Fuho CDR-E05 User manual

FUHO TECHNOLOGY CO., LTD.
DC5V
5M CMOS H.264
SD
GPS G
Sensor -10~+70℃
(vehicle inside)
OPTIONAL
67
115
122
120°
102
30
115
SD CARD
3"MONITOR
IR receiver
Audio
LENS MINI USB FOR PC
1. Easy installation. Compact and light structure, do not occupy space
in the car, suitable for all vehicles.
2. Full HD 5M CMOS Sensor.
3. View angle approx. 105 degrees.
4. Advanced H.264 compression technology for longer recording of higher
quality video.
5. 3 inch TFT LCD screen provides a platform for composing and playing
back your footage, while the fixed focus lens keeps things simple.
6.Build-in accelerometer, the system automatically determine the level of
the screen visualization, and make the screen self-rotated to normal position.
7. Support up to 32GB SD card.
8. G-sensor sensitivity can be adjusted according to vehicles and road situations. When detect a strong shock,
system will start emergency recording and keep the files without being overwritten.
9. Embedded GPS module ,Google map is available for viewing the recorded file and let user to view the routes.
10. G-sensor, GPS and Image data will be recorded simultaneously.
AV OUT
Manual
Recording
Button
Green light：Power
Red light：recording
Yellow Light：Playback
Blue Light：GPS 3D positioning
Standard : 1).CDR-E05 2).Installation CD 3). 5V Cigarette Light Adapter 4).User Manual 5.)
Optional: 1). SD Card 2).5M RCA AV Cable
Remote Controller.
Accessories
Features
FULL HD
1080P
30fps
3"
LCD
5 Megapixel Vehicle Video Recorder
Front/ Rear Panel Description
alarm shop

êVersion updating is not going to inform, please check the on-going updating information ---- FUHO TECHNOLOGY CO., LTD.
Chipset
Sensor Device
View Angel
Voltage
Operating Temp
Storage Device
Recording Frame
Recording Data
Recording Format
Microphone
Input Device
Others
Time Setup
G-Sensor
Important Notice
Ambarella H.264 image compression chip
Full HD 5M CMOS Sensor
3mm Len View angle approx. 105 degrees. (Option for M12 Len model)
5V±5%; Start 600mA,
Remark: Please use 5V±5%, 1A Cigarette lighter adapter.
The machine needs 4.8v to start.
-10℃~ +70℃ (Inside vehicle)
Silicon Power or Transcend SD card Class 6 or above recommend.
(min capacity 4G or above, Max 32G)
Full HD 1080P (1920x1080) @30fps. HD 720P (1280x720) @60fps/ 30fps.
Auto record when power up system. 30fps/ 60fps only choose one; provides two kind
of system NTSC/ PAL.
Date / time / video / audio / G-Sensor data / GPS data
Specific format for player software
Build-in Dual High Sensitivity Microphone
Emergency recording button, Remote controller
(a) TV-Out （1 Vp-p composite video output, 75 ohms）Two kind of system: NTSC/PAL
(b) Red light: recording (c) Green light: Power (d) Yellow Light: Playback
(e) Blue Light: GPS 3D positioning (f) Mini USB for PC connection
(g) Build-in accelerometer, the system automatically determine the level of the screen
visualization, and make the screen self-rotated to normal position.
Auto-calibrating by GPS signals. If GPS is not available, the built-in clock will be used.
Build in Internal 3D G-Sensor
(a)Machine must be installed in the area that wipe can be reached.
(b)Machine provides both NTSC and PAL systems, please using OSD to change
the right system in order to connect system monitor properly.
(c)After SD card formatted, user needs to set up time zone data from Software player
in order to display the correct time on OSD video output。
(d)SD card must be formatted by special player first to be used properly. After formatting,
the remaining capacity will show 80MB.
(e)GPS positioning speed will be affected by weather, window films, etc.
Windows film may contain metal substances and have impact on GPS positioning.
Speed meter
G Sensor
Volume
Video Search
GOOGLE MAP
Play Speed
5 Megapixel Vehicle Video Recorder
Specifications
