FULGOR Sofia User manual

PRO-RANGE 30”- 36” FULL GAS
USE & CARE MANUAL
GUIDE D’UTILISATION ET D’ENTRETIEN
MANUAL DE USO Y CUIDADO

Dear Customer,
Thank you for purchasing one of our Sofia ranges. This range was
conceived, designed and handcrafted in Italy.
Your selection of a Sofia range confirms you are among a special group
who share a love and passion for cooking. This unique community shares
in the experience of creating quality dishes; dishes that will satisfy the
palate while bringing the warmth of families and friends together to share
and rejoice. Impress a loved one with your ability to combine flavours and
ingredients or experiment with new foods and different culinary techniques
to create unexpected pleasures.

EN
1
Pay attention to these symbols present in this manual:
WARNING
• This is the safety alert symbol. This symbol alerts you to
potential hazards that can kill or hurt you and others.
• You can be killed or seriously injured if you don’t follow
these instructions.
READ AND SAVE THESE INSTRUCTIONS.
WARNING
If the information in this manual is not followed exactly, a fire
or explosion may result causing property damage, personal
injury or death.
- Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire
department.
- Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
IMPORTANT: Save these instructions for the local electrical
inspector use.
INSTALLER: Please leave this manual with owner for future
reference.
OWNER: Please keep this manual for future reference.
WARNING
Tip Over Hazard
A child or adult can tip the range and
be killed.
Ensure the anti-tip bracket is engaged
when the range is moved.
Do not operate range without anti-tip
bracket installed and engaged.
Failure to follow these instructions
can result in death or serious burns to
children and adults.
Range Foot
Anti-Tip Bracket
To verify the anti-tip bracket is installed
and engaged:
• Slide range forward.
• Look for the anti-tip bracket securely
attached to floor or wall.
• Slide range back so rear range foot
is under anti-tip bracket.
• See installation instructions for details.

EN
2
TABLE OF CONTENTS PAGE
1 - Safety Precautions 3
2 - Safety Instructions 5
Warnings for Gas and Electric Installation 5
3 - Features of your Oven 6
3 - Panel Controls 8
Control 8
Knobs 8
Signal lamps 8
5 - General Oven Information 9
6 - General Oven Tips 10
Oven Racks 10
Oven Telescopic Racks 11
7 - Setting the Clock and Timer 12
Mechanical Minute Timer 12
Timer Touch Control 12
8 - Selecting the Oven Mode 13
9 - Cooking In The Oven 14
10 - Solving Baking Problems 15
11 - Do-it-Yourself Maintenance Oven Door Removal 16
To Remove Door 16
To Replace Door 16
12 - Replacing an Oven Light 17
To Replace a Light Bulb 17
13 - Features of your Cooktop 18
TABLE OF CONTENTS PAGE
14 - Gas Cooktop Operation 20
Gas Control Knob Setting 20
Gas burners 20
Burners with two flame rings 20
Super Sealed Surface Burners 21
15 - Cookware 22
Cookware Characteristics 22
Match Pan Diameter to Flame Size 22
16 - General Oven Care 23
How to Use the Oven Cleaning Chart 23
Cleaning Chart 23
17 - Oven Finishes / Cleaning Methods 24
18 - Cleaning the Cooktop 25
Cooktop Part / Material Suggested Cleaners 25
19 - Solving Operational Problems 27
20 - Assistance or Service 28
21- Fulgor Milano WARRANTY for Home Appliances 29

EN
3
1 - Safety Precautions
IMPORTANT
Please read all instructions before using this appliance.
WARNING
When properly cared for, your new range has been designed
to be a safe, reliable appliance. Read all instructions
carefully before using this range. These precautions will
reduce the risk of burns, electric shock, fire, and injury
to yourself and others. When using kitchen appliances,
basic safety precautions must be followed, including the
following:
This appliance must be properly installed and grounded by
a qualified technician. Connect only to properly grounded
outlet. See “Grounding Instructions” found in the Installation
Instructions.
• This appliance should be serviced only by a qualified service
technician. Contact the nearest authorized service center for
examination, repair or adjustment.
• Do not repair or replace any part of the appliance unless
specifically recommended. Refer service to an authorized
servicer.
• Do not operate this appliance if it is not working properly
or if it has been damaged, until an authorized servicer has
examined it.
• Install or locate this appliance only in accordance with the
Installation Instructions.
• Use this range only as intended by the manufacturer. If you
have any questions, contact the manufacturer.
• Do not cover or block any openings on this appliance.
• Use this appliance only for its intended use as described
in this manual. Do not use corrosive chemicals, vapors, or
nonfood products in this appliance. This type of oven is
specifically designed to heat or cook. It is not designed for
industrial or laboratory use. The use of corrosive chemicals
in heating or cleaning will damage the appliance.
• In the event that personal clothing or hair catches fire, DROP
AND ROLL IMMEDIATELY to extinguish flames.
WARNING
• In the event of a grease fire SMOTHER FLAMES with a
close-fitting lid, cookie sheet, or other metal tray, then turn
off the gas burner.
• BE CAREFUL TO PREVENT BURNS. If the flames do not
go out immediately, EVACUATE AND CALL THE FIRE
DEPARTMENT.
• Do not use water, including wet dishcloths or towels on
grease fires. A violent steam explosion may result.
• NEVER PICK UP A FLAMING PAN. You may be burned.
• ALWAYS have a working SMOKE DETECTOR near the
kitchen.
• LEAVE THE HOOD VENTILATOR ON when flambéing
food.
• Do not obstruct the flow of combustion air at the oven vent
nor around the base or beneath the lower front panel of
the range. Avoid touching the vent openings or nearby
surfaces as they may become hot while the oven is in
operation. This range requires fresh air for proper burner
combustion.
• NEVER cover any slots, holes or passages in the oven
or cover an entire rack with aluminum foil. Doing so
blocks air flow through the oven and may cause carbon
monoxide poisoning. Aluminum foil linings may also trap
heat, causing a fire hazard.
• NEVER use this appliance as a space heater to heat or
warm the room. Doing so may result in carbon monoxide
poisoning.
To reduce the risk of burn injuries during cooktop
use, observe the following:
• Children or pets should not be left alone or unattended in an
area where appliances are in use.
• Children should never be allowed to sit or stand on any part
of the appliance.
• Do not store flammable materials on or near the cooktop.
• When using the cooktop: DO NOT TOUCH THE BURNER
GRATES OR THE IMMEDIATE SURROUNDING AREA.
• Use only dry potholders; moist or damp potholders on hot
surfaces may cause burns from steam.
• Never leave the cooktop unattended when in use.
• Boilovers cause smoking, and greasy spillovers may ignite.
A spill on a burner can smother all or part of the flame or
hinder spark ignition. If a boilover occurs, turn off burner
and check operation. If burner is operating normally, turn it
back on.
• During cooking, set the burner control so that the flame heats
only the bottom of the pan and does not extend beyond the
bottom of the pan.
• Take care that drafts like those from fans or forced air vents
do not blow flammable material toward the flames or push
the flames so that they extend beyond the edges of the pan.

EN
4
1 - Safety Precautions
• Always position handles of utensils inward so they do not
extend over adjacent work areas, burners, or the edge of
the cooktop.
• Wear proper apparel. Loose fitting garments or hanging
sleeves should never be worn while cooking.
• Never let clothing, potholders, or other flammable materials
come in contact with hot burners or hot burner grates.
• Use only certain types of glass, heatproof glass ceramic,
ceramic, earthenware, or other glazed utensils that are
suitable for cooktop use.
• Do not clean the cooktop while it is still hot. Some cleaners
produce noxious fumes when applied to a hot surface.
CAUTION
Do not allow aluminium foil, plastic, paper or cloth to come
in contact with hot burners or grates. Do not allow pans to
boil dry.
CAUTION
Do not store items of interest to children above the appliance.
If children should climb onto the appliance to reach these
items, they could be seriously injured.
To reduce the risk of fire in the oven cavity:
1. Do not store flammable materials in or near the oven.
2. Do not use water on a grease fire. Smother fire or use a dry
chemical or foam-type extinguisher.
3. It is highly recommended that a fire extinguisher be readily
available and highly visible next to any cooking appliance.
4. Do not overcook food. Carefully attend oven if paper,
plastic or other combustible materials are placed inside the
oven.
5. Do not use the cavity for storage purposes. Do not leave
paper products, cooking utensils or food in the cavity when
not being used.
6. If materials inside the oven should ignite, keep oven door
closed. Turn oven off and disconnect the circuit at the circuit
breaker box.
7. Do not block any vent openings.
8. Be sure the blower fan runs whenever the oven is in
operation. If the fan does not operate, do not use the oven.
Call an authorized service center.
9. For personal safety, wear proper clothing. Loose fitting or
garments with hanging sleeves should never be worn while
using this appliance.

EN
5
2 - Safety Instructions
• Tie long hair so that it doesn’t hang loose.
• Do not touch interior surfaces of oven.
• During and after use, do not touch or let clothing or other
flammable materials contact the burners or the interior
surfaces of the oven until they have had sufficient time to cool.
Other surfaces of the appliance may become hot enough
to cause burns - among these surfaces are (identification of
surfaces - for example, oven vent openings and surfaces near
these openings, oven doors, and windows of oven doors).
• The trim on the top and sides of the oven door may become
hot enough to cause burns.
• Use care when opening the door. Open the door slightly
to let hot air or steam escape before removing or replacing
food.
• Do not heat unopened food containers. Build-up of pressure
may cause the container to burst and cause injury.
• Always place oven racks in desired location while oven is
cool. If a rack must be moved while oven is hot, do not let
pot holder contact the hot burners.
• Use only dry pot holders. Moist or damp pot holders on hot
surfaces may result in burns from steam. Do not let pot holder
touch burners. Do not use a towel or other bulky cloth.
WARNING
• For proper lighting and performance of the burners, keep
the igniters clean and dry.
• In the event that a burner goes out and gas escapes, open
a window or a door. Wait at least 5 minutes before using
the cooktop.
• Do not obstruct the flow of combustion and ventilation air.
• Do not use aluminium foil to line any part of the cooktop.
• If the range cookers is near a window, be certain blow
over or near the burners; they could catch on fire.
Warnings for Gas and Electric Installation
In case of Propane gas installation
The appliance is produced ready for use with natural gas. It
may be converted for use with propane gas using the propane
conversion kit supplied with the appliance.
Be sure the unit being installed is correct for the type of gas being
used. Refer to the rating plate (see Installation Instructions).
WARNING
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
CAUTION
• Always disconnect the electrical plug from the wall
receptacle before servicing this unit.
• For personal safety, this appliance must be properly
grounded.
• Do not under any circumstances cut or remove the third
(ground) prong from the power cord plug..
CAUTION
When connecting the unit to propane gas, make certain
the propane tank is equipped with its own high pressure
regulator. In addition, the pressure regulator supplied with
the appliance must be on the inlet gas pipe of this unit.
In case of electrical failure
If for any reason a gas control knob is turned ON and there is
no electric power to operate the electronic igniter of the cook
top, turn OFF all gas control knobs and wait 5 minutes for the
gas to dissipate before lighting the burner manually.
To light the burner manually, carefully hold a lighted match to
the burner ports and push and turn the gas control knob to HI
until it lights and then turn the knob to desired setting.

EN
6
3 - Features of your Oven
FEATURES OF YOUR OVEN
Rack levels of
embossed cavity
4
6
5
3
2
1
Oven Rack Front
Oven Rack Back
Telescopic Rack
(if present) Stop
Pan Stop
Slide Arm
Handle (if equipped - not all models)
Broiler Pan Rack
Broiler Pan
Control panel
Broil Burner
Cooling Vents
Door gasket
Halogen Light
Model and Serial # Plate
Bottom Burner (concealed) Convection Fan (concealed)
Halogen Light
MODEL 30” NG (Natural) Gas, 5” W.C.P LP (Propane) Gas, 10” W.C.P.
BROIL 14000 Btu/h (4100W) 13000 Btu/h (3800W)
OVEN 18000 Btu/h (5300W) 16000 Btu/h (4700W)
MODEL 36” NG (Natural) Gas, 5” W.C.P LP (Propane) Gas, 10” W.C.P.
BROIL 18000 Btu/h (5300W) 17000 Btu/h (5000W)
OVEN 21500 Btu/h (6300W) 21500 Btu/h (6300W)

EN
7
3 - Features of your Oven
CONTENTS OF YOUR RANGE PACK
QTY DESCRIPTION QTY DESCRIPTION
1 RANGE COOKER
CAST IRON GRATES
2 Psc. FOR 30” RANGE
3 Psc. FOR 36” RANGE
13” BACKSPLASH
THREE FIXING SCREWS 1 PRESSURE REGULATOR
1 KICK COVER 1 NIPPLE
3 FEET 1 GASKET / WASHER
1 FOOT WITH COLLAR
MANUAL & GENERAL
DOCUMENTATION
1
“INSTALLATION INSTRUCTIONS”
1 ANTI TIP FOUR FIXING SCREWS
1 “USE & CARE”
1 GAS CONVERSION KIT
OVEN ACCESSORIES OF YOUR RANGE
QTY DESCRIPTION QTY DESCRIPTION
1 OVEN 1 ENAMELED ROASTING PAN
2 CHROMED RACKS 1ENAMELED ROASTING
PAN GRATE
1 TELESCOPIC CHROMED RACK

EN
8
4 - The Control Panels
Control
Model A: NO Timer
Model B: Mechanical Minute Timer
Model C: Electronic Timer
Knobs
Function selector, with two functions + OFF position.
1. Light
2. Oven fan
Thermostat with two functions + OFF position.
1. Counterclockwise: Oven burner + temperature regulation.
2. Clockwise: Grill Burner
Signal lamps
Left: Fan Failure
Right: ON oven indicator light
The user interface has the following features: display, preheat light indicators, keys for commands, cooking mode and temperature
selectors.
CONTROL PANEL
30”
A
B
C
36”
295
350 400 430 475 500 570
275
350 400 430 475 500 550

EN
9
5 - General Oven Information
Cooling Fan
The fan is situated at the top of the oven and creates a
circulation of cooling air inside the cabinet which comes out
of the slits under the instrument panel of the oven. It comes on
whenever the oven is turned on, for whatever function.
If it fails to come on call the nearest service centre.
Convection Fan
The convection fan operates during any convection mode.
When the oven is operating in the convection mode, the
fan will turn off automatically when the door is opened. The
convection fan always runs during the preheat time.
Oven Light
The knob is used to switch on the oven interior lights. Oven
lights turn on and off automatically when the door is opened
and closed.
Rear Oven Vent
An internal cooling fan operates during all oven modes.
The warm air from the oven is exhausted through vents located
at the rear of the cooktop. Do not allow the airflow from the
rear vents to be obstructed by cookware or towels.

EN
10
6 - General Oven Tips
Preheating the Oven
• Preheat the oven when using the Bake, Convection Bake and
Convection Roast modes.
• Selecting a higher temperature does not shorten the preheat
time.
• Preheating is necessary for good results when baking cakes,
cookies, pastry and breads.
• Preheating will help to sear roasts and seal in meat juices.
• Place oven racks in their proper position before preheating.
Operational Suggestions
• Do not set pans on the open oven door.
• Use the interior oven lights to view the food through the oven
door window rather than opening the door frequently.
Utensils
• Glass baking dishes absorb heat. Reduce oven temperature
25°F (15°C) when baking in glass.
• Use pans that give the desired browning. The type of finish
on the pan will help determine the amount of browning that
will occur.
• Shiny, smooth metal or light non-stick / anodized pans reflect
heat, resulting in lighter, more delicate browning. Cakes and
cookies require this type of cookware.
• Dark, rough or dull pans will absorb heat resulting in a
browner, crisper crust. Use this type for pies.
• For brown, crisp crusts, use dark non-stick / anodized or
dark, dull metal utensils or glass bake ware. Insulated baking
pans may increase the length of cooking time.
• Do not cook with the empty broiler pan in the oven, as this
could change cooking performance. Store the broil pan
outside of the oven.
Oven Condensation and Temperature
• It is normal for a certain amount of moisture to evaporate
from the food during any cooking process. The amount
depends on the moisture content of the food. The moisture
may condense on any surface cooler than the inside of the
oven, such as the control panel.
High Altitude Baking
• When cooking at high altitude, recipes and cooking time
will vary from the standard.
Oven Racks
• The oven has rack guides at six levels as shown in the
illustration on Page 6.
• Rack positions are numbered from the bottom rack guide
(#1) to the top (#6).
• Check cooking charts for best rack positions to use when
cooking.
• Each level guide consists of paired supports formed in the
walls on each side of the oven cavity.
• Always be sure to position the oven racks before turning on
the oven. Make sure that the racks are level and secure once
they are in position.
Please refer to illustration on Page 6 if there is any question
as to which side is the front of the rack.
• The racks are designed to stop when pulled forward to their
limit.
CAUTION
Never use aluminum foil to cover the oven racks or to line
the oven. It can cause damage to the oven liner if heat is
trapped under the foil.
CAUTION
Make sure you do not force it to avoid damage to the
enamel.
To remove oven rack from the oven:
1. Pull rack forward
2. Lift rack up at front and then remove it

EN
11
6 - General Oven Tips
To replace an oven rack:
1. Place rear of rack between rack level guides
2. While lifting front of rack, slide rack in all the way while
lowering the front
Oven Telescopic Racks
• The telescopic rack allows for easier access to cooking foods
for repetitive activities such as basting. It extends beyond the
standard flat rack bringing the food closer to the user.
CAUTION
When the rack is outside of the oven, slide arms do not
lock. They could unexpectedly extend if the rack is carried
incorrectly. Extending slide arms could cause injury. Rack
should only be held or carried by grasping the sides.
NOTE: Always remove the extendable rack before self-
cleaning the oven.
CAUTION
To avoid burns, pull rack all the way out and lift pan above
handle when transferring food to and from oven.
Please refer to illustration on Page 6 if there is any question
as to which side is the front of the rack.
To remove extendable rack from the oven:
1. Lift of rack slightly and push it towards the back of the oven
until the stop releases.
2. Raise back of rack until frame and stop clear rack guide
3. Pull rack down and out
To replace an extendable rack:
1. Grasp rack firmly on both sides. Place rack (including
frame) above desired rack guide
2. Push all the way in until the back of the rack drops into place
3. Pull both sections forward until stops activate. Rack should
be straight and flat, not crooked

EN
12
7 - Setting the Clock and Timer
Mechanical Minute Timer
The minute minder can be set to a maximum time of 60 minutes;
it emits an alarm tone when the set time period has elapsed.
The minute timer operates independently of the oven.
The timer knob must first be turned clockwise to the 60 minute
position and then turned anti-clockwise to the desired time
setting. When the set time has elapsed, the alarm will sound.
The alarm tone will stop automatically after a certain period.
Timer Touch Control
Setting the clock
“Auto” and “0:00” will start flashing when the unit is switched
on for the first time. To set the clock, press the central button for
about 3 seconds. When appears, press +or
-
to set
the correct time.
Wait until a beep tells you that the clock has been set.
To set the time at a later stage, press +and
-
together for 3
seconds and then adjust the clock as described above.
Minute counter
As this minute counter does not control the oven, when it
finishes counting the oven will continue to work.
To set, press the central button for 3 seconds until appears.
Press +and
-
to set the required time.
To set the minute counter at a later stage, press the central
button for 3 seconds and adjust as described above.
The minute counter beeps when it finishes counting.
To disable it, press any button.
Adjusting beep volume
To adjust beep volume, press +and
-
together.
Then press the central button and wait for “ton1 “ (high volume)
to flash. Press
-
to select ‘ton2” (medium volume) or “ton3”
(low volume).
Press the central button to set the selected volume.

EN
13
8 - Selecting the Oven Mode
Prior To Use
To ensure all residual oil from the manufacturing process has
been removed, each oven must go through the following
procedure.
1. Clean oven thoroughly with hot water and a mild detergent.
Rinse and dry with a soft cloth.
2. Turn on ventilation. Some smoke and odor is normal.
3. Set oven temperature to 250 °F (120°C) and allow oven to
heat for 1 hour.
4. Set oven temperature to 500 °F (260°C) and allow oven to
heat for an additional hour.
5. Turn oven off and allow it to cool with the door closed.
Bake Temperature Control
The temperature control knob serves to set the desired oven
temperature and is equipped with a safety valve. When the
oven is in operation the ON light is illuminated.
To turn on the bottom burner, push the temperature control
knob and turn it counterclockwise to the desired temperature.
The minimum position corresponds to an oven temperature of:
30” = 295°F (145°C)
36” = 275°F (135°C)
The control knob has stop in the minimum position.
The maximum position corresponds to an oven temperature of
30” = 570°F (300°C)
36” = 550°F (290°C)
and is obtained when the knob is turned fully counterclockwise.
The burner will be ignited electrically, and the safety valve
temperature sensor will heat up thereby allowing gas to
continue to flow to the burner.
WARNING
If, when turning the thermostat knob and it does not appear
to function properly, turn off the gas supply to the oven and
call the nearest service center.
Broil
To turn on the broiler, press and turn the knob clockwise to the
broil position.
WARNING
When using the broiler accessible parts may get hot, keep
children at a safe distance.
Ventilated Mode
By turning on the convection fan function, cold air (room
temperature) circulates inside the oven thus helping to rapidly
thaw frozen foods.
The convection fan function turned on together with the strong
heat coming from the bottom burner makes it possible to cook
foods more evenly and delicately than with the bottom burner
alone.
Cooking is faster than in a traditional oven. The system is
suitable for cooking foods of different types (fish, meat etc) on
a number of levels.
Pre-heating is not necessary when using ventilated mode but is
still recommended for baking.

EN
14
9 - Cooking In The Oven
With this cooking method, you can operate the oven in the
normal way and follow the instructions in recipe books.
The food to be cooked should preferably be placed on the
middle shelf of the oven.
WARNING
Prolonged use of gas appliances produces heat and humidity
in the kitchen. This may make additional ventilation such as
opening a window or more efficient ventilation necessary,
for example by boosting the level of mechanical ventilation
where present (suction hood).
MAIN COURSE TEMPERATURE °F (°C) COOKING TIME (min) PREHEAT
Genoese Sponge (Swiss Roll) 410 (210) 15 - 20 Yes
Short Pastry (Biscuits) 390 (200) 10 - 12 Yes
Dough With Raising Agent (Schiacciata) 390 (200) 25 - 30 Yes
Sponge Cake (Small Paper Pastry Cases) 375 (190) 20 - 25 Yes
Leavened Dough (Strudel) 355 (180) 40 - 50 Yes
Puff Pastry (Tartlets) 375 (190) 20 - 30 Yes
Soufflé 355 (180) 35 - 40 Yes
Sachertorte 355 (180) 55 - 60 Yes
Fruit Pie 320 (160) 160 - 180 Yes
Choux Pastry 390 (200) 35 - 40 Yes
Roast Beef (Approx. 1.5 Kg) 390 (200) 90 - 120 Yes
Pizza 390 (200) 20 - 25 Yes
Baked Fish 355 (180) 50 - 60 Yes
Baked Vegetables 340 (170) 30 - 40 Yes
Poultry 375 - 390 (190 - 200) 60 - 70 Yes
Guideline values for cooking with the grill
MAIN COURSE COOKING TIME (min) PREHEAT
Steaks 10 - 15 -
Cutlet 15 - 25 -

EN
15
10 - Solving Baking Problems
With either Bake or Convection Bake, poor results can occur for many reasons other than a malfunction of the oven. Check the chart
below for causes of the most common problems. Since the size, shape and material of baking cookware directly affect the baking
results, the best solution may be to replace old baking cookware that have darkened and warped with age and use.
BAKING PROBLEM CAUSE
Food browns unevenly
• Oven not preheated
• Aluminum foil on oven rack or oven bottom
• Baking cookware too large for recipe
• Pans touching each other or oven walls
Food too brown on bottom
• Oven not preheated
• Using glass, dull or darkened metal pans
• Incorrect rack position
• Pans touching each other or oven walls
Food is dry or has shrunk excessively
• Oven temperature too high
• Baking time too long
• Oven door opened frequently
• Pan size too large
Food is baking or roasting too slowly
• Oven temperature too low
• Oven not preheated
• Oven door opened frequently
• Tightly sealed with aluminum foil
• Pan size too small
Pie crusts do not brown on bottom or have soggy crust
• Baking time not long enough
• Using shiny steel pans
• Incorrect rack position
• Oven temperature is too low
Cakes pale, flat and may not be done inside
• Oven temperature too low
• Incorrect baking time
• Cake tested too soon
• Oven door opened too often
• Pan size may be too large
Cakes high in middle with crack on top
• Baking temperature too high
• Baking time too long
• Pans touching each other or oven walls
• Incorrect rack position
• Pan size too small
Pie crust edges too brown • Oven temperature too high
• Edges of crust too thin

EN
16
11 - Do-It-Yourself Maintenance Oven Door Removal
To Remove Door
1. Open the door completely.
2. Flip the hinge security clip on each hinge towards you (1).
3. Hold the door firmly on both sides using both hands and
close the door.
4. Hold firmly; the door is heavy.
5. Place the door in a convenient location.
TO REMOVE THE DOOR
1
1
To Replace Door
1. Insert the upper arms (2) of both hinges into the slots (3). The
recesses (4) must hook on the lips (5).
2. Move the hinge security clips (1) back into position.
3. Close and open the door slowly to assure that it is correctly
and securely in place.
TO REPLACE DOOR
2
4
3
5
ATTENTION
• Make sure oven is cool and power to the oven has been turned off before removing the door. Failure to do so could result in
electrical shock or burns.
• The oven door is substantial. Use both hands to remove the oven door. The door front is glass.
• Handle carefully to avoid breakage.
• Grasp only the sides of the oven door. Do not grasp the handle as it may swing in your hand and cause damage or injury.
• Failure to grasp the oven door firmly and properly could result in personal injury or product damage.
