Delivering touch screen capability, long battery life, and Microsoft Windows
computing power, the innovative LifeBook U810 mini-notebook is a stylish,
super light weight, ultra compact, fully functional convertible
notebook computer.
LifeBook U810 Notebook
BENEFITS
Powered by the Intel®Processor A110,
the Fujitsu LifeBook®U810 mini-note-
book provides the processing power and
efcient energy use to power through
your day. You will experience up to
5.5 hours1of ultra-mobile computing
on a single battery with this amazing
mini-notebook
Product Versatility
Don’t be fooled by its size, at a mere
1.56 lbs. and diminutive form factor,
the LifeBook U810 has plenty of
power to let you work, access your
ofce network, check e-mail, or
conduct video conferences. Whether
waiting for your next ight, or sipping
a latté at your favorite cafe, it lets you
watch downloaded movies, listen to
MP3 les, play games, browse the
Internet, take pictures, or stay connected
to your family and friends. It completely
revolutionizes the way you work and
play—wherever you are, whenever you
want. Welcome to the extremely free
lifestyle of the 21st Century with the
ultra mobile LifeBook U810 notebook.
Converging Connectivity
The LifeBook U810 mini-notebook features
an integrated Webcam with 0.3 mega
pixels (640 x 480 resolution) for easy
video chat with your friends and very
convenient digital picture-taking.
It truly epitomizes the idea of an
all-capable ultra-mobile companion.
If you use a Bluetooth-enabled cellular
phone or PDA, your LifeBook U810
mini-notebook is equipped with integrated
Bluetooth (version 2.0) wireless technology
for data synchronization and swapping
images. Its also very easy to stay connected
while on the go with Atheros Super AG™
802.11ABG wireless technology.
Uncompromised Security
With advanced security features such
as BIOS Lock3, Fingerprint Sensor, and
Trusted Platform Module (TPM), your
condential data is protected against
intrusion by unauthorized parties.
OVERVIEW
Convertible form factor with a brilliant 5.6"•
WSVGA Crystal View touch screen display
Pre-installed with Genuine Windows Vista®•
or Windows XP Tablet PC Edition 2005
and 1 GB of system memory
Solid computing power with the Intel• ®
processor A110 at 800 MHz and
Energy Star compliant for up to
5.5 hours of computing
Ultra versatile, multi-functional design for•
intuitive touch or pen input, or thumb
typing with the comfortable built-in
QWERTY keyboard
Comprehensive connectivity with•
built-in wireless LAN, Bluetooth,
and Ethernet-capability
With the integrated Fingerprint reader•
and BIOS Lock, your business and
personal data is protected against
unauthorized access

LifeBook®S2000 Notebook
Software
Operating Systems Genuine Windows Vista® Home Premium (or Genuine Windows Vista®
Business) (or Genuine Windows®XP Tablet PC Edition 2005)
Bundled Software
Microsoft Works with Office 2007 Home and Student Trial (on Genuine
Windows Vista® Home Premium model only), Microsoft Office OneNote
®
2007 (on Genuine Windows Vista® Business and XP TPC model only),
Microsoft Origami Experience Pack (on Genuine Windows Vista® models
only), Microsoft Experience Pack for Tablet (on XP TPC model only)
ArcSoft Web Companion 2, Softex OmniPass, Adobe Acrobat Reader,
Fujitsu Menu, Fujitsu Driver Update, Zoom utility, Bluetooth Driver and Utility
Software on CD Trusted Platform Module (TPM) Driver and Utility CD
Key Specications
Processor Intel®Ultra Mobile platform 2007
Intel®processor A110 (800MHz, 512KB L2 cache, 400MHz FSB)
Intel®945GU Express Chipset
Intel®ICH7U I/O Controller Hub
Memory 1GB DDR2 400MHz
Display LCD 5.6-inch Crystal View WSVGA, 1024 x 600 pixels,
Touch screen
Video
Controller Integrated Intel®Graphics with 3D Accelerator
Digitizer Passive Touch Screen
Web cam Integrated Camera, 0.3 MP (640 x 480 resolution)
Hard Drive240 GB, 1.8-inch PATA Ultra DMA 100 (4200rpm), S.M.A.R.T. support
Audio RealTek ALC262 HD audio codec with built-in digital microphone
Communication Realtek 8101L 100Base Ethernet
Wireless
Communication Bluetooth®v2.0, Atheros Super AG®802.11ABG wireless connection
with dual antenna
User Interface Keyboard with Glide Point: 56 key, 14mm key pitch, 1.3mm key stroke;
Left click and right click buttons
Fingerprint Sensor
Connector Interface USB 2.0 x 1, VGA (external display) and RJ45 (LAN) via LAN/VGA adapter
connector, Audio-in, Audio-out, Power Adapter DC-in VGA/Lan Adapter
External cable for connection to RJ45 (LAN), VGA (external display)
Card Slots 1 x Type I/II CF Card slot
1 x Secure Digital (SD) Card Reader
Security User and supervisor BIOS password3, Boot Sector Write Prevention,
Fingerprint Sensor, Trusted Platform Module (TPM)
Battery1Lithium ion; 4-cells, 7.2V, 5200mAh; rated up to 5.5 hours
AC Adapter Input AC 100~240V, Output DC 16V 40W, 4.22A
Dimensions/Weight 6.73" (W) x 5.24"~6" (D) x 1.04~1.26" (H) (with the 4-cell battery)
Approx. 1.56 lbs. with 4 cell battery
Operating
Temperature 41°F to 95°F/5°C to 35°C (ambient temperature); 20% to 85%
relative humidity, non-condensing
Non-Operating
Temperature 5°F to 140°F/-15°C to 60°C, 8% to 85% relative humidity, non-condensing
Key Accessories
For a full list of accessories, visit www.shopfujitsu.com or call 1-800-FUJITSU
Docking Cradle Connector Interface:
USB 2.0 x 4, VGA (external display), RJ45 (LAN), Power Adapter DC-in
Service Information
Warranty4One- or three-year International Limited Warranty on select corporate
configurations; 24/7 technical support; Fujitsu extended service
plans available.
Fujitsu Computer Systems Corporation
Business Sales:
1.800.831.3183
us.fujitsu.com/computers
Consumer Sales (24/7):
1.800.FUJITSU
www.shopfujitsu.com
1) Battery life estimates reflect the results of BAPCo
MobileMark2005 Productivity Workloads performed
upon systems with battery life setting enabled on
Windows®XP operating systems. Actual battery life will
vary based on screen brightness, applications used,
features selected, power management settings, battery
conditioning, and other customer preferences.
DVD/CD-RW, DVD Writer, LAN, wireless LAN or
hard drive usage may also have a significant impact
on battery life.
2) One gigabyte (GB) = one billion bytes; accessible
capacity will be less and actual capacity depends on
the operating environment and formatting.
3) BIOS Lock needs a supervisor/user password to
access BIOS setup. BIOS settings can be
configured to prompt for password at every
first bootup or all bootup sequences. Access to
BIOS setup is needed to configure Hard Disk Lock.
Hard Disk Lock requires an access key to retrieve
data on the hard disk. This is a Data Confidentiality
security feature. LifeBook Lock requires a supervisor/
user password to bootup the LifeBook when it
powers up or resumes last session from suspend/
hibernate mode. This is an anti-theft feature with more
than 800,000 password combinations using the
buttons on th e Quick Launch Panel. Anti-theft Lo ck Slot
allows the use of a lock to physically secure the
LifeBook. Smartcard slot usage is dependent on
customer’s solution. Fingerprint sensor uses AuthenTec
TruePrint™ Technology and Softex OmniPass to
remember customer list of user IDs and passwords.
Full security unlock sequence—LifeBook Lock, Bootup
Lock (BIOS Lock), Hard Disk Lock, Fingerprint
Windows Logon.
NOTE: Loss of password requires the LifeBook to be
returned to Japan factory for system refresh. Cost of
shipment and lost data will be borne by the customer.
Backup your user’s profile before changing HDD.
Without the user’s profile associated with a document
at the point of encryption, Softex OmniPass cannot
decrypt the encrypted document.
4) Service and warranty turnaround time may vary by
country and product. The International warranty is only
valid for products purchased in North, Central, and
South America.
Fujitsu, the Fujitsu logo, and LifeBook are trademarks
or registered trademarks of Fujitsu Limited in the United
States and other countries. Microsoft, Windows Vista
and Windows are trademarks or registered trademarks
of Microsoft Corporation in the United States and/
or other countries. Intel is a trademark or registered
trademark of Intel Corporation or its subsidiaries in the
United States and other countries. Atheros, the
Atheros logo and Super AG are all registered
trademarks of Atheros Communications. Memory Stick
is a registered trademark and Memory Stick PRO is
a trademark of Sony Corporation and/or its affiliates.
Adobe Reader is a registered trademark of Adobe
Systems, Inc. Wi-Fi is a trademark of the Wireless
Ethernet Compatibility Alliance (WECA). Norton
AntiVirus is a registered trademark of Symantec
Corporation. All other trademarks mentioned herein
are the property of their respective owners Product
description data represents Fujitsu design objectives
and is provided for comparative purposes; actual
results may vary based on a variety of factors.
Specifications are subject to change without notice.
©2007 Fujitsu Computer Systems Corporation.
All rights reserved. FPC58-1715-03 11/07.
