Fujitsu AMILO Mini Ui 3520 Manual

AMILO Mini Ui 3520
.
First-time setup
English
Deutsch
Français
Español
Italiano
Nederlands
Português

Microsoft, MS Windows and Windows XP are registered trademarks of the Microsoft Corporation.
Adobe Reader is a trademark of Adobe Systems Incorporated.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Siemens Computers GmbH 2008
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, in part or in whole.
In the event of violations, perpetrators will be liable to prosecution for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.

Contents
English
Contents
Innovativetechnology ................................................................. 1
Furtherinformation ...................................................................... 2
"AMILO Mini" operating instructions ................................................... 2
PortsandOperatingElements ......................................................... 3
Importantnotes ........................................................................ 4
First-timesetupoftheAMILOMini ..................................................... 5
AMILO Mini unpacking and checking . . ................................................... 5
Selectingalocation ..................................................................... 6
Mains adapter connecting . . . . ........................................................... 6
SwitchingontheAMILOMiniforthefirsttime ............................................. 7
Configure wireless Internet connection . ................................................... 7
UsingWLANaccess ................................................................ 7
AccessviaUMTS ................................................................... 8
Changing the Clip-on-Cover . . ........................................................... 8
Personalised Clip-on-Cover . . . ....................................................... 10
Technicaldata ......................................................................... 11
AMILOMini ............................................................................ 11
Mains adapter .......................................................................... 11
10600986639, edition 1 English

Contents
English 10600986639, edition 1

Innovative technology
Innovative technology
... and ergonomic design make your AMILO Mini a convenient and reliable companion.
The Microsoft Windows XP operating system is already installed and optimally configured on
the AMILO Mini. The device is ready for immediate use when you first switch it on, boots
up very quickly and offers a particularly long operating time because of its very high capacity
battery. Furthermore, an extensive range of software is already pre-installed: Microsoft Office
suite, Windows Media Player, Internet Explorer, Messenger and much more.
Your AMILO Mini is equipped with optimised technology to provide long
operating times and ease of use:
• two USB ports for easy expansion to add a printer, external fixed disk, USB flash memory etc.
• LAN and wireless LAN for Internet access
• a Bluetooth interface for wireless Internet access with mobile terminal equipment
• a VGA port for connection of an external monitor
• an integrated webcam and two digital microphones for the widest
variety of multimedia applications
• a multi-format card reader for rapid transfer of digital photos, music and
video clips onto your device
• an onboard sound card and stereo loudspeakers for your audio enjoyment
• in addition, input and output ports for high-quality audio accessories
• a 34 mm ExpressCard slot for expansion with a UMTS card, GPS satellite navigation etc.
• attachable outer covers (Clip-on-Covers) in a variety of colours available as accessories
With the user-friendly "BIOS Setup Utility" you can control your AMILO Mini’s hardware and better
protect your system against unauthorised access by using the powerful password properties.
This operating manual tells you how to prepare your AMILO Mini for use,
and how to operate it in daily use.
Expansion with an external DVD drive and recovery of installed software
Your AMILO Mini can be extended with an external DVD drive for installation of
additional software or for recovery of the system.
The DVD drive is connected to a USB port and is immediately ready for use.
For more information on purchasing the DVD drive with a recovery DVD, please refer to
the enclosed leaflet or the Internet under "www.fujitsu-siemens.com".
10600986639, edition 1 English - 1

Innovative technology
Further information
You will find general information on your AMILO Mini in the
"AMILO Mini" operating manual.
You will find the Windows XP drivers for your AMILO Mini on our Internet
website. The factory installation of your AMILO Mini does not support any
other operating system. Fujitsu Siemens Computers does not accept any
liability whatsoever if any other operating system is used.
Software oriented components of these instructions refer to Microsoft products, if
they come within the scope of the delivery of your AMILO Mini.
If you install other software products, pay attention to the operating
instructions of the manufacturer.
"AMILO Mini" operating instructions
The operating instructions for the "AMILO Mini" will be found in the Windows Start menu
or on the Internet under "www.fujitsu-siemens.com/support".
2 - English 10600986639, edition 1

Ports and Operating Elements
Ports and Operating Elements
This chapter presents the individual hardware components of your AMILO Mini. It gives
an overview of the displays and connections of the device. Please familiarise yourself
with these components before you start to work with the device.
14
13
3
1
6
10
16
5
7
11
2
17
18
4
4
12
9
19
15
8
1 = Webcam
2 = Microphones
3 = ON/OFF switch
4 = Loudspeakers
5 = Touchpad
6 = Keyboard
7 = Microphone / Line in port
8 = Headphone port
9 = Multi-format card reader
10 = Touchpad buttons
11 = Status indicators
12 = Ventilation slots
13 = USB port
14 = Monitor port (VGA)
15 = ExpressCard slot
16 = USB port
17 = LAN port
18 = DC input connector (DC IN)
19 = Battery
10600986639, edition 1 English - 3

Important notes
Important notes
Please observe the information provided in the "Safety" manual and
in the "AMILO Mini" operating manual.
4 - English 10600986639, edition 1

First-time setup of the AMILO Mini
First-time setup of the AMILO Mini
First-timesetupGettingstarted
If your device is equipped with a Windows operating system, the necessary
hardware drivers and supplied software are already pre-installed.
Depending on the hardware and software configuration, the first-time setup for
the Microsoft XP operating system can take up to 20 minutes.
A system test is performed when your device is first switched on. Various messages
can appear. The display may remain dark for a short time or may flicker.
Please follow the instructions on the screen.
NEVER switch off your device during the first-time setup process.
You must charge the battery before you can work with your AMILO Mini for the first time.
On delivery, the battery can be found in the battery compartment or in the accessories kit.
The battery must be charged if you want to operate your device using the battery.
When used on the move, the built-in battery provides the device with the necessary power. You
can increase the operating time by using the available energy-saving functions.
If you use your AMILO Mini at home or in an office, we recommend you use
the mains adapter instead of the battery.
For instructions on how to connect external devices (e.g. mouse, printer) to your AMILO
Mini, please refer to the "AMILO Mini" operating manual.
AMILO Mini unpacking and checking
Should you discover any damage that occurred during transportation,
notify your local sales outlet immediately!
►Unpack all the individual parts.
PackagingTrans port
►Check your device for any visible damage which may have occurred during transportation.
We recommend that you keep the original packaging material.
You may need the packaging in the future, if you need to transport your device.
10600986639, edition 1 English - 5

First-time setup of the AMILO Mini
Selecting a location
Selec tinga loca tionDeviceMainsadapter
Select a suitable location for the device before setting it up. Follow
the instructions below when doing so:
• Never place the device or the mains adapter on a heat-sensitive surface.
The surface could be damaged as a result.
• Never place the device on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause overheating and damage.
• Do not place the device on your legs for a long period of time. The underside
of the device heats up during normal operation. Prolonged contact with the
skin may become unpleasant or even result in burns.
• Place the device on a stable, flat, non-slippery surface. Please note that the
rubber feet of the device may mark certain types of delicate surfaces.
• Keep other objects at least 100 mm away from the device and its
mains adapter to ensure adequate ventilation.
• Never cover the ventilation slots of the device.
• Do not expose the device to extreme environmental conditions. Protect
the device from dust, humidity, and heat.
Mains adapter connecting
Preparingfor operationMainsadapter
Observe the safety precautions in the enclosed "Safety" manual.
The supplied power cable conforms to the requirements of the country in
which you purchased your device. Make sure that the power cable is approved
for use in the country in which you intend to use it.
The mains adapter’s power cable should only be connected to a mains socket
if the device is connected to the mains adapter.
Make sure that the rated current of the mains adapter is not higher than
that of the mains supply to which you connect the mains adapter (see
chapter "Technical Data""Mains adapter", Page 11).
1
2
3
►Connect the mains adapter cable (1) to
the DC jack (DC IN) of the device.
►Connect the power cable (2) to the
mains adapter.
►Plug the power cable (3) into a mains outlet.
6 - English 10600986639, edition 1

First-time setup of the AMILO Mini
Switching on the AMILO Mini for the first time
Switchingonforthefirsttime
The device must be supplied with power through the mains adapter during this process.
When you switch on the device for the first time, the supplied software is
installed and configured. Because this procedure must not be interrupted,
you should set aside enough time for it to be fully completed and connect
the device to the mains using the mains adapter.
During the installation process, DO NOT restart the device unless
you are requested to do so!
You can find information on how to restore the operating system, drivers, manuals
and special software in the "Recovery Process" manual.
To make it easier to use your device for the first time, the operating system
is pre-installed on the hard disk.
►Switch on your AMILO Mini (1).
►During installation, follow the instructions on screen.
Consult the operating system manual if anything is unclear about the requested input data.
If a Windows operating system is installed on your device, you will find more
information on the system and drivers, help programmes, updates, manuals etc. on
the device or on the Internet under "www.fujitsu-siemens.com/support".
Configure wireless Internet connection
With just a few steps you can wirelessly connect your AMILO Mini to the Internet.
Using WLAN access
• Requirement: You have a WLAN and the corresponding access data.
►Select Start - Settings - Network connections.
The Network connections window opens.
►In the window, double-click on the entry Wireless Network Connection.
The Wireless Network Connection window opens.
►Under Select Wireless Network, select the desired WLAN and confirm with Connect.
►If required, enter the corresponding access data (e.g. network key, password).
The connection to the WLAN is established.
10600986639, edition 1 English - 7

First-time setup of the AMILO Mini
Access via UMTS
You can purchase the accessories for UMTS reception from your retailer
or your Fujitsu Siemens Computer dealer.
You will find information on establishing the connection with the UMTS
network in the documentation for the hardware used.
Your AMILO Mini can connect with the Internet via UMTS. To do this, use
one of the following types of connection:
• USB dongle
a USB stick with your mobile phone provider’s SIM card
• a mobile end-device (e.g. mobile phone) with Bluetooth connection
• a mobile end-device (e.g. mobile phone) with data cable
• 34 mm ExpressCard with UMTS functionality
Changing the Clip-on-Cover
There are Clip-on-Covers available for your AMILO Mini, in various colours or transparent.
In order to protect the surfaces of your AMILO Mini, change the Clip-on-Cover
very carefully and as seldom as possible.
For further information about buying the Clip-on-Covers, please refer to the
enclosed leaflet and the Internet under "www.fujitsu-siemens.com/accessories"
or under ""www.fujitsu-siemens.com/online_shops.html".
8 - English 10600986639, edition 1

First-time setup of the AMILO Mini
►To secure the Clip-on-Cover, place it in on the notebook and press it on until it is felt to engage.
10600986639, edition 1 English - 9

First-time setup of the AMILO Mini
►To remove the Clip-on-Cover, lift it at both sides simultaneously and lift it away from the notebook.
Personalised Clip-on-Cover
You will need the transparent Clip-on-Cover for your personalised cover design. Print out
your favourite design in 25 x 14 cm format and slide it under the cover.
10 - English 10600986639, edition 1

Technical data
Technical data
Technicaldata
AMILO Mini
Technicaldata
Environmental conditions
Operating temperature 5 °C – 35 °C
Dimensions
Width x Depth x Height (front/back) 232.4 mm x 175 mm x 29.0/35.8 mm
Weight (including 4-cell rechargeable battery) Approx. 1 kg
The data sheet for the AMILO Mini contains further technical data. The data
sheet can be found on your AMILO Mini, or alternatively it is also available to
download from the Internet at "www.fujitsu-siemens.com".
Mains adapter
Technicaldata
Electrical data
Main 40 W
Rated voltage 100 V – 240 V (automatic)
Frequency 50 Hz – 60 Hz (automatic)
Sub
Rated voltage 20 V
Max. rated current 2.0 A
An additional mains adapter or power cable can be ordered at any time.
10600986639, edition 1 English - 11

Technical data
12 - English 10600986639, edition 1

AMILO Mini Ui 3520
.
First-time setup
English
Deutsch
Français
Español
Italiano
Nederlands
Português

Microsoft, MS, Windows, Windows XP sind eingetragene Warenzeichen der Microsoft Corporation.
Adobe Reader ist ein Warenzeichen der Adobe Systems Incorporated.
MultiMediaCard ist ein eingetragenes Warenzeichen der Infineon Technologies AG.
Sony und Memory Stick sind Warenzeichen der Sony Electronics, Inc.
Alle anderen Warenzeichen sind Warenzeichen oder eingetragene Warenzeichen der
jeweiligen Inhaber und werden als geschützt anerkannt.
Copyright © Fujitsu Siemens Computers GmbH 2008
Alle Rechte vorbehalten, insbesondere (auch auszugsweise) die der Übersetzung, des
Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.
Zuwiderhandlungen verpflichten zu Schadenersatz.
Alle Rechte vorbehalten, insbesondere für den Fall der Patenterteilung oder GM-Eintragung.
Liefermöglichkeiten und technische Änderungen vorbehalten.

Inhalt
Deutsch
Inhalt
InnovativeTechnologie ................................................................ 1
WeitereInformationen ................................................................... 2
Betriebsanleitung"AMILOMini" ...................................................... 2
AnschlüsseundBedienelemente ....................................................... 3
WichtigeHinweise ..................................................................... 4
ErstinbetriebnahmedesAMILOMini ................................................... 5
AMILO Mini auspacken und überprüfen ................................................... 5
Stellplatzauswählen .................................................................... 6
Netzadapter anschließen . . . . . ........................................................... 6
AMILOMinizumerstenMaleinschalten .................................................. 7
DrahtlosenInternet-Zugangeinrichten .................................................... 8
WLAN-Zugang nutzen . . . . ........................................................... 8
Zugang über UMTS . . . . . . ........................................................... 8
Clip-on-Coverwechseln ................................................................. 8
Individuelle Clip-on-Cover . ........................................................... 10
TechnischeDaten ...................................................................... 11
AMILOMini ............................................................................ 11
Netzadapter . . .......................................................................... 11
10600986639, Ausgabe 1 Deutsch

Inhalt
Deutsch 10600986639, Ausgabe 1
