Frigidaire FRT18QGF User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18QGFD3 FRT18QGF R134a System almond 115
FRT18QGFW3 FRT18QGF R134a System white 115
MARKET
North America
Publication No.
5995316501
990104
-EN/SERVICE /ECL
390
REFRIGERATOR
Model No.
FRT18QGF
©1999 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 218758400
OWNER’S GUIDE - # 218777700
SERVICE DATA SHEET - # 218758400
101 MASTERS BLVD.
ANDERSON, SC 29624

01/99 2
Publication No. FRT18QGF
5995316501
DOOR

# = Fast-moving Parts 3 01/99
* = Non-Illustrated Parts
FRT18QGF Publication No.
5995316501
DOOR
A = FRT18QGF (FRT18QGFD3)
B = FRT18QGF (FRT18QGFW3)
POS. NO PART NO DESCRIPTION
1 # 215608906 A - Gasket-frzr door,almond ,magnetic
1 # 215608916 - B Gasket-frzr door,white ,magnetic
2 # 218730606 A - Gasket-refr door,almond ,magnetic
2 # 218730605 - B Gasket-refr door,white ,magnetic
3 218360701 A B Panel-inner door,refr
5A 218758602 A B Support-door rack,RH/LH
7 5303308347 A B Door-dairy
8 218763627 A B Rack-door,(2)
9 218360101 A B Panel-inner door,frzr
10 5303001308 A - Plug-button,almond ,hinge brg hole
10 5308000134 - B Plug-button,white ,hinge brg hole
11 5303917796 A - Panel-frzr door,almond ,with insulation
11 5303917795 - B Panel-frzr door,white ,with insulation
12 218364002 A - Frame-nameplate,almond
12 218364001 - B Frame-nameplate,white
12* 215008614 A - Label-nameplate,almond
12* 215008613 - B Label-nameplate,white
12* 215518000 A B Magnet-nameplate
13 218800300 A B Door Stop,plated
13A 218249002 A - Door Stop,almond ,frzr section
13A 218249001 - B Door Stop,white ,frzr section
14 5308000181 A - Plug-button,almond
14 5308000090 - B Plug-button,white
14A 218110902 A - Plug-button,almond ,refr door front ,upper
14A 218110901 - B Plug-button,white ,refr door front ,upper
14B 218074002 A - Plug-button,almond ,refr door front ,lower
14B 218074001 - B Plug-button,white ,refr door front ,lower
15 5303917798 A - Panel-refr door,almond ,w/insul & brace
15 5303917797 - B Panel-refr door,white ,w/insul & brace
18 218668002 A - Handle-door,almond
18 218668001 - B Handle-door,white
21A 218251900 A B Screw,#8 oval head ,10-32CA x .625 ,cross recessed
21C 218252200 A B Screw,#8 truss hd ,10-32CA x .5
22 218519300 A B Bearing-hinge
26 3204522 A B Container-egg
27 218370101 A B Snugger-door bin,"paddle type" ,gallon door bin
37 215870628 A - Trim-handle,2.47" ,almond ,w/gold band
37 215870627 - B Trim-handle,2.47" ,white ,w/gold band
37* 218807701 A B Lock-handle trim,stick-on
37A 215867090 A - Trim-handle,almond ,lower ,w/gold band ,and snap locks
37A 215867089 - B Trim-handle,white ,lower ,w/gold band ,and snap locks
37A* 215940700 A B Lock-handle trim,stick-on
48 218592309 A B Bin-door,with trim
49 218592305 A B Bin-door,gallon ,with trim
58 218699800 A B Screw,truss head ,8-15A x 0.500
* 5303917276 A B Insulation-door,fiberglass ,(bulk)

01/99 4
Publication No. FRT18QGF
5995316501
CABINET
17
19
18 41
24
23
25
45
43
44
6
32
30 42
P05B0377
56
47
48
47
60
49
22
39
92
10
83
14
8
13
37
38
40
12 58
5
11
9
8
78
54
55
50 51
52
53
49
98
36
59
35
29
4
1
3
81
2

# = Fast-moving Parts 5 01/99
* = Non-Illustrated Parts
FRT18QGF Publication No.
5995316501
CABINET
A = FRT18QGF (FRT18QGFD3)
B = FRT18QGF (FRT18QGFW3)
POS. NO PART NO DESCRIPTION
1 218672501 A B Cover-fan
2 5303307351 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 218722200 A B Damper-fan cover,black
5 # 218649000 A B Fan Blade,black
6 218448302 A - Cover,almond ,lwr hinge hole
6 218448301 - B Cover,white ,lwr hinge hole
8 5300157666 A B Bushing-motor mtg,(2)
9 5303205118 A B Bracket-motor mtg,front
10 3206451 A B Cover-evap coil
10* 5303209814 A B Nut,"U" type ,8-15(A) ,fan mtr mtg
11 5303208309 A B Plug-hole,factory test
12 215079000 A B Plug-harness hole,round
12 215079100 A B Plug-wtr inlet tube,round
13 # 218878701 A B Motor-evap fan
14 5303322992 A B Bracket-motor mtg,rear
17 218725700 A B Trough-drain
18 215245000 A B Support-evap cover,(2)
19 5303001198 A B Tube,rubber
22 215774911 A - Plug-button,almond ,upr hinge holes
22 215774901 - B Plug-button,white ,upr hinge holes
23 5303269702 A B Tube-drain,w/seal ring
24 5303207353 A B * Seal Ring,drain tube
25 215774100 A B Spout-drain tube,w/mounting pins
29 5308000007 A B Washer,.34 x .62 x .05 ,nylon
30 3206136 A B Bracket-lower hinge
30* 215882300 A B Tapping Plate,lower hinge ,(2)
30* 218368500 A B Shim-lower hinge
32 215217703 A - Plug-button,almond ,cabinet base ,(2)
32 215217701 - B Plug-button,white ,cabinet base ,(2)
35 218220102 A - Bracket-ctr hinge,almond
35 218220101 - B Bracket-ctr hinge,light grey
36 218251300 A B Pin-center hinge
37 5303321082 A - Trim-cabinet corner,almond
37 5303321081 - B Trim-cabinet corner,white
38 3206100 A B Bracket-upper hinge
39 5303001037 A B Shim-upper hinge
40 3206105 A - Cover-upper hinge,almond
40 3206101 - B Cover-upper hinge,white
41 5303001609 A B Grommet,shelf/rod mtg ,RH
41* 5308009759 A B Grommet,shelf mtg ,LH
42 215880100 A B Screw-hinge mtg,hex wshr head ,1/4-20 x 0.685,(2)
43 218724000 A B Roller Assy,front ,complete
43* 218703002 A B Roller
43* 5308009760 A B * Roller
43* 5308009761 A B * Bolt-roller adj
43* 5308009790 A B * Spring-roller adj
43* 5308011326 A B * Washer,.34 x .62 x .02 ,nylon
44 5303283014 A B Roller Assy,metal housing
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
50 5308009765 A B Insulation-air duct,upper
51 3203820 A B Duct-meat pan,upper
52 5303001445 A B Control-damper,meat pan duct
53 215410000 A B Label-meat kpr duct
54 5303001443 A B Duct-meat pan,lower
55 5308009764 A B Insulation-air duct,lower
56 218220300 A B Pin-lower hinge
58 5308002748 A B Screw,hex wshr hd ,8-15A x 0.500 ,special
59 218188000 A B Screw,pan hd ,10-32 x 0.625 ,hng/mullin,thrd form
78 5303274237 A B Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B Bracket-connector
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875 ,(6)
98 215099711 A - Plug-button,almond ,ctr hinge hole
98 215099701 - B Plug-button,white ,ctr hinge hole
* 5303305324 - B Paint,touch-up ,white
* 5303305325 A - Paint,touch-up ,almond
* 5308016571 A B Plug-button,cabinet liner ,icemaker holes

01/99 6
Publication No. FRT18QGF
5995316501
SHELVES

# = Fast-moving Parts 7 01/99
* = Non-Illustrated Parts
FRT18QGF Publication No.
5995316501
SHELVES
A = FRT18QGF (FRT18QGFD3)
B = FRT18QGF (FRT18QGFW3)
POS. NO PART NO DESCRIPTION
1 218874311 A - Mullion,almond ,1
1 218874301 - B Mullion,white ,1
5 # 218781003 A B Heater-mullion
6 218845602 A B Tapping Plate,mullion mtg ,(2)
7 218814800 A B Panel-top,refr cavity
7* 5303001380 A B Screw,truss head ,8-10 x 1.750
8 218814600 A B Divider,styrofoam
8* # 3018900 A B Harness-wiring,control/divider
9 218814700 A B Panel-bottom,frzr cavity
10 215667501 A B Tray-ice,plastic
11 5303288242 A B Shelf-freezer,fixed/flat ,full width ,wire
11* 5303299664 A B Spacer-shelf
12 218730000 A B Deflector-air
12* 5303001449 A B Seal-air deflector,foam plastic ,(2)
13 218631001 A B Cover-air deflector
14 # 5309918806 A B Switch-light/lamp
15 5303001179 A B Light Bulb/Lamp,40 W
16A 218906801 A B Socket-light/lamp
17 5303321455 A B Control Box
18 5303311079 A B Knob-temp control
19 # 5303286905 A B Switch-energy saver,rocker type
21 # 5303321453 A B Control-temperature
21* 5303001260 A B Screw-control mtg,pan hd ,6-32 x 0.250
22A* 5303916855 A B Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B Tube,PVC ,white ,@ air deflector ,insulator
23 # 215267800 A B Timer-defrost
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438
25 215686501 A B Cover-crisper pan,with beam
25A 218905802 A B Trim-crisper cover
25B 5303307881 A B Control-humidity
26 3206438 A B Pan-crisper
28 3201150 A B End Cap-shelf,protector ,upper fzr shelf
31 215742603 A B Pan-meat
34 5303289069 A B Container-ice
36 215406127 A B Shelf-"Spill-Safe",fixed ,teal graphics
42 5304404462 A B Hanger-pan/tray,LH
42 5304404463 A B Hanger-pan/tray,RH
46 215357608 A B Front-crisper pan,(2)
47 218498125 A B Insert-pan cover,glass ,clear ,w/teal graphics
59 218188000 A B Screw,pan hd ,10-32 x 0.625 ,hng/mullin,thread form
60 218362500 A B Screw,hex washer head ,8-18AB x 1-1/4
61 215781501 A B Shelf-ice tray,wire
66 5304402116 A B Rack-wine
67 215357811 A B Front-meat pan
81 5308016566 A B Screw,hex wshr hd ,8-15A x 0.625 ,low profile
123 215005100 A B Screw-roller/hanger,8-10 x .438
145 218660800 A B Clip,plastic ,temp sensor mtg ,snap-in

01/99 8
Publication No. FRT18QGF
5995316501
SYSTEM

# = Fast-moving Parts 9 01/99
* = Non-Illustrated Parts
FRT18QGF Publication No.
5995316501
SYSTEM
A = FRT18QGF (FRT18QGFD3)
B = FRT18QGF (FRT18QGFW3)
POS. NO PART NO DESCRIPTION
1 # 218173900 A B Condenser
2 5308000296 A B Bracket,condenser mtg ,(4)
2* 5308009617 A B Washer,ext tooth lock ,#10
4 # 218541000 A B Drier-filter
5 # 218878500 A B Harness-wiring,control/divider
6 # 215257004 A B Harness-wiring,compressor
7 # 5316254901 A B Cord-electric power
8 5303001197 A B Cover-wiring
13 # 218429306 A B Heat Exchanger,suction line
14 # 3206453 A B Heater-defrost
15 # 3206452 A B Evaporator
16 5308000110 A B Strap-evap/heater,aluminum
17 5303207493 A B Insulator-evap,plastic
18 5308013648 A B Insulation Block,RH
19 5303007287 A B Insulation Plug,RH
20 5308017227 A B Insulation Block,LH
21 # 5316269001 A B Thermostat-defrost
22 218802500 A B Plate-compr mtg,with rail
22* 3051070 A B Screw 10-24 X 7/16,hex wshr hd ,10-24 x 7/16,special
23 218254500 A B Grommet-compr mtg,(4)
24 5308003633 A B Washer-compr mtg
25 5308003596 A B Clip-compressor mtg
26 215372500 A B Pan-defrost drain
26* 5308017610 A B Sound Tape,defrost pan
27 5303001348 A B Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B Pan Retainer Kit,Service
29 # 218846902 A B Compressor,R134a ,w/o electricals
30 # 218721103 A B Starter/Overload Assy
32 218740800 A B Wire-bale
41 5308000039 A B Screw,hex wshr hd ,8-32CA x 0.500 ,serrated head
43 5303001199 A B Clamp-wiring harness,strain relief ,galv steel
44 5308000133 A B Clamp,nylon ,.75 OD tube
45 5303001343 A B Screw,hex wshr hd ,8-15A x .5 ,spec
55 # 216236200 A B Capacitor-run
* # 3916557 A B Hot Tube Repair Kit,Service
