Frigidaire PLRH1779GS Instruction Manual

P08F0092.eps P08D0547.eps P08C1091.eps P08S0479.eps
Product No. PLRH1779GS0
Series Twins
Color black-s/s
Volts 115
Wiring Diagram 297005300
Owner's Guide 297208700
Market North America
Energy Guide 297115903
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995508776
08/03/14
(EN/SERVICE/MLR)
365
REFRIGERATOR
Model No.
PLRH1779GS
Copyright ©2008 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995508776 PLRH1779GS0
03/08 2
DOOR
59
13
21A
1
9
7
27A
49
49
48C
27
27
P08D0547
32
11
26
93
18
79
79
80
80
12
64

PLRH1779GS0 Publication No: 5995508776
# Functional Parts 3 03/08
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216522311 Gasket-door, black
7 240338313 Door, dairy, clear
9 216953601 Panel-inner door, refr
11 216526560 Panel-outer door, stainless
12 241808801 Label-nameplate
13 5303271076 Door Stop
18 240536818 Handle-door, stainless steel, with insert, & set screw
21A 5304460608 Screw, flat head, #1/4-20, door stop/hng
26 216524200 Gasket, secondary
27 5303212828 Clip, panel mtg
27* 5304406520 Clip, panel mtg kit, (40)
27A 240396102 Retainer, tall bottle
32 5309950074 Valve, breather
48C 297108200 Bin-door, gallon
49 297107800 Bin-door, 2-liter
59 216974500 Bearing, door closer
64 216403700 Plug-button, hole filler, door base
79 218755402 Screw-set, 10-32 x 0.375
80 218755504 Screw-shoulder, #10 AB, handle mounting
93 5304460605 Screw, ph truss head, 8-18AB x 0.500

Publication No: 5995508776 PLRH1779GS0
03/08 4
CABINET
6
93A
93A
169
50
13
5
6
9
9
93
131
3
32
29
35
34
15 16
15
132
47
63
25
19
18
71A 21
155
154 20
93B
80
24
22
22A
15A
34A
15A
16A
34B
P08C1091
14
41
28
152
38
41
40
93
72
37
37
26G 175
175
174
173
148B
47A
172
171
62
62
42
42
42
26C
26A
27A
26B
26F
26F
175
174
172
62
175
148A
47B
171
173
62

PLRH1779GS0 Publication No: 5995508776
# Functional Parts 5 03/08
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
3 216503100 Screen-drain
5 # 216325600 Fan Blade
6 297200600 Breaker Kit w/corners, no lock slot
9 297200100 Breaker Kit w/corners, 32", top and bottom
13 # 216934100 Motor, fan, 115 V
14 216998100 Switch, light/lamp, black, ramp
15 216988100 Light Bulb/Lamp, long, blue tint, 40 W, 120V
15A 297048600 Light Bulb/Lamp, short
16 241507803 Socket-light
16* 297109500 Washer, vinyl
16A 216817600 Socket, light/lamp, 25 W
18 216707200 Knob, temp control
19 216204902 Gasket-evap cover
20 216967200 Cover, temp control
21 # 216715500 Control temperature
22 216823500 Clamp, cap tube, cold control
22A 297058500 Tube, 10", plastic
24 5304460604 Screw, type A, 10-24 x 3/8
25 297099256 Cover-evaporator
26A 297091601 Case-crisper, deep
26B 297091800 Panel, crisper window
26C 297091703 Panel, crisper front
26F 297099401 Divider-crisper, deep
26G 297123700 Case-deli
27A 240362201 Control-humidity
28 297179300 Hinge, bottom/RH
29 216313501 Hose-drain
32 5308005500 Drain
34 216979504 Shield-light
34A 297053100 Shield-light
34B 297053200 Lens, light
35 216273000 Clip, drain hose
37 241611303 Trim-cabinet corner, black, (2)
38 297164300 Hinge-upper
40 297164401 Cover-upper hinge, black
41 240578902 Screw, hex head, 1/4-20 x 5/8
42 297108900 Shelf-sliding, w/brackets, (3)
47 216661601 Baffle-plate
47A 297102700 Insert-pan cover, glass
47B 297102701 Insert-pan cover, glass, lower
50 216394050 Bracket, fan motor mount
62 297142600 Screw, blunt, 8-32 x 5/8
63 216396900 Screw, leveling foot, plastic, adjustable
71A 297146800 Screw, 8-18AB x 0.470, EVAP PANEL
72 297036901 Grille/Kickplate, 32", black
80 06594601 Bracket, control
93 5304460605 Screw, ph truss head, 8-18AB x 0.500
93A 216629601 Screw, hex washer head, 10-16 x 0.500, tapping
93B 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA
131 297130200 Channel-shelf mtg, side, (2)
132 5304460601 Screw, 6-20AB x 3/8

Publication No: 5995508776 PLRH1779GS0
03/08 6
CABINET
6
93A
93A
169
50
13
5
6
9
9
93
131
3
32
29
35
34
15 16
15
132
47
63
25
19
18
71A 21
155
154 20
93B
80
24
22
22A
15A
34A
15A
16A
34B
P08C1091
14
41
28
152
38
41
40
93
72
37
37
26G 175
175
174
173
148B
47A
172
171
62
62
42
42
42
26C
26A
27A
26B
26F
26F
175
174
172
62
175
148A
47B
171
173
62

PLRH1779GS0 Publication No: 5995508776
# Functional Parts 7 03/08
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
148A 297092502 Frame-crisper cover, lower
148B 297092503 Frame-deli cover
152 216974600 Bearing, hinge closer
154 297053000 Wire, jumper
155 5303313703 Clip, (2)
169 216912401 Screw, hex washer head, 8-32 x 0.500, bracket fan mtr, (2)
171 297092700 Bracket, crisper cover, RH
172 297092701 Bracket, crisper cover, LH
173 297107600 Slide, crisper, RH
174 297107601 Slide, crisper, LH
175 297099500 Support-crisper
* 297001704 Insulation, 24", drain tube
* 297115903 Energy Guide

Publication No: 5995508776 PLRH1779GS0
03/08 8
SYSTEM
35
29 27
31
136 136
141
146
87
60
61
141A
BACK
4
5
86
107
1
87 24
23
24A
P08S0479
FRONT
19
20
14
130
18
15
15A
2
30
34

PLRH1779GS0 Publication No: 5995508776
# Functional Parts 9 03/08
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 297152200 Condenser, dynamic
2 5308000110 Strap-evap/heater, aluminum, (2)
4 # 216938600 Drier-filter
5 # 297171800 Harness-main
5* 240555002 Screw-#8-32 X 3/8
14 216730700 Heater-defrost
15 # 216997300 Evaporator
15A 216751100 Heat Exchanger
18 297078700 Insulator-evap, styrofoam
19 297078800 Insulator-evap, styrofoam
20 216731001 Thermostat, defrost
23 # 216744500 Timer-defrost
24 216968501 Bracket-timer
24A 297207900 Guard, timer
27 5308002681 Grommet, compressor
29 # 297054400 Compressor, assy, w/electricals
30 # 297054500 Relay Combo
31 297165800 Pan-drain
34 5306594529 Sleeve-compressor
35 5304460607 Screw, Ind hex sems, 1/4-28 unfx, compressor
60 241584301 Motor-condenser fan
61 241639501 Blade-condenser fan
86 216036601 Screw, RWHD, 8-32A x 0.500, GX-CA
87 5304463290 Screw, hi-lo blunt, #8-18X1/2
107 297165400 Shield, compressor, Compartment
* 5304460605 Screw, ph truss head, 8-18AB x 0.500
130 216486800 Support, evaporator mtg
136 240405201 Grommet, rubber, black, cond tube/wire
141 297164200 Divider, air flow
141A 297194700 Divider, small, air flow
146 297164000 Shroud-fan orfice
146* 216337701 Screw, HWH, 10-24 x 0.500, Swage
* 216502500 Sleeve, suction line
* # 297169901 Cord-power, flat
