Frigidaire FRT21R7AS User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21R7ASB2 FRT21R7AS R134a stain/blk 115
FRT21R7ASB5 FRT21R7AS R134a stain/blk 115
MARKET
North America
Publication No.
5995374633
020619
-EN/SERVICE/DCS
357
TOP MOUNT
REFRIGERATOR
Model No.
FRT21R7AS
ENERGY GUIDE LABEL - 240791408
OWNER’S GUIDE - 2 = 240400105 & 5 = 240400106
SERVICE DATA SHEET - # 240379009

DOOR

5995374633
A = FRT21R7AS (FRT21R7ASB2)
B = FRT21R7AS (FRT21R7ASB5)
POS. NO PART NO DESCRIPTION
1 # 240514611 A B Gasket,frzr door seal ,black ,magnetic
2 # 240514612 A B Gasket,refr door seal ,black ,magnetic
7 240338303 A B Door,dairy ,clear
10 240381305 A - Plug-button,gray ,hinge brg hole ,(2)
11 240450323 A - Door,frzr ,stainless steel, Reversable
11 240450335 - B Door-frzr,stainless steel, complete assy, Non-Reversable
12 240416304 A B Nameplate,black
13 240312405 A B Door Stop,black ,ref
13A 240312406 A B Door Stop,black ,frzr
14 240494005 A - Plug-button,gray
14B 240383603 A B Plug-button,black ,door handle
15 240450428 A - Door,refr ,stainless steel, Reversable
15 240450443 - B Door-refr,stainless steel, complete assy, Non-Reversable
18 240339203 A B Handle-door,black
18A 240339208 A B Handle-door,black
21 240383401 A B Screw,truss hd quad ,#10-16 x .500
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240311202 A - Bearing-hinge,black ,(8)
22 240527102 - B Bearing-hinge,black
48 240338101 A B Bin-door,pseudo ,bottom
48A 240338201 A B Bin-door,gallon
49 240495801 A B Bin-door,pseudo ,frzr
96 240345506 A B Plug,door foam hole ,black
* 218490900 A B Cleaner,stainless steel
DOOR

CABINET

5995374633
A = FRT21R7AS (FRT21R7ASB2)
B = FRT21R7AS (FRT21R7ASB5)
POS. NO PART NO DESCRIPTION
1 240355404 A B Cover-fan
5 # 5308000010 A B Fan Blade,red ,evaporator fan
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 240313606 A B Cover-evap coil
10* 240371303 A B Seal, insulation, 53.23 in. long, foam, coil cover
10*# 240385402 A - Wiring Harness,freezer section
10*# 240524701 - B Wiring Harness,freezer section
11 5303208309 A B Plug-hole,factory test
12 240366801 A B Plug-ice maker harness,rectangular
12A 240374401 A B Plug-wtr inlet tube,round ,1"
13 # 240369701 A B Motor-evap fan
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg,rear
14* 240433201 A B Screw,hex washer head ,8-18 x 0.375
18 240411901 A B Support-evap cover,(2)
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 215774918 A B Plug-button,black ,upr hinge holes
28 240335501 A B Bolt-roller adj,hex washer head, 1/4-20 x 4.020, (2), special
30 240314003 A B Bracket-lower hinge,black
34 240311301 A B Washer,hinge ,nylon ,(2)
35 240313803 A B Bracket-ctr hinge,black
35A 240336801 A B Spacer-hinge,center
36 240516401 A B Pin-center hinge
37 240337603 A B Trim-cabinet corner,black
38 240313701 A B Bracket-upper hinge
40 240354404 A B Cover-upper hinge,black
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
42 240315301 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 218362500 A B Screw,hex washer head ,8-18AB x 1.250
56 240516501 A B Pin-lower hinge
58 5303001343 A B Screw,hex washer head ,8-15A x 0.500
59 240442703 A B Screw-#10-32 X 3/4,black
72 240368203 A B Grille/Kickplate,black
81 5308016566 A B Screw,hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326115 A B Cover-access,with label
89* 241500301 A B Screw,hex washer head ,8-18AB x 0.500
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 218990901 A B Clip-wire
* 240479601 A B Plug,button ,cab liner holes
* 5303305345 A B Paint,touch-up ,black
CABINET

SHELVES

5995374633
A = FRT21R7AS (FRT21R7ASB2)
B = FRT21R7AS (FRT21R7ASB5)
POS. NO PART NO DESCRIPTION
10 215667501 A B Tray,ice cube ,plastic
11 240358003 A B Shelf,freezer ,full-width ,wire
11* 5303299664 A B Spacer,shelf
12 240417802 A B Diffuser-air,top
13 240362601 A B Diffuser,air ,bottom
13* 240466001 A B Seal,air diffuser
14 # 240505801 A B Switch,light/lamp
15 240436701 A - Light Bulb/Lamp, A-15,frosted,40 W,120 V,miniature
15 240436702 - B Light Bulb/Lamp, A-15,clear, 40 W, 120 V,miniature
16 241500701 A B Socket-light/lamp
17 240407301 A B Control Box
17*# 240388701 A B Wiring Harness,control box
18 240360801 A B Knob,temp control
21 # 5304421256 A B Control,temperature
22A 240468201 A B Tube, sensor sleeve, 31 inch, plastic, white
23 # 215846606 A B Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min
23* 5303001259 A B Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 240355214 A B Shelf-"Spill-Safe",cantilever ,fixed
25 240364718 A B Cover-crisper pan
25B 240361201 A B Control-humidity
25C 240361301 A B Damper,humidity cont.
26 240343803 A B Pan,crisper ,(2)
28 3201150 A B End Cap,freezer shelf ,protector
31 240530903 A B Pan-meat,w/o graphics ,clear
34 240385201 A B Container,ice bin
42 240356501 A B Hanger-meat pan,RH
42 240365401 A B Hanger-meat pan,LH
47 240350654 A B Insert-pan cover,glass
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
120 240366401 A B Guide-follower,cam follower
121 240366602 A B Cam Follower
122 240366501 A B Cam,damper
123 215005100 A B Screw,hanger/rlr mtg ,8-10 x 0.438
130 240366101 A B Damper-control box
130* 218249806 A B Seal,insulation ,foam ,damper
131 240366201 A B Retainer-damper,damper
132 240366302 A B Control Rod,damper
* 3205266 A B Edge Protector,wiring harness
SHELVES

SYSTEM

5995374633
A = FRT21R7AS (FRT21R7ASB2)
B = FRT21R7AS (FRT21R7ASB5)
POS. NO PART NO DESCRIPTION
1 # 240444401 A B Condenser,dynamic
4 # 218944001 A B Drier-filter,R134a System
6 # 240496101 A B Wiring Harness, machine compt, w/electric cord
6* # 240388701 A B Wiring Harness,control box
6* # 240385402 A - Wiring Harness,freezer section
6* # 240524701 - B Wiring Harness,freezer section
14 # 5303918247 A B Defrost Heater Kit
15 # 5303918250 A - Evaporator Kit
15 # 5303918274 - B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240434002 A B Trough-drain
18 240362301 A B Insulation,evap block ,foam ,RH
20 240362401 A - Insulation Block,LH
20 240518401 - B Insulation,evap block ,foam ,LH/RH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330006 A B Plate-compr mtg
22* 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B Grommet-compr mtg,(4)
25 240491501 A B Screw-compressor mtg, 1/4-28 x 1.16,shoulder,typ CF
26 240332602 A B Pan-defrost drain
29 # 5303918264 A B Compressor,w/electricals
30 # 218721120 A B Starter,PTC
32 240493301 A B Clamp, elec cont mtg, compressor, bale wire
34 240405201 A B Grommet,rubber ,black ,cond tube/wire
41 218897001 A B Screw,hex washer head ,8-32 x 1/4
44 215174700 A B Clamp-service cord, strain relief, galv steel
45 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
55 # 218909901 A B Capacitor-run,220 VAC ,15 microfarad
57 240403601 A B Clip-wiring harness
57* 218709100 A B Screw, hex head, 10-32 x 0.500
58 215004600 A B Screw, hx wshr hd, 8-36 x 7/16, cond fan motor,(2)
59 240315501 A B Shroud-cond fan
59* 240346701 A B Tape-foam seal,shroud
59* 240359401 A B Screw-fan shroud,(2)
59A 240346501 A B Bracket-support,cond mtr ,(3)
59B 240346601 A B Grommet-bracket,(3)
60 # 240334001 A B Motor,condenser fan
61 # 240315401 A B Fan Blade,galv steel ,condenser fan
61A 215004700 A B Nut,speed
61B 215004800 A B Grommet-silencer
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B Tube-drain,rubber ,lower
85 240493101 A B Tube-connector,suction
86 240409302 A B Spacer-cond tube,black
* 240396801 A B Clamp, tube/wiring, nylon, black/natural
* 5308000039 A B Screw, hex washer hd, 8-32CA x 0.500, serrated head
* # 5303918210 A B Heat Exchanger Kit,suction line
* # 5304421289 A B Hot Tube Repair Kit,Service
SYSTEM

WIRING SCHEMATIC

5995374633
WIRING DIAGRAM
