Frigidaire FRS22ZGGB2 Instruction Manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRS22ZGGB2 FRS22ZGG R134a black 115
FRS22ZGGD2 FRS22ZGG R134a almond 115
FRS22ZGGW2 FRS22ZGG R134a white 115
Publication No.
5995310322
980713
-EN/SERVICE /JLT
357
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS22ZGGB2
FRS22ZGGD2
FRS22ZGGW2
©1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
SIDE BY SIDE
REFRIGERATOR
WIRING DIAGRAM - # 218875901
OWNER’S GUIDE - # 218851800A
SERVICE DATA SHEET - # 218877000
101 Masters Blvd.
Anderson, SC 29624

07/98 2
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
FREEZER DOOR

# = Fast-moving Parts 3 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
FREEZER DOOR
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
1 # 215734323 A - - Gasket-frzr door,black ,magnetic
1 # 215734303 - B - Gasket-frzr door,almond ,magnetic
1 # 215734313 - - C Gasket-frzr door,white ,magnetic
5 5303288950 A B C Support-door rack,RH/LH
6 5303323484 A B C Support-door rack,white ,LH
6A 5303323485 A B C Support-door rack,white ,RH
8 218807025 A B C Rack-door,w/end caps
8A 215474038 A B C Rack-door
9 218510601 A B C Panel-inner door,frzr
11 5303917664 A - - Panel-frzr door,black ,w/foam insulatn
11 5303917663 - B - Panel-frzr door,almond ,w/foam insulatn
11 5303917662 - - C Panel-frzr door,white ,w/foam insulatn
13 5303289522 A B C Door Stop
18 218025205 A - - Handle-door,metallic gray ,soft grip
18 218025204 - B - Handle-door,almond ,soft grip
18 218025201 - - C Handle-door,white ,soft grip
21 5303001001 A B C Screw,hx wshr hd sems ,8-15A x 0.625
21A 218578600 A B C Screw-door stop mtg,phl truss hd ,
10-16 x 3/4
22A 215615300 A B C Bushing-door,bronze
* 215598900 A B C Washer-flat,.691x1x.05,zinc ,
I&W hinge brkt
23 5303001020 A B C Screw,cr flat head ,8-32D x 1/2
37 215867066 A - - Trim-handle,metallic gray ,upper ,
w/dec gold band,and snap lock
37 215867065 - B - Trim-handle,almond ,upper ,
w/dec gold band,and snap lock
37 215867064 - - C Trim-handle,white ,upper ,
w/dec gold band,and snap lock
37A 215867063 A - - Trim-handle,metallic gray ,lower ,
w/dec gold band,and snap locks
37A 215867062 - B - Trim-handle,almond ,lower ,
w/dec gold band,and snap locks
37A 215867061 - - C Trim-handle,white ,lower ,
w/dec gold band,and snap locks
37A* 215782300 A B C Lock-handle trim,snap-in
37A* 215940700 A B C Lock-handle trim,stick-on
37A* 218676003 A B C Band-decorative,gold
47 218849901 A B C Harness-wiring,frzr door
58 218749600 A B C Screw,#10 pan hd ,8-18 x .5
68 218020600 A B C Chute-ice
140 218518700 A B C Elbow-water tube
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)

07/98 4
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
REFRIGERATOR DOOR

# = Fast-moving Parts 5 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
2 # 215734324 A - - Gasket-refr door,black ,magnetic
2 # 215734304 - B - Gasket-refr door,almond ,magnetic
2 # 215734314 - - C Gasket-refr door,white ,magnetic
3 215390401 A B C Panel-inner door,refr
4 218807018 A B C Rack-door,w/end caps
5 5303288950 A B C Support-door rack,RH/LH
7 5304404909 A B C Door-dairy
12 218364006 A - - Frame-nameplate,black
12 218364005 - B - Frame-nameplate,almond
12 218364004 - - C Frame-nameplate,white
12* 215008606 A - - Label-nameplate,black
12* 215008605 - B - Label-nameplate,almond
12* 215008604 - - C Label-nameplate,white
12* 5315340712 A B C Tape,adhesive ,12" long ,foam ,
double-faced
13 5303289522 A B C Door Stop
15 5303917510 A - - Panel-refr door,black ,w/foam insulatn
15 5303917499 - B - Panel-refr door,almond ,w/foam insulatn
15 5303917498 - - C Panel-refr door,white ,w/foam insulatn
18 218025205 A - - Handle-door,metallic gray ,soft grip
18 218025204 - B - Handle-door,almond ,soft grip
18 218025201 - - C Handle-door,white ,soft grip
21 5303001001 A B C Screw,hx wshr hd sems ,8-15A x 0.625
21A 218578600 A B C Screw-door stop mtg,phl truss hd ,
10-16 x 3/4
22 5303289320 A B C Bearing-hinge
22* 3051070 A B C Screw,hex washer head ,10-24 x 7/16 ,
special
26 3204522 A B C Container-egg
27 218370101 A B C Snugger-door bin,"paddle type" ,
gallon door bin
27A 218714201 A B C Retainer,tall bottle
37 215867066 A - - Trim-handle,metallic gray ,upper ,
w/dec gold band,and snap lock
37 215867065 - B - Trim-handle,almond ,upper ,
w/dec gold band,and snap lock
37 215867064 - - C Trim-handle,white ,upper ,
w/dec gold band,and snap lock
37A 215867063 A - - Trim-handle,metallic gray ,lower ,
w/dec gold band,and snap locks
37A 215867062 - B - Trim-handle,almond ,lower ,
w/dec gold band,and snap locks
37A 215867061 - - C Trim-handle,white ,lower ,
w/dec gold band,and snap locks
37A* 215782300 A B C Lock-handle trim,snap-in
37A* 215940700 A B C Lock-handle trim,stick-on
37A* 218676003 A B C Band-decorative,gold
49 218592307 A B C Bin-door,gallon ,with trim
58 218749600 A B C Screw,#10 pan hd ,8-18 x .5
76 218423700 A B C Rack-microwave dish
77 218423501 A B C Dish-microwave,(2)
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,
low profile
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)
REFRIGERATOR DOOR

07/98 6
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
CABINET

# = Fast-moving Parts 7 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
10 215637602 A B C Cover-air duct
10* 5303209814 A B C Nut,"U" type ,8-15(A) ,fan mtr mtg
10A 215637401 A B C Cover-evap coil,lower
11 5303208309 A B C Plug-hole,factory test
12 215230400 A B C Plug-harness hole
15A 218708700 A B C Light Bulb/Lamp,crisper light ,(2)
16A 5303299157 A B C Socket-light/lamp,crisper light
18 5303289043 A B C Support-air duct cvr,2.55" long
18* 5303289044 A B C Support-air duct cvr,1.83" long
28 5303289062 A B C Bolt-roller adj,hex head ,5/16-24 x 7/8
29 215003200 A B C Washer,.40 x .63 x .16 ,nylon
29 215314301 A B C Washer,.40 x .75 x .06 ,nylon
30 5303289060 A B C Bracket-lower hinge,w/hinge pin
30* 218730800 A B C Tapping Plate,RH
30A 215009000 A B C Bracket-lower hinge,LH ,w/hinge pin
30A* 218730700 A B C Tapping Plate,LH
* 218730900 A B C Washer
37 5303321083 A - - Trim-cabinet corner,black
37 5303321082 - B - Trim-cabinet corner,almond
37 5303321081 - - C Trim-cabinet corner,white
38 218215214 A - - Bracket-upper hinge,with closer ,black ,RH
38 218215216 A - - Bracket-upper hinge,with closer ,black ,LH
38 218215221 - B - Bracket-upper hinge,with closer ,almond
38 218215223 - B - Bracket-upper hinge,with closer ,almond
38 218215213 - - C Bracket-upper hinge,with closer ,white ,RH
38 218215215 - - C Bracket-upper hinge,with closer ,white ,LH
40 218374409 A - - Cover-upper hinge,black
40 218374408 - B - Cover-upper hinge,almond
40 218374407 - - C Cover-upper hinge,white
43 218615300 A B C Roller Assy,front ,(2)
43* 5308017044 A B C Screw-roller mtg,spcl ind hex hd ,5/16-18(23)x7/8
44 218738300 A B C Roller Assy,rear ,(2)
47 218659500 A B C Channel-shelf mtg,side ,(2)
52 215454600 A B C Tube-water inlet
58 5308002748 A B C Screw,hex wshr hd ,8-15A x 0.500 ,special
66 215050201 A B C Damper-meat keeper
66A 218171301 A B C Cover-meat kpr dmpr
71 218515401 A B C Clip-grille
72 218359609 A - - Grille/Kickplate,black
72 218359605 - B - Grille/Kickplate,almond
72 218359601 - - C Grille/Kickplate,white
77 5303001216 A B C Washer-nylon,3/16 x 5/8 OD
78 5303274237 A B C Screw-bracket,hex wshr hd ,8-32CA x 0.500
80 218249802 A B C Seal-coil cover,(2)
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
85 218359805 A - - Cover-lower hinge,black
85 218359803 - B - Cover-lower hinge,almond
85 218359801 - - C Cover-lower hinge,white
89 215176300 A B C Cover-machine compt
90 215022602 A B C Seal-foam
90* 5303322647 A B C Tape-foam
91 218836401 A B C Deflector-air,ice maker
92 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875
100 5303288973 A B C Support-pan cover
101 215305702 A B C Seal-foam
107 218835901 A B C Shield-light,crisper
108 218834202 A B C Cover-wiring,crisper light
* 5303001038 A B C Washer,.28 x .62 x .19 ,nylon
* 5303305345 A - - Paint,touch-up ,black
* 5303305325 - B - Paint,touch-up ,almond
* 5303305324 - - C Paint,touch-up ,white
* 5308016571 A B C Plug-button,cabinet liner
CABINET

07/98 8
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
SHELVES

# = Fast-moving Parts 9 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
2 218383601 A B C Handle-frzr basket
11 218298001 A B C Shelf-freezer,sliding ,wire
11A 218298002 A B C Shelf-freezer,sliding ,wire
11C 218815501 A B C Shelf-pizza,24B
24 215406135 A B C Shelf-"Spill-Safe",fixed
25 218147701 A B C Cover-storage pan
25* 5303289586 A B C Trim-storage pan cvr,lower
25* 5303307878 A B C Trim-storage pan cvr,upper ,w/humidity hole
25* 5303307881 A B C Control-humidity
26 5303289500 A B C Pan-storage,upper
26A 5303289501 A B C Pan-storage,lower
39 215217543 A B C Trim-frzr shelf
42 215002301 A B C Hanger-pan/tray,LH
42* 215002401 A B C Hanger-pan/tray,RH
46 218278201 A B C Front-storage pan,upper
46A 218278202 A B C Front-storage pan,lower
47 215723574 A B C Insert-pan cover,glass ,clear ,w/teal graphics
47A 5303289387 A B C Insert-pan cover,glass ,clear
49 218384702 A B C Basket-sliding,(3)
51 5303288960 A B C Hanger-basket,RH
51A 5303301454 A B C Hanger-basket,RH
52 215162501 A B C Hanger-basket,LH,with/spring
52A 215162503 A B C Hanger-basket,LH ,with spring
57 5303271653 A B C Ferrule-inner
62 218285701 A B C Tray-deli
66 5304402116 A B C Rack-wine
67 218278501 A B C Front-deli tray
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
96 215192600 A B C Support-water tank
97 218871301 A B C Water Tank
98 5308015614 A B C Connector-tube
99 5300186057 A B C Grommet-tank
101 215005000 A B C Screw,hex wshr hd ,8-18AB x 0.750 ,gusset/hanger
123 215005100 A B C Screw-roller/hanger,8-10 x .438
126 218867401 A B C Channel,auger mtg ,LH
126 218867402 A B C Channel,auger mtg ,RH
129 5303299152 A B C Roller-hanger
129* 5303299153 A B C Bearing-roller
* 215328300 A B C Clip-shelf
SHELVES

07/98 10
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
CONTROLS

# = Fast-moving Parts 11 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
2 5303307883 A B C Knob-damper control,white/teal line
5 # 5308000010 A B C Fan Blade,red
7 5308000124 A B C Ring-fan orifice
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303205118 A B C Bracket-motor mtg,front
12 215809600 A B C Diffuser-air
13 # 215426200 A B C Motor-evap fan
13* 215474201 A B C Washer,"slinger" ,nylon ,evap fan shaft
14 5303205119 A B C Bracket-motor mtg,rear
15 5303001179 A B C Light Bulb/Lamp,40 W
16 5303289050 A B C Socket-light/lamp
17 218468701 A B C Control Box,refr ,w/light tunnel
17A 5303296581 A B C Control Box,frzr
* 215188300 A B C Screw-control box mtg,hex head ,8-15A x 1.000,refr/frzr
18 5303307882 A B C Knob-temp control
20 5303307884 A B C Label-control box,refr
20A 5303307888 A B C Label-control box,frzr
21 # 5303300027 A B C Control-temperature
22 5303319683 A B C Housing-temp sensor,plastic
22* 218731102 A B C Tube,insulator ,PVC ,white ,on temp sensor
23 # 5303321133 A B C Timer-defrost
23* 215277000 A B C Cover-defrost timer,top
23* 5303001259 A B C Screw-timer mtg,pan hd ,6-20 x 0.438
23* 5303289058 A B C Shield-defrost timr,btm
41 5308000039 A B C Screw,hex wshr hd ,8-32CA x 0.500 ,serrated head
53 215809508 A B C Box-damper control
65 5303001361 A B C Pin-mounting,push-in ,plastic
75 218465101 A B C Shield-light,refr
76 218225800 A B C Cover-light socket
78 5303274237 A B C Screw-bracket,hex wshr hd ,8-32CA x 0.500
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C Bracket-connector
111 5303289024 A B C Wireway,frzr
112 215277101 A B C Rod-damper extn
113 5303289047 A B C Cover-dmpr rod ext
114# 5303289051 A B C Switch-light/lamp,white
115 215011503 A B C Damper Assy,w/seal
116 215011400 A B C Seal-damper,foam
125 215334201 A B C Switch-auger kill,white
137# 218710901 A B C Filter-water,carbon ,with o’rings ,and wrench
* 218710300 A B C Wrench-filter
138 218657401 A B C Cup-water filter
138* 218720100 A B C O’ring,wtr filter cup
139 218657500 A B C Housing-water filtr
140 218518700 A B C Elbow-water tube
142 218657701 A B C Knob-indicator,filter replment
143 218696700 A B C Heater-water filter
* 218646000 A B C Harness-wiring,filter heater
CONTROLS

07/98 12
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
SYSTEM

# = Fast-moving Parts 13 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
1 218787800 A B C Condenser
1* 5303208866 A B C Spacer-tube
1* 5303289026 A B C Spacer-tube
2 5303289029 A B C Clip-cond mtg,(4)
3 218679603 A B C Block-evap coil,styrofoam ,(2)
4 # 218541000 A B C Drier-filter
5 218646100 A B C Harness-wiring,main
5* 215005200 A B C Harness-wiring,refr controls
5* 218463600 A B C Harness-wiring,crisper lights
5* 218646000 A B C Harness-wiring,filter heater
5* 218815101 A B C Harness-wiring,frzr controls
6 218872701 A B C Harness-wiring
7 215459201 A B C Cord-electric power
8 218803400 A B C Cover-wiring
8* 218754500 A B C Screw,hex hd ser wshr ,#8-18 x 3/8
13 # 215746800 A B C Heat Exchanger,suction line
14 # 218169802 A B C Heater-defrost
15 # 218691301 A B C Evaporator,R134a System
15* 3206414 A B C Tube-inlet
16 5308000110 A B C Strap-evap/heater,aluminum
17 5303289496 A B C Insulator-evap
19 218631200 A B C Tube,rubber
21 # 218673001 A B C Thermostat-defrost
22 218811100 A B C Base-compressor mtg,(drain pan)
22* 3051070 A B C Screw,hex washer head ,10-24 x 7/16 ,special
23 218513300 A B C Grommet-compr mtg,(4)
25 218773500 A B C Screw-compressor mtg,hex washer head ,10Bx11/4
29 # 5303917934 A B C Compressor,R134a System ,w/electricals
30 # 216008904 A B C Starter-PTC
31 # 5303321892 A B C Overload Protector
32 218762900 A B C Wire-bale
41 5308000039 A B C Screw,hex wshr hd ,8-32CA x 0.500 ,serrated head
43 215174700 A B C Clamp-service cord,strain relief ,galv steel
43* 5303001199 A B C Clamp-wiring harness,strain relief ,galv steel
45 5303001343 A B C Screw,hex wshr hd ,8-15A x .5 ,spec
45* 218769200 A B C Screw,hx wshr hd spec ,#6-32 x .5
45* 5300141713 A B C Screw,hex wshr hd ,8-32 x .625 ,spec
49 215506900 A B C Bracket-evap mtg
54 5303289027 A B C Rail-cabinet base,rear
54A 5303289311 A B C Rail-compr support
54B 5303289292 A B C Rail-cabinet base,front
55 # 218764601 A B C Capacitor-run
56 218769300 A B C Insert-compressor mtg
57 218247300 A B C Clip-wiring harness
58 215004600 A B C Screw-cond fan mtr,hx serr wshr hd ,8-36 x 7/16,(2)
59 5303289031 A B C Shroud-cond fan mtr
60 5303207328 A B C Screw,hex wshr hd ,8-15A x 1
60 # 215501901 A B C Motor-condenser fan
61 5303289032 A B C Blade-cond fan
61* 215004700 A B C Nut,speed
61* 215004800 A B C Grommet-silencer
62 215048701 A B C Trough-drain,w/shield assy ,& #17 insulator
64 5303289063 A B C Tube-drain
65 5303289301 A B C Spacer-tube
70 5303289041 A B C Bracket-evap/cvr mtg
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625 ,
low profile
* 5303917166 - - - Hot Tube Repair Kit,Service
SYSTEM

07/98 14
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
DISPENSER

# = Fast-moving Parts 15 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
1 5318582501 A B C Tube-water inlet,93" ,plastic ,
cut-to-size
1* 218832201 A B C Tube-water inlet,filter ,
to filter valve,w/elbow
1* 218859801 A B C Tube-water inlet,inlet valve ,to filter
1* 215294101 A B C Tube-water inlet,formed ,plastic ,
dispenser
2 218505303 A - - Deflector-ice disp,black
2 218505302 - B - Deflector-ice disp,almond
2 218505301 - - C Deflector-ice disp,white
3 # 215484300 A B C Heater-door housing
4 218432103 A - - Housing-dispenser,black
4 218432102 - B - Housing-dispenser,almond
4 218432101 - - C Housing-dispenser,white
7 # 218284800 A B C Switch-actuator,micro
7* 215944300 A B C Shield-micro switch
8 218505201 A B C Module-dispenser
10 218209800 A B C Spring,dispenser door
12 215766503 A - - Knob-selector,black
12 215766502 - B - Knob-selector,almond
12 215766501 - - C Knob-selector,white
13 215748101 A B C Ring-snap,actuator
14 218416162 A - - Label-module cover,black
14 218416161 - B - Label-module cover,almond
14 218416160 - - C Label-module cover,white
15 218284900 A B C Light Bulb/Lamp,4 W ,115 V
16 215284900 A B C Socket-light/lamp
17 215794400 A B C Screw,#6 x 1/4
17A 215840700 A B C Screw,truss head ,6-20 x 3/8
17A* 215923400 A B C Washer-flat
23 5303299660 A - - Drip Tray,black
23 5303297845 - B - Drip Tray,almond
23 5303297844 - - C Drip Tray,white
24 218796503 A - - Actuator Assy,black
24 218796502 - B - Actuator,almond
24 218796501 - - C Actuator,white
26 215503200 A B C Screw,cr pan hd ,10-16 x 1/2 ,
spec/hi-lo
27 218432600 A B C Cam-slide
27A 218814901 A B C Rocker-switch
28 218700603 A - - Cover-module,black
28 218700602 - B - Cover-module,almond
28 218700601 - - C Cover-module,white
30 215753600 A B C Door Assy-ice chute,w/gasket,insul
33 # 218849801 A B C Heater-disp throat
35 # 218740003 A B C Heat Motor,115V
36 218432400 A B C Cover-selector sw
38A# 218479900 A B C Switch-micro
38B# 218835401 A B C Switch-micro
39 218284600 A B C Wire-ice door
40 218284500 A B C Yoke-heat motor
41 215765400 A B C Spring-actuator
43 215760300 A B C Screw,#4 x 3/8
49 215794000 A B C Bracket-heat motor
56 218434300 A B C Screw-micro switch,pan head ,
4-24 x 9/16
61 215766000 A B C Ring-retainer,micro switch
82 215296300 A B C Screw,plask h/l ,#6 x 3/8
* 215781700 A B C Clip-tube
* 218432502 A B C Harness-wiring,disp
* 5300460947 A B C Tape-I&W dispenser,double faced ,foam ,
60 x1-1/4 x1/32,(2)
DISPENSER

07/98 16
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
ICE CONTAINER

# = Fast-moving Parts 17 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
2 5304404344 A B C Auger-ice
3 5304404343 A B C Cam-drive
4 218815300 A B C Container-ice
6 5304404346 A B C Drum-ice disp
7 218815400 A B C Front-ice container
10 5304404337 A B C Bar-drive
13 5304404359 A B C Gate
15 5303001179 A B C Light Bulb/Lamp,40 W
16 5303289050 A B C Socket-light/lamp
17 5304404345 A B C Drive Blade
18 # 5304404330 A B C Motor-auger
18* 5304404335 A B C Harness-wiring,auger motor
20 5304404974 A B C Cover-motor
21 215285100 A B C Nut-drive
23 5304404347 A B C Plate-front
25 5304404362 A B C Screw
26 215503200 A B C Screw,cr pan hd ,10-16 x 1/2 ,
spec/hi-lo
33 5304404351 A B C Spacer
34 5304404349 A B C Spacer
35A 5304404353 A B C Fixed Blade,round
35B 5304404352 A B C Fixed Blade,square
37A 5304404348 A B C Blade-crusher,#1
37B 5304404350 A B C Blade-crusher,#2
37C 5304404356 A B C Blade-crusher,#3
39 5304404365 A B C Screw
41 5304404358 A B C Housing-crusher
44 218359200 A B C Screw,pan head ,8-32 x .25
45 # 5304404333 A B C Solenoid Assy
46 5304404341 A B C Control Rod
47 5304404342 A B C Spring-control rod
48 5304404340 A B C Bracket-control rod
48* 5304404364 A B C Screw-bracket
49 5304404329 A B C Rail Assy
50 5304404334 A B C Guide-solenoid
51 5304404336 A B C Rotation Stop
52 5304404354 A B C Spacer-fixed blades
53 5304404355 A B C Pin-spiral,fixed blades
54 5304404357 A B C Nut-auger
55 5304404360 A B C Washer
56 5304404361 A B C E-ring
57 5304404363 A B C Door-access
58 5304404331 A B C Screw-solenoid
* 215781700 A B C Clip-tube
ICE CONTAINER

07/98 18
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
ICE MAKER

# = Fast-moving Parts 19 07/98
* = Non-Illustrated Parts
FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2 Publication No.
5995310322
A = FRS22ZGG (FRS22ZGGB2)
B = FRS22ZGG (FRS22ZGGD2)
C = FRS22ZGG (FRS22ZGGW2)
POS. NO PART NO DESCRIPTION
1 5318582501 A B C Tube-water inlet,93" ,plastic ,
cut-to-size
1* 218832201 A B C Tube-water inlet,filter ,
to filter valve,w/elbow
1* 218859801 A B C Tube-water inlet,inlet valve ,to filter
2 3206348 A B C Spring,shut-off arm
3 3206299 A B C Plate-I.D.
4 3206301 A B C Gear
5 3206303 A B C Plate-mounting
6 3206305 A B C Screw-ground wire,8-32 x 1/4
7 # 3206306 A B C Motor-ice maker
8 3206312 A B C Spacer-holding sw
9 3206313 A B C Cam
10 3206315 A B C Clamp
11 # 3206319 A B C Thermal Cutoff Assy
12 3206321 A B C Connector Plug,wiring harness
12 # 3206349 A B C Harness-wiring,IM internal ,with plug
13 # 3206322 A B C Thermostat Assy,ice maker
14 3206323 A B C Screw-switch mtg,4-24 x 3/4 ,
sw to support,(2)
15 # 3206324 A B C Switch,(3)
16 3206326 A B C Support
17 # 5303320545 A B C Mold-ice maker,with heater ,radius cube
18 3206328 A B C Ejector
19 3206330 A B C Bearing & Inlet
20 3206331 A B C Screw,8-18 x 3/8 ,(2)
21 3206332 A B C Ice Stripper
22 3206333 A B C Arm,shut-off
23 3206334 A B C Screw-sup/mold body,8-18 x 1 ,(4)
24 3206335 A B C Lever-arm
25 3206336 A B C Screw-arm levr/sprt,8-18 x 9/16
26 3206337 A B C Screw-thermo/sprt,4-24 x 3/8 ,(4)
27 3206338 A B C Screw-sw&spcr/plate,4-40 x 1
28 3206339 A B C Screw-timing stop,4-40 x 3/8
29 3206340 A B C Screw-mtr & sw/plate,4-40 x 3/4
30 3206341 A B C Screw-timing,8-32 x 1
31 3206342 A B C Insulator
32 3206343 A B C Plate-valve switch
33 3206344 A B C Spring
34 3206345 A B C Screw-mtg plate/sprt,8-18 x 7/16
35 3206346 A B C Screw-gear/cam,6-20 x 0.437
36 3206347 A B C Cover-complete
37 5303320544 A B C Data Sheet,ice maker
38 5303207445 A B C Envelope-data sheet
44 5308000133 A B C Clamp,nylon ,.75 OD tube
45 5303001343 A B C Screw,hex wshr hd ,8-15A x .5 ,spec
46 5303001193 A B C Clamp-inlet tube,metal
47 5308000205 A B C Adapter-water sply,straight
51 215811600 A B C Tube-fill
55 218832401 A B C Valve-water filter,dual solenoid ,115V ,
w/nut
55* 218873001 A B C Cap-water valve
59 5303001191 A B C Sleeve-tube insert
60 5303207328 A B C Screw,hex wshr hd ,8-15A x 1
61 218721500 A B C Bracket-leveling,ice maker
62 215230500 A B C Screw-bracket mtg,pan head ,
8-32T x 0.375
62 218737900 A B C Screw-IM mtg brkt,hex hd ,#8-32 x 3/8
64 5303001549 A B C Clamp-copper tube,steel
141# 218859701 A B C Valve-water filter,dual solenoid ,115V ,
w/nut
* 215290100 A B C Screw-solenoid valve,hx hd-slot wshr ,
12-24 x 3/4
* 218731600 A B C Nut,7/16 x 20 ,nylon
* 5308000200 A B C Nut,7/16 x 20 ,nylon
* 218836401 A B C Deflector-air,ice maker
ICE MAKER

07/98 20
Publication No. FRS22ZGGB2,FRS22ZGGD2,FRS22ZGGW2
5995310322
WIRING
