)
FFRT18IL6D (FRT18IL6DWL)
POS. NO PART NO. DESCRIPTION
1 240542121 A B C - E - Gasket-frzr door, black, magnetic
1 240542115 - - - D - F Gasket-frzr door, white, magnetic
2 240542124 A B C - E - Gasket-refr door, black, magnetic
2 240542118 - - - D - F Gasket-refr door, white, magnetic
7 240338313 A B C D E F Door, dairy, clear
10 240381303 A - - - - - Plug-button, black, hinge brg hole
10 240381306 - - C - - - Plug-button, silver mist, hinge brg hole
10 240381302 - - - D - - Plug-button, bisque, hinge brg hole, (2)
10 240381301 - - - - - F Plug-button, white, hinge brg hole, (2)
11 240409919 A - - - - - Door, frzr, black
11 241623306 - B - - - - Door-frzr, stainless, LH, complete assy
11 240409920 - - C - - - Panel-frzr door, s/mist, completeassy
11 240409902 - - - D - - Door-frzr, bisque, completeassy
11 241623305 - - - - E - Door, frzr, stainless, RH, complete assy
11 240409901 - - - - - F Door-frzr, white,complete assy
12 240572601 A B C D E F Label-nameplate
13 240312405 A B C - E - Door Stop, black, refr
13 240312407 - - - D - - DoorStop, bisque, ref
13 240312403 - - - - - F Door Stop, white, ref
13A 240312406 A B C - E - Door Stop, black, frzr
13A 240312408 - - - D - - DoorStop, bisque, frzr
13A 240312404 - - - - - F Door Stop, white, frzr
14 240494003 A - - - - - Plug-button, black
14 240494006 - - C - - - Plug-button, silver mist
14 240494002 - - - D - - Plug-button, bisque
14 240494001 - - - - - F Plug-button, white
14B 240383603 A B C - E - Plug-button, black, door handle
14B 240383602 - - - D - - Plug-button, bisque, door handle
14B 240383601 - - - - - F Plug-button, white, door handle
15 240410124 A - - - - - Door, refr, black
15 241623406 - B - - - - Door-refr, stainless steel, complete assy
15 240410135 - - C - - - Door,refr,silver mist
15 240410102 - - - D - - Panel-refr door, bisque, complete assy
15 241623405 - - - - E - Door, refr, stainless steel, stainless, RH
15 240410101 - - - - - F Panel-refr door, white, complete assy
18 240339203 A B C - E - Handle-door, black, refr-LH/frzr-RH
18 240339204 - - - D - - Handle-door, bisque, refr-LH/frzr-RH
18 240339201 - - - - - F Handle-door, white, refr-LH/frzr-RH
18A 240339208 A B C - E - Handle-door, black, refr-RH/frzr-LH
18A 240339209 - - - D - - Handle-door, bisque, refr-RH/frzr-LH
18A 240339206 - - - - - F Handle-door, white, refr-RH/frzr-LH
21 240383406 A B C D E F Screw, truss hd quad, #10-16 x .500, zinc
21C 218252200 A B C D E F Screw, #8 truss hd, 10-32CA x 0.500
22 240527102 A B C - E - Bearing-hinge, black
22 240527101 - - - D - F Bearing-hinge, natural color
48 240338101 A B C D E F Bin-door, pseudo, bottom
48A 240338201 A B C D E F Bin-door, gallon
49 240495804 A B C D E F Bin-door, pseudo, frzr
* 218490901 - B - - E - Cleaner, stainless steel

Publication No: 5995469276 FRT18IL6D
06/06 4
CABINET
83
82
89
11
10
1
81
4
58
2
3
40
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAAAA9
43
28
21C
21C
41
41
41
8
8
9
14
81
34
22
37

FRT18IL6D Publication No: 5995469276
# Functional Parts 5 06/06
* Non-Illustrated Parts
CABINET
Model Index: AFRT18IL6D (FRT18IL6DBL)
BFRT18IL6D (FRT18IL6DKL)
CFRT18IL6D (FRT18IL6DML)
DFRT18IL6D (FRT18IL6DQL)
EFRT18IL6D (FRT18IL6DSL)
FFRT18IL6D (FRT18IL6DWL)
POS. NO PART NO. DESCRIPTION
1 241652301 A B C D E F Cover-fan
2 240367001 A B C D E F Knob-damper control
3 5303001028 A B C D E F Nut, push-on
4 241523701 A B C D E F Damper-fan cover
5 # 5308000010 A B C D E F Fan Blade, red, evaporator fan
8 5300157666 A B C D E F Bushing-motor mtg, (2)
9 5303292396 A B C D E F Bracket-motor mtg, front
10 241652214 A B C D E F Cover-evap coil
10* 240568601 A B C D E F Seal-coil cover
10* 241520701 A B C D E F Harness-wiring, freezer
11 5303208309 A B C D E F Plug-hole, factory test
13 240369702 A B C D E F Motor-evap fan
13* 215474201 A B C D E F Washer, "slinger", nylon, evap fan shaft
13* 218931001 A B C D E F Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C D E F Bracket-motor mtg, rear
14* 240433202 A B C D E F Screw, hex washer head, 8-18 x 5/16
21C 218252200 A B C D E F Screw, #8 truss hd, 10-32CA x 0.500
22 215774918 A B C - E - Plug-button, black, upr hinge holes
22 215774919 - - - D - - Plug-button, bisque, upr hinge holes
22 215774901 - - - - - F Plug-button, white, upr hinge holes
28 240335502 A B C D E F Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314003 A B C - E - Bracket-lower hinge, black
30 240314011 - - - D - F Bracket-lower hinge, zinc
34 240311303 A B C D E F Washer, hinge, nylon, (2)
35 240313803 A B C - E - Bracket-ctr hinge, black
35 240313801 - - - D - F Bracket-ctr hinge, zinc
35A 240336802 A B C D E F Spacer-hinge, center
36 240516402 A B C D E F Pin-center hinge
37 241611303 A B C - E - Trim-cabinet corner, black, (2)
37 241611304 - - - D - - Trim-cabinet corner, bisque, (2)
37 241611301 - - - - - F Trim-cabinet corner, white, (2)
38 240313701 A B C D E F Bracket-upper hinge
40 240354404 A B C - E - Cover-upper hinge, black
40 240354403 - - - D - - Cover-upperhinge, bisque
40 240354401 - - - - - F Cover-upper hinge, white
41 5308009759 A B C D E F Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 A B C D E F Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335005 A B C D E F Roller Assy, adjustable, front, (2)
56 240516502 A B C D E F Pin-lower hinge
58 5303001343 A B C D E F Screw, hex washer head, 8-15A x 0.500
59 240442707 A B C - E - Screw-#10-32 X 3/4, black
59 240442706 - - - D - F Screw-#10-32 X 3/4, zinc
72 240368207 A B C - E - Grille/Kickplate, black
72 240368206 - - - D - - Grille/Kickplate, bisque
72 240368205 - - - - - F Grille/Kickplate, white

Publication No: 5995469276 FRT18IL6D
06/06 6
CABINET
83
82
89
11
10
1
81
4
58
2
3
40
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAAAA9
43
28
21C
21C
41
41
41
8
8
9
14
81
34
22
37

FRT18IL6D Publication No: 5995469276
# Functional Parts 7 06/06
* Non-Illustrated Parts
CABINET
Model Index: AFRT18IL6D (FRT18IL6DBL)
BFRT18IL6D (FRT18IL6DKL)
CFRT18IL6D (FRT18IL6DML)
DFRT18IL6D (FRT18IL6DQL)
EFRT18IL6D (FRT18IL6DSL)
FFRT18IL6D (FRT18IL6DWL)
POS. NO PART NO. DESCRIPTION
81 5308016566 A B C D E F Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B C D E F Roller, compressor base, rear, (2)
83 5304455655 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574607 A B C D E F Cover-access, w/label
89* 241500302 A B C D E F Screw, hex washer head, 8-18AB x 0.625
92 241624301 A B C D E F Screw-hinge mtg, hex head, 1/4-20 x 1.00
* 5303321321 A B C - E - Paint, touch-up, black
* 5304414035 - - - D - - Paint,touch-up, bisque
* 5303321319 - - - - - F Paint, touch-up, white

Publication No: 5995469276 FRT18IL6D
06/06 8
SHELVES
11
24A
24
25
47
26
26
23
21
22A
13
12
14
18
17
15
16
58
58
31
25B
25C
N05SACAFI17
34

FRT18IL6D Publication No: 5995469276
# Functional Parts 9 06/06
* Non-Illustrated Parts
SHELVES
Model Index: AFRT18IL6D (FRT18IL6DBL)
BFRT18IL6D (FRT18IL6DKL)
CFRT18IL6D (FRT18IL6DML)
DFRT18IL6D (FRT18IL6DQL)
EFRT18IL6D (FRT18IL6DSL)
FFRT18IL6D (FRT18IL6DWL)
POS. NO PART NO. DESCRIPTION
11 240358005 A B C D E F Shelf, freezer, full-width, wire
12 241542001 A B C D E F Diffuser, air, top
13 240362601 A B C D E F Diffuser, air, bottom
14 # 241554901 A B C D E F Switch-light/lamp
15 241555401 A B C D E F Light Bulb
16 241559801 A B C D E F Socket-light
17 240352701 A B C D E F Control Box
17* 240568607 A B C D E F Seal
17*# 240388701 A B C D E F Wiring Harness, control box
18 240360801 A B C D E F Knob, tempcontrol
21 # 5304421256 A B C D E F Control, temperature
22A 240468201 A B C D E F Tube, sensor sleeve, 31 inch, plastic, white
23 # 241621501 A B C D E F Timer-defrost
23* 5304455649 A B C D E F Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240358905 A B C D E F Shelf-"Spill-Safe", sliding
24A 240358906 A B C D E F Shelf-"Spill-Safe", sliding, w/pan hanger
25 240364714 A B C D E F Cover-crisper pan
25B 241613501 A B C D E F Control-humidity, RH
25C 241613502 A B C D E F Control-humidity, LH
26 240337103 A B C D E F Pan-crisper, clear, (2), no graphics
31 240530811 A B C D E F Pan-meat, w/o graphics, clear
34 240385201 A B C D E F Container, ice bin
47 241711219 A B C D E F Insert-pan cover, glass
58 5308016566 A B C D E F Screw, hex washer head, 8-15A x 0.625, low profile

Publication No: 5995469276 FRT18IL6D
06/06 10
SYSTEM
17 21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CAAAAA21
22
23
23
85
4
6
29
26
84
45
57
25
25

FRT18IL6D Publication No: 5995469276
# Functional Parts 11 06/06
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT18IL6D (FRT18IL6DBL)
BFRT18IL6D (FRT18IL6DKL)
CFRT18IL6D (FRT18IL6DML)
DFRT18IL6D (FRT18IL6DQL)
EFRT18IL6D (FRT18IL6DSL)
FFRT18IL6D (FRT18IL6DWL)
POS. NO PART NO. DESCRIPTION
1 241665701 A B C D E F Condenser, dynamic
4 # 218944001 A B C D E F Drier-filter, R134a System
6 # 241607001 A B C D E F Harness-wiring, machine compt
6* 241520701 A B C D E F Harness-wiring, freezer
6* # 240388701 A B C D E F Wiring Harness, control box
14# 240356214 A B C D E F Heater-defrost
15 # 5303918274 A B C D E F Evaporator Kit
16 5308000110 A B C D E F Strap-evap/heater, aluminum, (2)
17 241551801 A B C D E F Trough-drain
20 241551901 A B C D E F Insulation Block
21 # 5303918202 A B C D E F Thermostat-defrost, kit
22 241665503 A B C D E F Base-compressor
22* 218252201 A B C D E F Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B C D E F Grommet-compr mtg, (4)
25 240491503 A B C D E F Screw-compressor mtg, 1/4-28 x 1.16, (4)
26 241683601 A B C D E F Pan-defrost
29 # 5303918326 A B C D E F Compressor, w/electricals
30 # 241667501 A B C D E F Relay Combo
34 240405201 A B C D E F Grommet, rubber, black, cond tube/wire
41 240433204 A B C D E F Screw, hex washer head, 8-18 x 5/16
44 5304456288 A B C D E F Clamp-wiring harness, strain relief, galv steel
45 241500304 A B C D E F Screw, hex washer head, 8-18AB x 0.625
57 240542601 A B C D E F Clip-wiring harness
58 218897004 A B C D E F Screw, hex washer head, 8-32 x 0.375
59 5304430246 A B C D E F Bracket-cond motor assy
59* 240346701 A B C D E F Tape-foam seal, shroud
59* 240359403 A B C D E F Screw-fan shroud, (2)
60 # 240525402 A B C D E F Motor, condensor fan
61 # 240524101 A B C D E F Fan Blade, galv steel, condenser fan
82 5304418225 A B C D E F Roller, compressor base, rear, (2)
83 5304455655 A B C D E F Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B C D E F Tube-drain, rubber, lower
85 240493101 A B C D E F Tube-connector, suction
* 240396801 A B C D E F Clamp, tube/wiring, nylon, black/natural
* 5303918263 A B C D E F Heat Exchanger Kit, suction line
* 5303918222 A B C D E F Hot Tube Repair Kit, service

Publication No: 5995469276 FRT18IL6D
06/06 12
ICE MAKER

FRT18IL6D Publication No: 5995469276
# Functional Parts 13 06/06
* Non-Illustrated Parts
ICE MAKER
Model Index: AFRT18IL6D (FRT18IL6DBL)
BFRT18IL6D (FRT18IL6DKL)
CFRT18IL6D (FRT18IL6DML)
DFRT18IL6D (FRT18IL6DQL)
EFRT18IL6D (FRT18IL6DSL)
FFRT18IL6D (FRT18IL6DWL)
POS. NO PART NO. DESCRIPTION
1 218976901 A B C D E F Tube-water inlet, inlet valve, to ice maker
1* 240561701 A B C D E F Seal-water inlet, inlet valve, to ice maker
2 5304456650 A B C D E F Spring-shutoff arm, ICE MAKER
3 5304456657 A B C D E F Nameplate
4 5304456658 A B C D E F Gear
5 5304456659 A B C D E F Plate-mounting
6 5304456691 A B C D E F Screw, M 3x20 #3, valve plate
7 # 5304445222 A B C D E F Motor-ice maker Svo
7* 5304445223 A B C D E F Spring Beam
8 5304456661 A B C D E F Spacer-hold switch
9 5304456662 A B C D E F Cam
10 5304456689 A B C D E F Holder-thermostat
11 # 5304456663 A B C D E F Thermal Cutoff, ICE MAKER
12 # 5304456875 A B C D E F Harness-wiring, icemaker
13 5304456665 A B C D E F Thermostat, ICE MAKER
14 5304456666 A B C D E F Screw, M 3x20 #2, (6)
15 # 5304456667 A B C D E F Switch-micro, (3)
15* 5304456688 A B C D E F Terminal
16 5304456668 A B C D E F Support
17 5304456669 A B C D E F Mold-ice maker, w/therm cut off
18 5304456670 A B C D E F Ejector-ice
19 5304456671 A B C D E F Bearing & Inlet, fill cup
20 5304456687 A B C D E F Screw-IM brkt mtg, special, 8-32D x 0.375
21 5304456672 A B C D E F Ice Stripper
22 5304456673 A B C D E F Shut-off Arm
23 5304456674 A B C D E F Screw, M 4x25 #2, mold-to-support, (2)
24 5304456675 A B C D E F Lever Arm
25 5304456676 A B C D E F Screw, M 4x12.8 #2, lever arm/sprt
26 5304420654 A B C D E F Screw-thermo/sprt, 4-24 x 0.375, (4)
27 5304456677 A B C D E F Screw, M 3x25 #3, hold switch mtg, (2)
28 5304456660 A B C D E F Screw, M 4x6 #2
29 5304456678 A B C D E F Screw, M 3x12 #3, (2)
30 5304456679 A B C D E F Screw-timing adj, M 4x25 #3
31 5304456680 A B C D E F Insulator
32 5304456681 A B C D E F Plate-valve switch
33 5304456682 A B C D E F Spring, shut-off arm
34 5304456683 A B C D E F Screw, M 4x12 #2, (3)
35 5304456684 A B C D E F Screw
36 5304456685 A B C D E F Cover-ice maker
36* 5304456690 A B C D E F Label, on/off
37 5304408583 A B C D E F Spring-timing adj
41* 5308000039 A B C D E F Screw, hex washer head, 8-32CA x 0.500, serrated head
42 5303001199 A B C D E F Clamp-wiring harness, strain relief, galv steel
45 241500302 A B C D E F Screw, hex washer head, 8-18AB x 0.625
45 5303001343 A B C D E F Screw, hex washer head, 8-15A x 0.500

Publication No: 5995469276 FRT18IL6D
06/06 14
ICE MAKER

FRT18IL6D Publication No: 5995469276
# Functional Parts 15 06/06
* Non-Illustrated Parts
ICE MAKER
Model Index: AFRT18IL6D (FRT18IL6DBL)
BFRT18IL6D (FRT18IL6DKL)
CFRT18IL6D (FRT18IL6DML)
DFRT18IL6D (FRT18IL6DQL)
EFRT18IL6D (FRT18IL6DSL)
FFRT18IL6D (FRT18IL6DWL)
POS. NO PART NO. DESCRIPTION
45 5304455650 A B C D E F Screw, hex washer head, 8-15A x 0.625, low profile
46 5303001193 A B C D E F Clamp, .50 ID, steel, water tube
46 5308000133 A B C D E F Clamp, nylon, .625 ID
51 241523501 A B C D E F Tube-water, ice mold fill, extension
55 # 240519601 A B C D E F Valve-water, single solenoid, 60 Hz, 105/120 V
60 218362501 A B C D E F Screw, hex washer head, 8-18AB x 1.250, spacer, (2)
61 5304456686 A B C D E F Bracket-leveling, ICE MAKER
62 218737900 A B C D E F Screw-IM brkt mtg, hex washer head, 8-32D x 0.375
64 5304455846 A B C D E F Clamp, .31 ID, steel, water tube
* 5304456737 A B C D E F Washer
* 218888001 A B C D E F Adapter-water supply, nut & sleeve, compression ftg
* 241642501 A B C D E F Ice Maker, radius cube, 115 V, Svce
* 5304456692 A B C D E F Washer
* 5304456693 A B C D E F Nut, M 3.5

Publication No: 5995469276 FRT18IL6D
06/06 16
WIRING SCHEMATIC

FRT18IL6D Publication No: 5995469276
# Functional Parts 17 06/06
* Non-Illustrated Parts
WIRING DIAGRAM
