Fujian Allen Electronics EA1214 User manual

Electric
S t o ve
User Ma
nu a l
Save these
i nstruct i ons .
This product is only suitable for well insulated spaces or occasional use.

QUICK REFERENCE GUIDE
READ ALL INSTRUCATIONS BEFORE USING THIS
APPLIANCE
1.Before permanently placing your stove, plug it into a
convenient outlet to verify that the circuit breakers for
the outlet are on.
2.The heater may emit a slight, harmless odor when first
used. This odor is normal and is caused by the initial
heating of internal heater parts and will not occur again.
3.If your electrical heater does not emit heat, consult your
owner’s manual for further information.
KEEP DRAPERY AND OTHER FURNISHINGS AT LEAST 1
METER FROM THE FRONT AND SIDES OF THE ELECTRICAL
HEATER.
WARNING:
1.RISK OF FIRE – KEEP COMBUSTIBLE M ATE R IA L
AWAY FROM THE FRONT OF THE E L E C T R I C A L
HEATER.
2.SERVICING SHOULD BE DONE ONLY WHILE T H E
ELECTRICAL HEATER IS DISCONNECTED F R O M
THE POWER SUPPLY
SPECIAL CHARACTERISTICS:
A) The smoldering glow of the flames can hardly be
distinguished from that of a real fire. This heater is ideal
for use all year round, even when central heating has
been turned off.
B) This heater produces a hot current of air.
UNPACKING AND INSTALLING THE ELECTRICAL HEATER.
1.Open the packaging carefully and remove the heater.
2.Remove and discard the plastic bag.
3.BE RESPONSIBLE HANDLING THE PACKING
MATERIALS.
WARNING: KEEP PLASTIC WRAPPING AWAY FROM
CHILDREN.
4.Keep the original packing for future transport and/or
storage.
5.Keep the front of the unit, through which the heat is
radiated, at least 1 meter away from furniture, curtains
and other flammable objects/materials at all times.
6.Ensure there is a grounded socket nearby (back of the
appliance).
7.The power cord must remain at the back of the appliance
and must not be in contact with any hot element.
REPLACEMENT LIGHT BULB CAUTION:
REPLACEMENT SHOULD ONLY BE DONE WITH E14 TYPE
CANDLE LAMP BULBS, RATED 220-240V, 40W MAXIMUM.
1

NOTE:
A dedicated power circuit is recommended for the unit
but not required. Additional appliances on the same
circuit mayexceed the current (amperage) rating for that
circuit. If after the installation of your unit, the circuit
breaker trips or the fuse fails on a repeated basis, then a
dedicated circuit will likely be required.
Any new wiring must be done in compliance with local
and national codes and other applicable regulations in
order to reduce the risk of fire, electrical shock or other
injuries. It is strongly recommended that you hire a
licensed electrician to complete any such work.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: WHEN USING THIS P R O DUC T,
BASIC PRECAUTIONS SHOULD A LW A YS
BE FOLLOWED, INCLUDING
THE FOLLOWING:
Your electric stove is classified as a heater. As with any
electrical appliance and particularly with electrical
heaters, basic precautions must be followed in order to
reduce the risk of fire, burns, electrical shocks and/or
other serious injuries or death.
1. Read all the instructions in your User’s Manual before
using this unit.
WARNING: ANY OTHER USE NOT
RECOMMENDED OR DESCRIBED IN
YOUR OWNER’S MANUAL MAY
CAUSE FIRE BURN S,ELE C T R I CA L
SHOCKS AND/OR OTHER SE R IO U S
INJURIES OR DEATH.
2. The unit can become hot when in use. To avoid
accidental burns, do not allow bare skin to come in
contact with the hot surfaces of the unit.
EXTREME CAUTION IS NECESSARY WHEN THE
HEATER IS LEFT OPERATING AND UNATTENDED. KEEP
CHILDREN, INVALIDS AND PETS AWAY FROM THE UNIT
WHEN IN USE.
3. Keep combustible materials such as, curtains, drapes,
furniture, pillows, clothing, linens, bedding, paper, etc.,
at least 1 meter from the front and sides of the unit. Do
not use this unit in areas where gasoline, paint, or
other flammable liquids or their associated vapors may
be present.
4．Donot use this unit for drying any wet objects, such as
clothes, toys etc.
5. Do not operate the unit if it is damaged or has
malfunctioned.
6．For indoor use only.
7. Do not use or install this unit in areas prone to
dampness, or where it may come in contact with water.
This unit is not intended for use in bathrooms, laundry
areas, or other locations where water may be present.
8. To reduce the risk of fire, do not place or install this unit
in areas where the ventilation or circulation ducts may
become blocked. Do not use on soft surfaces, like a
bed, where openings may become blocked. Make sure
there are at least 10.15 cm of space between the back
of your heater and the wall. Keep a minimum distance
of 5.08 cm on each side of your heater free.
9.Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an
electric shock or fire, or damage the heater.
10.The unit’s power cord must be connected to 220-240V
outlet. To reduce the risk of fire, avoid running the
power cord under rugs, carpets, etc. Keep the power
cord away from high traffic areas where it may pose a
tripping hazard.
11.Always plug directly into a wall outlet.
Never use with an extension cord or outlet/power strip.
12.Do not run cord under carpeting. Do not cover cord with
throw rugs, runners, or similar coverings
Arrange cords away from traffic areas where it will not
be tripped over.
IMPORTANT SAFETY INSTRUCTION DON’T
13.Never operate the unit on a program switch, timer or
any other appliance for automatic operation.
14.Always disconnect the unit from the power supply
before performing any cleaning, light bulb replacement,
maintenance, relocating the electric heater or when the
unit is not in use for long periods of time. To disconnect
the heater, push the master power switch to the OFF
position before removing the plug from the outlet.
15.When transporting or storing the unit, keep it in a dry
location, free from dust, excessive vibration or other
factors, which may damage the unit.
16.Always unplug the heater when not in use.
DANGER:HIGH TEMPERATURES MAY
BE GENERATED UNDER CERTAIN
ABNORMAL CONDITIONS. DO NOT
PARTIALLY OR FULLY COVER OR
OBSTRUCT THE FRONT OF THIS
HEATER
2

3
SPECIFICATIONS
Technical Specifications
Model EA1214
Voltage 220-240V Frequency 50Hz
Power 900/1800W
DIMENSIONS
TESTING THE UNIT
Carefully remove the unit from the box. Prior to installing the unit, test to make sure the unit operates properly by
plugging the unit’s power cord into a conveniently located 220-240V outlet.
Refer to the Operating Instructions regarding the various controls and features of the unit.
NOTE: This appliance comes equipped with double overheat protection safety device. Should the
appliance begin to overheat for any reason, it will automatically turn all heater functions of the
appliance off. The appliance will have to be reset prior to continuing use. To reset the overheat
protection safety device, turn all controls off and unplug the appliance. Wait 10 minutes, plug the
appliance back in and turn on.
OPERATING I NSTRUCT I ONS
CONTROL PANEL OPERATING PROCEDURES
Once the unit has been properly connected to a grounded electrical outlet, it is ready to operate.
Note: Ensure the circuit breakers for the power supply are turned

HEATER OPERATION (Refer to Fig. 1)
1.Ensure the power switch is on. You will know that you
have power to the heater when the flame effect is on.
2.Flip the second rocker switch to the right, marked
“Ⅰ”. This switch gives you 900W of power to your
heater. This switch is for low-level heating. For
high-level heating, make sure that both “Ⅰ”and “Ⅱ”
rocker switches are on.
3.Move the first rotary knob to adjust the
heating temperature of the unit.
4.Move the second rotary knob to adjust the
flame brightness
Fig 1
MAINTENANCE
Tools Required: Philips Screwdriver (#1)
REPLACING THE LIGHT BULB
WARNING: THE UNIT MUST BE UN PL U GGE D
FROM THE POWER SUPPLY PRIOR TO AN Y
MAINTENANCE OR CLEANING IN ORDER TO
REDUCE THE RISK OF ELECTRIC S H O CK
OR FI R E.
. CAUTION: SHARP E D GES !
Figure 3 -back side of the unit
Fig. 3
LIGHT BULB MAY BECOME LOOSE DURING
SHIPPING.
If the simulated flame effect is dim or does not operate
properly at first, please ensure that the light bulb is
properly secured in the socket (bulb should be finger
tight –do not over tighten).
TO REPLACE FLAME EFFECT LIGHT BULB
1.Turn all controls to “OFF”
2.Unplug the unit from the power supply.
3. Remove back panel by removing 4 screws as shown.
(See Fig. 4)
4. Unscrew the light bulb (turning counter-clockwise) and
remove.
5.Replace with new light bulb, turning clockwise.
6.Replace back panel and secure with screws.
7.Plug the unit into the power supply.
8.Turn the power switch to the “ON” position.
This comes with the following light bulb:
40W E14 candle lamp bulb (SeeFig.3)
Fig. 2
Replace this bulb only with identical size and wattage.
4

You can c ean he ex e o o he hea e w h a so damp
PROBLEM
POSSIBLE CAUSE
SOLUTION
No warm air is
Coming from the
heater
The overheat protection
device in the appliance
has been triggered
Turn all controls off, unplug
the appliance, allow to cool
for at least 10 min plug
back in and restart
The appliance
turns off and
will not t urn
back on.
1. The overheat protection
device in the appliance
has been triggered.
2. House circuit breaker
has been tripped.
1.Turn all controls off,
unplug the appliance, allow
to cool for at least 10 min.,
plug back in and restart.
2. Reset house circuit
breaker.
The appliance
does not turn on
whenthe button
is pushed to
“ON”
The overheat protection
device in the appliance
has been triggered
Turn all controls off,
unplug the appliance,
allow to cool for at least
10 min., plug back in
and restart
Flame is
dim or not
present
1 Light bulb is burnt out.
2 “Flame wand”has
come loose from
bracket.
3“Flame wand”motor is
not functioning.
1 Inspect light bulb and
replace if necessary.
(see Maintenance
section of this manual)
2 Remove screws
holding back access
panel in place and
remove back access
panel .Secure end of
“flame wand”back into
the support bracket.
CLEANING YOUR HEATER
WARNING: BEFORE CLEANING THE
EXTERIOR OF THE APPLIANCE,
DISCONNECT THE UNIT FROM THE
POWER SUPPLY AND LEAVE UNTIL
TROUBLESHOOTING:
WARNING: Turn off the appliance, unplug and let
cool for at least 10 minutes before attempting to
service. Only a qualified professional should
attempt to service or repair the appliance.
l
L. t ri r f t t r it ft, ,
lint-free cloth. Do not use cleaning or polishing products.
CLEANING THE FRONT GLASS PANEL
WARNING: BEFORE CLEANING THE
EXTERIOR OF THE APPLIANCE,
DISCONNECT THE UNIT FROM THE
POWER SUPPLY AND LEAVE UNTIL
COOL.
FREQUENTLY ASKED QUESTIONS(FAQS)
Over time, the front glass panel may become dirty
or dusty. Dust can be removed by lightly rubbing
the glass surface with a clean lint-free cloth or
paper towel. To remove fingerprints or other marks,
use a soft, damp, lint-free cloth with a good quality
household glass cleaner. The front glass panel
should always be completely dried with a lint-free
cloth or paper towel cloth or paper towel.
Storage: When not in use, unplug the unit from the
power supply and store it in a dry, dust-free location.
. CAUTION: DO NOT USE ABRASIVE
CLEANERS ON THE GLASS PANEL.
DO NOT SPRAY LIQUIDS DIRECTLY
ON TO ANY SURFACE OF THE UNIT.
5

Table for information requirementsfor electric local space heaters
P
Model identifier(s): EA1214
Item
Symb
ol
Value
Unit
Item
Unit
Heat output
Type of heat input, for electric storage local space
heaters only (select one)
Nominal heat
output
Pnom
1,8
kW
Manual heat charge control with
integrated thermostat
[no]
Minimum heat
output (indicative)
Pmin
0.9
kW
Manual heat charge control with room
and/or outdoor temperaturefeedback
[no]
Maximum
continuous heat
output
Pmax
1,8
kW
Electronic heat charge control with
room and/or outdoor temperature
feedback
[no]
Auxiliary electricity consumption
Fan assisted heat output
[no]
At nominal heat
output
elmax
1,767
kW
Type of heat output/room temperature control
(select one)
At minimum heat
output
elmin
0,899
kW
Single stage heat output and no room
temperature control
[no]
In standby mode
elSB
N/A
W
Two or more manual stages, no room
temperature control
[no]
With mechanic thermostat room
temperature control
Yes
With electronic room temperature
control
[no]
Electronic room temperature control
plus day timer
[no]
Electronic room temperature control
plus week timer
[no]
Other control options (multiple selections possible)
Room temperature control, with
presence detection
[no]
Room temperature control, with open
window detection
[no]
With distance control option
[no]
With adaptive start control
[no]
With working time limitation
[no]
With black bulb sensor
[no]
Contact details:
Fujian Allen Electronics Co., Ltd.
Allen Industrial Zone, North Binjiang Road, Luojiang, Quanzhou, Fujian, China
Remark:
For electric local space heaters, the measured seasonal space heating energy efficiency ηs cannot
be worse than the declared value at the nominal heat output of the unit.
