Fujitsu Single Drive FTM7924FB User manual

-30
-25
-20
-15
-10
-5
0
0 5 10 15 20
Frequency [GHz]
S11 [dB]
-9
-6
-3
0
0 5 10 15 20
Frequency [GHz]
EO [dB]
Specifications
Single Drive
Single Drive
12Gbps LiNbO3External Modulator
Description
RF performance (for 0-Chirp) Waveform (for 0-chirp)
• Two products for single drive, chirp=0 and ±0.7 (Z-cut)
• Low driving voltage: <5V for RF
• Small size; 65mm x 11.4mm x 4.9mm
(The common package for both chirp 0 and ±0.7)
• Integrating electrical function (Monitor PD, Bias Tee)
• Built-in a monitor PD for auto bias control
• Stable operation in long term for low DC drift
• RoHS compliant
• Applications:
- Optical transponder module
- DWDM optical transmission equipment (2.5Gbps,10Gbps)
- Measurement equipment for high speed telecommunications
Specifications are subject to change without prior notice.
Fujitsu Limited
Optical Components Unit
Sales Department
1-1 Kamikodanaka 4-chome, Nakahara-ku, Kawasaki, 211-8588, Japan (Company Mail No. H0913)
Tel: [phone], Fax: [phone]
E-mail: [email protected]
http://www.fujitsu.com/global/services/telecom/optcompo January, 2008
-5 to 75 ºCOperating Case Temperature
>0.001 A/WMonitor PD Responsivity
65 x 11.4 x 4.9 mm / 2.56 x 0.45 x 0.19 inchesPackage Size (L x W x H)
±0.7 0αParameter (Typ.) <5.5 dBL band
<5.0 dBC band
Insertion Loss
>20 dBExtinction Ratio at Low Frequency
<5.0 V
Driving Voltage (Vπ) at 12.5G 1530 to 1610 nmOperating Wavelength
>10 GHzOptical Bandwidth (-3dB)
FTM7924FBFTM7926FB
Part Number
