Dscription
No sensory room? Transform a corner of your school or clinic into a relaxing and interactive sensory
space. Spending a few minutes in the Custom Corner Bubble Tube Area can help kids chill out and
reset their mood. It's filled with sensory room equipment like a color column and sensory lighting. Step
through the curtain of glowing LED fiber optic lights into the semi-enclosed structure with mirrored
sides and ceiling. Sit on the soft, cushioned platform and use the kid-friendly wireless remote to change
the colors and effects of the Waterless LED Color Column. Shatterproof mirrors create an optical
illusion, enhancing the visual effects of the changing lights. Helps enhance relaxation, encourage visual
tracking and improve visual development.
Includes
Custom Corner Bubble Tube Area
Waterless Color Column
Fibre Optic Strands
Come pre-installed in the top
You may not the drill depending on the wall construction. The crosspoint screwdriver will be required to use on all the
*All our equipment is designed for users with special needs. We suggest supervision at all
times when using this equipment.
*For indoor use only. The panel uses a mains power supply. Do not use any other power
cord than the one supplied.
*The platform is designed to support no more than 275 lbs. It is designed for one person
at a time.
*Do Not use free standing. The panel should be installed securely to the wall.
*Never use abrasive cleaning pads to clean this item.
Warnings
8 Way Wireless Rechargeable Remote
2 x power adapters for
column and remote
3
Carefully check you have all the parts listed. Inform us immediately if anything is missing.

Additional Tools (not included)
You will need the following tools to complete the installation:
Drill
Phillips Head Screwdriver
Pieces and Hardware
1 x LH Wall panel
Part Number 1
1 x RH Wall panel
Part Number 2
1 x Platform
1 x Top
Part Number 3
12 x 6 mm Screws 12 x 6 mm Washers
Front Front
Power Cord
Panels are Identified viewing from front edge
Note: 8 x 6 mm screws and washers are required for this installation. Twelve are provided .
Carefully check you have all the parts listed. Inform us immediately if anything is missing.
4

!4
Installation
The sensory equipment connects to a power supply. All the connecting cables are pre-installed in the top
section and the platform. Connect the power cord to the equipment and install all the cables before the
corner is pushed into the final corner position and attached to the wall.
Corner Placement
DO NOT use as standalone equipment. Select the corner where the equipment will be positioned and
complete the installation in this area. This equipment will not fit through doors and it is extremely
heavy once it has been assembled.
We recommend two people to lift the panel onto the wall panel. Do not remove the
protective mirror film until the very end of the installation process.
•Take the RH Wall Panel (Part 2) and stand on its end with edge packer on the left side while looking
at the back.
•Attach 1 x Corner Bracket.
Step 1
RH Wall Panel
Edge packer
Corner Bracket
Part 2
5
Note: The corner bracket may be already installed depending on the model.

!5
• Screw 2 x corner brackets to the top (A) and bottom (B) of the panel using 4 x 6mm washers
and 4 x 6 mm screws. Some models will already have these brackets fitted to them.
Part 2
Step 2
6

!6
1 x LH Wall Panel
Part 1
Part 2
•Take the LH Wall Panel (Part 1) and stand on its end with edge packer on the right side while
looking at the back.
•Attach 1 x corner bracket and use 2 x 6mm washers and 2 x 6mm screws.
The bracket has a black mark to let you know which holes in the bracket to use.
Step 3
7

!7
Place Top (Part 3) and align
holes. Screw 4 x 6mm washers
and 4 x 6mm screws into holes
identified with arrows.
Part 3
Part 2 Part 1
Holes are
identified
with arrows.
Holes are
identified
with arrows.
LH Wall panelRH Wall panel
Step 4
Holes on top
Holes on top
8

Remove cover from top by detaching the Velcro closures .
Fiber Optic Lightsource is secured in place with a
Velcro strip (not shown). The Fiber Optic harness
is pre-installed (not shown).
Step 5
Move the entire corner piece near the final location and rotate so the plinth can be installed.
Velcro Tabs
Step 6
Velcro
Tabs
9

Velcro Tabs
Step 7 • Push the Platform into the corner created by part 1 and part 2 wall panels.
•Attach the velcro tabs to the wall panels
Step 8 Remove seating area of the platform by lifting up on it. The Velcro closures will need to be
gently but firmly pulled apart.
10

!10
1 ) Carefully draw the two IEC cables out of the
top section B . One of the two is labeled AB .
2)Connect this to the cable to the one on the
back of LH Wall Panel, the cable is also labeled
AB. Then connect the supplied IEC mains cord.
The cable is labeled A - Place label A to A
IEC Plugs and sockets
Top Section
IEC Mains Cord
AA
Installing the Power Cables
The power cables are all flexible cables fitted with IEC plugs and sockets. They are fed from the top section
behind the wall panels and into the platform and to the power cord.
Panel 1 1
2
11

!11
3 ) Plug the other lead from the top section
labeled “B” and connect to the cable fastened
to RH wall panel 2.
B
B
B
B
Cable C is used to supply power to
other pieces of equipment you may buy
in the future. It should be tucked out of
the way if not in use.
C
AB
AB
AB
AB
4) Feed Cables labeled “Platform” between the wall
pads gap and feed under into the platform
3
4
12

!12
Attach panels to the wall using the four brackets. Use screws and anchors appropriate for the type
of wall construction where the equipment will be positioned.
Attaching to the Wall
The panels must be installed to a permanent wall of solid construction. The panels have wall brackets, but
screws or wall anchors are not provided. Your professional installer will need to use the appropriate screws
and anchors for your type of wall to be attached to. Professional installation is highly recommended.
Step 1
Step 2
13
Place Waterless LED Color Column into the
platform and plug in the power supply to the
Column and replace the platform lid.

Depending which model you have , the pack will include the relevant instructions for
the equipment.
Step 3 Mirrors are covered in a protective film. Carefully, peel the film away and dispose of it.
Step 4 Connect the electrical supply to the mains power cord. Please refer to the Waterless LED
Color Column and the Fiber Optic Strands with Lightsource instructions for further
information.
Cleaning
We suggest a quick wipe every day after use . A more rigorous cleaning can be completed once a
week.
Before you start to clean unplug the equipment from the electrical outlet.
To clean your Custom Corner Bubble Tube Area, use a soft, lint free white cloth and mild
detergent such as dish washing liquid.
Never use an abrasive cloth or any solvent liquid such as mineral spirits or bleach. The mirrors
and the column can become damaged if appropriate cleaners or cloths are not used.
If the material is ripped, stop using immediately.
14

!13
1. The appliance shall have been purchased and used solely in accordance with Standard
operating instructions and the technical and/or Safety Standards required in the country where this
appliance is to be used
2. All enquiries must be through such dealers .For appliances used in the UK., U.S.A., Channel
Islands, Isle of Man, and Republic of Ireland the appliance should be returned together with this
guarantee and proof of purchase promptly on being found defective, at the purchasers risk and
expense, to the authorised dealer from whom the appliance was purchased.
3. This guarantee shall not apply to damage caused through fire, accident, misuse, wear and tear,
neglect, incorrect adjustment or repair, to damage caused through where this appliance is used, or to
damage occurring during Installation, adaptation, modifications, or use in an improper manner or
inconsistent with the technical and/or safety standards required in the country transit to or from the
purchaser.
4. If at any time during the guarantee period any part or parts of the appliance are replaced with a
part or parts not supplied or approved by us or of an objective quality safe and suitable for the
appliance, or the appliance has been dismantled or repaired by a person not authorised by us, the
purchaser shall not be entitled to any rights and/or remedies under this guarantee.
5. The purchasers sole and exclusive remedy under this guarantee against us is for the repair (or
at our discretion the replacement) of the appliance or any part or parts and no other remedy,
including, but not limited to, incidental or consequential damage or loss of whatsoever nature shall be
available to the purchaser.
6. This guarantee shall not apply to lamps, batteries, color filters, cabinet parts or any other parts
of a limited natural life.
7. Our decision on all matters relating to complaints shall be final. Any appliance or defective part
which has been replaced shall become our property until paid for in full.
8. The guarantee period applicable to all new appliances shall be 12 months.
Guarantee
CONDITIONS OF GUARANTEE
This guarantee is in addition to and does not in any way affect any statutory or other rights of
consumer purchasers.If within the applicable guarantee period (as shown in 8 below) the appliance
proves to be defective by reason of faulty design, workmanship or materials, we undertake subject
to the following conditions to have the defective appliance (or any part or parts thereof) repaired or
at our discretion replaced free of charge.
15

!14
Electrical information
Sensasoft LH Wall Panel - Weight 33 lbs. (15 KG)
Sensasoft RH Wall Panel - Weight 33 lbs. (15 KG)
Sensasoft Top - Weight 44 lbs. (20 KG)
Sensasoft Platform - Weight 33 lbs. (15 KG)
Overall Size - 76.8"H x 41.3H
(1050mm Wide x 1950mm High)
The Custom Corner Bubble Tube Area uses no electrical power , it is a piece of furniture. When
the sensory equipment is installed it uses an IEC mains lead to supply power to the equipment.
Spacekraft copyright July 2022
Disclaimer
No part of this manual may be reproduced in any form or by any means
(graphic, electronic or mechanical, including recording, taping,
photography or information retrieval system) without express written
permission of the publisher of this material.
All information is correct at date of publication.
PO Box 11, Merion Station, PA 19066
QUESTIONS? call us at 800-231-6329 or email us at [email protected].
We are committed to going above and beyond to address your questions, ideas and feedback.
