Frigidaire FSC23F7D Instruction Manual

E23CS75DSS0.eps N58FCFEFA0.eps N58RCFCHA0.eps N58BABAAD0.eps
N58SEHLBC1.eps N58TBAAAB1.eps N58CAAAAC1.eps N58XEAAAA0.eps
N58YDAAACO.eps N58I115T.eps W241516401A.eps S241516401A.eps
Product No. FSC23F7DB3 FSC23F7DW3
Series counter depth counter depth
Color black white
Volts 115 115
Wiring Diagram 241516401A 241516401A
Owner's Guide 241540301 241540301
Market North America North America
Energy Guide 240598639 240598639
Service Data Sheet 241532603 241532603
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995435632
05/04/27
(EN/SERVICE/DCS)
357
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23F7D
Copyright ©All rights reserved.

Publication No: 5995435632 FSC23F7D
04/05 2
FREEZER DOOR
68
5
22C
22A
21A
13A
11
4B
4B
4B
N58FCFEFA0
1
21C
21
21
21
21C
21C
21
74
74
74
72
72
73
73
73
18
37

FSC23F7D Publication No: 5995435632
# Functional Parts 3 04/05
* Non-Illustrated Parts
FREEZER DOOR
Model Index: AFSC23F7D (FSC23F7DB3)
BFSC23F7D (FSC23F7DW3)
POS. NO PART NO. DESCRIPTION
1 # 241510204 A - Gasket-frzr door, black, magnetic
1 # 241510202 - B Gasket-frzr door, white, magnetic
4B 241511602 A B Bin-door
5 241545001 A B Bin-tilt out, tilt-out
11 240554271 A - Door-frzr, black, complete assy
11 240554270 - B Door-frzr, white, complete assy
13A 240537106 A - Door Stop, black, frzr
13A 240537102 - B Door Stop, white, frzr
18 240359108 A - Handle-door, black, LH
18 240359106 - B Handle-door, white
21 218781100 A B Screw, pan head, 8-18 x 0.625
21A 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
21C 240521302 A B Screw, #8-18 x 3/4
22A 240328204 A - Bearing-hinge(frz), black, closer
22A 240328202 - B Bearing-hinge(frz), closer
22C 240328404 A - Bearing-hinge, black, upper
22C 240328402 - B Bearing-hinge, natural, upper
37 240359203 A - Trim-handle, 30.13", black, lower
37 240359201 - B Trim-handle, 30.13", white, lower
68 241525101 A B Chute-ice
72 240421701 A B Button-handle mtg, dovetail
73 218396700 A B Block-handle mtg, dovetail
74 215503200 A B Screw, cr pan hd, 10-16 x 0.500
* 240352102 A B Connector-water, straight
* 240552102 A B Harness-wiring, door
* 5303918256 A B Dispenser heater kit

Publication No: 5995435632 FSC23F7D
04/05 4
REFRIGERATOR DOOR
70
49A
49
48
7
6
5
21A
22
13
15
22B
2
N58RCFCHA0
50
21
21
21
21C
21C
21
74
74
74
72
72
73
73
73
18
37
12
27A

FSC23F7D Publication No: 5995435632
# Functional Parts 5 04/05
* Non-Illustrated Parts
REFRIGERATOR DOOR
Model Index: AFSC23F7D (FSC23F7DB3)
BFSC23F7D (FSC23F7DW3)
POS. NO PART NO. DESCRIPTION
2 # 241510203 A - Gasket-refr door, black, magnetic
2 # 241510201 - B Gasket-refr door, white, magnetic
5 241516102 A B Rack-can
6 241515901 A B Lug-dairy compartment
7 241515601 A B Door-dairy
12 240449710 A - Nameplate
12 240449708 - B Nameplate
13 240537105 A - Door Stop, black, ref
13 240537101 - B Door Stop, white, ref
15 241534505 A - Door-refr, complete assy
15 241534504 - B Door-refr, white, complete assy
18 240359103 A - Handle-door, black, RH
18 240359101 - B Handle-door, white
21 218781100 A B Screw, pan head, 8-18 x 0.625
21A 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
21C 240521302 A B Screw, #8-18 x 3/4
22 240328203 A - Bearing-hinge, black, closer
22 240328201 - B Bearing-hinge(ref), closer
22B 240328403 A - Bearing-hinge, black, upper
22B 240328401 - B Bearing-hinge(ref), natural, upper
27A 240396102 A B Retainer, tall bottle
37 240359203 A - Trim-handle, 30.13", black, lower
37 240359201 - B Trim-handle, 30.13", white, lower
48 241511701 A B Bin-door, ref
49 241505301 A B Bin-door, 2-liter
49A 241505501 A B Bin-door, gallon
50 241508401 A B Cover-magnet
70 241515801 A B Compartment-dairy, removable
72 240421701 A B Button-handle mtg, dovetail
73 218396700 A B Block-handle mtg, dovetail
74 215503200 A B Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995435632 FSC23F7D
04/05 6
CABINET
100
92
92
90
89
83
82
81
81
72
66
54
53
52
50
47
45
45
45
45
45
45
45
43
42
42
41
38
38
37
37
28
30A
30
23
23
22
22
21C
21C
11
10A
10
N58BABAAD0
14A
58
58
40
40

FSC23F7D Publication No: 5995435632
# Functional Parts 7 04/05
* Non-Illustrated Parts
CABINET
Model Index: AFSC23F7D (FSC23F7DB3)
BFSC23F7D (FSC23F7DW3)
POS. NO PART NO. DESCRIPTION
10 241509802 A B Cover-air duct
10A 240475907 A B Cover-evap coil, lower
11 5303208309 A B Plug-hole, factory test
14A 241547901 A B Switch-light/lamp, frzr door
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 240457702 A - Plate-door closer
22 240457701 - B Plate-door closer
23 240402701 A B Screw-#10-32 x 1/4 flat hd
28 240335501 A B Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240419101 A B Bracket-lower hinge, ref
30A 240419102 A B Bracket-lower hinge
37 240337603 A - Trim-cabinet corner, black, (2)
37 240337601 - B Trim-cabinet corner, white, (2)
38 240327201 A B Bracket-upper hinge
40 240327007 A - Cover-upper hinge, black
40 240327005 - B Cover-upper hinge, white
41 241550801 A B Grommet-shelf mtg, 1.40" long
41* 241550701 A B Grommet-shelf mtg, .96" long
42 240578901 A B Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B Roller Assy, front, (2)
45 241500301 A B Screw, hex washer head, 8-18AB x 0.500
47 241513001 A B Channel-shelf mtg, side, (2)
50 241511101 A B Board-main power
50* 241524801 A B Seal-Mother Board Housing
50* 241532501 A B Clip-harness
52 241524802 A B Seal, housing
53 241509101 A B Bracket
54 241532401 A B Channel
58 218781100 A B Screw, pan head, 8-18 x 0.625
66 241513601 A B Damper Assy
72 241521610 A - Grille/Kickplate, black
72 241521608 - B Grille/Kickplate, white
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574602 A B Cover access
90 218249808 A B Seal-coil cover
92 216850900 A B Screw, hex washer hd, 1/4 x 7/8, hinge mtg
100 240423701 A B Support, crisper cover, front, (4)
100* 240350802 A B Support, crisper cover, rear, (4)
* 240479601 A B Plug, button, cab liner holes, (2)
* 241591701 A B Louver
* 5303305345 A - Paint, touch-up, black
* 5303305324 - B Paint, touch-up, white

Publication No: 5995435632 FSC23F7D
04/05 8
SHELVES
52
49B
51
2
N58SEHLBC1
24B
24
140
25
26
47
25A
27
47A
49
2
26A
26A
52
101
101
51
100
81
109 15A
16A
97
11
11
39
39
126
81
81
126
120
24B
52A
11A
51A
39
122
121
136
62
47B
25B
41
66

FSC23F7D Publication No: 5995435632
# Functional Parts 9 04/05
* Non-Illustrated Parts
SHELVES
Model Index: AFSC23F7D (FSC23F7DB3)
BFSC23F7D (FSC23F7DW3)
POS. NO PART NO. DESCRIPTION
2 241510605 A B Trim-basket
11 240443357 A B Shelf-freezer, glass, lower
11A 240443358 A B Shelf-freezer, glass, upper
15A 241552801 A B Light Bulb
16A 241507803 A B Socket-light
16A* 241523201 A B Harness-wiring
24 240355240 A B Shelf-"Spill-Safe", fixed, (3)
24B 240350129 A B Shelf-"Spill-Safe", cantilever, sliding
25 240599301 A B Cover-crisper pan, upper
25* 240362101 A B Clip-slide, cover-crisper
25A 240350902 A B Cover-crisper pan, lower
25B 240599801 A B Cover-meat pan
26 240351005 A B Pan-crisper, upper
26* 240349801 A B Clip-slide, pan-crisper
26A 240362201 A B Control-humidity
27 240351205 A B Pan-crisper, lower
39 240367603 A B Trim-shelf, 11.65", front
41 241571201 A B Trim-shelf, rear
47 240350633 A B Insert-pan cover, glass
47A 240350603 A B Insert-pan cover, glass
47B 240443360 A B Insert-pan cover, glass
49 241515001 A B Basket-sliding
49B 241514901 A B Basket-sliding, upper, full
51 241514501 A B Hanger-basket, RH
51A 241514701 A B Hanger-shelf glass, RH
52 241514601 A B Hanger-basket, LH
52A 241514801 A B Hanger-shelf glass, LH
62 240599701 A B Pan-meat
66 5303295947 A B Rack-wine
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
97 241532002 A B Water Tank
100 241549901 A B Cover-water tank
101 218493100 A B Screw, hex washer head, 8-18AB x 1-3/4
109 241513202 A B Base-crisper light socket
120 241504501 A B Shelf-ice cream
121 241504701 A B Rail-ice cream shelf, LH
122 241504702 A B Rail-ice cream shelf, RH
126 241630701 A B Channel, auger mtg, LH
126 241630702 A B Channel, auger mtg, RH
136 240424502 A B Dispenser-can, clear
140 240430504 A B Channel, wtr tube cover

Publication No: 5995435632 FSC23F7D
04/05 10
CONTROLS
201
199
198
151
149
139
138
137
116
115
81
81
81
75
61
60
23
22
21
17
16
15
15
14
13
9
8
5
N58TBAAAB1
54
53
52
50
