Fujitsu Siemens Computers MYRICA VQ32-1T User manual

Issue
October2006
MYRICAVQ32-1T
LCD TVPages
2
Avibrant,cinema-likeimagemakestheMYRICA VQ32-1Tidealforhomeentertainment. Lightandthinenoughtohang
on yourwall, yetpackedwithcutting-edgefeatures:it’stheperfectenhancementofyourdigitalhome.
The32-inch(81cm)LCD screenwithexcellent1200:1contrastensuresastunning image.High-definitionTV
technologyfortomorrow’sHDTVcontentand integratedstereospeakersenrichyourlivinghome.
n32-inchwidescreenLCD display
nHD ready
n1xHDMI and1xDVI-I(bothwithHDCPsupport)
nHigh resolution 1366x768pixels
n16.7Miocolors
nViewing angle178° horizontal,178°vertical
nHigh brightness 500cd/m²and
veryhigh contrast(1200:1)
nPrecisereproductionof fastmovements
nMultinormdualTVtuner(PAL/SECAM)
nMultiplevideoinputs
nTeletext (5000pages)
nPlugandPlay(DDC 2Binterface)
nAnalogPCinputviaDVI-I
nImmunetoexternalelectromagneticfields
n13 languagesOSDmenu
nCountryspecificwarranty
nMadeinGermany

DataSheet Issue: October2006 MYRICAVQ32-1T Page 2/ 2
All rights,includingrightscreated bypatentgrant orregistration of autilitymodelordesign aswell
asrightsof technicalmodificationsarereserved. Deliverysubject toavailability. Designationsmay
be trademarks, theuseofwhichbythirdpartiesfortheirownpurposesmayviolatethe rightsof the
trademarkowners.
Copyright FujitsuSiemensComputers,10/2006
Published by
FujitsuSiemensComputers
http://www.fujitsu-siemens.com/
Companystamp
Visiblescreendiagonal 32-inch(81.3cm)WXGA
Panelresolution
Pixels1366 x768
Pixelpitch0.511x0.511mm
Picturesize 697.68x392.26mm
Peak brightness (typical)500cd/m²
Contrast (typical)1200:1
Response time g/gavg 8ms
Viewingangle (typical)
Horizontal178°
Vertical178°
Options
TVtuner TwinTuner VHF/UHF/cable
StandardPALB/G, D/K, I
SECAMB/G,DK,L
Sound systemMono,stereo, dualtone
Teletext5000 pages(FLOF/TOP)
VideoI/O
2xTV-RFInIEC-connectors
1xTV-RFOutFeedforsecondtuner
1xHDMIwithHDCPsupport
DVI-I withHDCPsupport
SCART121-pinSCART(CVBS/RGB)
SCART221-pinSCART
(CVBS/S-Video)
AV: CompositevideoinRCAComponent Yin
S-Video(In)(4pinHOSIDEN)(YC)
Componentvideo3xRCA(YUV)
(Ysharedwith
CompositeVideoIn)
PC(Input)
DVI-I Resolutions
(withHDCPsupport)1360 x768 60Hz
1280 x1024 75Hz
1280 x720 60Hz
1024 x768 60Hz
800x600 60Hz
720x400 70Hz
640x480 60Hz
Videoformats (overHDMI, DVI andComponent in)
480i, 480p,576i, 576p,720p,1080i
1360x768 50/60HzforDVI and HDMI
Audiocharacteristics
CVBS /YUVAudioIn2xRCA
S-VideoAudioIn2xRCA
PCAudioin3,5mm Jack/Stereo
Subwoofer(passive)1xRCA
Audiolineout(stereo)1xRCA
SPDIFin1xRCA
SPDIFout1xRCA
InternalSpeakers7W(L)+7W(R)
Electricalvalues
Ratedvoltage110-240V
Frequency 50 -60Hz
Powerdraw
Operatingtypical170W
Standbymode<0.6W
Protectionclass1
Temperatures/dimensions/ weight
Ambienttemperature(toIEC721):
Recommendedrange15°Cto35°C
Limit5°Cto35°C
Dimensions(HxWxD):
withstand535.8x783.2x188.7mm
w/ostand 493.9x783.2x114.1mm
Weight:
withstandapprox.9.2kg
w/ostand approx.7.5kg
Compliancewithstandards
ProductsafetyEN60065
ErgonomicsGSmark
RadiationimmunityandCEcertification according
RFI suppressiontoECDirective
89/336/EEC
(EN55013, EN55020,
EN61000-3-2/-3)
Accessories
Powercable(1.8m)forwallsocket
Euro-Schuko-TypeCEE7
plugtypeIEC-320-C13
SCARTcable1,5m21-pin
Antenna cable1,5mIEC(female/male)
Remotecontrolincl.batteries(2xAAA)
Usermanualmultilanguage
Warrantybooklet
GettingStarted
Specialfeatures
PIP(PictureinPicture)
VariousZoommodes
Automaticprogramsearch
CinemaMode
DigitalAudioOut
Surround Sound
GraphicequalizerviaOSD(usermode)
Ordercode S26361-K1123-V171
EAN 4045827843207
