PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18QGHD0 FRT18QGH R134a System almond 115
FRT18QGHW0 FRT18QGH R134a System white 115
FRT18IQGHD0 FRT18IQGH R134a System almond 115
FRT18IQGHW0 FRT18IQGH R134a System white 115
MARKET
North American
Publication No.
5995323879
990527
-EN/SERVICE /ECL
390
REFRIGERATOR
Model No.
FRT18QGH
FRT18IQGH
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218758400
OWNER’S GUIDE - # 218942600
SERVICE DATA SHEET - # 218758400
101 MASTERS BLVD.
ANDERSON, SC 29624

06/99 2
Publication No. FRT18QGH & FRT18IQGH
5995323879
DOOR

# = Fast-moving Parts 3 06/99
* = Non-Illustrated Parts
FRT18QGH & FRT18IQGH Publication No.
5995323879
DOOR
A = FRT18QGH (FRT18QGHD0)
B = FRT18QGH (FRT18QGHW0)
C = FRT18IQGH (FRT18IQGHD0)
D = FRT18IQGH (FRT18IQGHW0)
POS. NO PART NO DESCRIPTION
1 # 215608906 A - C - Gasket-frzr door,almond ,magnetic
1 # 215608916 - B - D Gasket-frzr door,white ,magnetic
2 # 218730606 A - C - Gasket-refr door,almond ,magnetic
2 # 218730605 - B - D Gasket-refr door,white ,magnetic
3 218360701 A B C D Panel-inner door,refr
5A 218758602 A B C D Support-door rack,RH/LH
7 5303308347 A B C D Door-dairy,12.96" wide
8 218763627 A B C D Rack-door,22.36" x 2.04"
9 218360101 A B C D Panel-inner door,frzr
10 5303001308 A - C - Plug-button,almond ,hinge brg hole
10 5308000134 - B - D Plug-button,white ,hinge brg hole
11 5303917796 A - C - Panel-frzr door,almond ,with insulation
11 5303917795 - B - D Panel-frzr door,white ,with insulation
12 218425013 A - C - Nameplate Assy,almond
12 218425012 - B - D Nameplate Assy,white
12* 218364002 A - C - • Frame-nameplate,almond
12* 218364001 - B - D • Frame-nameplate,white
12* 215008614 A - C - • Label-nameplate,almond
12* 215008613 - B - D • Label-nameplate,white
12* 215518000 A B C D • Magnet-nameplate
13 218800300 A B C D Door Stop,plated
13A 218249002 A - C - Door Stop,almond ,frzr section
13A 218249001 - B - D Door Stop,white ,frzr section
14 218915702 A - C - Plug-button,almond
14 218915701 - B - D Plug-button,white
14B 218074002 A - C - Plug-button,almond ,refr door front ,lower
Use when relocating door trim.
14B 218074001 - B - D Plug-button,white ,refr door front ,lower
Use when relocating door trim.
15 5303917798 A - C - Panel-refr door,almond ,w/insul & brace
15 5303917797 - B - D Panel-refr door,white ,w/insul & brace
18 218668002 A - C - Handle-door,almond
18 218668001 - B - D Handle-door,white
21C 218252200 A B C D Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B C D Bearing-hinge
26 215817806 A B C D Tray-egg
37 215870628 A - C - Trim-handle,2.47" ,almond ,w/gold band
37 215870627 - B - D Trim-handle,2.47" ,white ,w/gold band
37A 215867090 A - C - Trim-handle,29.84" ,almond ,lower ,w/band & locks
37A 215867089 - B - D Trim-handle,29.84" ,white ,lower ,w/band & locks
37A* 218676003 A B C D • Band-decorative,gold
37A* 218906701 A B C D • Lock-handle trim,stick-on
37A* 215782300 A B C D • Lock-handle trim,snap-in
48 218592309 A B C D Bin-door,2 liter ,with trim
49 218592305 A B C D Bin-door,gallon ,with trim
58 218699800 A B C D Screw,truss head ,8-15A x 0.500
* 5303917276 A B C D Insulation-door,fiberglass ,(bulk)

06/99 4
Publication No. FRT18QGH & FRT18IQGH
5995323879
CABINET

# = Fast-moving Parts 5 06/99
* = Non-Illustrated Parts
FRT18QGH & FRT18IQGH Publication No.
5995323879
CABINET
A = FRT18QGH (FRT18QGHD0)
B = FRT18QGH (FRT18QGHW0)
C = FRT18IQGH (FRT18IQGHD0)
D = FRT18IQGH (FRT18IQGHW0)
POS. NO PART NO DESCRIPTION
1 218672501 A B C D Cover-fan
2 5303307351 A B C D Knob-damper control
3 5303001028 A B C D Nut,push-on
4 218722200 A B C D Damper-fan cover,black
5 # 218649000 A B C D Fan Blade,black
8 5300157666 A B C D Bushing-motor mtg,(2)
9 5303205118 A B C D Bracket-motor mtg,front
10 3206451 A B C D Cover-evap coil
10* 5303209814 A B C D Nut,"U" type ,8-15(A) ,fan mtr mtg
11 5303208309 A B C D Plug-hole,factory test
12 215079000 A B - - Plug-harness hole,round
12 215079100 A B - - Plug-wtr inlet tube,round
13 # 218878701 A B C D Motor-evap fan
14 5303205119 A B C D Bracket-motor mtg,rear
17 218725700 A B C D Trough-drain
18 215245000 A B C D Support-evap cover,(2)
19 5303001198 A B C D Tube,rubber
22 215774911 A - C - Plug-button,almond ,upr hinge holes
22 215774901 - B - D Plug-button,white ,upr hinge holes
23 5303269702 A B C D Tube-drain,w/seal ring
24 5303207353 A B C D • Seal Ring,drain tube
25 215774100 A B C D Spout-drain tube,w/mounting pins
29 5308000007 A B C D Washer,.34 x .62 x .05 ,nylon
29 5308011326 A B C D Washer,.34 x .62 x .02 ,nylon
30 5304409595 A B C D Bracket-lower hinge
30* 215882300 A B C D Tapping Plate,lower hinge ,(2)
35 218220102 A - C - Bracket-ctr hinge,almond
35 218220101 - B - D Bracket-ctr hinge,light grey
36 218251300 A B C D Pin-center hinge
37 5303321082 A - C - Trim-cabinet corner,almond
37 5303321081 - B - D Trim-cabinet corner,white
38 3206100 A B C D Bracket-upper hinge
40 3206105 A - C - Cover-upper hinge,almond
40 3206101 - B - D Cover-upper hinge,white
41 5303001609 A B C D Grommet,shelf/rod mtg ,RH
41* 5308009759 A B C D Grommet,shelf mtg ,LH
42 215880100 A B C D Screw-hinge mtg,hex washer hd ,1/4-20 x 0.685,(2)
43 218724000 A B C D Roller Assy,front ,complete
43* 218703002 A B C D • Roller
43* 5308009790 A B C D • Spring-roller adj
43* 5308000186 A B C D • Washer,.34 x .62 x .10 ,nylon
43* 5308009761 A B C D • Bolt-roller adj
43* 3051070 A B C D Screw 10-24 X 7/16,hex washer head ,10-24 x 7/16
44 5303283014 A B C D Roller Assy,metal housing
45 5303001343 A B C D Screw,hex wshr hd ,8-15A x .5 ,spec
47 218233300 A B C D Channel-shelf mtg,side ,(2)
48 5303292395 A B C D Channel-shelf mtg,center
49 218362500 A B C D Screw,hex washer head ,8-18AB x 1.250
50 5308009765 A B C D Insulation-air duct,upper
51 3203820 A B C D Duct-meat pan,upper
52 5303001445 A B C D Control-damper,meat pan duct
53 215410000 A B C D Label-meat kpr duct
54 5303001443 A B C D Duct-meat pan,lower
55 5308009764 A B C D Insulation-air duct,lower
56 218220300 A B C D Pin-lower hinge
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625 ,hng/mlln,thrd forming
72 218915402 A - C - Grille/Kickplate,almond ,w/fasteners
72 218915401 - B - D Grille/Kickplate,white ,w/fasteners
73 218896804 A B C D • Fastener-grille,button ,(2)
78 5308000039 A B C D Screw,hex wshr hd ,8-32CA x 0.500 ,serrated head
81 5308016566 A B C D Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C D Bracket-connector
92 5303001479 A B C D Screw-hinge mtg,hex hd ,1/4-20 x 0.875 ,(6)
98 215099711 A - C - Plug-button,almond
98 215099701 - B - D Plug-button,white
* 5308016571 A B C D Plug-button,cab liner holes
* 5303305325 A - C - Paint,touch-up ,almond
* 5303305324 - B - D Paint,touch-up ,white

06/99 6
Publication No. FRT18QGH & FRT18IQGH
5995323879
SHELVES

# = Fast-moving Parts 7 06/99
* = Non-Illustrated Parts
FRT18QGH & FRT18IQGH Publication No.
5995323879
SHELVES
A = FRT18QGH (FRT18QGHD0)
B = FRT18QGH (FRT18QGHW0)
C = FRT18IQGH (FRT18IQGHD0)
D = FRT18IQGH (FRT18IQGHW0)
POS. NO PART NO DESCRIPTION
1 218874311 A - C - Mullion,almond
1 218874301 - B - D Mullion,white
5 # 218781003 A B C D Heater-mullion
6 218845602 A B C D Tapping Plate,mullion mtg ,(2)
7 218814800 A B C D Panel-top,refr cavity
8 218872903 A B C D Divider,styrofoam ,w/foil tape
8* # 218878500 A B C D Harness-wiring,control/divider
9 218814700 A B C D Panel-bottom,frzr cavity
10 215667501 A B - - Tray-ice,plastic
11 5303288242 A B C D Shelf-freezer,fixed/flat ,full width ,wire
11* 5303299664 A B C D Spacer-shelf
12 218730000 A B C D Deflector-air
12* 5303001449 A B C D Seal-air deflector,foam plastic ,(2)
13 218631001 A B C D Cover-air deflector
14 # 5309918806 A B C D Switch-light/lamp
15 5303001179 A B C D Light Bulb/Lamp,40 W
16A# 218906801 A B C D Socket-light/lamp
17 5303321455 A B C D Control Box
18 5303311079 A B C D Knob-temp control
19 # 5303286905 A B C D Switch-energy saver,rocker type
21 # 5304404821 A B C D Control-temperature
21* 5303001260 A B C D Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B C D Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B C D Tube,PVC ,white ,@ air deflector ,insulator
23 # 215846605 A B C D Timer-defrost
23* 5303001259 A B C D Screw-timer mtg,pan hd ,6-20 x 0.438
25 215686501 A B C D Cover-crisper pan,with beam
25A 218905802 A B C D Trim-crisper cover
25B 5303307881 A B C D Control-humidity
26 3206438 A B C D Pan-crisper
28 3201150 A B C D End Cap-shelf,protector ,frzr shelf
31 215742603 A B C D Pan-meat
34 5303001568 A B C D Container-ice
36 215406127 A B C D Shelf-"Spill-Safe",cantil ,half width,teal grphcs ,fixed
42 5304404462 A B C D Hanger-pan/tray,LH
42 5304404463 A B C D Hanger-pan/tray,RH
46 215357608 A B C D Front-crisper pan
47 218498125 A B C D Insert-pan cover,glass ,clear ,w/teal graphics
59 218188000 A B C D Screw,pan hd ,10-32 x 0.625 ,hng/mlln,thrd forming
60 218362500 A B - - Screw,hex washer head ,8-18AB x 1.250
61 215781501 A B - - Shelf-ice tray,wire
67 215357811 A B C D Front-meat pan
81 5303001380 A B C D Screw,truss head ,8-10 x 1.625
123 215005100 A B C D Screw-roller/hanger,8-10 x .438
145 218660800 A B C D Clip,plastic ,temp sensor mtg ,snap-in

06/99 8
Publication No. FRT18QGH & FRT18IQGH
5995323879
SYSTEM

# = Fast-moving Parts 9 06/99
* = Non-Illustrated Parts
FRT18QGH & FRT18IQGH Publication No.
5995323879
SYSTEM
A = FRT18QGH (FRT18QGHD0)
B = FRT18QGH (FRT18QGHW0)
C = FRT18IQGH (FRT18IQGHD0)
D = FRT18IQGH (FRT18IQGHW0)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B C D Condenser
1* 5303208866 A B C D Spacer-cond tube,black
2 5308000296 A B C D Bracket,condenser mtg ,(4)
2* 5308009617 A B C D Washer,ext tooth lock ,#10 ,grounding
4 # 218541000 A B C D Drier-filter,R134a System
5 # 218878500 A B C D Harness-wiring,control/divider
6 # 215257004 A B C D Harness-wiring,compressor
7 # 5316254901 A B C D Cord-electric power
8 5303001197 A B C D Cover-wiring
13 # 218429306 A B C D Heat Exchanger,suction line
14 # 3206453 A B C D Heater-defrost
15 # 3206452 A B C D Evaporator
16 5308000110 A B C D Strap-evap/heater,aluminum ,(2)
17 5303207493 A B C D Insulator-evap,plastic
18 5308013648 A B C D Insulation Block,RH
19 5303007287 A B C D Insulation Plug,RH
20 5308017227 A B C D Insulation Block,LH
21 # 5316269001 A B C D Thermostat-defrost
22 218802500 A B C D Plate-compr mtg,with rail
23 218254500 A B C D Grommet-compr mtg,(4)
24 5308003633 A B C D Washer-compr mtg
25 5308003596 A B C D Clip-compressor mtg
26 215372500 A B C D Pan-defrost drain
27 5303001348 A B C D Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C D Pan Retainer Kit,Service
29 # 218846902 A B C D Compressor,R134a ,w/o electricals
30 # 218721103 A B C D Starter/Overload Assy
32 218740800 A B C D Wire-bale
41 5308000039 A B C D Screw,hex wshr hd ,8-32CA x 0.500 ,serrated head
43 5303001199 A B C D Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B C D Clamp,nylon ,.75 OD tube
45 218843800 A B C D Screw,hex wshr hd ,#8 14 x 1/2 ,wiring clamps
45 5300141713 A B C D Screw,hex wshr hd ,8-32 x .625 ,spec
45 5303001343 A B C D Screw,hex wshr hd ,8-15A x .5 ,spec
55 # 216236200 A B C D Capacitor-run,180-200 VAC ,15 microfarad
* # 3916557 A B C D Hot Tube Repair Kit,Service

06/99 10
Publication No. FRT18IQGH
5995323879
ICE MAKER

# = Fast-moving Parts 11 06/99
* = Non-Illustrated Parts
FRT18IQGH Publication No.
5995323879
ICE MAKER
C = FRT18IQGH (FRT18IQGHD0)
D = FRT18IQGH (FRT18IQGHW0)
POS. NO PART NO DESCRIPTION
1 5303015131 - - C D Tube-water,71" ,valve-to-IM
2 3206348 - - C D Spring,shut-off arm
3 3206299 - - C D Plate-I.D.
4 3206301 - - C D Gear
5 3206303 - - C D Plate-mounting
6 3206305 - - C D Screw-ground wire,8-32 x 1/4
7 # 3206306 - - C D Motor-ice maker
8 3206312 - - C D Spacer-holding sw
9 3206313 - - C D Cam
10 3206315 - - C D Clamp
11 # 3206319 - - C D Thermal Cutoff,icemaker ,complete assy
12 # 3206349 - - C D Harness-wiring,IM internal ,with plug
12 3206321 - - C D • Connector Plug,wiring harness
13 # 3206322 - - C D Thermostat Assy,ice maker
14 3206323 - - C D Screw-switch mtg,4-24 x 3/4 ,sw to support,(2)
15 # 3206324 - - C D Switch,(3)
16 3206326 - - C D Support
17 # 5303320545 - - C D Mold-ice maker,radius cube ,with heater
18 3206328 - - C D Ejector
19 3206330 - - C D Bearing & Inlet
20 3206331 - - C D Screw,8-18 x 0.375 ,(2)
21 3206332 - - C D Ice Stripper
22 3206333 - - C D Arm,shut-off
23 3206334 - - C D Screw-sup/mold body,8-18 x 1 ,(4)
24 3206335 - - C D Lever-arm
25 3206336 - - C D Screw-arm levr/sprt,8-18 x 9/16
26 3206337 - - C D Screw-thermo/sprt,4-24 x 3/8 ,(4)
27 3206338 - - C D Screw-sw&spcr/plate,4-40 x 1
28 3206339 - - C D Screw-timing stop,4-40 x 3/8
29 3206340 - - C D Screw-mtr & sw/plate,4-40 x 3/4
30 3206341 - - C D Screw-timing,8-32 x 1
31 3206342 - - C D Insulator
32 3206343 - - C D Plate-valve switch
33 3206344 - - C D Spring
34 3206345 - - C D Screw-mtg plate/sprt,8-18 x 7/16
35 3206346 - - C D Screw-gear/cam,6-20 x 0.437
36 3206347 - - C D Cover-ice maker,complete
37 5303320544 - - C D Data Sheet,ice maker
38 5303207445 - - C D Envelope-data sheet
39 # 3206358 - - C D Harness-wiring,ice maker
40 5305877995 - - C D Sealing Strip
41 5308000039 - - C D Screw,hex wshr hd ,8-32CA x 0.500 ,serrated head
43 5303001199 - - C D Clamp-wiring harness,strain relief ,galv steel
44 5308000133 - - C D Clamp,nylon ,.75 OD tube
45 218843800 - - C D Screw,hex wshr hd ,#8 14 x 1/2 ,wiring clamps
46 5303001193 - - C D Clamp-inlet tube,metal
47 5308000205 - - C D Adapter-water sply,straight
48 5308000200 - - C D Nut,7/16 x 20 ,nylon
49 5303001147 - - C D Plug-harness hole,(2)
52 215456100 - - C D Tube-water,ice mold fill
55 # 218720300 - - C D Valve-water,120 V 60 Hz ,flow restricter
55* 5303015102 - - C D Cap-water valve
59 5303001191 - - C D Sleeve-tube insert
60 218362500 - - C D Screw,hex washer head ,8-18AB x 1.250
61 218721500 - - C D Bracket-leveling,ice maker
62 215230500 - - C D Screw-bracket mtg,pan head ,8-32T x 0.375
64 5303001549 - - C D Clamp-copper tube,steel
