T e c h n i c a l P r o c e d u r e
LifeBook P-103x
Disassembly Procedure
1. To begin the disassembly proce-
dure, make sure the unit is powered
off. Remove the battery.
4. Also detach the LAN cable. Press
the locking clip to release the
modem card and pull it out of its
socket.
3. Turn the modem cover over and
detach the modem cable from the
card.
2. Remove five screws securing the
hard disk drive and modem covers.

2
7. Pry up and remove the hinge cover.
8. Underneath, unlock and remove the
keyboard’s flex cable.
9. Slide the keyboard forward and tilt
it up. Detach the cable to the point-
ing device and lift the keyboard off.
10. Detach the cable to the status
LCD.
5. Detach the hard disk drive’s flex
cable and lift the drive from its bay. 6. Remove seven case screws. Pry off
the unit’s feet and remove the two
screws beneath.

3
13. Remove the screw securing the
upper cover.
11. At the rear, remove the two hinge
screws. 12. Detach the main LCD cable. Lift
off the LCD.
14. At the front, detach the cable from
the click assembly. Lift off the
upper cover. Remove the left and
right side panels.
15. Remove the screw securing the
heat sink and lift it off. 16. Unlock and remove the USB
cable.

19. Detach the speakers’ cable at the
lower right.
17. Remove the two screws securing
the USB board and lift it off. 18. At the upper right, detach the DC
board cable.
20. Lift out the motherboard and turn
it over. Detach the bridge bat-
tery’s cable from the motherboard
and lift the battery off.
21. To disassemble the main LCD,
remove four corner screw caps
and the screws underneath.
22. Gently pry the edge of the frame
to separate it from the rear cover
and lift it off.
4

5
25. Detach the LCD’s cable from the
controller board.
23. Remove two screws securing the
status LCD and lift off its cover. 24. Remove the screw securing the
LCD panel and tilt it up.
27. Unlock and remove the inverter
cable. Slide the inverter card from
its sleeve.
26. Detach the LCD’s cable to the
inverter card.
28. Unlock and remove the two status
cables from the back side of the
status LCD.

6
29. Detach its cable to the control
board and lift out the status LCD.
31. Detach the LAN cable and lift it
out. 32. Remove the antennae from its
cover. The disassembly of this
LifeBook is now complete.
30. Remove two screws securing the
wireless LAN antennae and left
hinge.

LifeBook P-103x
Assembly Procedure
1. Fit the wireless LAN antennae into
its cover and position it in the rear
cover. Secure it with two screws.
2. Position its cable and secure the
hinge.
3. Insert and lock the LAN’s status
cable. 4. On the underside of the status LCD
attach its two cables.
T e c h n i c a l P r o c e d u r e
7

7. Place the LCD panel next to the
rear cover so that you can attach its
cable to the inverter card.
5. Attach also the status LCD’s main
cable to the controller card. 6. Slide the inverter card into its
sleeve. Insert and lock its cable.
8. Tilt the LCD over so that you can
connect its cable to the controller
card. Tilt the LCD into the rear
cover.
9. Position and secure the cover to the
status LCD.
10. Position the frame to the rear
cover and snap it into place.
Secure the frame with four screws
and replace the screw caps.
8

9
13. Maneuver the motherboard into
the lower cover.
11. Place the speakers into the lower
cover and position their cable.
12. Connect the bridge battery to the
motherboard and position it.
14. Attach the cable from DC board
and position it.
15. Position and secure the USB
board with two screws. 16. Attach its cable.

10
19. Position the right and left side
panels. Position the upper cover
so that you can attach the click
assembly cable.
17. Connect the speakers’ cable on the
lower right. 18. Position the heat sink over the
motherboard and secure it.
20. Secure the cover.
21. Lower the LCD onto the hinge
cover. Connect its cable. 22. At the rear, secure the two hinges
and replace the screw caps.

11
25. Position the keyboard so that you
can attach the cable to the point-
ing device.
23. Maneuver the LAN cable to the
underside of the unit so as to con-
nect it to the modem card later.
24. Connect the status LCD cable to
the motherboard.
26. Tilt down the keyboard so that
you can insert and lock its data
cable.
27. Snap the hinge cover into place.
Close the unit and turn it over. 28. Insert the modem card into its
socket and press to lock it.
Connect the LAN cable.

12
31. Place the hard disk drive into its
bay and press to connect its flex
cable.
29. Replace two case screws between
the modem card and hard drive
bay.
30. Place the modem cover so that
you can connect the modem cable
and then position the card.
32. Replace the drive’s cover and
secure it with two screws. Secure
the modem cover with three
screws.
33. Replace two case screws at the
rear and secure the feet. Continue
to replace five more case screws.
34. Press the battery into its bay until
it locks. The assembly of this
LifeBook is now complete.
