Fujitsu Siemens Computers AMILO Pi 3625 User manual

Quick Start Guide
Copyright
© Fujitsu Siemens Computers 2008
Published by
Fujitsu Siemens Computers GmbH
Mies-van-der-Rohe-Straße 8
80807 München, Germany
Contact
www.fujitsu-siemens.com/support
All rights reserved, including intellectual property rights.
Technical data subject to modi cations and delivery subject
to availability. Any liability that the data and illustrations are
complete, actual or correct is excluded. Designations may be
trademarks and/or copyrights of the respective manufacturer,
the use of which by third parties for their own purposes may
infringe the rights of such owner. For further information see
http://www.fujitsu-siemens.com/terms_of_use.html
1
2
AMILO Notebook Pi 3625
Getting started
2
1
SAP: 10600969176
FSP: 440N00686
English
Deutsch
Français
Español
Italiano
Nederlands
Português
10600969176
Cover_AmiloPi3625.indd 1 09.06.2008 18:13:14
All manuals and user guides at all-guides.com

3
4
5
6
w
w
w
1
2
2x
Cover_AmiloPi3625.indd 2 09.06.2008 18:13:16
All manuals and user guides at all-guides.com

AMILO Notebook Pi 3625
.
First-time setup
English
Deutsch
Français
Español
Italiano
Nederlands
Português
All manuals and user guides at all-guides.com

Microsoft, MS Windows and Windows Vista are registered trademarks of the Microsoft Corporation.
Adobe Reader is a trademark of Adobe Systems Incorporated.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2008
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, either in part or in whole.
Non-compliance is subject to compensation for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.
All manuals and user guides at all-guides.com

Contents
English
Contents
Innovativetechnology ................................................................. 1
Furtherinformation ...................................................................... 1
"AMILO Notebook" Operating Manual . . ............................................... 1
Portsandoperatingelements .......................................................... 2
Importantnotes ........................................................................ 3
Preparingyournotebookforuse ....................................................... 3
Unpacking and checking your notebook . . . . ............................................... 3
Selectingthelocation ................................................................... 4
Connecting the mains adapter . .......................................................... 4
Switching the notebook on for the firsttime ................................................ 5
Technicaldata ......................................................................... 6
Notebook ............................................................................... 6
Mainsadapter .......................................................................... 6
10600969176, edition 1 English
All manuals and user guides at all-guides.com

Contents
English 10600969176, edition 1
All manuals and user guides at all-guides.com

Innovative technology
Innovative technology
... and ergonomic design make your AMILO Pi 3625 Notebook a reliable and convenient notebook.
If you have purchased a notebook with a Microsoft Windows operating system, this is pre-installed and
optimally configured for you. The notebook is ready to use immediately the first time you switch it on.
Your notebook features the very latest technology so that you get the best
performance from your computing experience.
• a drive for reading and writing CDs/DVDs and, depending on your particular
model, for reading Blu-ray discs
• three USB ports, providing simple expansion options for game pads, printers and more
• a combined eSATA/USB port for connecting an external SATA hard disk or another USB device
• LAN and wireless LAN for Internet and network access
• a DVI-I port for full-digital data transfer to an external monitor
• an integrated webcam and analogue microphones for a wide variety of multimedia applications
• a multi-format card reader for rapid transfer of digital photos, music and
video clips onto your notebook
• an integrated audio controller and stereo speakers for true listening pleasure
• additional inputs and outputs for high quality audio accessories
• a keyboard with separate number block
• an on-screen display for visual control over the key settings of your notebook
The user-friendly "BIOS Setup Utility" offers powerful password protection functions which can be
used to control your notebook’s hardware and protect your system better against unauthorised use.
This Operating Manual tells you how to get your AMILO Notebook up and
running and how to operate it in daily use.
Further information
General information about your AMILO Notebook can be found in the
"AMILO Notebook" operating manual.
The Windows Vista drivers for your AMILO notebook are available to download
from our website. This computer is not designed to support any other operating
systems. Fujitsu Siemens Computers accepts no liability for consequences
arising from the use of other operating systems.
Software-related portions of this manual relate to Microsoft products if
they are included with your AMILO Notebook.
Please refer to the relevant manufacturer’s operating instructions when
installing other software products.
"AMILO Notebook" Operating Manual
The "AMILO Notebook" Operating Manual can be found in the Windows Start menu
or on the Internet at "www.fujitsu-siemens.com/support".
10600969176, edition 1 English - 1
All manuals and user guides at all-guides.com

Ports and operating elements
Ports and operating elements
This chapter presents the individual hardware components of your notebook. It gives
an overview of the displays and ports of the notebook. Please familiarise yourself with
these components before you start using your notebook.
15 14
13
2
1
4
76
21
24
26
3
5
22
8
9
10
19
19
17
12 11
20
25
23
27
16
17
18
1 = Webcam
2 = Quick Start buttons
3 = Touchpad
4 = Keyboard with separate number block
and application buttons
5 = Status indicators
6 = Touchpad buttons
7 = Multi-format card reader
8 = Line In port
9 = Microphone port
10 = Headphones/SPDIF/Line Out port
11 = ExpressCard slot
12 = Network port
13 = Combined eSATA/USB port
14 = Ventilation slots
15 = DC input jack (DC IN)
16 = Kensington Lock
17 = Loudspeakers
18 = ON/OFF switch
19 = Microphones
20 = CD/DVD drive
21 = USB ports
22 = DVI-I port
23 = USB port
24 = Hard disk 2 service compartment
25 = Hard disk 1 service compartment
26 = Battery
27 = Memory service compartment
2 - English 10600969176, edition 1
All manuals and user guides at all-guides.com

Preparing your notebook for use
Important notes
Please read and observe the safety instructions in the "Safety" manual
and in the "AMILO Notebook" operating manual.
Preparing your notebook for use
First-timesetupNotebookGettingstartedNotebook
If your notebook comes with a Windows operating system then all of the necessary
hardware drivers and the supplied software will already be pre-installed.
With the operating system Microsoft Vista, it may take up to 20 minutes to prepare your
notebook for use depending on the hardware fitted and the software supplied.
When you switch on the notebook for the first time it will perform a system
check. A number of different messages may be displayed. In the process,
the display may flicker or darken temporarily.
Please follow the instructions on the screen.
It is very important that you do not switch the notebook off during this initial set-up process.
Before you can use your notebook for the first time you will need to charge the battery.
On delivery, the battery can be found in the battery compartment or in the accessories kit. The
battery must be charged if you want to operate your notebook with the battery.
When not plugged into a mains socket, the notebook runs on its built-in battery. You can
increase the battery’s life by enabling the system’s energy saving functions.
If you use the notebook in at home or in an office, we recommend you use
the mains adapter instead of the battery.
Please refer to the "AMILO Notebook" operating manual for instructions on how to connect
external devices (e.g. a mouse or a printer) to the notebook..
Unpacking and checking your notebook
Should you discover any damage incurred during transportation, notify
your local sales outlet immediately!
►Unpack all the individual parts.
PackagingTrans port
►Check your notebook for damage incurred during transportation.
We recommend that you keep the original packaging material.
You may need the packaging in the future if you need to transport your device.
10600969176, edition 1 English - 3
All manuals and user guides at all-guides.com

Preparing your notebook for use
Selecting the location
Location,selectingtheNotebookPoweradapte r
Select a suitable location for the notebook before setting it up. Consider
the following points when selecting a location:
• Never place the notebook and the mains adapter on a heat-sensitive
surface. This could damage the surface.
• Never place the notebook on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause damage due to overheating.
• Do not place the notebook directly on your legs for extended periods. The
underside of the notebook heats up during normal operation. Extended contact
with the skin can become unpleasant or even result in burns.
• Place the notebook on a stable, flat, non-slip surface. Please note that
the rubber feet may mark certain types of surfaces.
• Keep other objects 100 mm away from the notebook and its mains
adapter to ensure adequate ventilation.
• Never cover the ventilation slots on the notebook.
• Do not expose the notebook to extreme environmental conditions. Protect
the notebook against dust, humidity and heat.
Connecting the mains adapter
Preparingfor operationMains adapter
Please observe the safety precautions in the enclosed "Safety" manual.
The supplied mains cable conforms to the requirements of the country in which
you purchased your notebook. Make sure that the mains cable is approved
for use in the country in which you intend to use it.
The mains cable of the mains adapter must only be connected to a mains
socket if the notebook is connected to the mains adapter.
Make sure that the rated current of the mains adapter is not higher than that
of the power system to which you connect the mains adapter (refer to the
"Technical Data" section, "Mains adapter ", Page 6 ).
1
2
3
►Connect the mains adapter cable (1) to the
DC jack (DC IN) on the notebook.
►Connect the mains cable (2) to the
mains adapter.
►Plug the mains cable (3) into a mains outlet.
4 - English 10600969176, edition 1
All manuals and user guides at all-guides.com

Preparing your notebook for use
Switching the notebook on for the first time
Switchingonforthefirsttime
We recommend that the notebook is supplied with power through
the mains adapter during this procedure.
When you switch your notebook on for the first time, the supplied software
is installed and configured. Because this installation procedure must not be
interrupted, you should set aside enough time for it to be fully completed and
connect the notebook to the mains outlet using the mains adapter.
During installation, the notebook must only be rebooted when you are requested to do so!
You will be prompted to create a backup copy of the pre-installed operating system. This
backup copy can be used later to restore your notebook to its delivery configuration.
You can find information on how to restore the operating system, drivers, manuals
and special software in the Recovery Process manual.
Your operating system is pre-installed on the hard disk to help you when you
start using your notebook for the first time.
1
►Switch the notebook on (1).
►During installation, follow the on-screen instructions.
Consult the operating system manual if anything is unclear about the requested input data.
If a Windows operating system is installed on your notebook, you will find additional
information on the system and drivers, help programmes, updates, manuals etc. on
your notebook or on the Internet at "www.fujitsu-siemens.com/support".
10600969176, edition 1 English - 5
All manuals and user guides at all-guides.com

Technical data
Technical data
Technicaldata
Notebook
Technicaldata
Ambient conditions
Operating temperature 5°C – 35°C
Dimensions
Width x Depth x Height (front/back) 400 mm x 302.5 mm x 29/40.5 mm
Weight (including battery) Approx. 3.6 kg
The data sheet for this notebook contains further technical data. The data
sheet can be found on your notebook, or alternatively it is also available to
download from the Internet at "www.fujitsu-siemens.com".
Mains adapter
Technicaldata
Electrical data
Primary 65 W
Rated voltage 100 V – 240 V (automatic)
Rated frequency 50 Hz – 60 Hz (automatic)
Secondary
Rated voltage 20 V
Max. rated current 3.25 A
An additional mains adapter or power cable can be ordered at any time.
6 - English 10600969176, edition 1
All manuals and user guides at all-guides.com

AMILO Notebook Pi 3625
.
Erstinbetriebnahme
English
Deutsch
Français
Español
Italiano
Nederlands
Português
All manuals and user guides at all-guides.com

Microsoft, MS Windows and Windows Vista are registered trademarks of the Microsoft Corporation.
Adobe Reader is a trademark of Adobe Systems Incorporated.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2008
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, either in part or in whole.
Non-compliance is subject to compensation for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.
All manuals and user guides at all-guides.com

Inhalt
Deutsch
Inhalt
InnovativeTechnologie ................................................................ 1
WeitereInformationen ................................................................... 1
Betriebsanleitung "AMILO Notebook" . . ............................................... 2
AnschlüsseundBedienelemente ....................................................... 3
WichtigeHinweise ..................................................................... 4
ErstinbetriebnahmedesNotebook ..................................................... 5
Notebook auspacken und überprüfen . . . . . . ............................................... 5
Stellplatzauswählen .................................................................... 6
Netzadapter anschließen . . .............................................................. 6
NotebookzumerstenMaleinschalten .................................................... 7
TechnischeDaten ...................................................................... 9
Notebook ............................................................................... 9
Netzadapter . . ......................................................................... 9
10600969176, Ausgabe 1 Deutsch
All manuals and user guides at all-guides.com

Inhalt
Deutsch 10600969176, Ausgabe 1
All manuals and user guides at all-guides.com

Innovative Technologie
Innovative Technologie
... und ergonomisches Design machen Ihr AMILO Notebook Pi 3625 zu einem
benutzerfreundlichen und zuverlässigen Notebook.
Wenn Sie ein Notebook mit einem Microsoft Windows-Betriebssystem gekauft haben,
ist dieses bereits vorinstalliert und für Sie optimal konfiguriert. Das Notebook ist sofort
startbereit, wenn Sie es zum ersten Mal einschalten.
Ihr Notebook ist mit neuester Technologie ausgestattet, damit Sie Ihre
Computer-Erfahrung optimal umsetzen können.
• ein Laufwerk zum Lesen und Beschreiben von CDs/DVDs und je nach
Geräteausstattung, zum Lesen von Blu-ray-Discs
• drei USB-Anschlüsse für eine einfache Erweiterung durch Game-Pads, Drucker und mehr
• ein eSATA-/USB-Kombinationsanschluss, um eine externe SATA-Festplatte oder
ein weiteres USB-Gerät anschließen zu können
• LAN und Wireless LAN für Internet- und Netzwerkzugang
• ein DVI-I-Anschluss für die volldigitale Datenübertragung zu einem externen Monitor
• eine integrierte Webcam und analoge Mikrofone für die verschiedensten
Multimedia-Anwendungen
• ein Multi-Format-Kartenleser, um digitale Fotos, Musik und Videoclips schnell
auf Ihr Notebook zu übertragen
• ein integrierter Audio-Controller und Stereo-Lautsprecher für echten Hörgenuss
• zusätzliche Ein- und Ausgänge für hochwertiges Audio-Zubehör
• eine Tastatur mit separatem Ziffernblock
• ein On-Screen-Display zur visuellen Kontrolle der wichtigsten Einstellungen Ihres Notebooks
Mit dem benutzerfreundlichen "BIOS-Setup-Utility" können Sie die Hardware Ihres
Notebook steuern und Ihr System besser vor unbefugtem Zugriff schützen, indem
Sie die leistungsfähigen Passwort-Eigenschaften nutzen.
Diese Betriebsanleitung zeigt Ihnen unter anderem, wie Sie Ihr AMILO Notebook
in Betrieb nehmen und bedienen.
Weitere Informationen
Allgemeine Informationen zu Ihrem AMILO Notebook finden Sie in
der Betriebsanleitung "AMILO Notebook".
Die Treiber für Windows Vista für Ihr AMILO Notebook finden Sie auf
unserer Internetseite. Werkseitig unterstützten diese Geräte keine anderen
Betriebssysteme. Fujitsu Siemens Computers übernimmt keine Haftung
bei der Verwendung anderer Betriebsysteme.
Softwarebezogene Teile dieser Anleitung beziehen sich auf Microsoft-Produkte,
falls sie zum Lieferumfang Ihres AMILO Notebook gehören.
Beachten Sie bei der Installation von anderen Softwareprodukten die
Bedienungsanleitungen des Herstellers.
10600969176, Ausgabe 1 Deutsch - 1
All manuals and user guides at all-guides.com

Innovative Technologie
Betriebsanleitung "AMILO Notebook"
Die Betriebsanleitung "AMILO Notebook" finden Sie im Windows-Startmenü oder
im Internet unter "www.fujitsu-siemens.com/support".
2 - Deutsch 10600969176, Ausgabe 1
All manuals and user guides at all-guides.com

Anschlüsse und Bedienelemente
Anschlüsse und Bedienelemente
In diesem Kapitel werden die einzelnen Hardware-Komponenten Ihres Notebook vorgestellt.
Sie erhalten eine Übersicht über die Anzeigen und die Anschlüsse des Notebook. Machen
Sie sich mit diesen Elementen vertraut, bevor Sie mit dem Notebook arbeiten.
15 14
13
2
1
4
76
21
24
26
3
5
22
8
9
10
19
19
17
12 11
20
25
23
27
16
17
18
1 = Webcam
2 = Schnell-Start-Tasten
3 = Touchpad
4 = Tastatur mit separatem Ziffernblock
und Applikationstasten
5 = Statusanzeigen
6 = Touchpad-Tasten
7 = Multi-Format-Kartenleser
8 = Line-In-Anschluss
9 = Mikrofonanschluss
10 = Kopfhörer-/SPDIF-/Line-Out-Anschluss
11 = ExpressCard-Steckplatz
12 = Netzwerkanschluss
13 = eSATA-/USB-Kombinationsanschluss
14 = Lüftungsschlitze
15 = Gleichspannungsbuchse (DC IN)
16 = Kensington Lock-Vorrichtung
17 = Lautsprecher
18 = Ein-/Ausschalter
19 = Mikrofone
20 = CD/DVD-Laufwerk
21 = USB-Anschlüsse
22 = DVI-I-Anschluss
23 = USB-Anschluss
24 = Servicefach Festplatte 2
25 = Servicefach Festplatte 1
26 = Akku
27 = Servicefach Speicher
10600969176, Ausgabe 1 Deutsch - 3
All manuals and user guides at all-guides.com

Wichtige Hinweise
Wichtige Hinweise
Beachten Sie die Sicherheitshinweise im Handbuch "Sicherheit" und in
der Betriebsanleitung "AMILO Notebook".
4 - Deutsch 10600969176, Ausgabe 1
All manuals and user guides at all-guides.com
