FrontLine FLO-3BL User manual

Built-in Models
For Outdoor Use Only
To installer or person assembling grill: Leave this manual with grill for future reference.
To consumer: Keep this manual for future reference.
FrontLine Outdoors LLC www.FLOGrills.com
FLO Stainless Steel Gas Grill
Use & Care Manual
For Liquid Propane and Natural Gas Models
FRONTLINE OUTDOORS WWW.FLOGRILLS.COM
FLO-3BL-_ _ FLO-3BR-_ _ FLO-4BL-_ _
FLO-4BR-_ _ FLO-5BR-_ _
Conforms to ANSI STD
21.58a-2008
Certificated to CSA STD
1.6a-2008
3174816

2
Welcome & Congratulations
Congratulations on your purchase of your new FLO grill! We are very proud of our product and
we are completely committed to providing you with the best service possible. Your satisfaction
is our goal.
Please read this manual carefully to understand all the instructions about how to install,
operate and maintain for optimum performance and longevity.
We know you’ll enjoy your new grill and thank you for choosing FLO Grills. We know you will
have years of great memories to come with your FLO Gas Grill.
Please read and save the instructions
This Manual provides specific operating instructions for your model. Use your grill only as
instructed in this manual. These instructions are not meant to cover every possible condition
and situation that may occur. Common sense and caution must be practiced when installing,
operating, and maintaining any appliance.

3
Table of Contents
Safety Instructions ......................4
Grill Models ..................................6
Gas Requirement .........................7
Location For Grill .........................11
Pre-Operation Leak Testing ........13
Parts List ....................................14
Lighting the Grill ...........................22
Operation and Features ..............24
Care & Maintenance ...................28
Troubleshooting Your Grill ..........30
Limited Warranty .........................32
Safety Symbols
•WARNING
IF YOU SMELL GAS:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open Lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
•WARNING
WARNING:
1. DO NOT store or use gasoline or other
flammable liquids or vapors in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
•WARNING
DANGER indicates an imminently
hazardous situation which, if not
avoided, will result in death or serious
injury.
•CAUTION
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate personal injury, or property
damage.
•WARNING
FOR OUTDOOR USE ONLY:
NEVER operate grill in enclosed areas, as
this could lead to gas accumulating from a
leak, causing an explosion or a carbon
monoxide buildup which could result in injury
or death. DO NOT use your grill in garages,
breezeways, sheds or any enclosed area.
NOT FOR USE BY CHILDREN. If these
instructions are ignored, a hazardous fire or
explosion could result in physical injury,
death, or property damage!
•WARNING
WARNING indicates a potentially
hazardous situation which, if not
avoided, could result in death or
serious injury.

4
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury
or property damage. Read the installation, operating and maintenance instructions thoroughly
before installing or servicing this equipment.
General Safety Instructions
1. For Household Outdoor Use Only – DO NOT use indoors or in any type of enclosed area such as a
garage, shed, or breezeway. Keep clear of trees and shrubs. The grills are not intended for
installation in or on recreational vehicles, portable trailers, boats, or any other moving installation.
Not for commercial use.
2. The area surrounding your new grill should be kept clean and free from flammable liquids and other
combustible materials such as mops, rags, or brooms as well as solvents, cleaning fluids, and
gasoline.
3. To reduce the risk of serious or fatal injury from breathing toxic fumes and from explosion and fire as
a result of leaking gas, use only outdoors in an open area with good ventilation. Do not obstruct the
flow of combustion and ventilation air.
4. Never use the grill in windy conditions. If located in a consistently windy area (oceanfront,
mountaintop, etc.) a wind break will be required. Always adhere to the specified clearances listed.
5. Do not leave the grill unattended while cooking.
6. Do not use natural gas in a unit designed for liquid propane gas or vice versa.
7. Do not use fuel such as charcoal briquettes in a gas grill.
8. Keep children and pets away from hot grill. DO NOT allow children to use or play near the grill.
9. Never attempt to repair or replace any part of the grill yourself unless specifically recommended in
this manual. All other services should be performed by a qualified service technician.
10. Never lean over an open grill. Do not place clothing or other flammable material on or near the grill.
Do not wear loose-fitting clothes or long sleeves while using the grill as some fabrics can be highly
flammable.
11. Have an ABC fire extinguisher accessible. Never attempt to extinguish a grease fire with water or
other liquids.
12. Never use aluminum foil to line the grill racks or the drip trays, this can alter airflow for proper
combustion and also build up heat in the control area causing the knobs and igniter to melt.
13. When using the grill, do not touch the grill rack, burner grate, or immediate surroundings as these
areas become extremely hot and can cause burns. Always use a covered hand when opening the
grill hood and only do so slowly to allow heat and steam to escape.
14. DO NOT allow grease or other hot material dripping from the grill onto valve, hose or regulator. Turn
off gas supply immediately. After the grill has cooled, determine the cause and correct it. After
cleaning the valve, hose, and regulator, perform a leak test before continuing use.
15. Do not heat any unopened glass or metal container of food on the grill. Pressure may build up and
cause the container to burst, possibly resulting in serious personal injury or damage to the grill.
16. Keep any electrical supply cords away from water or heated surfaces. Electrical cords should be
placed away from walkways to avoid tripping hazard.
17. Keep gas supply lines as short as possible.
18. Never move the grill when hot.
19. DO NOT use while under the influence of drugs or alcohol.
Safety Instructions

5
20. DO NOT store a spare gas cylinder under or near your grill.
21. DO NOT grill without the drip tray in place, hot grease could leak downward and produce a fire or an
explosion. Drip tray should be pushed all the way to the rack located just under the grill.
22. Grease is extremely flammable. Let hot grease cool down before attempting to handle or dispose of
it. The drip tray should be cleaned and free of grease on a regular basis.
23. In the event that a burner goes out, turn burner knobs to the full OFF position, fully open the grill
hood and let it air out. Do not attempt to use the grill until the gas has had time to dissipate.
24. Do not use grill until leak check has been made.
25. Turn off the cylinder valve when your grill is not in use.
26. Ensure the control knobs are in the “OFF” position when not in use.
27. DO NOT install in any type of combustible construction material.
28. Grills are made to hang in place and are not to be sitting on a shelf as this will not allow the Grill to
properly vent, and this can cause fire.
29. Proper cross venting in any cabinet the grill is placed into is required to prevent gas/ heat build up
that can cause a fire and / or serious bodily and structure damage.
CALIFORNIA PROPOSITION 65 - WARNING: The burning of gas cooking fuels generates some
byproducts which are on the list of substances which are known by the State of California to cause
cancer or reproductive harm. California law requires businesses to warn customers of potential
exposure to such substances. To minimize exposure to these substances, always operate this unit
according to the Use and Care Manual, ensuring you provide good ventilation when cooking with gas.

6
(Need to describe their main characteristic what a feature that helps to identify, tell apart, or describe
recognizably; a distinguishing mark or trait)
FLO-4BR-_ _ FLO-5BR-_ _
Model No. Product Size
(inch/mm)
BTU/HR
(Main/Back)
Burner(s) Rotisserie
Motor
FLO-3BL-LP
FLO-3BL-NG 28 (711.2) 45,000/None Three SUS burners No
FLO-3BR-LP
FLO-3BR-NG 28 (711.2) 45,000/15,000 Three SUS burners and
one back burner
Yes
FLO-4BL-LP
FLO-4BL-NG 34(863.6) 60,000/None Four SUS burners No
FLO-4BR-LP
FLO-4BR-NG 34(863.6) 60,000/15,000 Four SUS burners and
one back burner
Yes
FLO-5BR-LP
FLO-5BR-NG 42(1066.8) 75,000/15,000 Five SUS burners and
one back burner
Yes
Grill Models
FLO-3BL-_ _ FLO-3BR-_ _ FLO-4BL-_ _

7
IMPORTANT:
Before connecting grill to gas source, make sure BBQ Grill control knobs are in “OFF” position.
Verify the type of gas supply to be used, either natural or LP, and make sure the marking on the
appliance rating label agrees with that of the supply.
All pipe sealants must be an approved type and resistant to the actions of LP gas. Never use pipe
sealant on flare fittings. The installation of this appliance must conform with local codes or, in the
absence of local codes, with either National Fuel Gas Code, ANSI Z223.1/ NFPA 54, Natural Gas and
Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2, or the
Standard for Recreational Vehicles, ANSI A 119.2/ NFPA 1192M, and CSA Z240 RV Series,
Recreational Vehicle Code, as applicable.
WARNING: Gas valves are preset at the factory to operate on LP or natural gas. DO NOT change or
Drill out Yourself. Contact your Dealer for option.
This propane gas grill is designed to operate on propane gas ONLY, at a pressure regulated at 11” water
column (W.C.) when equipped with the correct propane orifices on the valves and a propane regulator
on the supply line regulated at the residential meter. The LP gas grill is designed to be used with a
standard 20 lbs gas cylinder and must be constructed and marked in accordance with specifications of
the US Department of Transportation for propane gas cylinders.
Always keep cylinder securely fastened in an upright position. Never connect an unregulated propane
gas cylinder to the grill.
Do not subject propane cylinders to excessive heat.
CAUTION: Never store a LP gas cylinder inside a building or in the vicinity of any gas-burning
appliance.
Cylinder Specifications
- Any L.P. gas supply cylinder used with this grill must be approximately 12 inches diameter and 18
inches high. The maximum fuel capacity is 80% and is approximately 20 pounds of propane.
Gas Requirement
WARNING: Never attach an unregulated gas line to the appliance. Connection to an
unregulated gas line can cause excessive heat or fire.
NOTE: Always have a qualified service technician perform difficult conversions
or modifications.
LP Gas Hook-up

8
- The L.P. cylinder must have a shut-off valve (see picture) terminating
a Type 1 L.P.
- A Type 1 compatible cylinder with a Type 1 cylinder valve has a
back-check valve which does not permit gas flow, until a positive seal
has been obtained.
- The cylinder must be arranged for vapor withdrawal. It must also
include a collar to protect the cylinder valve. A safety relief device
having direct communication with the vapor space of cylinder must be
provided. This will expel high pressure gas if the cylinder is overfilled
overheated which could result in fire or explosion.
- All L.P. gas cylinders used with this appliance shall be constructed and marked in accordance with
the specifications for L.P. gas cylinders of the U. S. Department of Transportation (DOT) or the
National Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of
Dangerous Goods; and Commission, as applicable; and shall be provided with a listed overfilling
prevention device.
- Read labels on the L.P. Gas Supply Cylinder.
- New cylinders are always shipped empty for safety.
- Allow only qualified L.P. gas dealers to fill or repair your L.P. gas supply cylinder.
- Inform the gas dealer if it is a new or used cylinder to be filled.
- After filling, have the gas dealer check for leaks and to see that the relief valve remains free to
function.
Hose and Regulator
The Type 1 connection system has the following features:
- The system will not allow gas to flow until a positive connection
been made.
NOTE: The cylinder control valve must be turned off before
any connection is made or removed.
- The system has a thermal element that will shut off the flow of gas
in the event of a fire.
- The system has a flow limiting device which, when activated, will
limit the flow of gas to 10 cubic feet per hour.
- NEVER use grill without leak testing this connection.
LP(Propane) Gas Supply Connection
1. The tank valve should be in the “OFF” position. If not, turn the knob
clockwise until it stops.
2. Make sure all burner valves are in the “OFF” position.
3. Always connect the gas supply regulator as follows:
Insert the regulator inlet into the tank valve and turn the coupling nut
clockwise until the coupler tightens up (see picture). Do not over
tighten the coupler. Turn the main tank valve on and turn the burner
control valves on the unit to the “HIGH” position for about 20 seconds to allow the air in the system to
purge before attempting to light the burners.

9
LP Gas Supply Cylinder Disconnection
1. Turn the burner valves off.
2. Turn the tank valve off. (Turn clockwise to stop).
3. Detach the regulator assembly from the tank valve by turning the quick coupling nut
counterclockwise.
LP Tank Removal, Transport, and Storage
- Turn OFF all control knobs and LP tank valve. Turn coupling nut counterclockwise by hand only - do
not use tools to disconnect. Lift LP tank wire upward off of LP tank collar, then lift LP tank up and off
of support bracket. Install safety cap onto LP tank valve. Always use cap and strap supplied with
valve. Failure to use safety cap as directed may result in serious personal injury and/or property
damage.
- A disconnected LP tank in storage or being transported must
have a safety cap installed
(as shown). Do not store an LP tank in enclosed spaces such
as a carport, garage, porch, covered patio or other building.
Never leave a LP tank inside a vehicle which may become
overheated by the sun.
- Do not store LP tank in an area where children play.
LP Tank Filling
- Use only licensed and experienced dealers.
- LP dealer must purge tank before filling.
- Dealer should NEVER fill LP tank more than 80% of LP tank volume. Volume of propane in tank will
vary by temperature.
- A frosted regulator indicates gas overfill. Immediately close LP tank valve and call local LP gas
dealer for assistance.
- Do not release liquid propane (LP) gas into the atmosphere. This is a hazardous practice.
- To remove gas from LP tank, contact an LP dealer or call a local fire department for assistance.
Check the telephone directory under “Gas companies” for nearest certified LP dealers.
LP Tank Exchange
- Exchange your Type 1 cylinder with OPD safety feature-equipped ONLY.
- Always keep new and exchanged LP tanks in upright position during use, transit or storage. Leak
test new and exchanged LP tanks BEFORE connecting to grill.
WARNING: Always perform a leak test before lighting the grill to prevent a possible fire or
explosion. Never store a spare propane cylinder in the vicinity of this Grill or in the vicinity of any other
potential heat source.

10
-
Always check the rating plate to make sure the gas supply you are hooking up to is the gas type the grill
is manufactured for.
This natural gas grill is designed to operate on natural gas ONLY, at a pressure regulated at 4”
(101.6mm) water column (W.C.) when equipped with the correct natural gas orifices on the valves and a
natural gas regulator on the supply line regulated at the residential meter.
IMPORTANT: Never connect the grill to an unregulated gas supply.
Natural gas connections must be performed by a licensed contractor or local gas company
representative.
Hose and Regulator
IMPORTANT: NEVER use grill without leak testing this connection.
Natural gas regulator model: GR120N
Gas pressure: 4” (101.6mm)
Quick disconnect model: 1/2QDD-DK
Gas hose connector model: CFN12
Maximum rate working pressure: 1/2 Psig
Natural Gas Supply Connection and Disconnection
1. Make sure all burner valves are in the “OFF” position.
2. To connect-push back sleeve of socket, insert Plug release sleeve. Push Plug until sleeve snaps
forward locking Plug in Socket. (THIS TURNS GAS ON AUTOMATICALLY).
3. To disconnect: Push sleeve back and pull out plug. (THIS AUTOMATICALLY SHUTS OFF GAS)
4. Connected hose assembly shall be of adequate length and capacity for intended application. Final
assembly must be tested for leaks.
Natural Gas Hook-up

11
Check your local building codes for the proper method of installation. In the absence of local codes, this
unit should be installed in accordance with the National Fuel Gas Code No. Z223.1-1998 USA or
CAN/CGA-B149.1/.2 Natural Gas/Propane Code (Canada) latest edition or the National Electrical Code
ANSI/NFPA No. 70 or the Canadian Electrical Code CSA C22.1, 1990 or latest version.
- Before installing built-in grills in enclosures, copy all product information such as model number,
serial number and type of grill (e.g. natural gas or LP) and store information in a safe place.
- If the grill is installed by a professional installer or technician, be sure that he shows you where your
gas supply shut-off is located. All gas lines must have a shut-off that is readily and easily accessible.
If you smell gas, check for gas leaks immediately. Check only with a soap and water solution. Never
check for gas leaks with an open flame.
- Use grill, as purchased, only with LP (propane) gas and the regulator / valve assembly supplied. A
conversion kit must be purchased for use with natural gas.
- This grill is safety certified for use in the United States and/or Canada only. Do not modify for use in
any other location. Modification will result in a safety hazard.
Notice: We strongly recommend professional installation and hookup of your Gas BBQ grill. These
instructions will provide you with the measurements necessary for you or your builder to construct a
masonry structure to house your outdoor gas grill.
IMPORTANT: Gas fittings, regulator, and installer supplied shut-off valves must be easily accessible.
Location
Install the grill only in a well ventilated area. Never install the grill in a building, garage, breezeway, shed
or other such enclosed areas without an approved ventilation system. During heavy use, the grill will
produce a lot of smoke. Ensure there is adequate area for it to dissipate.
Clearance
- CLEARANCE FOR NON-COMBUSTIBLE CONSTRUCTION: A minimum of 8.5" (217mm)
clearance from the back of the grill is needed for the purpose of opening the hood fully. It is
desirable to allow at least 2"(50.8mm) side clearance to non-combustible construction above the
cooking surface for counter space. If you wish to use the rotisserie option, the space is essential for
motor and skewer clearance. The grill can be placed directly adjacent to non-combustible
construction below the cooking surface. The grill exhausts combustion products and cooking
greases to the back. Never locate the grill where this exhaust will be difficult to clean.
- CLEARANCE FOR COMBUSTIBLE CONSTRUCTION: A Minimum of 24" (609.6mm) from the
sides and a minimum of 24" (609.6mm) from the back must be maintained from the grill above and
below the cooking surface to adjacent vertical combustible construction.
Location For Grill

12
HEIGHT
For Built-in Installations
A Built-in Grill is designed for easy installation into masonry enclosures. For non-combustible
applications, the grill drops into the opening (as shown in cut-out detail drawing - Fig. A) above or
below depending on space, and hangs from its counter top trim. A deck is not required to support it from
the bottom. It is recommended that the enclosure have ventilation vents to prevent gas build-up in the
event of a leak. The deck ledges and counter should be flat and level in reference to the floor. If your grill
is equipped with a rotisserie, electrical service should be provided. If your grill is equipped with a
rotisserie, a minimum of 24" (609.6mm) of clearance is needed on each side of the grill for the motor and
skewer.
LP TANK STORAGE AREA MUST BE ISOLATED FROM GRILL AND MUST BE VENTED.
Cut out Dimensions Figure A
WIDTH DEPTH HEIGHT
3 Burner 24 ¾” (629mm)
22 ½” (572mm) 10 ¾” (274mm)
4 Burner 30 ¾” (782mm)
22 ½” (572mm) 10 ¾” (274mm)
5 Burner 38 ¾” (985mm) 22 ½” (572mm) 10 ¾” (274mm)
WIDTH
DEP
TH
OPEN AREA OF
CABINET

13
DANGER
1. Do not insert any tool into the valve outlet or safety relief valve. You may damage the valve and
cause a leak. Leaking propane may result in explosion, fire, severe personal injury, or death.
2. If a leak is detected at any time or you cannot stop a gas leak, immediately close pipeline valve and
call LP gas supplier or you fire department!
3. Check all gas supply fittings before each use and each time the gas supply cylinder is connected to
the regulator. Have a qualified service technician leak test the grill any time a part of the gas system
is replaced.
WARNING
Never attempt to attach this grill to the self-contained LP gas system. Do not use grill until leak testing
has been performed.
Before Testing
DO NOT smoke while leak testing. Extinguish all open flames. Never leak test with an open flame. Mix a
solution of equal parts mild detergent or liquid soap and water.
Leak Testing Valves, Hose and Regulator
1. Turn all grill control knobs to OFF.
2. Be sure the hose is tightly connected to LP tank.
3. Completely open LP tank valve by turning cylinder
valve knob counterclockwise (right to left). If you hear
a rushing sound, turn gas off immediately. There is a
major leak at the connection. Correct before
proceeding by calling franchiser for replacement
4. Brush soapy solution onto areas where bubbles
are shown in LP tank (see picture).
5. If “growing” bubbles appear, there is a leak. Close
LP tank valve immediately and retighten connections.
If leaks cannot be stopped do not try to repair. Call
franchiser for replacement.
6. Always close LP tank valve after performing leak test by turning cylinder valve knob clockwise.
NOTE: When leak testing this appliance, make sure to test and tighten all loose connections, including
the side burner. A slight leak in the system can result in a low flame, or a hazardous condition. Most LP
gas tanks now come equipped with a leak detector mechanism internal to the tank; when gas is allowed
to escape rapidly, it shuts off the gas supply. A leak may significantly reduce the gas flow making the grill
difficult to light or causing low flames.
Pre-Operation Leak Testing

14
FLO-3BL-LP/ FLO-3BL-NG
Parts List

15
FLO-3BL-LP/ FLO-3BR-NG PARTS LIST
No. Name Qty Part No. No. Name Qty Part No.
1 Hood Handle 1 F32B4SOB-14 13 Grate 2 F32B4SOB-11
2 Thermometer 1 F32B4SOB-42 14 Heat Shield 2 F-S32B4SOB-13
3 Handle Fixing 2 F32B4SOB-15 15 Grill Bottom Body 1 F32B4SOB-01
4 Upper Hood 1 F32B4SOB-02 16 Burner 3 F-S32B4SOB-10
5
Lower Hood Inner
Panel 1 F32B4SOB-03-02 17 Gas Pipe 1 F32B4SOB-27
6 Lower Hood 1 F32B4SOB-03 18 Valve 3 F32B4SOB-45
7 Hood Axle 2 F-S32B4SOB-29 19 Control Panel Frame 1 F32B4SOB-05
8 Flame Tamer 3 F32B4SOB-09 20 Control Panel 1 F32B4SOB-04
9 Drip Tray 1 F32B4SOB-06 21 Impulse Ignitor 1 F32B4SOB-36
10 Warming Rack Bracket 2 F-S32B4SRB-19 22 Control Knob Base 3 F-S32B4SOB-20
11 Light 2 F32B4SOB-32 23 Control Knob 3 F-S32B4SOB-22
12 Warming Rack 1 F32B4SRB-18 24 Control Knob Rubber
Ring 3 F32B4SOB-37
FLO-3BR-LP/ FLO-3BR-NG PARTS LIST
No. Name Qty Part No. No. Name Qty Part No.
1 Upper Hood 1 F32B4SOB-02 13 Control Knob 3 F-S32B4SOB-22
2 Shaft Collar 2 F32B4SRB-28-03 14 Control Knob Base 4 F-S32B4SOB-20
3 Warming Rack Bracket 2 F-S32B4SRB-19 15 Control Panel 1 F32B4SRB-04
4 Warming Rack 1 F32B4SRB-18 16 Drip Tray 1 F32B4SOB-06
5 Fork Assembly 1 F32B4SRB-28 17 Grill Bottom Bracket 1 F32B4SOB-01
6 Infrared Burner Switch
Box 1 F-S32B4SRB-16 18 Grill Bottom Body 1 F32B4SOB-01
7 Grate 2 F32B4SOB-11 19 Flame Tamer Bracket 1 F32B4SOB-08
8 Heat Shield 2 F-S32B4SOB-13 20 Motor Bracket 1 F-S32B4SRB-26
9 Flame Tamer 3 F32B4SOB-09 21 Motor 1 F32B4SRB-35
10 Burner 3 F-S32B4SOB-10 22 Rotisserie Lighting
Bracket 1 F-S32B4SRB-17
11 Control Panel Frame 1 F32B4SOB-05 23 Lower Hood 1 F32B4SOB-03
12 Control Knob Rubber
Ring 3 F32B4SOB-37
24 Hood Axle 2 F-S32B4SOB-29

16
FLO-3BR-LP/ FLO-3BR-NG

17
FLO-4BL-LP/ FLO-4BL-NG

18
FLO-4BL-LP/ FLO-4BL-NG PARTS LIST
No. Name Qty Part No. No. Name Qty Part No.
1 Hood Handle 1 F42B4SOB-14 12 Grate 2 F42B4SOB-53
2 Handle Fixing 2 F-S32B4SOB-15 13 Heat Shield 3 F-S32B4SOB-13
3 Upper Hood 1 F42B4SOB-02 14 Burner 4 F-S32B4SOB-10
4
Lower Hood Inner
Panel 1 F42B4SOB-03-02 15 Gas Pipe 1 F42B4SOB-27
5 Lower Hood 1 F42B4SOB-03 16 Valve 4 F32B4SOB-45
6 Light 2 F32B4SOB-32 17 Control Panel Frame 1 F42B4SOB-05
7 Flame Tamer 3 F42B4SOB-09 18 Control Panel 1 F42B4SOB-04
8 Grill Bottom Body 1 F42B4SOB-01 19 Impulse Ignitor 1 F32B4SOB-36
9 Drip Tray 1 F42B4SOB-06 20 Control Knob Base 4 F-S32B4SOB-20
10 Warming Rack
Bracket 2 F-S32B4SRB-19 21 Control Knob 4 F-S32B4SOB-22
11 Warming Rack 1 F42B4SRB-18 22 Control Knob Rubber
Ring 4 F32B4SOB-37
FLO-4BR-LP/ FLO-4BR-NG PARTS LIST
No. Name Qty Part No. No. Name Qty Part No.
1 Upper Hood 1 F42B4SOB-02 14 Small Control Knob
Rubber Ring 1 F32B4SRB-38
2 Warming Rack
Bracket 2 F-S32B4SRB-19 15 Big Control Knob 4 F-S32B4SOB-22
3 Shaft Collar 2 F32B4SRB-28-03 16 Small Control Knob 1 F-S32B4SOB-23
4 Infrared Burner
Switch Box 1 F-S32B4SRB-16 17 Control Knob Base 5 F-S32B4SOB-20
5 Warming Rack 1 F42B4SRB-18 18 Control Panel 1 F42B4SRB-04
6 Fork Assembly 1 F42B4SRB-28 19 Drip Tray 1 F42B4SOB-06
7 Grate 2 F42B4SOB-53 20 Grill Bottom Bracket 1 F42B4SOB-00
8 Heat Shield 3 F-S32B4SOB-13 21 Grill Bottom Body 1 F42B4SOB-01
9 Flame Tamer 4 F42B4SOB-09 22 Flame Tamer Bracket 1 F42B4SOB-08
10 Burner 4 F-S32B4SOB-10 23 Motor Bracket 1 F-S32B4SRB-26
11 Control Panel
Frame 1 F42B4SOB-05 24 Motor 1 F32B4SRB-35
12 Impulse Ignitor 1 F32B4SOB-36 25 Lower Hood 1 F42B4SOB-03
13 Big Control Knob
Rubber Ring 4 F32B4SOB-37
26 Hood Axle 2 F-S32B4SOB-29

19
FLO-4BR-LP/ FLO-4BR-NG

20
FLO5BR-LP/ FLO-5BR-NG
