Frigidaire PLHT219SCB8 User manual

Top Mount
®
Welcome ....................... 2
Safety Instructio s............ 3
Installation =- _ncludeaConnecting
Optional Ice MakerTo Water Supply ..... 4 = 5
Espafiol ........... 19
Door
Removal & Reversal .......6 -9
Features at a Glance ......... 9
Temperature Controls .... 9 - 10
Looking Inside .......... 10 - 12
Ice Service .............. 12 - 13
Food Storage
& Energy Saving Tips ....... 13
Normal Operating Sounds..14
Care & Cleaning ......... 15 - 16
Warranty ...................... 17
Before You Call ............... 18
READ AND SAVE THESE INSTRUCTIONS P/N2417968o0(loo6)

Congratulations on your purchase of a new refrigerator! We
here at Electrolux Home Products, Inc. are very proud of our
product and we are completly committed to providing you with
the best service possible. Your satisfaction is our #1 priority.
Please read this Use & Care Manual very carefully. It contains
valuable information on how to properly maintain your new
refrigerator.
We know you'll enjoy your new refrigerator and ThankYou for
choosing our product. We hope you consider us for future
purchases.
PLEASE READANDSAVETHESEINSTRUCTIONS
This Use & Care Manual provides specific operating
instructions for your model. Use your refrigerator only as
instructed in this manual. These instructions are not meant to
cover every possible condition and situation that may occur.
Common sense and caution must be practiced when installing,
operating and maintaining any appliance.
Please record your model and serial numbers below for
future reference.This information is found on your serial
plate located inside the refrigerator compartment.
o
iiiiiiiiiii!iiiiiiiiiisiiii, ,!,i
................. -_ii!i!i!i!ii!i_ii
Model Number:
Serial Number:
Purchase Date:
Questions?
1-800-944-9044
(United States)
1-800-668-4606
(Canada)
Extend Your Warranty Protection
With An
Extended Service Contract
CALL 1-800-944-9044
To Enjoy These Benefits:
®
®
Total freedom from repair bills so
unexpected repairs won't upset your budget.
Fast, convenient toll=free service is just a
phone call away.
Top-quality repairs byfactory-trained experts.
Quick access to genuine replacement parts
so you can rest assured your refrigerator is
repaired with the proper components,
Please attach sales receipt
here for future reference.
PLEASE COMPLETE AND MAIL IN THE PRODUCT
REGISTRATION CARD INCLUDED WITHYOUR
REFRIGERATOR.
2

FORYOUR SAFETY
• Do not store or use gasoline, or other flammable liquids
in the vicinity of this or any other appliance. Read product
labels for warnings regarding flammability and other
hazards.
• Do not operate the refrigerator in the presense of
explosive fumes.
Avoid contact with any moving parts of automatic ice
maker.
Remove all staples from the carton. Staples can cause
severe cuts, and also destroy finishes if they come in
contact with other appliances or furniture.
CHILD SAFETY
Destroy or recycle the carton, plastic bags, and any exterior
wrapping material immediately after the refrigerator is
unpacked. Children should NEVER use these items to play.
Cartons covered with rugs, bedspreads, plastic sheets or
stretch wrap may become airtight chambers, and can quickly
cause suffocation.
ELECTRICAL INFORMATION
•The refrigerator must be plugged into its own dedicated
115 Volt, 60 Hz., AC only electric outlet. The power cord
of the appliance is equipped with a three-prong grounding
plug for your protection against electrical shock hazards. It
must be plugged directly into a properly grounded three-
prong receptacle. The receptacle must be installed in
accordance with local codes and ordinances. Consult a
qualified electrician. Do not use an extension cord or
adapter plug.
• If the power cord is damaged, it should be replaced by the
manufacturer, service technician or a qualified person to
prevent any risk.
• Never unplug the refrigerator by pulling on the power
cord. Always grip the plug firmly, and pull straight out
from the receptacle to prevent damaging the power cord.
• Unplug the refrigerator before cleaning and before
replacing a light bulb to avoid electrical shock.
• Performance may be affected if the voltage varies by 10%
or more. Operating the refrigerator with insufficient power
can damage the compressor. Such damage is not covered
under your warranty.
• Do not plug the unit into an outlet controlled by a wall
switch or pull cord to prevent the refrigerator from being
turned off accidentally.
• Avoid connecting refrigerator to a Ground Fault Interruptor
(GFI) circuit.
PROPER DISPOSAL OFYOUR REFRIGERATOR OR
FREEZER
Risk of child entrapment
Child entrapment and
suffocation are not problems of
the past. Junked or abondoned
refrigerators or freezers are still
dangerous - even if they will sit
for "just a few days." If you are
getting rid of your old refrigerator
or freezer, please follow the
instructions below to help
prevent accidents.
Before you throw away your old refrigerator/freezer:
• Remove doors.
• Leave shelves in place so children may not easily climb
inside.
• Have refrigerant removed by a qualified service
technician.

ThisUse&CareManualprovidesspecificoperating
instructionsforyourmodel.Usetherefrigeratoronlyas
instructedinthisUse&CareManual.Beforestartingthe
refrigerator,followtheseimportantfirststeps.
LOCATION
• Choose a place that is near a grounded electrical outlet.
Do Not use an extension cord or an adapter plug.
• If possible, place the refrigerator out of direct sunlight
and away from the range, dishwasher or other heat
sources.
• The refrigerator must be installed on a floor that is level
and strong enough to support a fully loaded refrigerator.
• Consider water supply availability for models equipped
with an automatic ice maker.
LEVELING
All four corners of your refrigerator must rest firmly on a solid
floor. Your refrigerator is equipped with adjustable front rollers
or front leveling screws to help level your unit.
To Level Your Refrigerator:
1. Remove toe grille.
2. Use flat-blade screwdriver
or 3/8" socket wrench to
adjust front rollers. Use
adjustable wrench to
adjust eveling screws.
INSTALLATION
Installation Clearances
Allow the following clearances for ease of installation,
proper air circulation, and plumbing and electrical
connections:
Sides & Top 3/8"
Back 1"
Raise
Adjustable Front Roller
(some models)
Raise
Stationary Front Roller
with Leveling Screw
(some models)
DOOR OPENING
Your refrigerator should be positioned to allow easy access to
a counter when removing food. To make this possible, the
direction in which the doors open can be reversed. See Door
Removal & Reversal Instructions.
4

To Connect Water Supply Line To ice Maker Inlet Valve
1. Disconnect refrigerator from electric power source.
2. Place end of water supply line into sink or bucket. Turn ON
water supply and flush supply line until water is clear. Turn
OFF water supply at shutoff valve.
3. Unscrew plastic cap from water valve inlet and discard
cap.
4. Slide brass compression nut, then ferrule (sleeve) onto
water supply line, as shown.
5. Push water supply line into water valve inlet as far as it
will go (1_inch). Slide ferrule (sleeve) into valve inlet and
finger tighten compression nut onto valve. Tighten another
half turn with a wrench; DO NOT over tighten.
6. With steel clamp and screw, secure water supply line to
rear panel of refrigerator as shown.
7. Coil excess water supply line (about 2Y2 turns) behind
refrigerator as shown and arrange coils so they do not
vibrate or wear against any other surface.
8. Turn ON water supply at shutoff valve and tighten any
connections that leak.
9. Reconnect refrigerator to electrical power source.
10. To turn ice maker on, lower wire signal arm (see ice
maker front cover for ON!OFF position of arm).
Before Installing The Water Supply Line, You Will Need
• Basic Tools: adjustable wrench, flat-blade screwdriver,
and PhillipsTM screwdriver
• Access to a household cold water line with water pressure
between 30 and 100 psi.
• A water supply line made of 1_inch (6.4 mm) OD, copper
tubing. To determine the length of copper tubing needed,
you will need to measure the distance from the ice maker
inlet valve at the back of the refrigerator to your cold water
pipe. Then add approximately 7 feet (2.1 meters), so the
refrigerator can be moved out for cleaning (as shown).
• A shutoff valve to connect the water supply line to your
household water system. DO NOT use a self-piercing type
shutoff valve.
• A compression nut and ferrule (sleeve) for connecting the
water supply line to the ice maker inlet valve.
_ Plastic Water Steel
\_\ Tubing to Ice Maker "_ _ Clamp
\\ ./_ FilITube _]v
\\_" / Brass
\_ / Compression
Nut
L Ferrule
s,eovo,
_'_ Copper
_ water line
\ WaterVa,ve
_./_ "'_'_.,. ".,.._., _ /k---Bracket
/// \- i/2 L_
Yz_ L_ Valve Inlet
Water Valve
ousehold water supply
cludee ng i to I
moving refrigerator out for cleaning.)

DoorStop Handle
So ...... _ _S ....
_ge '_ Center '_ :Hinge
Su_vv
l H nge _crew
Tools Necessary: _ KnifePUtly
Phillips head
Quadrex head Socket Adjustable
screwdriver Wrench Sef Wrench
Awl
DOOR REMOVAL AND REVERSAL INSTRUCTIONS:
Cabinet Hole
Plugs
Hinge Hole
Top Hinge
Handle Hole
PUug
/
Door Stop
Screw
Washer
/Hinge
Pin
Center
nge
Door Stop
inge
Bottom
iHinge
1. Remove toe grille.
2. Remove top hinge with 3/8" hex driver and lift freezer door off of center
hinge pin. Set door aside.
3. Unscrew center hinge pin using adjustable wrench and save for
reassembly. Ensure plastic washer stays on hinge pin.
4. Lift refrigerator door off of bottom hinge and set aside.
5. Remove center hinge and shim by removing inside screw and
loosening two outside screws enough to allow hinge and shim to slide out.
Tighten screws.
6. Loosen two outside screws on opposite side of refrigerator, remove inside
screw and install center hinge.
7. Remove two screws on bottom hinge with 3/8" socket wrench.
8. Install bottom hinge on opposite side with the two screws removed from
step 7.
9. Unscrew bottom hinge pin using adjustable wrench. Move hinge pin to
other hole in hinge and tighten with adjustable wrench.
10. Reverse door handles (see instructions on next page).
11. Move freezer and refrigerator door stops to opposite side. Before starting
screws, use an awl to puncture the foam.
12. Position refrigerator door onto bottom hinge pin and screw center hinge pin
through center hinge into top of door. Close refrigerator door to help align
hinge hole.
13. Tighten center hinge pin with adjustable wrench.
14. Remove cabinet and hinge hole plugs and move to opposite side.
15. Lower freezer door onto center hinge pin.
16. Close freezer door. Have an assistant lift up on opposite side of door while
tightening screws to install top hinge.
17. Replace toe grille.
18. Plug in electrical power cord and turn refrigerator temperature control to
center position. Adjust setting as necessary.
6

TO REMOVE FREEZER HANDLE:
(Handles may be easier to reverse while doors are off.)
1. Remove two screws attaching handle to bottom of freezer
door.
2. Remove short trim piece by sliding trim straight up and off
of handle bracket.
3. Remove screw attaching top of handle to door.
4. Magnetic Nameplate Models: Gently pry magnetic
nameplate frame from door. Remove nameplate from its
frame, turn frame upside down and install in old handle
holes. Insert magnetic nameplate into frame.
Self-Adhesive
Nameplate Models:
Gently peel off
nameplate from door
and reapply over old
handle holes. -n
TO ATTACH FREEZER
HANDLE:
pl
Frame -_
1. Reinstall handle on
opposite side, using
same hole as
nameplate.
2. Attach handle to
bottom of door.
3. Slide trim piece
straight down onto
handle bracket.
Self Adhesive
Nameplate
isome modelsJ
TO REMOVE FREEZER HANDLE:
(Handles may be easier to reverse while doors are off.)
1. Remove two screws attaching handle to bottom of freezer
door.
2.
3.
TO ATTACH FREEZER
HANDLE:
1. Secure side of
handle to door and
replace button plug.
2. Secure handle to
bottom of door.
Remove button plug using edge of putty knife.
Remove screw on side of freezer door and remove
handle.
Button
TO REMOVE FREEZER HANDLE:
(Handles may be easier to reverse while doors are off.)
1. Remove two screws attaching handle to bottom of freezer
door.
2. Swing bottom of handle away from the door and slide
handle straight up and off of dovetail button.
3. Remove screw and dovetail button and install on other
side, using the same holes as nameplate.
4. Magnetic Nameplate Models: Use putty knife to gently pry
magnetic nameplate frame from door. Remove nameplate
from its frame, turn frame upside down and install in old
handle holes. Insert magnetic nameplate into frame.
Self-Adhesive Nameplate Models: Use putty knife to
gently peel off nameplate from door and reapply over old
handle holes.
TO ATTACH FREEZER
HANDLE:
1. Start with handle
offset away from
door. Place top of
handle over dovetail
button, swing handle
into an upright
position and pull
downward, locking it
into place.
2. Secure bottom of
handle with two
screws removed
earlier.
self AdheSive
Nameplate Nameplate
(some models)_ Fram_
IScrew-J _'_i../_ --\
scre_ Dovetail Button
TRIM REMOVAL (FULL=LENGTHTRIM MODELS ONLY)
In some models, the refrigerator door has a full length trim
piece which continues from the bottom of the handle to the
bottom of the door. The top of the trim attaches to the handle
bracket (Figure 1) or fits around the base of the handle (Figure
2). An adhesive "trim lock" is positioned about halfway down.
The bottom of the trim is held in place by either an adhesive
trim lock, or a trim lock with two prongs inserted into a hole on
the face of the door.
TO REMOVETRIM:
1. Remove trim by gently pulling trim lock areas out and
away from door.
2. When trim is free from door, slide the trim straight down
and away from base of handle.

TO REMOVE REFRIGERATOR HANDLE:
(Handles may be easier to reverse while doors are off.)
Figure 1 Style Handles
1. Remove two screws attaching handle to top of refrigerator
door.
2. Remove screw attaching bottom of handle to door.
3. Remove two hole plugs and hinge pin plug on top of door
and install on opposite side. Use Phillips head screwdriver
to remove plastic screw plug from front of door and install
on opposite side
Figure 2 Style Handles
1.
2.
3.
TO ATTACH TRIM:
1. Slide both trim locks out of trim.
2. Insert new adhesive trim locks contained in your literature
pack.
3. Install trim to handle by sliding under base of handle.
Carefully align trim and press down at trim lock locations.
4. Use rubbing alcohol to remove any adhesive residue from
old trim lock locations.
Remove two screws attaching handle to top of refrigerator
door.
Swing top of handle away from door and slide handle
down and off of dovetail button.
Remove screw and dovetail button and install on other
side, moving hole plugs from corresponding holes to
opposite side.
TO ATTACH REFRIGERATOR HANDLE:
Figure 1 Style Handles
1. Secure bottom of handle with screws.
2. Secure top of handle with screws.
Figure 2 Style Handles
1. Start with handle offset away from door. Place bottom of
handle over dovetail button, swing handle into an upright
position and pull upward, locking it into place.
2. Secure top of handle with screws.
TO REMOVE REFRIGERATOR HANDLE:
(Handles may be easier to
reverse while doors are off.)
1. Remove two screws
attaching handle to top of
refrigerator door.
2. Remove button plug
using edge of putty knife.
3. Remove screw on side of
refrigerator door and
remove handle.
4. Reverse freezer and
refrigerator handles as
shown in figure 3. Figure 3 - Handle Reversal
i-Screw
-- Handle
Button
PIL
TO ATTACH
REFRIGERATOR HANDLE:
1. Secure side of handle to
door and replace plug
button.
2. Secure handle to top of
door.
Refrigerator Door Without Trim
; i
Lock Handle
Figure 1 Figure 2
REMOVING STAINLESS STEEL DOORS AND HANDLES
To Remove Doors
Stainless steel doors are not reversible. Follow these steps to
remove doors.
1. Remove toe grille and
top hinge cover.
2. Remove top hinge and
lift freezer door off of
center hinge pin. Set
door aside.
3. Unscrew center hinge
pin using adjustable
wrench and save for
reassembly. Ensure Typical Handle
plastic washer stays on
hinge pin.
4 Lift refrigerator door off of bottom hinge and set aside.
5. Remove center hinge and shim by removing inside
screw and loosening two outside screws enough to allow
hinge to slide out. (continued on next page)
- Handle
Shoulder- Set
Screw
8

6. Remove bottom hinge. Reinsert two outside screws in
holes and tighten.
7. Reverse steps 1 - 6 to reinstall doors
To Remove Handles
1. Firmly hold freezer handle while loosening set screws
with 3/32" allen wrench. Remove freezer handle.
2. Repeat step 1 for refrigerator door.
Features may vary
according to model
ice Maker_
ice Bucket _ \
Freezer Shelf _
Freezer
Control
Refrigerator
Control
Dell Drawer
Cover
Dell Drawer _
Half Shelf --
Wine Rack--
Full Shelf _
Special Item Rack j
Mid Level Light j
Crisper Cover _
Crisper /
D rawe rs
Fixed Door Bin
_Door Rack
Dairy Door
Tall Bottle
Snugger
Fixed Door Bin
COOL DOWN PERIOD
To ensure safe food storage, allow the refrigerator to operate
with the doors closed for at least 8 to 12 hours before loading
it with food.
REFRIGERATOR & FREEZER CONTROLS
TEMPERATURE ADJUSTMENT
•Adjust temperature gradually: move the knob in small
increments, allowing the temperature to stabilize.
• For colder temperatures, turn the knob towards Colder.
• For warmer temperatures, turn the knob towards Cold.
Turning the refrigerator control will change temperatures in
both compartments. For example, if the refrigerator control is
turned to a colder setting, the freezer control may have to be
adjusted to a warmer setting. Turning the freezer control will
change only the freezer temperature.
To maintain temperatures, a fan circulates air in the
refrigerator and freezer compartments. For good circulation,
do not block cold air vents with food items.

Recommended i
Freezer Control (some models
Refrigerator Control (some models)
% o°".........o o......
Refrigerator & Freezer Control (some models)
TEMPERATURE ADJUSTMENT GUIDE
If Refrigerator compartment Is Too Warm Turn Refrigerator Control Slightly Towards Colder.
If Refrigerator compartment Is Too Cold Turn Refrigerator Control Slightly Towards Cold.
If Freezer compartment Is Too Warm Turn Freezer Control Slightly Towards Colder.
If Freezer compartment Is Too Cold Turn Freezer Control Slightly Towards Cold.
* To Turn Refrigerator Off Turn Refrigerator Control To 0.
SHELF ADJUSTMENT
Refrigerator shelves are easily adjusted to suit individual needs. Before adjusting the shelves, remove all food.
To adjust sliding shelves:
Remove shelf by pulling forward to stop position.
Lift front edge up and pull out.
Replace the shelf on any pair of rails by reversing this procedure.
Sliding Glass Shelf Sliding Wire Shelf
10

To adjust cantilever shelves:
O Lift front edge up.
O Pull shelf out.
Replace the shelf by inserting the hooks at rear of the shelf into
the wall bracket. Lower the shelf into the desired slots and lock
into position.
SpillSafe TMglass shelves (some models) catch and hold
accidental spills. In some models, the SpillSafe TM shelves slide
out for easy access to food and for fast cleaning. The shelves
slide out independently of the cantilever brackets. Just pull the
front of the shelf forward. The shelf can be extended as far as
the stopper will allow but it is not removable from the cantilever
bracket.
Full Width Cantilever
Glass Shelf
Cantilever Glass Shelf
Fixed and Sliding
DOOR STORAGE
Door bins, shelves, and racks are provided for convenient
storage of jars, bottles, and cans. Frequently used items can be
quickly selected.
Some models have door
racks or bins that can
accommodate gallon-sized
plastic drink containers and
economy-sized jars and
containers. Some racks are
adjustable for maximum
storage capacity.
The dairy compartment,
which is warmer than the ....
general food storage section,
is intended for short term
storage of cheese, spreads, Door Rack
or butter.
ADJUSTABLE DOOR BiNS
Some models have adjustable door bins that can be moved to
suit individual needs.
To move door bins
1. Lift bin straight up.
2. Remove bin.
3. Place bin in desired
position.
4. Lower bin onto supports
until locked in place. Adjustable
Door Bin
TALL BOTTLE RETAINER (SOME MODELS)
The Tall Bottle Retainer keeps tall containers in the bin from
falling forward when opening or closing the refrigerator door.
To install, hold the retainer at the top, and slide it over the
outside wall of the bin, as shown in the diagram. The Tall Bottle
Retainer works best with a Bin Snugger.
Tall Bottle Retainer (left) and Bin Snugger (right)
SPECIAL ITEM RACK (SOME MODELS)
The innovative design of the _.!'"
Special Item Rack allows you
to store a six-pack of 12 ounce
drink cans, a bottle of wine, a
two-liter soft drink bottle, or a
carton of eggs. The Special
Item Rack mounts on the left
side of your refrigerator. To
install, just slide the Special
Item Rack onto any shelf as
shown in the drawing. Special Item Rack
CRISPERS (SOME MODELS)
The crispers, located under
the bottom refrigerator shelf,
are designed for storing fruits,
vegetables, and other fresh
produce. Wash items in clear
water and remove excess
water before placing them in
the crispers. Items with strong
odors or high moisture content
should be wrapped before
storing. Crisper Drawer
11

HUMiDiTYCONTROL
(SOMEMODELS)
TheHumidityControl,
presentonsomemodels
withcrisperdrawers,allows
youtoadjustthehumidity
withinthecrisper.Thiscan
extend the life of fresh
vegetables that keep best in
high humidity.
DELl DRAWER (SOME
MODELS)
Low .
aumidity_ Some models are equipped _ //
with a Deli Drawer for storage
of luncheon meats, spreads,
High cheeses, and other deli items.
Humidit, /
Crisper Humidity Control WiNE RACK (SOME
MODELS)
The Wine Rack stores bottles
of wine, or single two-liter
plastic bottles of juice or soda
pop. To install, slide the Wine
Rack onto the shelf with the
curve facing in. To remove,
slide the Wine Rack out.
Install on either side of shelf.
/S/
Deli Drawer
Wine Rack
If your refrigerator has an automatic ice maker, it will provide a
sufficient supply of ice for normal use. During the initial staff[up
of your refrigerator, however, no ice will be produced during
the first 24 hours of operation. Automatic ice makers are also
optional accessories that may be installed in most models at
any time. Call your local dealer for information.
The ice maker produces 2 to 5 pounds of ice every 24 hours
depending on usage conditions. Ice is produced at a rate of 8
cubes every 80 to 160 minutes.
TURNINGYOUR iCE MAKER ON
After the plumbing connections have been completed, the
water supply valve must be opened. Place the ice container
under the ice maker, pushing it as far back as possible. Lower
the wire signal arm to its "down" or ON position. New plumbing
connections may cause the first production of ice cubes to be
discolored or have an odd flavor. These first cubes should be
discarded until the cubes produced are free of discoloration
and taste.
TURNINGYOUR iCE MAKER OFF
To stop the ice maker, lift the
wire signal arm until it clicks
and locks in the "up" or OFF
position. The ice maker also
turns off automatically when
the ice container is full. Ifyour
model has an adjustable
freezer shelf, place the shelf in
the lower position, so that the
wire signal arm will hit the ice
when the container is full.
Signal Arm
Maker
iCE MAKER TiPS
• Ice cubes stored too long may develop an odd flavor.
Empty the ice container and ensure that the wire signal
arm is in its "down" or ON position. The ice maker will then
produce more ice.
• Occasionally shake the ice container to keep ice
separated.
Keep the wire signal arm in its "up" or OFF position until
the refrigerator is connected to the water supply or
whenever the water supply is turned off.
The following sounds are normal when the ice maker is
operating:
• Motor running
• Ice loosening from tray
• Ice dropping into ice container
• Running water
• Water valve opening or closing
12

• Wash the ice container in warm water with mild detergent.
Rinse well and dry.
• Stop the ice maker when cleaning the freezer and during
vacations.
• If the ice maker will be turned off for a long period of time,
turn the water supply valve to the closed position.
FOOD STORAGE iDEAS
Fresh Food Storage
• The fresh food compartment should be kept between 34°F
and 40° F with an optimum temperature of 37° R
• Avoid overcrowding the refrigerator shelves. This reduces
the circulation of air around the food and results in uneven
cooling.
Fruits and Vegetables
• Storage in the crisper drawers traps moisture to help
preserve the fruit and vegetable quality for longer time
periods.
Meat
• Raw meat and poultry should be wrapped securely so
leakage and contamination of other foods or surfaces
does not occur.
Frozen Food Storage
• The freezer compartment should be kept at 0° F or lower.
• A freezer operates most efficiently when it is at least 2/3
full.
Packaging Foods for Freezing
• To minimize dehydration and quality deterioration, use
aluminum foil, freezer wrap, freezer bags or airtight
containers. Force as much air out of the packages as
possible and seal them tightly. Trapped air can cause food
to dry out, change color, and develop an off-flavor (freezer
burn).
• Wrap fresh meats and poultry with suitable freezer wrap
prior to freezing.
• Do not refreeze meat that has completely thawed.
Loading the Freezer
• Avoid adding too much warm food to the freezer at one
time. This overloads the freezer, slows the rate of freezing,
and can raise the temperature of frozen foods.
• Leave a space between the packages, so cold air can
circulate freely, allowing food to freeze as quickly as
possible.
• Avoid storing hard-to-freeze foods such as ice cream and
orange juice on the freezer door shelves. These foods are
best stored in the freezer interior where the temperature
varies less.
ENERGY SAVING iDEAS
Locate the refrigerator in the coolest
part of the room, out of direct
sunlight, and away from heating
ducts or registers. Do not place the
refrigerator next to heat-producing
appliances such as a range, oven,
or dishwasher. If this is not possible,
a section of cabinetry or an added
layer of insulation between the two appliances will help
the refrigerator operate more efficiently.
• Level the refrigerator so that the doors close tightly.
• Refer to this Use & Care Manual for the suggested
temperature control settings.
• Periodic cleaning of the condenser will help the
refrigerator run more efficiently. See the Care and
Cleaning Chart on page 15.
• Do not overcrowd the refrigerator or block cold air vents.
Doing so causes the refrigerator to run longer and use
more energy.
• Cover foods and wipe containers dry before placing them
in the refrigerator. This cuts down on moisture build-up
inside the unit.
• Organize the refrigerator to reduce door openings.
Remove as many items as needed at one time and close
the door as soon as possible.
13

UNDERSTANDINGTHE SOUNDSYOU MAY HEAR
Your new high-efficiency refrigerator may make unfamiliar
sounds. These are all normal sounds and soon will become
familiar to you. They also indicate your refrigerator is operating
as designed. Hard surfaces, such as vinyl or wood floors,
walls, and kitchen cabinets may make sounds more
noticeable. Listed below are descriptions of some of the most
common sounds you may hear, and what is causing them.
A. Evaporator
The flow of refrigerant through the evaporator may
create a boiling or gurgling sound.
B. Evaporator Fan
You may hear air being forced through the refrigerator
by the evaporator fan.
C. Defrost Neater
During defrost cycles, water dripping onto the defrost
heater may cause a hissing or sizzling sound. After
defrosting, a popping sound may occur.
O
D. Automatic Ice Maker
E.
If your refrigerator is equipped with an automatic ice
maker,you will hear ice cubes falling into the ice bin.
Cold Control & Defrost Timer or Automatic
Defrost Control
These parts can produce a snapping or clicking sound
when turning the refrigerator on and off. The timer also
produces sounds similar to an electric clock.
F. Condenser Fan
If condenser coils are located underneath your
refrigerator as shown in the drawing at the left, you
have a condenser fan. You may hear air being forced
through the condenser by the condenser fan.
G. Compressor
Modern, high-efficiency compressors operate much
faster than older models. The compressor may have a
high-pitched hum or pulsating sound.
H. Water Valve
If your refrigerator is equipped with an automatic ice
maker, you will hear a buzzing sound as the water valve
opens to fill the ice maker during each cycle.
L Drain Pan (Nonremovable)
You may hear water running into the drain pan during
the defrost cycle. The drain pan will be located on top
of the compressor for air-cooled condensers (black coils
on back of refrigerator).
J. Condenser Coils (Fan-cooled models only)
14

Keep your refrigerator and freezer clean to prevent odor build-up. Wipe up any spills immediately and clean both sections at
least twice a year. Never use any type of scouring pads, brushes, abrasive cleaners or strong alkaline solutions on any surface.
Do not wash any removable parts in a dishwasher. Always unplug the electrical power cord from the wall outlet before
cleaning.
Care & Cleaning Chart
Part
Interior/Door •Soap and water
Liner •Baking soda and water
Door Gaskets • Soap and water
Drawers/Bins • Soap and water
Glass Shelves • Soap and water
• Glass cleaner
• Mild liquid sprays
Toe Grille • Soap and water
• Mild liquid sprays
• Vacuum attachment
Exterior and • Soap and water
Handles
Exterior and
Handles • Soap and water
• Ammonia
• Stainless Steel Cleaners
(Stainless Steel
Models Only)
Condenser • Condenser Cleaning
Coils Brush is available from
(Fan-cooled your dealer.
models only) • Vacuum Cleaner
Condenser
Coils • Vacuum Cleaner
(Air-cooled
models only)
Defrost Water • Soap and water
Pan
What To Use Tips and Precautions
Use 2tablespoons of baking soda in 1 quart of warm water. Be sure to wring
excess water out of sponge or cloth before cleaning around controls,
light bulb or any electrical part.
Wipe gaskets with a clean soft cloth.
Do not wash any removable items (bins, drawers, etc.) in dishwasher.
Allow glass to warm to room temperature before immersing in warm water.
Vacuum dust from front of toe grille. Remove toe grille (See illustration on
page 4). Vacuum backside and wipe with sudsy cloth or sponge. Rinse and
dry.
Do not use commercial household cleaners, ammonia, or alcohol to clean
handles.
Never use CHLORIDE to clean stainless steel.
Clean stainless steel front and handles with non-abrasive soapy water and a
dishcloth. Rinse with clean water and a soft cloth. Wipe stubborn spots with an
ammonia-soaked paper towel, and rinse. Use a non-abrasive stainless steel
cleaner. These cleaners can be purchased at most home improvement or
major department stores. Always follow manufacturer's instructions.
NOTE: Always clean, wipe and dry with the grain to prevent cross-grain
scratching. Wash the rest of the cabinet with warm water and mild liquid
detergent. Rinse well, and wipe dry with a clean soft cloth.
No need to clean unless operating refrigerator under particularly dusty or
greasy conditions, or if there is significant pet traffic in your home. If cleaning
is necessary, remove toe grille and use extended vacuum attachment and
condenser cleaning brush to remove dust build-up from condenser coils (see
item "J" in illustration on page 14 for location).
Use the dusting tool attachment on your vacuum to remove dust build-up on
the condenser coils (black tubes and wires) attached to the back of air-cooled
refrigerators only.
Some models have defrost water pan located on top of compressor at bottom
rear of refrigerator (see illustration on next page). Wipe water pan with damp
cloth. NOTE: The defrost water pan is NOT removable.
15

NEVERCLEANCONDENSER(SOMEMODELS)
Ifyourrefrigeratoris
equipped with a Defrost _
Never Clean Wate
condenser, there's
no need to clean the
condenser under
normal operating !
conditions. If the
refrigerator is
operated under
particularly dusty or
greasy conditions, or
if there is significant
pet traffic in your
home, it may be necessary to periodically clean the condenser
for maximum efficiency.
i iii
Defrost Water Pan (some models)
REPLACING THE FREEZER LIGHT BULB (SOME
MODELS)
1. Unplug refrigerator.
2. Wear gloves as protection against possible broken glass.
3. Unsnap light shield as shown.
4. Unscrew and replace old bulb with an appliance bulb of
the same wattage.
5. Replace light shield.
6. Remember to plug the refrigerator back in.
Avoid cuts when replacing light bulbs,
I \\\ \
Freezer Light Cover Removal
Light
_ulbs (2)
Light
Cover
Refrigerator Mid-Level Light Cover Removal
Vacation and Moving Tips
Short •
Vacations •
Long
Vacations
Moving
Leave refrigerator operating during vacations of 3 weeks or less.
Use all perishable items from refrigerator compartment.
Turn automatic ice maker off and empty ice bucket, even if you will only be gone for a
few days.
Remove all food and ice if you will be gone one month or more.
Turn controls to "O" (the OFF position) and disconnect power.
Turn off automatic ice maker and turn water supply valve to closed position.
Clean interior thoroughly.
Leave both doors open to prevent odors and mold build-up. Block doors open if
necessary.
• Remove all food and ice.
• If using handcart, load from side.
• Adjust rollers all the way up to protect them during sliding or moving.
• Pad cabinet to avoid scratching surface.
16

Yourapplianceis covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to
be defective in materials or workmanship when such appliance is installed, used and maintained in
accordance with the provided instructions.
Exclusions This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed outside the USA or
Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased "as-is" are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances
not in ordinary household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,
etc.,which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or
knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip
charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not limited to floors,
cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
external causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR.
ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS
PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN
LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE
DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO
YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER
RIGHTS THAT VARY FROM STATE TO STATE.
If You Need
Service Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period
should service be required. If service is performed, it is in your best interest to obtain and keep all receipts.
Service under this warranty must be obtained by contacting Electrolux at the addresses or phone
numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted by Electrolux Major Appliances
North America, a division of Electrolux Home Products, Inc. In Canada, your appliance is warranted by Electrolux Canada
Corp. Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and
parts under this warranty must be performed by Electrolux or an authorized service company. Product features or
specifications as described or illustrated are subject to change without notice.
USA
1.800.944.9044
Electrolux Major Appliances
North America
P.O. Box 212378
Augusta, GA 30907
Electrolux
Canada
1.800.668.4606
Etectrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
17

See
ATTENTION
To
See
Properly Install Your Refrigerator
"Installation" Section On Pages 4-5
OR
To Reverse The Doors
"Door Removal & Reversal" Section On Pages 6-9
Before calling for service, review this list. It may save you time and expense. This
Common list includes common occurrences that are not the result of defective workmanship
Occurrences or materials in this appliance.
Refrigerator does not run.
• Ensure plug is tightly pushed into electrical outlet.
• Check/replace fuse with a 15 amp time-delay fuse. Reset circuit breaker.
• The temperature control is turned to "O".
• Refrigerator may be in defrost cycle. Wait 20 minutes and check again.
Freezer temperature too cold. • Set freezer control to a warmer setting until freezer temperature is satisfactory.
Refrigerator temperature is Allow 24 hours for the temperature to stabilize.
satisfactory.
Refrigerator temperature too cold. • Set refrigerator control to a warmer setting. Allow 24 hours for temperature to
Freezer temperature is satisfactory, stabilize. Then check freezer temperatures and adjust as needed.
• The cabinet is not level.
* Refrigerator is noisy or vibrates. • Floor is weak.
• Interior needs to be cleaned.
Odors in refrigerator. • Foods that produce odors should be covered or wrapped.
Cabinet light not working.
Automatic ice maker not working.
(some models)
• Replace light bulb.
• Ensure plug is tightly pushed into electrical outlet.
• Light switch may be stuck. Push in light switch, located on the refrigerator
control box, to release.
• Ensure the Wire Signal Arm is not in UP position.
• Ice maker should produce 4 to 5 pounds of ice in a 24 hour period.
• Water supply is turned off.
• Water pressure is too low.
• The freezer is not cold enough.
* See Normal Operating Sounds and Sights section on page 14.
18
