Frigidaire GLTF530D User manual

Product No. GLTF530DS0
Series Frigidaire
Market Lowes
Color white
Volts 120
Wiring Diagram 134390100
Owner's Guide 134031900
Energy Guide 134393000
Installation Instructions 134127900
Operating Instructions 134392600
P12L0050.eps P12C0331.eps P12V0057.eps P12T0083.eps 134390100_1.eps
134390100_2.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995409868
04/05/12
(EN/SERVICE/KC)
361
FRONT-LOAD
WASHING MACHINE
Model No.
GLTF530D
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995409868 GLTF530DS0
05/04 2
CONTROL PANEL
MAX MAX
LIQUID
BLEACH
LIQUID
BLEACH
MAX MAX
FABRIC
SOFTEN
FABRIC
SOFTEN
44
37
33
32
33 38
36
43
39
26
46
12
42
27
13
14
17
21
18
30
29 31
54
16
19
6
1
2
3
7
9
8
P12C0331
45
53
33
69
40

GLTF530DS0 Publication No: 5995409868
# Functional Parts 3 05/04
* Non-Illustrated Parts
CONTROL PANEL
POS. NO PART NO. DESCRIPTION
1 131272100 Cover, bleach
2 131272000 Cover, softener
3 131271910 Drawer, dispenser
6 131374500 Latch, disp drawer hdl
7 131427500 Spring
8 131373800 Magnet
9 131691208 Handle, disp drawer, w/trim & tape
12 # 131505901 Switch, reed
13 131857500 Switch temp select 3pos rot
14 # 131048300 Buzzer, adjustable
16 # 131724700 Light, pilot
17 # 134381100 Switch, pressure
18 # 134378400 Timer
19 131243800 Screw, pan hd locking, 8-32CA x 0.375, cup point
21 131243700 Screw, pan head, 8-18AB x 0.375, cr/sq drive
26 131823400 Screw, 8-18 x 2.00
27 131887207 Console, frame/trim assy
29 131761704 Knob, rotary, white/dark gray
30 134191800 Knob, timer
31 131853900 Pointer, timer, white, gray indicator
32 131786100 Hose, dispenser
33 131306216 Clamp
36 # 131974700 Valve, dispenser, w/seal
37 131271600 Hose, tub
38 134266700 Dispenser Assy, housing, w/cover, valves
39 131863300 Siphon
39* 131307900 Clamp, siphon/bellows
40 # 134040800 Switch, on/off, white, round
42 131168200 Screw, pan head, 8-18B x 0.31
43 131749200 Gasket, seal
44 131786000 Hose, dispenser
45 5303321107 Bushing, idler
46 134191412 Panel, control mtg., wing bend
46*# 134390000 Wiring Harness
* 131931201 Dampener, vibration, 3.5 x 2 x 2 in., foam
53 131724800 Lens, pilot light
54 5308015493 Spacer, timer shaft
69 131907500 Wiring Harness, dispenser valve

Publication No: 5995409868 GLTF530DS0
05/04 4
CABINET/TOP
21
2
20 22
1
3
26
25
24
2
31
32
44
8
33
35
13
13
14
2
45
28
4
70
71
77
76
76
21
21
36
9
9
17
19 18
30
39
7
15
29
16
10
11
12
P12V0057
23
23

GLTF530DS0 Publication No: 5995409868
# Functional Parts 5 05/04
* Non-Illustrated Parts
CABINET/TOP
POS. NO PART NO. DESCRIPTION
1 131279602 Hose, water inlet, cold
2 131168200 Screw, pan head, 8-18B x 0.31
3 131279603 Hose, water inlet, hot
4 # 134149200 Controller Assy, speed, w/base & shield
7 131205300 Screw, 10-16 x 0.750
8 # 131763200 Door Lock/Switch Assy
9 131303300 Screw, pan head, 10-16AB x 0.500, locking
10 131278700 Frame, outer door, white
11 131278800 Panel, door glass
12 131278900 Frame, inner door, white
13 131302901 Screw, 10-16 x 0.750
14 131763310 Striker, door/lock/sw
15 134264600 Hinge, door
16 131696300 Screw, quad pan head, 10-16 x 0.312
17 131346400 Pin, panel locator, side
18 131279300 Panel, Service, white, kick plate
19 131358400 Screw, hex washer hd, 8-18AB x 1.125
20 131460900 Bracket, top panel mtg., front
21 131243700 Screw, pan head, 8-18AB x 0.375, cr/sq drive
22 131279500 Retainer, spring steel
23 131243800 Screw, pan hd locking, 8-32CA x 0.375, cup point
24 134086842 Panel, white, top
25 131668200 Bracket, top panel mtg.
26 134178901 Screw, 8-18AB x 0.455
28 131978500 Panel, back
29 131752030 Panel, cabinet front, white
30 131859600 Shield, overflow
31 # 134100800 Power Cord, electric svce
32 5303209428 Bushing, power cord
33 # 5303207418 Valve, water
35 131732902 Bracket, reinforcement, top rear
36 131841600 Leveling Leg Assy, bolt, pad & nut
39 134178900 Screw, Quad, 8-18AB x 0.455
44 131707800 Ring, drain hose
45 134049200 Hose, drain
70 134048600 Shield, drip protector
71 134048400 Base, controller mtg
76 131267401 Panel, side, white, (2)
77 131458240 Base Plate
* 5303937142 Shipping Brace Kit

Publication No: 5995409868 GLTF530DS0
05/04 6
MOTOR/TUB

GLTF530DS0 Publication No: 5995409868
# Functional Parts 7 05/04
* Non-Illustrated Parts
MOTOR/TUB
POS. NO PART NO. DESCRIPTION
3 131793302 Bolt, carriage, 1/4-20 x 4.00
6 131975300 Counterweight, one piece
7 131277300 Spring, boot retainer
8 134177600 Bellows, door boot
10 131304700 Nut, hex, 1/4-20 UNC-2B
11 131276900 Washer, Bellville, spring steel
12 131793500 Plate, counterweight
13 131618600 Shell, outer tub, front
14 134144700 Spring Assy, suspension, w/sleeves
14* 131592200 Sleeve, protector, upr spring hook
14* 131560000 Sleeve, protector, lwr spring hook
15 131303900 Screw, hex washer head, 1/4-10A x 2.165
16 131618500 Drum Assy, spin basket
17 131274600 Vane
18 131302800 Screw, vane mtg., 10-16AB x 0.375
19 # 131770600 Motor
20 131303500 Screw, hex washer head, 12-14AB x 1.50, motor mtg.
21 134146100 O-ring, tub
22 131462800 Shell, outer tub, rear, with bearing
23 134125900 Counterweight, drum rear
25 134051000 Belt, drive-V, 6-rib
26 131883400 Pulley, drive, large, drum rear, reinforced
27 131304400 Washer, 0.41 x 1.50, 0.12 thick
28 131304500 Washer, lock, 3/8
29 131303700 Screw, pulley mtg., m10 x 0.92, metric
30 131268200 Shock Absorber, air, stabilizer
31 131268300 Pin, shock mtg.
32 131268100 Bracket, shock mtg.
33 134160900 Screw, quadrex, 10-16AB X 0.750
35 134051100 Pump, drain
41 134044200 Coin Trap
42 131333101 Clamp
43 131277500 Chamber, air
44 131277600 Hose, air pressure
45 131306202 Clamp, pressure hose
48 131306234 Clamp, pump to trap
49 134266500 Clamp, bellows/boot, 0.059 OD wire, spring held
* 134393000 Energy Guide

Publication No: 5995409868 GLTF530DS0
05/04 8
WIRING DIAGRAM

GLTF530DS0 Publication No: 5995409868
# Functional Parts 9 05/04
* Non-Illustrated Parts
WIRING DIAGRAM
