Frigidaire CTF140FS2 Manual

Coin- Operated Commercial
Tumble Action Washer
achine A Laver Par
Culbutage Commerciale
_ encaissement automatique
PIN 134777900 (0706) Made in USA

TABLE OF CONTENTS
Important Safety Instructions .......................................... 3
Prednstallation Requirements ....................................... 4
Electrical Requirements ................................................. 4
Grounding Requirements .............................................. 4
Water Supply Requirements .......................................... 4
Drain Requirements ........................................................ 4
Location Of You rWasher. .............................................. 4
Roughdn Dimensions .................................................... 5
Unpacking ....................................................................... 6
Installation .................................................................. 6-7
Coin slide installation ................................................ 7-9
Meter case instructions ................................................. 9
Replacement Parts.......................................................... 10
Partslists.................................................................... 10-11
Warranty......................................................................... 12
Fran_ais.................................................................. 13-24
Before beginning installation, carefully read
these instructions. This will simplify the
installation and ensure the washer is
installed correctly and safely. Leave these
instructions near the washer after
installation for future reference.
NOTE: The electrical service to the washer
must conform with local codes and
ordinances and the latest edition of the
National Electrical Code, ANSI/NFPA 70.
F "oduct F ec:ocd
For Frigidaire warranty information or to contact a Frigidaire
ServiceCenter, call 1-866-738-164e
If you need SERVICE or PARTS for your Frigidaire coin-
operated washer: be ready' to give the model number, serial
number and date of purchase. Record below.
Model number
Serial number
NOTE: The instructions appearing in this
INSTALLATION AND SAFETY INSTRUCTIONS
manual are not meant to cover every possible
condition and situation that may occur. Common
sense and caution must be practiced when
Purchase date
Record Coin Box
Key Number
installing, operating and maintaining any
appliance. Key number is on key and/or coin box.
iWASHER SAFETY
Your safety and the safety of others is very important. We have provided many important safety messages in the Installation
Instructions/Use & Care Guide and on your appliance. Always read and obey all safety messages.
_rhis isthe safety alert symbol. This symbol alerts you to hazards that can kill or hurt you or others. All safety messageswill be
preceded by the safety alert symbol and the word "DANGER" or "WARNING ". These words mean:
You can be killed or seriously injured if you don't immediately follow instructions.
You can be killed or seriously injured if you don't follow instructions.
All safety messages will identify the hazard, tell you how to reduce the ct_ance of injury, and tell you what can happen if the
instructions are not followed.
Foryour safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent
property damage, personal injury or Jossof life.
- Do not store or usegasoline or other flammable vapors and liquid in the vicinity of this or any other appliance.
-WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
• Clear the room, building or area of all occupants.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas suppliers instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Your washer isequipped with a door safety interlock. Verify proper operation of interlock system daily, using the following procedure:
1.With the washer door open, insert the required number of coins and pressthe STARTbutton. THE WASHERMUSTNOTSTART!
2.C_sethewasherd_r.PresstheSTARTbutt_naga_nt_startthemachine.Attemptt_penthed_r_with_ut exerting excessive
force. THEDOORMUSTNOTOPEN!
IF THE WASHER STARTS WITH THE DOOR OPEN, OR THE DOOR CAN BE OPENED WHILE THE WASHER ISOPERATING, THE
MA CHINEMUS TIMMEDIA TELY BETAKEN OUT OFSERVICE.DISCONNECT THEPOWERCORD,AND MARK THEMA CHINE "OUT
OF ORDER", UNTIL THE INTERLOCK SYSTEM IS REPAIRED,AND OPERA TESAS DESCRIBEDABO VE.

Avoid fire
hazardor electrical shock.
Do not use an adaptor plug
or extension cord or
remove grounding prong
from electrical power cord.
Failure to follow this
warning can cause serious
injury, fire or death.
Grounding type wall receptacle
Donotunderany
circumstances cut, remove,
or bypass the grounding
prong from this plug,
Powersupplycor with
CORRECT Use this way ONLY
Do not use or mix
fiquid chlorine bleach with
other household chemicals
such as toilet cleaners, rust
removers, acid or products
containing ammonia. These
mixtures can produce
dangerous fumes which can
cause serious injury or death.
Important Safety Instructions Read all instructions before using this washer.
You can be kifled or seriously injured if you don't follow these Important Safety Instructions:
• To reduce the risk of fire, electrical shock, or injury to persons when using this washer, comply with the basic warnings listed below.
• Failure to comply with these warnings could result in serious personal injuries.
Prevent Fire
Do not wash items that have been previously cleaned in, soaked in, or spotted with gasoline, cleaning solvents, kerosene, cooking
oils, waxes, etc. Do not store these items on or near the washer. These substances give off vapors or chemical reactions that could
ignite or explode.
* Do not put oily or greasy rags or clothing on top of the washer. These substances give off vapors that could ignite the materials.
Do not add gasoline, cleaning solvents, or other flammable or explosive substances to the wash water. These substances give
off vapors that could ignite or explode.
FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or
any other appliance.
Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using the washer, turn
on all hot water faucets and let the water flow from each for several minutes. This will release any accumulated hydrogen gas.
Hydrogen gas isflammable; do not smoke or use an open flame during this time.
Failure to comply with these warnings could result in fire, explosion, serious bodily injury and/or damage to the rubber or plastic
parts of the washer.
Protect Children
Do not allow children to play on or in the washer. Close supervision of children isnecessary when the washer isused near children.
As children grow, teach them the proper, safe use of all appliances.
Destroythe carton, plastic bag and other packing materials after the washer isunpacked. Children might usethem for play. Cartons
covered with rugs, bedspreads or plastic sheets can become airtight chambers.
Keep laundry products out of children's reach. To prevent personal injury, observe all warnings on product labels.
Before the washer is removed from service or discarded, remove the washer lid to prevent accidental entrapment.
Failure to comply with these warnings could result in serious personal injuries.
Prevent Injury
oTest door interlock system daily. Follow instructions on previous page.
To prevent shock hazard and assurestability during operation, the washer must be installed and electrically grounded by a qualified
service person in accordance with local codes. Refer to INSTALLATION AND SAFETYINSTRUCTIONSfor detailed grounding
procedures. If the washer is moved to a new location, have it checked and reinstalled by a qualified service person.
_To prevent personal injury or damage to the washer, the electrical power cord of the washer must be plugged into a properly
grounded and polarized 3-prong outlet The third grounding prong must never be removed. Never ground the washer to
a gas pipe. Do not use an extension cord or an adaptor plug.
Follow package directions when using laundry products. Incorrect usage can produce poisonous gas--resulting in serious injury
or death.
-Do not combine laundry products for use in 1 load unless specified on the label.
-Do not mix chlorine bleach with ammonia or acids such as vinegar.
To prevent serious personal injury and damage to the washer:
-All repairs and servicing must be performed by an authorized servicer unless specifically recommended in this
INBTALLATION AND SAFETY INSTRUCTIONS manual. Use only authorized factory parts.
-Donottamperwith controls.
-Do not install or store the washer where it will be exposed to the weather.
• To reduce the risk of electric shock, disconnect this appliance from the power supply before attempting any user maintenance.
Turning the controls to the OFFposition does not disconnect this appliance from the power supply.
To prevent injury, do not reach into the washer while parts are moving. Before loading, unloading or adding items, push in the cycle
selector knob and allow the tub to coast to a complete stop before reaching inside.
• Failure to comply with these warnings could result in serious personal injuries.
_This washer is equipped with an electrical overload protector. The motor will stop if it becomes overheated. The washer will
automatically restart after a cool down period of up to 30 minutes, if the washer has not been manually turned off during this time.
SAVE THESE INSTRUCTIONS
3

PRE-INSTALLATION REQUIREMENTS DRAIN REQUIREMENTS
Tools Required for Installation:
I. 1/4 in. nut driver
2. 3/8 in. socket with ratchet.
S. 3/8 in. open end wrench.
4. 7/16 in. socket with ratchet.
5. 9/16 in. open end wrench.
6. ChanneNock adjustable pliers.
7. Carpenter's level.
ELECTRICAL REQUIREMENTS
CIRCUIT- individual, properly polarized and grounded 15 amp.
branch circuit fused with I 5 amp. time delayfuse or circuit breaker.
POWER SUPPLY- 2 wire, with ground, 120 volt, single phase, 60
Hz,Alternating Current. NOTE:The useof this washer with power
created by gas powered generators, solar powered generators,
wind powered generators or and other generator other than the
local utility company is not recommended.
OUTLETRECEPTACLE - Properly grounded 3-prong receptacle to
be located sothe power supply cord isaccessiblewhen the washer
is in an installed position. NOTE: GFI (Ground Fault Interrupter)
receptacle is not required.
Models equipped with drain pump:
1. Drain MUST be capable of eliminating 17 gab (64.3 L)per
minute.
2. A standpipe diameter of I-I/4 in. (3.18 cm) minimum.
3. The standpipe height above the floor should be:
O r[
i! o I
96 in.
(244 cm)
Max.
24 in.
(61 cm)
Min.
GROUNDING REQUIREMENTS
Improper connection of the equipment grounding
conductor can result in a risk of electrical shock. Check with a
licensed electrician if you are in doubt asto whether the appliance
isproperly grounded.
I. The washer MUST be grounded. Inthe event of malfunction
or breakdown, grounding will reduce the risk of electrical
shock by a path of least resistance for electrical current.
2. Since your washer is equipped with a power supply cord
having an equipment-grounding conductor and a grounding
plug, the plug MUSTbe plugged into an appropriate, copper
wired receptacle that is properly installed and grounded in
accordance with all local codes and ordinances or in the
absence of local codes, with the National Electrical Codes,
ANSI/NFPA 70 (latest edition). If in doubt, call a licensed
electrician.
DO NOTcut off or alter the grounding prong on the power supply
cord. Insituations where a two-slot receptacle is present, it isthe
owner's responsibility to have a licensed electrician replace it
with a properly grounded three prong grounding type
receptacle.
WATER SUPPLY REQUIREMENTS
Hot and cold water faucets MUST be installed within 42 inches
(107 cm) of your washer's water inlet. The faucets MUST be 3/4
inch (I .g cm) garden hosetype so inlet hoses can be connected.
Water pressureMUSTbe between 10 and 120 pounds per square
inch (maximum unbalance pressure, hot vs. cold, 10 psi.) Your
water department can advise you of your water pressure.
NOTE:
Drain hose attached to the washer can reach a 58 in. (147 cm)
high standpipe. For higher standpipe usehose P/N 1S4592701,
available from an authorized parts distributor. If drain is less
than 24 in. (61 cm), install a siphon break kit, available at your
local hardware store.
Models equipped with gravity drain:
1. Floor drain MUST be capable of eliminating 17 gab (64.3 L)
per minute.
2. Floor drain diameter must be at least I/2 inch larger than
drain hose.
LOCATION OF YOUR WASHER
See rough-in dimensions on the next page (Figure 1).
DO NOT/NSTALL YOUR WASHER:
1. In an area exposed to dripping water or outside weather
conditions. The ambient temperature should never be below
60 degrees F(15.6 degrees C) for proper washer operation.
2. in an area where it will come in contact with curtains or
drapes.
13. in an area (garage or garage-type building) where gasoline
of other flammables are kept or stored (including
automobiles).
4. On carpet. Floor MUST be solid with a maximum slope of
1/2 in. per foot (1.27 cm per 30.5 cm). Toensure vibration or
movement does not occur, reinforcement of the floor may
be necessary.
IMPORTANT MINIMUM INSTALLATION CLEARANCES
When installed in alcove: Sides, Rear,Top = 0 in (0 cm).
When installed in closet: Sides, Rear,Top = 0 in (0 cm),
Front = 1 in (2.54 cm).
Closet door ventilation openings required: 2 louvers each 60 in'
(387 cm2)- i_in (7.6 cm) from top and bottom of door.
4

17
(43.2)
(1
ROUGH-iN DIMENSIONS
_._4 3/7 60
3"_(152.4)
(62.9) v _'(2.54)
1½ )
'POWER
_CORD
331/2
(85)
inch (cm)
36
(91.5)
43/8
(11.2)_
8
:20,4)
JNDER
_,OUNTER
345/8
(87.9)
263,4
_ (67.9) }1,,
....... ii!ii i
BACK
inch (cm)
WATER
iNLETS
31%
(80.3)
(Figure 1).
5

UNPACKING
1. Cut the shipping carton along the dotted line along tile base
of the unit.
2. While in the carton carefully lay the washer on its back
side.
3. Removethe styrofoam base.
4. Carefully return the washer to an upright position and remove
the carton.
5. Carefully move the washer to within 4 feet (122cm) of the
final location.
6. Remove the following from the back side of the washer:
3 bolts,
3 yellow plastic spacers,
2 or 3 metal "P" clamps.
®_r
@
BOLT
CLAMP
7.
8.
Remove the service panel from the front of the washer.
Remove the 4 nuts and 6 large washers that attach the 2
yellow shipping braces to the drum and the base. Lift up on
the drum and remove the braces (a yellow ribbon surrounds
the items to be removed). These braces must be removed to
allow the power supply cord to be releasedfrom the shipping
ring.
@
@
.9. Remove the large styrofoam block located under the drum.
Lift up on the drum, tilt the base of the foam block inwards
toward the rear of the washer until free, then pull it out.
10. Remove and discard the yellow ribbon and label from the
front of the washer.
11. From the rear of the washer, carefully pull out the power
supply cord through the hole in the backsheet.
12. Replace the service panel and screws.
NOTE: If the washer isto be transported at a later date, the
shipping support hardware must be reinstalled to prevent
shipping damage.
INSTALLATION
I.
2.
3.
4.
Run some water from the hot and cold faucets to flush the
water linesand remove particles that might clog up the water
valve screens.
Removethe inlet hoses and rubber washers from the plastic
bag and install the rubber washers in each end of the inlet
hoses.
Carefully connect the inlet hosemarked "HOT" to the outside
"H" outlet of the water valve. Tighten by hand, then tighten
another 2/3 turn with pliers. Carefully connect the other
inlet hose to the inside "C" outlet of the water valve. Tighten
by hand, then tighten another 2/3 turn with pliers. Do not
crossthread or over-tighten these connections.
Connect the inlet hose ends to the HOT and
COLD water faucets tightly by hand, then
tighten another 2/3 turn with pliers. Turn the
water on and check for leaks.
6

5. Onmachinesequippedwithdrainpump,form
aUshapeontheendofthedrainhose,with
thehosepointedtowardthedrain•
NOTE: If the drain hose isplaced in a standpipe
without forming a Ushape, a siphoning action
could occur. There must be an air gap around
the drain hose. A snug hosefit can also cause a
siphoning action• 1
6. Carefully move the washer to its final location•
NOTE: Do not usethe dispenser drawer or door to lift washer•
Excessivenoise and vibration can be prevented by properly
leveling the washer•
7. Forfree standinq installation and with the washer in it's final
position, place a level on top of the washer• Adjust the leveling
legs so the washer is level front-to-rear and side-to-side, and
stable corner-to-corner.
COIN BOX ADJUSTMENT
The tight fit of the money box isset at the factory• Customer may
loosen fit as desired by loosening the slotted nuts. SeeFIG.2.
FIGURE2
Keep A record ef all coin-box key numbers.
A lost keycan only be replaced by ordering the key numbers from
the place were tile unit was purchased• The key number islocated
both on the key and behind the end panel of the coin box. If the
key number isnot available, the lock must be drilled out to remove
the coin box.
Instructions for Changing Vend Price
TOOLSNEEDED
• Medium sized slotted screwdriver
• Small slotted Phillips screwdriver
Placeall screws and other items removed from coin slide assembly
on a cloth sothey will not get lost•
STEP!
Remove slide mechanism from meter case•(see FUGURE1).
FIGURE I
Pressdown on alternate corners and sides and feel for tile
slightest movement• Adjust the appropriate leg sothe washer
is SOLIDon the floor on ALL four legs. Keep the leveling leg
extension at a minimum for best performance of thewasher.
8. Forpedestal installations, See additional installation
instructions included with the pedestal•
STEP2
Removethe coin slide extension from coin slide by removing two
mounting screws and spacers
(see FIGURE2).
(2) Mounting Screws
and Spacers
9. Plug the power cord into a grounded outlet.
NOTE: Check to ensure the power is off at the circuit breaker/
fuse box before plugging the power cord into an outlet.
10.Turn on the power atthe circuit breaker/fuse box.
11.Be sure you have read the "Important Safety Instructions"
before operating this washer•
12.Run the washer through a complete cycle• Cbeck for water
leaks and proper operation•
13. Keep these instructions for future reference•
NOTE: A wiring diagram is located inside the washer on the
side panel•
Slide Return Spring

STEP3
Remove coin slide from coin chute:
• Unhook and remove the coin slide return spring. (see FIGURE2).
, Turn coin slide mechanism upside down.
Remove coin slide stop by taking out two screws to the chute bottom
(see FIGURE3).
(2) Slide Stop
Pull coin slide out of coin chute (seeFIGURE4).
FIGURE4
STEP4
Turn coin slide upside down and remove screw that holds coin receiver
block (see FIGURE5).
(1) Receiver Block Screw
Spare Parts
Compartment
and Screw
STEP5
Remove coin receiver block from coin slide (see FIGURE 6):
• Turn coin slide right side up. Keep coin receiver block in place with
your fingers.
Carefully lift coin slide from coin receiver block. If necessary,shake
coin slide gentlyto loosen block.
STEP6
Setnew vend price byadding or removing the appropriate
block-out keys and/or dime inserts accordinc to th Table
of Vend Prices
(see FIGURE7). FIGURE7
NOTE:
Black
colored
slots are
closed off
by block-
out key.
TABLEOF VEND PRICE
VEND COIN SLOTS
PRICE 2345678
o||||||||
$.10 D||||B||
$.20 DD=|=|||
$.25 1| B=|| ||
$.35 D|B|I|||
$.45 DD[3|||||
$.50 1| BB |1 1|
$.SO D|[][]||||
$.7o E]E]DB||||
$.75 ||BBB|||
$.85 D|DDB|||
$.95 [] D[] [] []| | |
$1.oo | |[] [] [][] | |
$1.1o D |[] [3[] [] | |
$1.20 DE]B BDB||
$1.25 |[3[] Q[313||
$1.35 [3| [3[] [3[] [3|
$1.45 DDB BBBB|
$1.5o |BBDDBD|
$1.so D[3[3 [3[3[] [3 |
$1.70 [31313[][3 [] [] [3
$1.75 | [] [3[3[3[3 [] []
$1.85 D [] [] [] [] [] [3[3
$2.oo [] [] [3 [] [3 [] [] []
To remove block-out keys, pull straight up.
NOTE: Be sure block-out keys and/or dime inserts are
seated properly and ratchet dog is in place with irsspring
connected (see FIGURE8).
Be sure the proper coin sizing block isin place.
Ratchet
Dog and
Spring
Block-Out
8
FIGURE8

Changecoinsizingblock:
• Remove two screws that hold upper coin chute cover.
Remove cover (see FIGURE9).
(2) Upper Coin
Chute Cover
FIGURE 9 Anti-Cheat
Gate
Meter Case Instructions
INSTRUCTIONS TO CHANGE THE NUMBER OFCOIN SLIDE
INSERTIONS TOSTARTAPPLIANCE.
1. Disconnect power from machine.
2. Remove meter-case service door. (Fig.l)
FIGURE 10
o Removetwo screws that hold coin sizing block to upper
coin chute cover cover (see FIGURE10).
• Put new coin sizing block in place. Reinsert and tighten
mounting screws.
Replace coin chute cover. Reinsert and tighten screws.
STEP7
Replace coin receiver block into slide:
Hold coin receiver right side up in the palm of one hand.
• Lower coin slide until coin receiver block fits into the
coin slide cavity. CAUTION: Do not dislodge ratchet dog
and spring.
Hold coin receiver block in place with your fingers and
turn slide upside down.
• Insert and tighten screw.
STEP8
Install slide into coin chute. Slide can only be pushed in if
the anti-cheat gate in flange is pushed to the left. (see
FIGURE9).
STEP9
Replace coin slide stop with two screws. Replace coin
slide return spring. Replacecoin slide extension with two
screws (be sure spacers are in place).
STEP10
Replace coin slide mechanism in meter case. Replace and
tighten coin slide mounting bolt.
NOTE: It may be easierto insert coin slide mounting bolt if
you removethe timer from the mounting screwstemporarily.
3. Turn Shaft & CarT]Assembly in a clockwise direction until switch
lever arm drops into cam notch (Fig. 2).
4. Lift Adjusting Tab away from cam with finger and turn Tab to
desired number. Make sure Tab\ locks into place in new position.
5. Turn Shaft & Cam Assembly in a clockwise direction until switch
lever arm ison top of Tab to assure that both mechanism switches
are open (Fig. 3).
6. Replace meter-case service door and reconnect power to machine.
EXAMPLE: To change from $1 to $2 move tab from 1 to 2.
FIGURE 2 USEFINGER
CAM NOTCH TOLIFTPAD
ADJUSTMENT
TAB
CLOCKWISE
DIRECTION
TO LIFT
FIGURE 3
9

REPLACEMENTPARTS
If replacement parts are needed for your dryer, contact the source where you purchased your dryer, or call Frigidaire at
1-866-738-1640. Forcoin box parts, call 1-800-221-0982, Greenwald Industries.
Destroy the carton and plastic bags after the washer is unpacked. Children might use them for play. Cartons covered
with rugs, bedspreads, or plastic sheetscan become airtight chambers causing suffocation. Placeall materials in a garbage container
or make materials inaccessible to children.
The instructions in this manual and all other literature included with this washer are not meant to cover every possible
condition and situation that may occur. Good safe practice and caution MUST be applied when installing,operating and maintaining
any appliance.
Maximum benefits and enjoyment are achieved when all the Safety and Operating instructions are understood and practiced
as a routine with your laundering tasks.
Parts List for series 7682 "Quick-Chanae" Start Mechanism
Item 27A: Models 76-1030-21 (115v-60Hz)7
| 76-1030-22 (230v-60Hz) _
|item 27B: Models 76-1030-11 (115v-60Hz), I
76-1030-12 (230v-60Hz)
1 2 00-7185 #4-40 SELF-TAPPING SC
2 1 76-6009-* TIMER MOTORASS'Y
3 1 76-1037 SWITCH & BRACKET SUB-ASS'Y
4 1 76-50t4 DRIVE SELEEVE
5 1 76-2033 SLEEVE
6 1 00-8149 TORSION SPRING
7 3 00-7070 RETAINING RING
8 2 76-5013 DRIVE BUSHING
9 1 00-8003 SPRING
10 1 76-1036 RACTHETARM & PAWL ASS'Y
11 1 76-5017 RACHETWHEEL
12 1 76-2003 WASHER
13 1 59-204 SPRING
14 1 76-5012 CAM
15 1 76-5010 ADJUSTER TAB
16 1 00-7055 SPRING WASHER
17 1 00-7047 WASHER
ITE.._MM
18 I
19 2
20 2
21
22
23
24
28
26 2
27A 1
27B 1
28 1
29 1
3O 1
10
PART NO DESCRIPTION
76-2026 DRIVE SHAFT
00-7458 #4-40 3/16 PAN HD SC.
00-7097 #4 SPLIT LOCKWASHER
00-6189 SNAP SWITCH
00-6190 SNAP SW & LEVERARM ASS'Y
76-5009 SWITCH INSULATOR
76-2035 NUT PLATE
76-6000 WIRE HARNESS ASS'Y
02-0810-00 #8-32x5/16 SEMS SCREW
76-2059 MOUNTING BRACKET
76-2027 MOUNTING BRACKET
59-0314 CABLE TtE
58-172-* GROUNDWIRE
00-7558 WASHER

V8 Coin Chute Parts List
V8 Parts List
DESCRIPTION
SCREW (METRIC)
SCREW (METRIC)
TOP HOUSING
SHIM
COIN SIZING BLOCK
GATE COVER
GATE
20-3000
2 00 9724 00 7924
2 00 7938 00 7938
I 20 3019 20 3002
2 20 2042
f 20 3006 20 3006
I 20 2043 20 2006
F 20 2035 20 2000
8 20 20/I 292011
I 20 4004 20 4000
/ 00 9905 )0 9905
/ 20 3020 20 3000
I 20 302I
I 009/04 009104
4 007483 6_55
I 00 8148 00 8148
i DESCRIPTION
I6iSPRING
17 3PRFNG PROTECTOR
I8 _ACK
19 _CREW (METRIC)
20 _0¢ INSERT varies
22 SHDE STOP
25 SLIDE RATCHET DOG
26 STORAGE COMP COVER
27 SCREW (METRIC)
8 BUFFER
) RATCHET DOG POST
30 COIN RETAINER optional
20-3000
1 20 2040 20 200/ 31
20 2038 20 2007 32
/ 20 2023 20 2005 33
200 793/ 00 793/ 34
20 3023 20 500/ 35
200 7923 00 7929 37
I 20 2039 20 2004 38
I 00 8123 00 8123 39
20 5002 20 20_0 40
I 20 2041 20 2008 41
20 2037 20 2003
2 00 7935
I 20 2034
20 4005
Opt 00 8168
11
DESCRIPTION }REQ
3OIN SFZING BLOCK valies I
PRESSURE SPRING AS[_Y i Opt
r_AGNET i Opt
SHIELD IOpt
JOIN RECEIVER BLOCK _ I
i
LOCK WASHER } /
} I
BCREW (METRIC)
BCREW &,IETRIC )
SCREW
TOP HOUSING ASMY i
20-3020
20 3007
20 /012
00 9256
20 2045
00 7.54/
20 1/03 I
20-3000
20 3007
2010_2
00 9256
20 2045
20 2003
00 7934
00 7933
00 7932
00 7541
201104 I

NEW VEND PRICE
To change vend price, detach and mail the lower portion to:
Customer Service Department
Greenwald industries Inc,
212 Middlesex Ave.
Chester, CT 06412
Order required parts using this tear-off. Block-out keys will be
shipped to you at no charge. Follow product information
instructions.
Quantity.
Existing Vend Price
Name
Company_
The coin chute has been pre-set at the factory. Address
When increasing in $.25 pricing
Follow product information instructions; no extra parts required. City.
When decreasing in $.25 pricing - or - changing to StatetZip_
$.10 pricing. Daytime phone
(Coin sizing block required; see "Changing Vend Price" section.) Purchase date........
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux willpay all costs,
exceptas set forth below, for repairing or replacing any parts of this appliance that prove to be defective inmaterials or workmanship when
suchappiiance is installed, used, and maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
t. Payment acceptance devices for commercial laundry products.
2. Products with original serial numbers that have been removed, altered or cannot be readily determined
3. Normal wear and tear and gradual deterioration.
4. Product that has been transferred from its originaI owner to another party or removed outside the USA or Canada.
5. Rust on the interior or exterior of the unit.
6. Products purchased "as-is".
7. Food loss due to any refrigerator or freezer failures.
8. Damage caused at any time during shipment.
9. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances used other than in
accordancewith the provided instructions.
10. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
11. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are not a part
of the appliance when it is shipped from the factory.
12. Service calls to replace appliance light bulbs, air filters, water filters, other consumables, or knobs, handles, or other cosmetic parts.
13. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, toffs, ferry trip charges, or mileage
expensefor service calls to remote areas, including the state of Alaska.
14. Damages to the finish of appliance and/or location that are incurred during installation, including but not fimited to floors, cabinets,walls,
etc.
15 Damages caused by: services performed by unauthorized service companies; use of parts other than genuine EtectroIux parts or
parts obtained from persons other than authorized service companies; or external causes such as abuse, misuse, inadequate
power suppIy, accidents, fires, or acts of God.
16. Labor costs after ninety (90) days from your original date of purchase incurred for product repair or replacement as provided herein
for appliances operated by a concessionaire or vendor in a trailer or other motorized vehicle or at varying locations.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR REPLACEMENTAS
PROVIDEDHEREtN. CLAIMS BASED ON IMPLIED WARRANTIES, iNCLUDING WARRANTIES OF MERCHANTABILITY OR FtTNESSFOR
A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THANONE
YEAR. ELECTROLUX SHALL NOT BELIABLE FOR CONSEQUENTIAL OR iNCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGEAND
INCIDENTAL EXPENSES RESULTING FROM ANYBREACH OF THIS WRITTEN LIMITED WARRANTY ORANY IMPLIED WARRANTY.SOME
STATES AND PROVINCES DO NOTALLOW THE EXCLU-StON OR LiMiTATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,OR
LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SOTHESE LIMITATIONS OR EXCLUSIONS MAY NOTAPPLY TO YOU.THIS
WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAYALSO HAVE OTHER RIGHTS THAT VARY FROM STATETO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period shouIdservice be required.
If service is performed, it is in your best interest to obtain and keep alI receipts. Service underthis warranty must be obtained by
contacting Electrolux at the addresses or phone numbers below.
Your appliance is covered by a one year limited warranty. For one year from your originat date of purchase, Eiectrotux willpay all costs,except
as set forth below, for repairing or replacing any parts of this appliance that prove to be defective inmateriats or workmanship whensuch
appliance is installed, used, and maintained in accordance with the provided instrucfions This warranty only applies in the USA
andCanada. In the USA, your appliance is warranted by Electrolax Major Appliances North America, a division of Electrolux Home
Products, Inc. tn Canada, your appliance is warranted by Electrolux Canada Corp. Electroluxauthorizes no person to change or add to
any obligations under this warranty. Obligations for service and parts under this warranty mustbe performed by Eiectrolux or an
authodzedservice company. Product features or specifications as described or illustrated are subjectto change without notice.
USA 1.886.738.1640 Canada 1.888.738.1640
Etectrolux Major Appliances North America Etectrolux Canada Corp.
5855 Terry Fox Way
P.O. Box 212378Augusta, GA 30907 Mississauga, Ontario, Canada L5V 3E4

Contents
Consignes de s_curit6 irnportantes ................. 13-15
Avant I'installation ................................. 15
Installation _lectrique ............................. 15
Mise a la terre ........................................ 15
Alimentation en eau .............................. 15
Evacuation d'eau .................................. 15
Dimensions de I'emplacement ................ 16
Emplacement de la laveuse ................... 17
D_ballage ............................................... 17
Installation .......................................... 17
Posez le m_canisme de glissi#re & monnaie....18-20
Instructions pour le bo_tier du compteur ........... 20-21
Piecesde rechange ................................................ 21
Liste des pi_ces ............................................... 21-22
Garantie .................................................... 23
Enregistrement du produit
Pour des informations sur la garantie de Frigidaire ou pour
communiquer avec le Centre de service Frigidaire, appelez
1-866-738-1640
Pour tout service ou piece pour la machine a laver
encaissement automatique Frigidaire, ayez _ pottle de la
main le num_ro du module, le num_ro de s@ie et la date
d'achat. Enregistrez ces informations
ci-dessous :
N°de modete
N°de s_rie
Date de I'achat
Enregistrez la bo_te _monnaie
Num_ro de la cle
Le num_ro de la cl_ est situ_ sur la cl_ et!ou sur la
bo_te _ monnaie.
SL:CURIT - RELATIVE AUNE LAVEUSE
La securite de I'utilisateur et celle des autres sont tres importantes.
Le guide de I'utilisateur, les consignes d'utilisation et les directives d'installation contiennent de nombreuses
consignes de s_curit_ importantes. Toujours lire et respecter toutes les consignes de s_curit_.
[]Voici le symbole de mise en garde. Ce symbole met en garde contre les risques pouvant entratner le d_c#s
ou des blessures &soi ou aux autres. Tous les messages relatifs & la s_curit_ sont precedes du symbole de mise
en garde et du terme <<DANGER >>ou <<AVERTISSEMENT >>. Ces termes signifient :
_!_ L'utilisateur sera tu_ ou gravement bless_ s'il ne suit pas ces directives.
L'utilisateur peut _tre tu_ ou gravement bless_ s'il ne suit pas ces directives.
Tousles messages relatifs a ta securite indiquent le risque, comment reduire le risque de blessure et ce
qui peut survenir si on ne suit pas les directives.
r_ Pour votre s6curit_, suivre les directives donn6es dans le present guide pour minimiser les risques
d'incendie, d'explosion, de dommages materiels, de blessures et de mort.
- Ne pas entreposer ni utiliser d'essence ou d'autres vapeurs ou liquides inflammables _ proximit_ de cette s_cheuse
ou de tout autre appareil 61ectrom_nager.
QUE FAIRE S'IL YA UNE ODEUR DE GAZ
N'allumer aucun appareil _lectrique.
Ne toucher aucun commutateur _lectrique; ne pas utiliser le t_l_phone dans I'immeuble.
Faire sortir tousles occupants de la piece, de I'immeuble ou de la zone avoisinante.
Appeler la compagnie de gaz imm_diatement en utilisant le t_l@hone d'un voisin. Suivre les instructions de la
compagnie de gaz.
S'il est impossible de joindre la compagnie de gaz, appeler les pompiers.
L'installation et les r@arations doivent _tre effectu_es par un installateur ou un technicien qualifi_ ou par la compagnie
de gaz.
Votre laveuse est _quip_e d'un contact de s_curit_ de porte. V_rifiez I'op_ration appropri_e du systeme de couplage
quotidienne, en utilisant le proc_d_ suivant:
1. Avec la porte de laveuse ouverte, ins_rez le nombre requis de pi_ces de monnaie (ou de la carte appropriee, sur
des machines _quip_es de I'carte-commencez le syst#me) et serrez le bouton marche. LA LAVEUSE NE DOITPAS
COMMENCER !
2. Fermez la porte de laveuse. Serrez le bouton marche encore pour mettre en marche la machine. Essayez
d'ouvrir la porte, sans exercer la force excessive.
LA PORTE NE DOlT PAS S'OUVRIR ! SI LA LAVEUSE COMMENCE PAR LA PORTE OUVERTE, OU LA PORTE
PEUT ETRE OUVERTE TANDIS QUE LA LAVEUSE FONCTIONNE, LA MACHINE DOlT IMMEDIATEMENT ETRE
PRISE HORS DU SERVICE. DEBRANCHEZ LE CORDON DE SECTEUR, ET MARQUEZ LA MACHINE "EN PANNE';
JUSQU'A CE QUE LE SYST_ME DE COUPLAGE SOIT R_PARE, ET FONCTIONNEZ COMME DECRIT CI-DESSUS.
I3

Pour Prisemurale
raise _ la
pr6venirlesrisquesd'incendie telre
OUd'61ectrocution,ne pas
utiliserdefiche adaptatriceni
de cordonde rallongeet ne
pasretirer laprisedeterredu
cordon d'alimentation
electrique.Toute d6roga-tion
cetteconsignepourrait
entratner desblessures
graves,unincendieoulamort.
Hne faut el/au, un
CaB COU/)el} f et[l_r OU
(ontoumer la brx)che
de terre de cette
fiche
Cordond'alimentation avecfiche
3 brochesraisea laterre
CORRECT Utiliser 5EULEMENT
de cette foe;on
Ne pas
utiliserni melanger dejavellisant
liquide chlore avec d'autres
produits chimiques d'usage _
domestique comme [es net-
toyantspourcuvettes,lesproduits
d@ouillants,acidesoucontenant
de I'ammoniaque. Cesmelanges
peuvent d6gager des vapeurs
dangereusescapablesdecauser
desblessuresgravesou lamort.
AMMONIAQUE JAVELLISANT
POUR VOTRE
S_-CURITE
Ne pas
entreposer I/i
utiliser de Pessence
ni tout autre
vapeur ou [iquide
inflammable _
proximit_ de cet
appareil ou de tout
autre appareil
elect_om#nager.
Consignes de s_curit_ importantes CONSERVERCEMODED "EMPLO!
Pour r#,ctuirele risque de feu de choc #,lectrique de blessure graves ou de dommage aux biens, respectez
es avertissements de base #,num#,r#,sdans esInstructions de s#curit_ importantes et ceux #,num#,r#,sa-dessous:
• Pour r#,duireles risques d'incendie, d'#,lectrocution ou de blessures pendant I'utilisation de la laveuse, respecter toutes lesmisesen
garde fondamentales qui suivent.
. Toute d#,rogation _ cesraisesen garde pourrait entraTner desblessuresgraves.
Prevention des incendies
. Ne pas laver dans cet appareil des articles qui ont #,t#,au pr#,alablelav#,sou tremp#,s dans de I'essence, du solvant nettoyant, du
k#,ros_ne,de I'huile a cuisson, de la cite, etc., ni des articles qui soot souill#,sde cesproduits. Ne pas entreposer de tels articles sur la
laveuse ni _proximit#, de celle-ci. Lesproduits d#,critsci-dessusd#,gagent desvapeurs ou r#,actionschimiques qui peuvent s'enflammer
ou exploser.
• Nepas d@oser de chiffons ou de v#,tements imbib#,sd'huile ou de graisse sur le dessusde la laveuse.Ces substances d#,gagent des
vapeurs qui peuvent enflammer lestissus.
. Nepasajouter d'essence, de solvant nettoyant ni toute autre substance inflammable ou explosive a I'eau de lavage. Ces substances
d#,gagent desvapeurs qui peuvent s'enflammer ou exploser.
•Dans certaines circonstar ces,de Ihydrog#,ne peut s accumuler danslescanalisations d eau chaude qui demeurent inutilis#,espendant
deux semaines ou plus. L'HYDROGENE ESTUN GAZEXPLOSIF. Sila canalisation d'eau chaude n'a pas#,t#,utilis#,edepuis au moins
deux semaines, ouvrir tousles robinets d'eau chaude et laisser couler I'eau pendant plusieurs minutes avant d'utiliser la laveuse. De
cette fat on, toute trace d'hydrog#,ne serapurg#,ede lacanalisation. L'hydrog_ne est ungaz explosif; ne pasfumer ni utiliser deflamme
vive pendant la purge de la canalisation.
•Toute d#,rogation aces raisesen garde pourrait entraTnerun incendie, Lineexplosion, desblessuresgravesou desdommages auxpi#,ces
en caoutchouc ou en plastique de la laveuse.
Protection des enfants
• Nepaspermettre aux enfants dejouer surla laveuse ni a I'int#,rieur de celle-ci. Lorsque la laveuse est utilis#,ea proximit#, d'enfants, il
est recommand#,de lessurveiller attentivement. Desque lesenfants sont assezgrands, leur enseigner I'utilisation correcte et s#,curitaire
detousles appareils #,ledrom#,nagers.
. D#,truirela boite, le sacen plastique et lesautres mat#,riauxd'emballage qui enveloppent la laveuse.Lesenfants risqueraient de s'en
servircommejouet. Lescartons recouverts d'un tapis, d'un couvre-lit ou d'une feuille deplastique peuvent former unechambre #,tanche.
• Garder lesproduits alessivehors de port#,e des enfants. Pour pr#,venir les blessures, respecter toutes lesconsignes de s#,curit#,qui
figurent surI'#,tiquette deces produits.
° Avant de mettre la laveuse hors d'usage ou de lajeter, retirer la porte pour #,viterque quelqu'un ne s'emprisonne accidentellement
dans I'appareil.
• Toute d#,rogation a cesmisesen garde pourrait entratner desblessuresgraves.
Pour pr#,venirlesblessures, ne pasins#,rerla main dons la laveusetant que lespi#,cesmobiles sont en mouvement. Avant de charger
ou de d#,charger une brass#,eou d'ajouter desarticles, enfoncer les#,lecteurde cycleetattendre que letambour s'arr_te compl#,tement
avant d'ins#,rer la main dons la laveuse.
° Toute d#,rogation aces misesen garde pourrait entratner desblessuresgraves.
. Cette laveuse est pourvue d'un disjoncteur thermique. Lemoteur s'#,teint de lui-mame Iorsqu'il surchauffe. La laveuse red#,marre
d'elle-m#,me apr#,sunep#,riodede refroidissement pouvant atteindre 30 minutes acondition qu'elle n'ait pas#,t#,arr#,t#,emanuellement.
Prevention des blessures
° Examinez le journal de systeme de couplage de porte. Suivez les instructions a la page pr#,c#,dente.
Pour pr#,venirlesrisquesd'#,lectrocution etassurer la stabilit#,de I'appareil pendant lefonctionnement, la laveusedoit #,treinstall#,eet
mise _ laterre par un technicien qualifi#,conform#,ment aux codes Iocaux. LaNotice d'installation accompagne la laveuse,mais elle est
destin#,ea I'installateur. Sereporter a la NOTICED'INSTALLATION pour obtenir la marche a suivre pour la mise a laterre. Sila laveuse
doit #,tred@lac@, lafaire v#,rifieret r#,installerpar un technicien qualifi&
• Pour pr#,venirlesblessureset #,viterd'endommager la laveuse,lecordon d'alimentation #,lectriquede lalaveusedolt @trebranch#_dans
une prise a 13trous correctement mise a la terre et polaris#,e.La troisi_me broche de mise ala terre ne dolt en aucun cas _tre
retiree. Ne iama isrelier la la veuse a un tuyau de gaz pour la mettre b la terre. Nepas uti liser de corden de raIionge ni de fiche
adaptatrice.
° Suivrele mode d'emploi de chaque produ it a lessiveutilis& Uneutilisation incorrecte pourrait produire desgaztoxiques et causerdes
blessuresgraves ou la mort.
Nepas utiliser plus d'un seulproduit _ lessivepar brass#,e,a moins d'indications contraires sur I'emballage.
Ne pas m#,langer d'eau de javel avec de I'ammoniaque ou des produits acides comme levinaigre.
I4 Imprimeaux_tats-Unis

Consignes de s_curit_ importantes (suite)
o Pour prevenir lesblessuresgraves et ne pasendornmager la laveuse :
Lesr_parati_nset_entret_end_vent_treeffectu_suniquementparunagentdeserviceaut_risea moins d'indications
sp_cifiques _ I'effet contraire dans le present Guide de I'utilisateur. N'utiliser que des pi_ces recommandees par le fabricant.
Nepas modifier lescommandes.
Nepas installer ni entreposer la laveusedans un endroit ou elle serait exposee aux conditions atmosph_riques.
N'installezpas la machine a laver sur un tapis. Installez la sur un plancher solide. IIs'averera peut-_tre necessairede solidifier
le plancher pour emp_cher lesvibrations et le deplacement de la machine.
Pour reduire lesrisquesd'electrocution, debrancher I'appareil desasource d'alimentation avant d'effectuer toute mesure d'entretien.
M_me si lescommandes sont en position ferm@ (OFF),I'appareil demeure relie a sasource d'alimentation.
AVANT L'INSTALLATION
Outils requis pour I'installation :
1. Tournevisadoui%del/4 po
2. Cle a cliquet avec douille de 3/8 po
S. Cleouvertede3/8 po
4. Cle a cliquet avec douille de 7/16 po
5. CI6ouvertedeg/16 po
6. Pincesmultiprise
7. Niveau de menuisier
INSTALLATION ELECTRIQUE
CIRCUIT-Derivation distincte convenablement polaris@et mise
a laterre de 15 A avecfusible a retardement ou disjoncteur de
I5A.
ALIMENTATION ELECTRIQUE - 2 fils avec prise de terre,
120 volts, une phase, 60 Hz, courant alternatif. NOTE:
L'utilisation d'laveuse aveclecourant faire de generateu ra gaz,
g_nerateur asolaire, generateura vent, ou d'autre generateur
excepte la centrale 61ectrique n'est pasrecommander.
Encasdedoute, contacter un electricien agr6e.NEPAS couper
ni modifier labroche de raise_laterre du cordon d'alimentation
electrique. Lorsque la prise murale n'a que deux ouvertures, il
incombe au proprietaire de lalaveusedecontacter un(qectricien
agr(_epour remplacer cette prisepar une priseatrois ouvertu res
convenablement mise b la terre.
ALIMENTATION EN EA U
Lesrobinetsd'eau chaudeetd'eau froide DOIVENT6tre instalK_s
au plus 107 cm (42 po) de I'arrivee d'eau de la laveus. Les
robinets DOIVENT_tre du type qu'on utilise pour un boyau
d'arrosage et mesurer 1,g cm (3/4 po) pour que les boyaux
d'arrivee d'eau puissent 6tre branches. La pression de I'eau
DOITsesituerentre lOet 120 livres par pouce carr_ @cartde
pression maximum entre I'eau chaude et I'eau froide de 10 Ib/
po;). Leservicedesaqueducs de votre Iocalite peut vous aider
a determiner la pression d'eau. L'eau chaude devrait 6tre a
environ 4g°c (120%).
EVACUATION D'EAU
PRISEDE COURANT- Prise_ 3 ouvertures convenablement
mise a la terre et situee de fa_on ace que le cordon
d'alimentation _lectrique soit accessible unefois la laveuseen
place. NOTE:Prisea GFI(Ground Fault interrupter) n'est pas
requise. MISE ALA TERRE
Le branchement inadequat du
conducteur de raise a la terre pourrait presenter un risque
d'electrocution. En cas de doute quant a la raise _ la terre
adequate de I'appareil, contacter un electricien agree.
1. La laveuse DOIT_tre raise a la terre. Encas de mauvais
fonctionnement ou de panne, la raisea la terre reduit les
risquesd'electrocution en offrant un parcours de moindre
resistance au courant.
2. Puisque cette laveuse est pourvue d'un cordon
d'alimentation ebctrique comportant un conducteur etune
fiche de terre, lafiche DOIT6t_e branchee dans une prise
murale_ conducteur en cuivreconven-aNement raccord6e
au reseauet raisealaterre conformeme nt _to uslescodes
etordonnances Iocauxou, s'il n'existe pasde codesIocaux,
conformement au Code ANSVNFPA70 (l'edition la plus
recente).
Hauteur minimum :
61 cm(24 po)
Hauteur maximum :
244 cm (96 po)
1. Renvoicapabled'evacuer64,3 L(17 gallons)parminute.
2. Tuyau de chute de 3,18 cm (1-I/4 po) de diametre au
minimum.
3. Hauteur du tuyau de chute par rapport au plancher :
i
I
I
I
O244 cm
(96 po)
max.
61 cm
(24 po)
mln.
I5
REMARQUE:
Leboyaud'evacuation relieala laveusepeutatteindre untuyau
de chute de 147 cm (58 po). Pour lestuyaux de chute plus
elev@s,seprocurer un boyau n° de piece IS1461201 aupres
d'un fournisseur de piecesagree. Silerenvoi mesure moins de
61 cm (24 po), poser un ensembb anti-siphon, se procurer
aupres d'une quincaillerie locale.

DIMENSIONS DE L'EMPLA CEMENT
17
(1.9;F_-
i i
-J3.72)
C6te
1½
(3.81)
Cordon
inch(cm) Pieds de nivellement
43/8
(11.2)
8"['
(20.4)
36
[913)
34%
(87.9)
......Y..........................Y.........................
26%
Robinets
d'arrivee
d'eag
4, y
16

EMPLA CEMENT DE LA LAVEUSE
NEPASINSTALLERLA LAVEUSE :
1. Darts un endroit expose _ un ecoulement d'eau ou aux
conditions atmospheriques. Latemperature ambiante nedoit
jamais descendre en-dessous de 15,6°C (60%) pour que Ja
laveusefonctionne correctement.
2. Dans un endroit ou elle serait en contact avecdes rideaux ou
destentures.
;3. Darts un endroit (garage ou structure semblable) ou de
I'essence ou d'autres produits inflammables sont conserves
ou entreposes ('j compris une automobile).
4. Sur un tapis. Leplancher DOIT_tre ferme et presenter une
pente maximum de 1,27 cm par 30,5 cm (1/2 po par pied).
Pour #viter toute vibration ou tout mouvement, il peut #tre
necessairede renforcer le phncher.
IMPORTANT
DEGAGEMENTSMINIMAUXPOURL'INSTALLATION
Installation en ak6ve ou armoire:
C6tes, Arriere = 0 cm (0 po)
Dessus= 0 cm (0 po) ModUle _ ConsoleAvant
Dessus= 38, 1cm (15 po) Mod_le _Console ArtiSte
Installation en armoire: Avant = 2,B4 cm (1 po)
Ventilation requisedansla porte du placard: 2 ouvertureschacune
2 volets de 387 cm2(60 po2_chacun, a 7,6 cm (3 po) du baset du
haut de la porte. DEBALLAGE
1.Couper lecarton d'emballage le long de la ligne pointill@edans
le has de I'appareil.
2. En laissantI'appareil darts le carton, coucher la laveuse surson
panneau arriere.
13.Retirer la baseen styrofoam.
4.Replacer delicatement la laveuse _ la verticale, puis retirer le
carton.
5.Deplacerd(_licatementlalaveusejusqu'a cequ'elle soit aenviron
122 cm (4 pieds) de son emplacement ddinitif.
6. Retirer lespi@cessuivantes de I'arriere de la laveuse
3 boulon,
3 entretoises en plastique jaunes,
2 ou :3attaches
metalliques en
folme de "R"
7. Retirer le panneau avant de la laveuse.
8. Demontezles4 ecrous etles6 grossesrondelles qui retiennent
lesdeux attaches d'expeditionjaunes au tambour et _ la base.
Soulevez letambour et retirez lesattaches (un ruban jaune
entoure leselements a retirer). IIfaut retirer cesattaches afin
de liberer lecordon d'alimentation desanneauxd'expedition.
9. Retirer le grand morceau de styrofoam situ6 sous le tambour.
Soulever le tambour, basculer le basdu morceau de mousse
vers I'interieu et vers I'arri@rede la laveusejusqu'a cequ'il se
degage, puis le sortir en tirant.
10. Retirer et jeter le ruban jaune et I'etiquette du devant de la
laveuse.
11. A I'arriere de lamachine a laver,irezsoigneusement lecordon
d'alimentation a travers du trou pourvu _ cette fin dans le
panneau arri@re.
12. Remonter le panneau de serviceet lesvis.
REMARQUE:
Dans I'eventualite ou la machine _ laverdolt @tretransportee
une date ulterieure, ilfaut r_installerla quincaillerie d'expedition,
les attaches et supports, pour prevenir tout dommage durant
I'expedition. Conservez cette quincaillerie dans I'envelope de
plastique fournie a cet effet.
INSTALLATION
®
©ENFORME
DE 'P'
1.0uvrir les robinets d'eau chaude et d'eau
froide defaqon _nettoyer lacanalisation et
eliminer toute par_iculequi pourrait engorger
lefiltre des robinets.
2.Enlevezdu sacen plastique lestuyaux d'arrivee
et les rondelles caoutchouc et installez les
rondelles a chaque extremitY_.
I7

3.(Quantre-vingt-dixdegredescoudes)Branchezsoigneusement
letuyaud'arriveemarqueHOT(CHAUDE)alasortieinfd_rieure
delasoupaped'eau.Serrezalamain,puisserrezencorede
2/3detouraI'aidedepinces.BranchezsoigneusementI'autre
tuyauCOLD(FROIDE)d'arriveealasortiesuperieuredela
soupaped'eau.Serrezalamain,puisserrezencorede2/3de
touraI'aidedepinces.
NE FAUS-SEZ PA5 LE FILETAGEET NE SERREZPAS TROP
CESRACCORDEMENTS.
4.Determinez quel est le robinet d'eau CHAUDE et branchez
soigneusement le tuyau d'arrivee inferieur au robinet d'eau
CHAUDE, serreza la main, puisserrez encore de 2/3 de tour, a
I'aide de pinces. Branchez soigneusement le tuyau d'arrivee
superieur au robinet d'eau FROIDE,serreza lamain, puisserrez
encore de 2/13de tour, a I'aide de pinces.
5. Recourber I'extremit6 du boyau de vidange en
forme de Uverslecircuit devidange. Leplacerclans
une cuve ou un tuyau fixe et fixer le tout avec _
I'attache fournie dans I'ensemble ci-joint. _-_I
REMARQUE: Sileboyaudevidangeestplace ! .
dans un tuyau sans6tre recourbe en forme de U, tJ_
un effet de siphon peut en resulter. IIfaut qu il y
ait une prised airautour du boyau devidange. Un
ajustement trop serre du boyau dans letuyau de
vidange peut egalement causerun effet de siphon.
che
6. Placer la laveuse avec soin dans son emplacement ddinitif.
Le bruit et lavibration excessifs peuvent atre emp6ches en
nivelant correctement la laveuse.
7. Pour I'installation debout libre et avec la laveuse en elle est
la position finale, placent un niveau sur la laveuse. Ajustez
lesjambes de mise a niveau ainsi la laveuse est, et coin-a-
coin stable de I'avant a I'arriere et vertical de niveau.
g. Brancher le cordon d'alimentation (electrique dans une prise
murale raise a la terre.
REMARQUE :S'assurerque le courant est coupe a la botte de
fusiblesou dedisjoncteursavantde brancherlecordon danslaprise.
10.Remettre lecourant a labotte defusibles ou de disjoncteurs.
11.Soyez sOr que vous avez lu "les instructions de sOrete
importantes" avant d'actionner cette laveuse.
12.Fairefonctionner lalaveusesurun cyclecomplet. S'assurerqu'il
n'y a pasde fuite et que la laveusefonctionne correctement.
13.Placercette notice prosde la laveuse pour reference future.
REMARQUE : Un schema de cablage setrouve darts le panneau
avant de la laveuse.
REGLAGE DE LA BO[TE A MONNAIE
Le r_glage serre de la botte
monnaie est effectue
I'usine. Le client peut la
r__glera son goQt en
desserrant lesecrous
creneaux. Voir Fig. 2
Coftseyver eft dossier tou$ I_
num_ros de cl_ de bofte a monnaie. Fig. 2
Une tie perdue ne peut _tre remplacee qu'en commandant les
numeros de cle a I'etablissement ou I'appareil a ete achete. Le
numero de tie est situe a lafois sur la cl_ et derriere le panneau
du fond de la boite a monnaie. Si le num_ro de cl(_n'est pas
disponible, le verrou dolt _tre perce pour retirer la bofte a
monnaie.
INS TRUCT!ON POUR MODIFIER LE PRIX DE VENTE
OUTILS REQUIS
• Tournevis a fente moyen pour ecrou
o Tournevis a petite pointe cruciforme
Placezlestournevis et autres articles demontes de I'assemblage
de la glissiere a monnaie sur un linge de maniere a ne pas les
perdre.
EAPE1
Demontez le mecanisr'nede glissi_re du bottler du compteur
(Voir Figure 1)
Appuyez des coins et des c6tes alternatifs et sentez pour le
plus lager mouvement. Ajustez la jambe appropriee ainsi la
laveuse est PLEINEsur le plancher sur CHACUNE DESquatre
jambes. Gardez la prolongation de raise a niveau de jambe
a un minimum pour la meilleure execution de la laveuse.
8. Pour des installations de piedestal, Voir les instructions
d'installation additionnelles incluses avec le piedestal.
'_TAPE2
Demontez le rallonge de glissiere a monnaie de la glissiere a
monnaie en d#montant les deux vis de montage et les
entretoises. (Voir Figure 2)
I8

"_TAPE3(2) Vis d'arr_t
sensdessusdessous.
, Demontez I'arr_t de glissiere
monnaie en demontant los
deux vis au bas de la chute (voir Figure 13).
FIGURE 3
,, Retirez de la chute a monnaie en la tirant
de la glissiere _ monnaie (voir Figure 4).
FIGURE 4
ETAPE4
Tournez la glissi_re a monnaie sons dessus dessous et demontez la vis fixant le bloc de
cuvette a monnaie (voir Figure 5).
(1) Vis de
CUVette
Compartiment de pi_ces
ETAPE5 FIGURE5 de rechange et vis.
Demonter le bloc de la cuvette a monnaie de la glissiere a monnaie (Volt Fig. 6):
,, Tournez le c6te droit de la glissiere _ monnaie vers le haut. Gardez le bloc de la
cuvette a monnaie en place avec vos doigts.
,, Soulevez prudemment la glissiere a monnaie du bloc de la cuvette _ monnaie. Au
besoin, agitez doucement la glissiere _ monnaie pour la desserrer du bloc.
_'TAPE6
Fixez le nouveau prix de vente en
ajoutant ou enlevant los cles
bloquees appropriees et/ou les
languettes _ piece de monnaie selon
le Tableau de prix de vente
(voir Figure 7).
NOTA : Losfentes de couleur noire
sont fermees par une cle bloquee.
FIGURE 7
TABLEAU DEPRIX DE VENE
VEND COIN SLOTS
PRfCE 12345678
o|||||I|I
$.10 D || | | |i |
$.20 DD | || |i |
$.25 |IB||III
$.35 DIDi|l|i
$.45 D D _ I i||I
$.50 IIII [][] |11 IIII
$.6o DII [] []II | | II
$.70 DD[][]IIIi
$#5 I I[][][] I I I
$.85 Di[] []1] I i I
$.95 DD[] [][]1 ! i
$_.00 I I[] I] I]1] I i
$1.10 _ | D D D [_II |
$_.20 _ _1111
$1.35 D| [_ [_[_[_[_|
$1.45 D u [_ [_[_[_ [_|
$1.50 | [] [] [] [] [] [] II
$_.s0 _ [_[_ [_[_ [_[_|
$1.70 [313[_ [_[_ [_ [_[_
$1#5 | [_[_ [_[_[_[_[_
$1.85 D[_[_ [_[_[_[_[_
$2.0o [_[_[_[_[_ [_[_[_
Bloc de cuvett
& monnaie FIGURE 6 I9

Pourdemonterlesclesbloquees,tirez-lesenlignedroite.
NOTA :Assurez-vous que lescles bloquees et/ou leslanguettes a
piece de monnaie sont bien assises et le toc _ rochet en place
avec son ressort raccorde (voir Figule 8).
Assurez-vous que le bloc de dimension de piece de monnaie
approprie est en place.
Cl_s bloqu_es
Zoc et ressort
b rochet
#
FIGURE 8
Changer un bloc de dimension de piece de monnaie :
o Demontez lesdeux visfixant le couvercle superieur de la chute
monnaie. Retirez le couvercle (voir Figure g).
(2) Vis du
couverde de
la chute
monnaie
sup_rieure.
FIGURE 9
(2) Vis de bloc de L_ - __...
dimension de _
pi cede /2:
monnaie. _ _ "_
FIGURE 10
La barri_re le
and-tricher
Bloc de
dimension
de piece de
monnaie.
ETAPE7
Replacez le bloc de la cuvette _ monnaie clans la glissi_re:
, Tenez le c6te droit de la cuvette a monnaie vers le haut
dans la paume de votre main.
o Abaissez la glissiere a monnaie jusqu'a ce que le bloc de
cuvette a monnaie s'ins_re darts la cavite de la glissiere
monnaie. ATTENTION : Ne d(_logezpas le toc et le ressort
rochet.
, Tenez le bloc a cuvette a monnaie en place avec vos doigts
et tournez la glissiere sens dessus dessous.
o Inserez et serrez los vis.
ETAPE8
Posez la glissiere dans la chute a monnaie. La glissiere ne
pout _tre inseree que si la g_chette anti-vol dans la bride est
poussee a gauche (voir Figure 9).
ETAPE9
Reposez I'arr_t de la glissiere a monnaie a I'aide des deux
vis. Reposez le ressort de retour de glissiere a monnaie.
Reposez le rallonge de glissi_re _ monnaie _ I'aide des deux
vis (assurez-vous que los entretoises sont en place).
ETAPE10
Reposez le mecanisme de glissiere a monnaie dans le bo_tier
du compteur. Reposez et serrez le boulon de montage de la
glissiere a monnaie.
NOTA "II pout _tre plus facile d'inserer le boulon de montage
de la glissiere _ monnaie si vous demontez temporairement
la minuterie des vis de montage.
Instructions pour le boitier du compteur
INSTRUCTIONS POUR CHANGER LENOMBRE DE
PLAQUETTES DE GLISSIEREA MONNAIE POUR
DEMARRER L'APPAREIL
1. Mettez I'alimentation de I'appareil hors tension.
2. Demontez la porte de service du boftier du compteur.
(Fig. 1)
,, Demontez lesdeux vis fixant le bloc de dimension de piece de
monnaie au couvercle superieur de la chute a monnaie
(voir Figure 10).
Posez le nouveau bloc de dimension de piece de monnaie.
Reposez et serrez losvis de montage.
o Replacez le couverde de la chute b monnaie. Reinserez et
serrez los vis.
2O
3.Tournez dans le sonsdesaiguilles d'une montre I'assemblage
de I'arbre et de la came jusqu'b ceque le bras de levier de
I'interrupteur tombe dans I'encoche de la came. (Fig. 2)
4. Soulevez la languette de r(_glage hors de la came avec les
doigts et tournez la languette au chiffre desire. Assurez-
vous que la languette est bien verrouill_e en place dans sa
nouvelle position.
