Frigidaire GLTF1570F User manual

Product No. GLTF1570FS0
Series Frigidaire
Market Canada
Color white
Volts 120
Wiring Diagram 134832300
Owner's Guide 134837900
Energy Guide 134814800
Installation Instructions 134836900
Operating Instructions 134836600
P12L0036.EPS P12C0352.eps P12V0076.eps P12T0087.eps 134832300-1.eps
134832300-2.eps
Electrolux Major Appliances
North & Latin America
5855 TERRY FOX WAY
MISSISSAUGA, ONTARIO, CANADA L5V
3E4 Publication No.
5995484259
07/02/13
(EN/SERVICE/WC)
361
FRONT-LOAD
WASHING MACHINE
Model No.
GLTF1570F
Copyright ©2007 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995484259 GLTF1570FS0
02/07 2
CONTROL PANEL
MAX
LIQUID
BLEACH
LIQUID
BLEACH
MAX
FABRIC
SOFTEN
FABRIC
SOFTEN
44
37
33
40
32
33
36
38
43
39
26
46
26
42
27
13
17
21
18
29
19
6
1
2
3
7
9
76
75
70
P12C0352
45
15 14
63
33
69
30
31
54

GLTF1570FS0 Publication No: 5995484259
# Functional Parts 3 02/07
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
1 131272100 Cover, bleach
2 131272000 Cover, softener
3 131271910 Drawer, dispenser
6 131374500 Latch, disp drawer hdl
7 131427500 Spring
9 131691248 Handle, dispenser, w/trim
13 # 134401700 Switch, temp selector, 7 position
14 # 131963800 Beeper, signal switch
15 # 134126800 Switch, option selector, 2 position
17 # 134818201 Switch, pressure, single level
18 # 134795000 Timer
19 131243800 Screw, pan hd locking, 8-32CA x 0.375, cup point
21 131243700 Screw, pan head, 8-18AB x 0.375
26 131823400 Screw, 8-18 x 2.00
27 131887220 Console, frame/trim assy
29 134042700 Knob, rotary, white
30 134042400 Knob, timer, white
31 131853900 Pointer, timer, white, gray indicator
32 131786100 Hose, siphon/valve
33 131306216 Clamp
36 # 131974700 Valve, dispenser, w/seal
37 131271600 Hose, tub
38 131803710 Dispenser Assy
39 131863300 Siphon
39* 131307900 Clamp, siphon/bellows
40 # 134040800 Switch, on/off, white, round
42 131168200 Screw, pan head, 8-18B x 0.31
43 131749200 Gasket, seal
44 # 131899800 Thermistor, w/hose & clamp
45 5303321107 Bushing, idler
46 134191412 Panel, control mtg., wing bend
54 5308015493 Spacer, washer, timer shaft
63 # 134175600 Switch, 3 posn rotary
69 # 134565600 Wiring Harness, main
70 134178901 Screw, 8-18AB x 0.455
75 # 131949010 Lamp, status ind., with bracket
76 131974500 Screw, pan head, 6-20AB x 0.750, #8 comb head
* 131931201 Dampener, vibration, 3.5 x 2 x 2 in., foam

Publication No: 5995484259 GLTF1570FS0
02/07 4
CABINET/TOP

GLTF1570FS0 Publication No: 5995484259
# Functional Parts 5 02/07
* Non-Illustrated Parts
CABINET/TOP
POS. NO PART NO. DESCRIPTION
1 131279602 Hose, water inlet, cold
2 131168200 Screw, pan head, 8-18B x 0.31
3 131279603 Hose, water inlet, hot
4 # 134149220 Controller Assy, speed, w/base & shield
7 131205300 Screw, 10-16 x 0.750
8 # 131763245 Door Lock/Switch Assy
9 131303300 Screw, pan head, 10-16AB x 0.500, locking
10 131278700 Frame, outer door, white
11 131278800 Panel, door glass
12 131278900 Frame, inner door, white
13 134227100 Screw, flat head, 10-16 x 0.600, quadrex
14 131763310 Striker, door/lock/sw
15 134264600 Hinge, door
16 131696300 Screw, quad pan head, 10-16 x 0.312
17 131346400 Pin, panel locator
18 131279300 Panel, service, white, front
19 131358400 Screw, hex washer hd, 8-18AB x 1.125
20 131460900 Bracket, top panel mtg., front
21 131243700 Screw, pan head, 8-18AB x 0.375
22 131279500 Retainer, spring steel
23 131243800 Screw, pan hd locking, 8-32CA x 0.375, cup point
24 134086842 Panel, white, top
25 131668200 Bracket, top panel mtg.
26 134178901 Screw, 8-18AB x 0.455
28 131978500 Panel, back
29 131752030 Panel, cabinet front, white
30 131859600 Shield, overflow
31 # 134501000 Power Cord, electric svce
32 5303209428 Bushing, power cord
33 # 134812800 Valve, water, 115 V
35 131732902 Bracket, reinforcement, top rear
36 131841600 Leveling Leg Assy, bolt, pad & nut
44 131707800 Ring, drain hose
45 # 134592700 Hose, drain
58 131800410 Insulation, noise absorber
58A 131744202 Damper, vibration
64 # 134224300 Control Board, temperature, automatic
65 131894600 Housing, temp cont board
70 134048600 Shield, drip protector
71 134048400 Base, controller mtg
76 134390701 Panel, side, white, RS/LS, (2)
77 131458240 Base Plate
80 134547800 Screw, 10-16AB x 0.375
* 131931201 Dampener, vibration, 3.5 x 2 x 2 in., foam
* 5303937142 Shipping Brace Kit

Publication No: 5995484259 GLTF1570FS0
02/07 6
MOTOR/TUB
7
49
8
3
36
14 16
13 19
20
21
17
18
12
11
10
15
35
58
41
48
48
43
42 32
31
33
30
31
45
44
26
27
28
29
25
3
23
22
P12T0087
40

GLTF1570FS0 Publication No: 5995484259
# Functional Parts 7 02/07
* Non-Illustrated Parts
MOTOR/TUB
POS. NO PART NO. DESCRIPTION
3 131793302 Bolt, carriage, 1/4-20 x 4.00
6 131975300 Counterweight, one piece
7 131277300 Spring, boot retainer
8 134177600 Bellows, door boot
10 131304700 Nut, hex, 1/4-20 UNC-2B, (2)
11 131276900 Washer, Bellville, spring steel
12 131793500 Plate, counterweight
13 131618600 Shell, outer tub, front
14 134144700 Spring Assy, suspension, w/sleeves
14* 131560000 Sleeve, protector, lwr spring hook
14* 131592200 Sleeve, protector, upr spring hook
15 131303900 Screw, hex washer head, 1/4-10A x 2.165
16 131618500 Drum Assy, spin basket
17 131274600 Vane
18 131302800 Screw, 10-16AB x 0.375
19 # 131770600 Motor
20 131303500 Screw, 12-14AB x 1.50, motor mtg.
21 134146100 O-ring, tub
22 131462800 Shell, outer tub, rear, with bearing
23 134125900 Counterweight, drum rear
25 # 134051000 Belt, drive, 6-rib
26 # 131883400 Pulley, drum drive, large, rear
27 131304400 Washer, 0.41 x 1.50, 0.12 thick
28 131304500 Washer, lock, 3/8
29 131303700 Screw, pulley mtg., m10 x 0.92, metric
30 131268200 Shock Absorber, air, stabilizer
31 131268300 Pin, shock mtg.
32 131268100 Bracket, shock mtg.
33 134532200 Screw, 10-16AB x 0.500
35 # 134051100 Pump, drain
40 134565200 Filter, pump
41 134044200 Hose, coin trap, tub-to-pump
42 134737300 Clamp, hose
43 131277500 Chamber, air
44 131277600 Hose, air pressure
45 131306202 Clamp, hose
48 131306234 Clamp, hose, wire
49 134266500 Clamp, bellows/boot, 0.059 OD wire, spring held
58 134160900 Screw, washer hd, 10-16AB X 0.75
* 134814800 Energy Guide

Publication No: 5995484259 GLTF1570FS0
02/07 8
WIRING DIAGRAM

GLTF1570FS0 Publication No: 5995484259
# Functional Parts 9 02/07
* Non-Illustrated Parts
WIRING DIAGRAM
