Even though the Fujitsu LifeBook PH520 notebook is
ultra-thin and portable in size, it offers many of the
features that are standard in larger notebooks.
PORTABLE PERFORMANCE
The Fujitsu LifeBook PH520 notebook is the ideal
mobile solution for highly mobile users, who like full
functionality in a compact footprint at an affordable
price. With a configurable weight of just 3.08
pounds, a very 1.02" thin, and a power-efficient AMD
Athlon® II Neo Processor K125, the Fujitsu LifeBook
PH520 notebook delivers on ultra-portability, and
full-functionality at an affordable price. With the
exhaustive time now needed to travel, it’s good to
know your notebook will be ready to let you catch up
on work even during those unending flights. But don’t
let the small size fool you; the LifeBook PH520 has a
good size keyboard for fast and comfortable use.
The standard built-in camera, centered above the
display, is ideal for visually demonstrating a
complicated procedure over the web, showing what
something actually looks like, or just messaging to
your buddies.
The gesture enabled touchpad adds a whole new
level of functionality to the PH520 LifeBook. You will
be able to vertically scroll up and down through web
pages and documents much faster with a flick of your
finger across the touchpad. By moving your finger in
a circular motion on the touchpad, you will also be
able to easily rotate photos. With an in or out pinching
gesture you will have to power to zoom in and out
of images or documents. This makes navigating files
much easier and faster.
By simply pressing the Fn and F11 keys together (ECO
mode) you will instantly go into a power saving mode,
allowing you to get longer use from your battery. ECO
mode can also adjust the notebook settings to deliver
the most power while you are working in the office.
FLEXIBLE COMMUNICATION OPTIONS
The Fujitsu LifeBook PH520 notebook conforms
to your lifestyle, you have the flexibility to connect
to your office network and the Internet, via the
Ethernet LAN or Atheros Align™ 802.11BGN
wireless LAN. The integrated Bluetooth not only
connects to headphones, mice, or keyboards, but
it lets you enjoy CD quality sound over Bluetooth
speakers. It also allows for quick data interchange
with your cell phone or MP3 players.
COMPLETE ARRAY OF INDUSTRY STANDARD PORTS
FOR QUICK CONNECTIONS
The Fujitsu LifeBook PH520 notebook design includes
a wide variety of ports that you would typically find
on a notebook computer twice its size, including
three USB 2.0 ports, external monitor port, an HDMI
port, RJ-45 ports, and headphone and microphone
jacks. For fast and easy storage, transfer of music,
pictures, and data, the Fujitsu LifeBook PH520
notebook is equipped with a Memory Stick®/Secure
Digital (MS/SD) card slot.
UNCOMPROMISING QUALITY
Fujitsu takes the extra steps needed to ensure a
long and happy relationship with your LifeBook. The
spill-resistant keyboard helps your notebook survive
accidental spills—instant death for most other
notebooks. The My Recovery feature allows you
to create your own recovery disc, giving you the
peace-of-mind of having the hard drive base recovery
always available. Fujitsu takes pride in its own
world-class design, and rigorous testing capabilities,
providing extremely high quality mobile
computers with one of the lowest failure rates in
the industry.
§ JUST OVER 3 LBS. AND SLIGHTLY THICKER THAN 1"
§ ENERGY EFFICIENT AMD ATHLON
®
II NEO
PROCESSOR K125 (1.7 GHZ, 1 MB L2 CACHE)
§ 11.6" CRYSTAL VIEW WIDE-XGA LED BACKLIT
HD DISPLAY
§ RUNS STANDARD MICROSOFT
®
WINDOWS
®
7
PROFESSIONAL OPERATING SYSTEM
§ FEATURING 82-KEY SPILL RESISTANT KEYBOARD
WITH ENLARGED TOUCHPAD
§ HDMI PORT FOR CONNECTING TO A
LARGE SCREEN TV
§ TRANSMIT STEREO CD QUALITY SOUND
TO BLUETOOTH HEADPHONE OR
BLUETOOTH SPEAKERS
§ FAST AND LONG RANGE 802.11BGN WIRELESS
§ 5 HOUR AND 30 MINUTES BATTERY LIFE
DATASHEET FUJITSU LIFEBOOK PH520 NOTEBOOK
DATASHEET
LIFEBOOK® PH520 NOTEBOOK
EXPERIENCE FULL PC PRODUCTIVITY ON AN AFFORDABLE ULTRA-THIN NOTEBOOK.

TECHNICAL DETAILS
SOFTWARE
OPERATING SYSTEMS: Genuine Windows® 7 Professional (64 bit)
SOFTWARE: Microsoft® Office Starter 20101 ,Acrobat Adobe
Reader®, CyberLink YouCam, Roxio Creator LJ, Microsoft® Internet
Explorer, Microsoft® Windows® Live Essentials and Silverlight,
Symantec Norton Internet Security™ 20102
KEY SPECIFICATIONS
(listed specifications are for the current model only and not for earlier models or revisions to this product.)
PROCESSOR: AMD Athlon® II Neo Processor K125 (1.70 GHz,
1 MB L2 cache)
CHIPSET: AMD™ RS880M AMD SB820
SYSTEM MEMORY: Two DIMM slots; 2 GB DDR3 1333 MHz3
SDRAM memory (1 GB +1 GB); Expandable to 8 GB (4 GB x2) max.
DISPLAY:
LCD LED backlit 11.6" Crystal View WXGA HD display
Resolution Internal: 1366 x 768 pixel resolution (16:9),
16M colors
External: 1600 x 1200 pixel resolution,
16M colors
Simultaneous: 1366 x 768 pixel resolution,
16M colors
Video Controller ATI™ Mobility Radeon® HD 4225; AMD™
RS880 video graphics (up to 896 MB of
HyperMemory graphics)
System Memory Hyper Memory System Memory Hyper Memory
2 GB – 3 GB 896 MB 4 GB – 6 GB 1919 – 2815 MB
9 GB – 4 GB 1408 MB 6.5 GB and more 3067 MB
HARD DRIVE4: 320 GB S-ATA, 5400 rpm hard drive
OPTIONAL WEBCAM: Integrated 1.3 mega-pixel webcam
OPTICAL DRIVE: Optional external USB optical drive
AUDIO: Realtek codec ALC269Q-VB5 with High Definition
(HD) audio
COMMUNICATION: 10/100 Ethernet LAN
WIRELESS COMMUNICATION: Integrated Atheros XSPAN® 802.11BGN
(802.11 b/g/n) wireless; Integrated Bluetooth V2.1 technology
USER INTERFACES: Spill resistant 82-key keyboard with 17.5
mm key pitch (92% of full-size) ,and 2 mm key stroke. Standard
integrated touchpad pointing device with gesture support
NOTEBOOK PORTS: One 15-pin D-SUB connector for VGA external
monitor, one HDMI port, three USB 2.0 connectors, one DC In
connector, one stereo headphone jack, one stereo microphone/
line-in jack, one LAN (RJ-45) connector
CARD SLOTS: MemoryStick®, SD card slot
SECURITY: Security lock slot
BATTERY LIFE5: 6-cell Lithium ion battery, rechargeable, 10.8V,
5800 mAh. Battery life: approx. 5 hrs. 30 mins.
AC ADAPTER: Auto-sensing dual voltage support, 100-240V AC
supplying 19V DC, 3.16A (60W)
DIMENSIONS AND WEIGHT: Approx 11.22"(w) x 8.11"(d) x 1.02" /
1.31" (h); Approx. 3.08 lbs.
OPERATING TEMPERATURE: 41° F to 95° F / 5° C to 35° C
(ambient temperature); 20% to 85% relative humidity,
non-condensing
NON-OPERATING TEMPERATURE: 5° F to 140° F / -15°C to 60° C;
8% to 85% relative humidity non-condensing
KEY ACCESSORIES: External USB optical drive, Additional Battery,
Additional AC Adapter
For a full list of accessories visit us.fujitsu.com/solutions
or call 1-800-831-3183
COMPLIANCE AND SERVICE INFORMATION
Compliance FCC Part 15B Class B; FCC Part 15C; IC ICES-003
Class B and RSS-210; FCC Part 15 E; UL-cUL Listed;FCC Part
68; IC CS-03; ENERGY STAR® qualified
WARRANTY6: One-year International Limited Warranty on select
corporate configurations; 24/7 technical support; Fujitsu extended
service plans available.
FUJITSU AMERICA, INC.
1250 East Arques Avenue
Sunnyvale, CA 94085-3470, U.S.A.
Telephone: [phone]
or 408 746 6000
Fax: [phone]
Web: solutions.us.fujitsu.com
Email: [e-mail]
1) Microsoft® Office Starter 2010(32-bit)
includes reduced-functionality versions of
Word® and Excel® only, with advertising.
2) Preinstalled with a free 60-day trial version of
Symantec Norton Internet Security 2009. The
60-day trial version is activated upon user’s
acceptance of software license agreement.
After 60 days, the user must purchase a
subscription from Symantec to download latest
virus definitions.
3) Clocked at 800MHz by the chipset
4) One gigabyte (GB) = one billion bytes.
Accessible capacity will be less and actual
capacity depends on the operating environment
and formatting. Approximately 16.2GB of
the hard drive is reserved for system
recovery software.
5) Battery life tested using MobileMark 2007
and may include audio muted. Battery life will
vary depending on the product configuration,
product model, application loaded on the
product, power management settings on the
product, Operating System, and the product
features used by the customer. As with all
batteries, the maximum capacity of the installed
batteries will decrease with time, usage, and
how often the batteries are charged by the user.
6) Service and warranty turnaround time may
vary by country and product. International
warranty valid only for products purchased in
North, Central, and South America
