FujiFilm XF1 User manual

©2012 FUJIFILM Corporation
Microsoft, Windows and Windows logo are trademarks,
or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Macintosh and Mac OS are trademarks of Apple Computer, Inc., registered in the U.S. and other countries.
SD logo is a trademark. All other trademarks are the property of their respective holders.
Specifications and design are subject to change without notice.
All sample photos are simulated images.
For more information, please visit our Website:
http://www.fujilm.com/products/digital_cameras/index.html
XF1_Cover
Red Brown
Color variations
Soft case SC-XF (Black)
Accessories
*1 : Number of eective pixels: The number of pixels on the image sensor which receive input light through the optical lens, and which are eectively reected in the nal output data of the still image.
*2 : Please see the Fujilm website to check memory card compatibility.
2/3-inch EXR CMOS with primary color lterImage sensor
Lens Fujinon 4× optical zoom lens
F1.8 (Wide) - F4.9 (Telephoto)
f=6.4 - 25.6 mm, equivalent to 25 - 100 mm on a 35 mm camerafocal length
full-aperture
6 groups 7 lenses (4 aspherical glass molded lenses included)constitution
F1.8 - F11 (Wide), F4.9 - F11 (Telephoto) 1/3 EV step (controlled - 6 blade aperture diaphragm)Aperture
3.0-inch, approx. 460,000 dots, color LCD monitor, approx. 100% coverageLCD monitor
1920 × 1080 pixels, 1280 × 720 pixels, 640 × 480 pixels (30 frames/sec.) with stereo sound Optical zoom function (manual) can be used.
Movie recording
Lens shift type
Image stabilizer
CP-50 with AC power adapter AC-5VX (sold separately)
NP-50A Li-ion battery (included)
Power supply
12.0 million pixels
Number of eective pixels*1
Weight Approx. 225g /7.9 oz. (including battery and memory card)
Approx. 204g /7.1 oz. (excluding battery and memory card)
Macro: (Wide) Approx. 3 cm - 3.0 m / 1.1 in. - 9.8 ft., (Telephoto) Approx. 50 cm - 3.0 m / 1.6 ft. - 9.8 ft.
Normal: (Wide) Approx. 50 cm to innity / 1.6 ft. to innity, (Telephoto) Approx. 80 cm to innity / 2.6 ft. to innity
Focus distance
(from lens surface)
Sensitivity Auto, Equivalent to ISO 100/200/250/320/400/500/640/800/1000/1250/1600/2000/2500/3200/4000*/5000*/6400*/12800* (Standard Output Sensitivity)
*ISO 4000/5000/6400 : M mode or lower, ISO12800 : S mode
Dimensions 107.9 (W) x 61.5 (H) x 33.0 (D) mm / 4.2 (W) x 2.4 (H) x 1.2 (D) in.
Guide to the number of available
frames for battery operation
Approx. 300 frames CIPA standard
Intelligent digital zoom approx. 2.0× (up to approx. 8×, with 4× optical zoom)Digital zoom
Internal memory (approx. 25MB), SD/SDHC/SDXC (UHS-I) memory card*2
Storage media
SPECIFICATIONS

XF1_P1P2
It’s Your Life. Capture it in Style.It’s Your Life. Capture it in Style.

The bright f/1.8 lens lets you capture quality pictures not normally possible with a compact camera. Noise is kept to
a minimum without boosting sensitivity, while camera shake and subject motion are prevented due to high shutter
speeds. And thanks to the large aperture, you can also create attractive "bokeh" blurred background effects.
With a maximum aperture of f/1.8 at the wide angle setting and a six-blade aperture diaphragm, the XF1’s lens delivers beautiful defocused blur.
Together with macro capabilities to within just 3cm of your subject, that means huge photographic potential in a highly compact body.
Six-blade aperture diaphragm and 3cm macro
Working in tandem with the 2/3-inch EXR CMOS sensor, the EXR processor helps take image
quality to a new level. The fast, powerful twin CPU EXR Core is recongurable, meaning it
instantly adapts to complex processing needs. The benets: superb quality still photographs,
rapid-re continuous shooting, and true high-resolution video.
Fujinon manual 4x optical zoom lens with bright f/1.8 aperture
produces stunning pictures in low light
F
u
ji
pro
d
In the XF1, FUJIFILM brings its unique EXR CMOS pixel array to a larger 2/3-inch sensor.
Because each pixel is larger, it can capture more light, dramatically reducing false color
artifacts and noise at high sensitivities. Plus, thanks to further speed improvements in
high-performance CMOS technology, you’ll enjoy rapid continuous shooting as well as
high-resolution video.
Large 12M 2/3-inch EXR CMOS Sensor adapts to ensure
high quality images, whatever the situation
EXR Processor for superior resolution, wide dynamic range,
high sensitivity, and low noise
Featuring state-of-the-art technologies including aspherical elements and high refractive index glass, the XF1’s lens boasts a fast f/1.8 maximum aperture
and a slim prole that would be virtually impossible with conventional lens designs. Another important feature is Optical Image Stabilization, which shifts
one group of four elements to minimize camera shake without compromising resolution around the edges of the image, a common problem with
conventional stabilization systems.
New Fujinon f/1.8 lens: Compact size, superb quality
High Transmittance EBC (Electron Beam Coating) is FUJINON’s unique wide-band technology developed for FUJINON
broadcast-use lenses. The XF1 is the rst compact camera to use High Transmittance EBC for double sides of all glass
lenses. Because highly refractive glass bends light rays more sharply than conventional optical glass, it creates greater
potential for reections which can cause ghosting and are. HT-EBC technology effectively minimizes this stray light,
assuring sharp, clear images under even the most demanding conditions.
Newly developed High-Transmittance EBC
NEW

XF1_P5P6
A selection of six special lter effects lets you create distinctive photos. Filter effects can be veried on the LCD monitor to ensure you get
exactly the results you’re hoping for.
Advanced Filter
NEW
NEW
The E-Fn extended function button lets you customize your XF1 to offer immediate access to your most-used controls. One touch and the
monitor displays a menu of six items of your choice. Full control, at your ngertips!
Customized control: The E-Fn button
Menu screen Custom screen
E-Fn button
The conveniently located Main Command Dial gives you easy access to Shutter
Speed and Aperture settings.
Quick-response command dial
Main command dial
Quick response and superb results makesQuick response and superb results makes
taking photos a pleasure!taking photos a pleasure!
Designed for style, ease of use, andDesigned for style, ease of use, and
effortless operationeffortless operation
EXR Auto with Motion Detection instantly recognizes 58 types of
scene, automatically optimizes every setting from exposure to
white balance, and switches to the ideal sensor mode for the
scene and subject: HR High Resolution for well-lit conditions, SN
High Sensitivity/Low Noise mode for low light, and DR Dynamic
Range mode for high-contrast scenes.
EXR AUTO 103 Shooting Patterns
and
DR
Dynamic
Minimize blur in shots with moving subjects
Portrait & Motion x Beach x HRNG
Face tracking
for
perfect focus
ortr
ait &
Moti
on x
Beach
x HR
NEW
The XF1 takes the guesswork out of recording movies with a new Movie Scene Recognition function. Automatically optimizing settings for a
variety of shooting conditions, Movie Scene Recognition combines with Face Tracking AF to give you crisp, colorful HD movies with impressive
stereo sound.
Full HD movies Movie Scene Recognition
AUTO Night MacroLandscape Portrait BacklitNight Portrait Portrait
Pop color Toy camera Miniature High-key Partial color
Red, Orange, Yellow, Green,
Blue, Purple
Dynamic tone
In QUICK START MODE, the XF1 is ready to shoot in just 0.55
seconds.
Fast Startup 0.55 sec.
Locking on to your subject in as little as 0.16 seconds, High Speed Contrast
Detection AF captures even spur-of-the-moment shots with sharp clarity at
maximum 4x zoom. And unlike conventional premium digital cameras, the
XF1 autofocus system reacts quickly even in low light, making it possible to
shoot high-quality hand-held photos indoors or at night.
Quick, responsive AF, even in low light
From quicker startup to shorter shot-to-shot delay (minimum 0.8
sec. delay), the responsive EXR sensor and processor ensure you
never miss a shot.
Shooting interval 0.8 sec includes in AF
From Standby Mode, a touch of the zoom ring opens the lens and activates the camera into Shooting Mode, powering up in an
instantaneous 0.55 seconds. In Portable Mode, the lens retracts fully inside the camera, minimizing camera size.
Three stylish congurations
Unlike power zoom, the XF1’s zoom ring provides direct
manual controls, keeping the zoom action very smooth. The
4x optical zoom is complemented by a super resolution digital
zoom up to 8x.
*35mm format equivalent
25-100mm manual 4x optical zoom lens
s
fully
inside
the
camera
,
minimizing
camera
size.
s
www.fujifilm.com/products/digital_cameras/x/fujifilm_xf1/For more information, visit the XF1 website
Portable Mode
Standby Mode
Shooting Mode
