FUNAI HT2-M200 User manual

INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
Home Theater System
HT2-M200
OWNER’S MANUAL
For Customer Use:
Carefully read the Model No. and Serial No. located at the back
of the unit and enter the information below. Retain this
information for future reference.
Model No. __________________________
Serial No. __________________________
E1T12ED_EN.book Page 1 Tuesday, August 3, 2010 5:13 PM

2EN
INTRODUCTION
This unit employs a laser. Only qualified service personnel
should remove the cover or attempt to service this unit,
due to the possibility of eye injury.
The power supply is connected and the unit is live when
the mains cable is plugged into a 220 - 240 V~, 50 Hz AC
outlet. To operate the unit, press [STANDBY/ON Q].
1 Do not attempt to open the cabinet. There are no
user serviceable parts inside. Refer all servicing to
qualified service personnel.
2 Slots and openings in the cabinet at the sides and
underneath are provided for ventilation. To ensure
reliable operation and to protect the unit from
overheating, these openings must not be blocked or
covered.
Avoid installation in enclosed spaces such as
bookcases unless suitable ventilation is provided.
3 Keep the unit away from radiators and other heat
sources.
4 Avoid use near strong magnetic fields.
5 Do not push objects of any kind into the unit through
the cabinet slots or openings as they could touch
electrically live parts or short circuit parts resulting in a
fire or electric shock.
6
To prevent fire or shock hazard, do not expose this
apparatus to dripping or splashing, no objects filled
with liquids, such as vases, should be placed on the
apparatus.
7 Do not stand the unit vertically. Use the unit in a
horizontal (flat) position only.
8 This product is in Stand-by mode when turned off
while the mains cable is connected.
To completely shut down the unit, you must
disconnect the mains cable.
9 Do not place any combustible objects on the device
(candles, etc.).
10 Before moving the unit, be sure to remove any discs
and unplug the mains cable from the AC outlet.
11 Disconnect the mains plug to switch off when the unit
becomes faulty or not in use.
12 The mains plug shall remain readily operable.
13 Read the manual instructions to ensure correct and
safe installation and interconnection of the unit in
multimedia systems.
14 This apparatus should not be placed in a built-in
installation such as a bookcase or rack unless proper
ventilation is provided. Make sure to leave a space of
20cm or more around this apparatus.
Safety Instructions
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE.
The important note and rating are located on the rear or
bottom of the cabinet.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
The symbol for CLASS II (Double Insulation)
Laser Safety
CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
CAUTION: CLASS 2 LASER RADIATION WHEN OPEN
DO NOT STARE INTO THE BEAM
LOCATION: INSIDE, NEAR THE BD MECHANISM
Power Supply
WARNING: LIVE PARTS INSIDE.
DO NOT REMOVE ANY SCREWS.
Caution
E1T12ED_EN.book Page 2 Tuesday, August 3, 2010 5:13 PM

3EN
INTRODUCTION
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
For safety and optimum performance of this unit:
• Install the unit in a horizontal and stable position.
• Keep the unit away from electronic equipment such as
an amplifier, TV, etc. to prevent warping, damage, fire
and malfunction.
• Do not place anything directly on top of the unit.
• Shield the unit from direct sunlight and keep away from
sources of intense heat. Avoid dusty or humid locations.
Avoid locations with insufficient ventilation for suitable
heat dissipation. Do not block the ventilation holes on
the sides of the unit. Avoid locations subject to strong
vibration or strong magnetic fields.
• Do not handle the mains cable with wet hands.
• Do not pull on the mains cable to disconnect it from the
AC outlet. Grasp it by the plug.
• If, by accident, water is spilled on the unit, unplug the
mains cable immediately and take the unit to an
authorized service centre for servicing.
Moisture condensation may occur inside the unit when it
is moved from a cold place to a warm place, after heating a
cold room, or under conditions of high humidity. Do not
use the unit for at least 2 hours to allow the inside to dry.
Unauthorised copying, broadcasting, public performance
and lending of discs are prohibited. This item incorporates
copy protection technology that is protected by U.S.
patents and other intellectual property rights of Rovi
Corporation. Reverse engineering and disassembly are
prohibited.
Consumers should note that not all high definition
television sets are fully compatible with this product and
may cause artifacts to be displayed in the picture. In case
of picture problems with 480 or 576 progressive scan
output, it is recommended that the user switch the
connection to the ‘standard definition’ output. If there are
questions regarding your TV set compatibility with this
480p or 576p product, please contact our customer service
centre.
A NOTE ABOUT RECYCLING
This product’s packaging materials are recyclable and
can be reused. Please dispose of any materials in
accordance with your local recycling regulations.
This product consists of materials which can be
recycled and reused if disassembled by a specialised
company.
Following information is only for EU-member
states:
The use of the symbol indicates that this product may
not be treated as household waste. By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which
could otherwise be caused by
inappropriate waste handling of this
product. For more detailed information
about recycling of this product, please
contact your local city office, your
household waste disposal service or the
shop where you purchased the product.
Following information is only valid EU-member
States:
Disposal of batteries and/or accumulators
The crossed out wheeled dust bin symbol indicates that
batteries and/or accumulators must be collected and
disposed of separately from household waste. If the
battery or accumulator contains more than the
specified values of lead (Pb), mercury (Hg), and/or
cadmium (Cd) defined in the Battery Directive (2006/
66/EC), then the chemical symbols for lead (Pb),
mercury (Hg) and/or cadmium (Cd) will appear below
the crossed out wheeled dust bin symbol. By
participating in separate collection of batteries, you will
help to assure the proper disposal of products and
batteries and thus help to prevent potential negative
consequences for the environment and
human health. For more detailed
information about the collection and
recycling programmes available in your
country, please contact your local city
office or the shop where you purchased
the product.
Make your contribution to the environment!!!
• Exhausted batteries do not belong in the
dustbin.
• You can dispose of them at a collection
point for exhausted batteries or special
waste.
• Contact your council for details.
Do not place the unit on the furniture that is capable of
being tilted by a child and an adult leaning, pulling,
standing or climbing on it. A falling unit can cause
serious injury or even death.
Pb, Hg, Cd
Installation Location
Avoid the Hazards of Electrical Shock and Fire
Moisture Condensation Warning
About Copyright
Notice for the Progressive Scan Outputs
E1T12ED_EN.book Page 3 Tuesday, August 3, 2010 5:13 PM

4EN
INTRODUCTION
Cleaning the Unit
Use a soft cloth slightly moistened with a mild detergent
solution. Do not use solutions containing alcohol, spirits,
ammonia or abrasives.
Cleaning Discs
If a disc becomes dirty, clean it with a cleaning cloth. Wipe
the disc from the centre out. Do not wipe in a circular
motion.
Do not use solvents such as benzine, thinners,
commercially available cleaners, detergent, abrasive
cleaning agents or antistatic spray intended for analogue
records.
Disc Handling
Handle the discs so that fingerprints and dust do not
adhere to the disc surfaces.
Always store the disc in its protective case when it is not in
use.
Servicing
If the unit becomes inoperative, do not try to correct the
problem by yourself. There are no user serviceable parts
inside. Turn the unit off, unplug the mains cable, and
consult your dealer or an authorised service centre.
Cleaning the Disc Lens
If the unit does not perform correctly even though you
have referred to “Troubleshooting” and the relevant
sections in the Owner’s Manual, the laser optical pickup
unit may be dirty. Consult your dealer or an authorised
service centre for inspection and cleaning of the laser
optical pickup unit.
IR Signal Check
If the remote control is not working properly, you can use a
digital camera (including a cellular phone with built-in
camera) to see if it is sending out an infrared signal.
With a digital camera
(including built-in cell phone cameras):
Point a digital camera towards the remote
control. Push any button on the remote
control and look through the digital
camera. If the infrared light appears
through the camera, the remote control is
working.
Maintenance
E1T12ED_EN.book Page 4 Tuesday, August 3, 2010 5:13 PM

5EN
INTRODUCTION
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
• Remote Control
• Batteries (R6,1.5V × 2)
•Videocable
• FM wire antenna
• 1 centre, 2 front, 2 rear speakers and 1 subwoofer
•Owner’sManual
• Quick Start Guide
•CD-ROM
• Warranty card
INTRODUCTION
Safety Instructions ........................................................................2
Supplied Accessories ...................................................................5
Trademark Information...............................................................6
Symbols Used in this Manual....................................................6
Features ............................................................................................7
Front Panel.......................................................................................8
Rear Panel.........................................................................................8
Remote Control..............................................................................8
Opening Screen .............................................................................9
Front Panel Display.................................................................... 10
CONNECTIONS
Placing the Speakers ................................................................. 11
Connection to the TV................................................................ 11
Connecting Speakers and Subwoofer ................................ 13
Connecting Audio from Cable Box / Recorder /
Game Console or TV.............................................................. 13
Connecting Portable Media Player ...................................... 14
Connecting FM Radio Antenna ............................................. 14
Network Connection with LAN .............................................14
Finding the Video Channel on Your TV.............................. 15
PLAYBACK
Information on Playback.......................................................... 16
How to Insert a Disc................................................................... 19
Selecting the Media Mode...................................................... 19
Playing Back a BD, DVD or a Disc with AVCHD Files ...... 20
Playing Back an Audio CD or a Disc with DivX® /
MP3 / Windows Media™ Audio / JPEG Files .................21
KODAK Picture CD...................................................................... 22
Reading the SD Memory Card ...............................................22
About DivX® and DivX® VOD.................................................. 23
Playing Back DivX® with DivX® External Subtitle ............ 24
Fast Forward / Fast Reverse.................................................... 24
Slow Forward Playback ............................................................ 24
Step by Step Playback .............................................................. 25
Repeat Playback.......................................................................... 25
Programme Playback................................................................ 25
Random Playback....................................................................... 26
Noise Reduction.......................................................................... 27
PIP (BONUSVIEW) Setting ........................................................ 27
Camera Angle .............................................................................. 27
Enjoying BD-Live Discs with Internet..................................27
Search..............................................................................................28
Switching Subtitles.....................................................................29
Switching Audio Soundtrack..................................................29
Setting the BD Audio Mode ....................................................30
Volume Control ...........................................................................30
Selecting Surround Mode........................................................31
Selecting Sound Effect Mode .................................................31
Switching Active Source Mode..............................................32
Sleep Timer....................................................................................32
Play from Portable Media Player ...........................................32
Radio Operations ........................................................................32
Enjoying Internet Radio with vTuner...................................33
FUNCTION SETUP
How to Navigate through the Setup Menus.....................36
List of Setup Menus....................................................................36
TV Aspect .......................................................................................43
Audio Output ...............................................................................43
Parental...........................................................................................45
fun-Link(HDMI CEC) ...................................................................45
Network Connection .................................................................46
Software Update .........................................................................49
Initialise...........................................................................................50
OTHERS
Troubleshooting..........................................................................51
Glossary ..........................................................................................53
Language Code List....................................................................55
Specifications ...............................................................................56
Network Service Disclaimer ....................................................57
Supplied Accessories
Contents
E1T12ED_EN.book Page 5 Tuesday, August 3, 2010 5:13 PM

6EN
INTRODUCTION
“Blu-ray Disc” and are trademarks.
is a trademark of DVD Format/Logo Licensing
Corporation.
To specify which media type each function is applicable to,
we put the following symbols at the beginning of each
item to operate.
If you do not find any of the symbols listed above under the
function heading, the operation is applicable to all media.
Trademark Information
HDMI, the HDMI Logo, and
High-Definition Multimedia
Interface are trademarks or
registered trademarks of HDMI
Licensing LLC in the United
States and other countries.
Manufactured under license from
Dolby Laboratories. Dolby, Pro
Logic, and the double-D symbol are
trademarks of Dolby Laboratories.
Manufactured under license
under U.S. Patent #'s: 5,451,942;
5,956,674; 5,974,380; 5,978,762;
6,487,535 & other U.S. and
worldwide patents issued &
pending. DTS and the Symbol are
registered trademarks, & DTS-HD,
DTS-HD Advanced Digital Out
and the DTS logos are trademarks
of DTS, Inc. Product includes
software.
© DTS, Inc. All Rights Reserved.
“x.v.Color” and “x.v.Color” logo are
trademarks of Sony Corporation.
“AVCHD” and the “AVCHD”
logo are trademarks of
Panasonic Corporation
and Sony Corporation.
“BONUSVIEW” is
trademark of Blu-ray Disc
Association.
“BD-Live” and “BD-Live” logo are
trademarks of Blu-ray Disc Association.
Java and all other Java trademarks and
logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the
United States and/or other countries.
DivX®, DivX Certified® and associated
logos are registered trademarks of DivX,
Inc. and are used under license.
Windows Media and the Windows
logo are trademarks or registered
trademarks of Microsoft Corporation
in the United States and/or other
countries.
vTuner is a trademark of
Nothing Else Matters
Software, Ltd.
Kodak and KODAK Picture CD
Compatible are trademarks of Kodak
used under license.
Symbols Used in this Manual
Symbol Description
Description refers to BD-video and BD-RE
(ver.2.1) / BD-R (ver.1.1/1.2/1.3) recorded in
BDMV format
Description refers to DVD-video
Description refers to audio CD / DTS-CD
Description refers to DVD-RW/-R and SD
Memory Card with AVCHD files
Description refers to BD-RE/-R, DVD-RW/-R,
CD-RW/-R and SD Memory Card with DivX®
files
Description refers to BD-RE/-R, DVD-RW/-R,
CD-RW/-R and SD Memory Card with MP3 files
Description refers to BD-RE/-R, DVD-RW/-R,
CD-RW/-R and SD Memory Card with Windows
Media™ Audio files
Description refers to BD-RE/-R, DVD-RW/-R,
CD-RW/-R and SD Memory Card with JPEG files
E1T12ED_EN.book Page 6 Tuesday, August 3, 2010 5:13 PM

7EN
INTRODUCTION
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
Blu-ray Disc
You can enjoy Blu-ray Disc which is capable of storing five
times more data than a conventional DVD.
BD-Java
With some BDs which support Java applications, you can
enjoy the interactive functions such as games or
interactive menus.
BD-Live
BD-Live (BD-ROM version 2 Profile 2.0) that allows
interactive functions to be used when this unit is
connected to the Internet in addition to the BONUSVIEW
function. The various functions differ depending on the
disc.
Full high-definition video playback
Watch movies in the highest picture quality available for
your HDTV. This unit offers full high-definition video
playback up to 1080p resolution with multi-channel
surround sound capabilities for an amazing viewing
experience. A highly detailed picture and increased
sharpness delivers a more true-to-life picture.
DVD upscaling for enhanced picture quality
Your current DVD will look even better than before thanks
to video upscaling. Upscaling will increase the resolution
of standard definition DVD to high definition up to 1080p
over an HDMI connection. The picture will be less jagged
and more realistic for a near high definition experience.
Enjoy your content on different kinds of media
Full backwards compatibility with BD, DVD, CD and SD
card ensures that you can continue to enjoy your current
audio-video collection. Additionally, you can enjoy
AVCHD / DivX®/ MP3 / WMA / JPEG files.
Listen to rich multi-channel surround sound
Multi-channel surround sound, which recognises real-to-
life sound and makes you feel like you are really there.
PIP (BONUSVIEW)
Some BD-videos have the PIP function which enables you
to display the secondary video in the primary video. You
can call up the secondary video by pressing [MODE]
whenever the scene contains the secondary video.
Pop-up menu
Some BD-video have pop-up menu which is a navigation
menu that can be called up and be operated on the TV
screen without interrupting playback. You can call up the
pop-up menu by pressing [POP MENU / MENU]. Contents
in the pop-up menu vary depending on the disc.
Playing back contents from an SD Memory Card
You can play back AVCHD / DivX®/ MP3 / WMA / JPEGs
stored in an SD Memory Card. BD-ROM Profile 2.0 (BD-Live)
and Profile 1.1 discs sometimes store picture-in-picture
commentary, subtitles or other extras in the SD Memory
Card for use during playback with the BD-video.
Playing Back AVCHD Files
This unit supports playback of AVCHD format files (new
format for high definition video camcorders) recorded on
disc/SD card. Your high definition personal archive is
playable in HD quality.
x.v.Color
This unit supports playback of video contents on discs
recorded with “x.v.Color” technology. To watch this video
content with the “x.v.Color”, a TV or other display device
supporting both video image reproduction using the
“x.v.Color” standard and capable of manually switching it’s
colour setting is required. Please refer to the owner’s
manual of your display device for further information.
vTuner
This unit supports vTuner which is a database service of
Internet radio stations. You can enjoy various kinds of
Internet radio stations with vTuner via the Internet.
Connect this unit to your HDTV with one single HDMI
(High-Definition Multimedia Interface) cable. It is
recommended to use a High Speed HDMI cable for better
compatibility. The high definition video output signal will
be transferred to your HDTV without conversion to
analogue signals, so you will get excellent picture and
sound quality, completely free from noise.
Thanks to other multiple outputs, you can also easily
connect to your home theater system or amplifier.
HDMI Deep Colour
Deep Colour reduces posterisation effect of the playback
image. Refer to “HDMI Deep Color” in “FUNCTION SETUP”
on page 37.
fun-Link(HDMI CEC)
This unit supports fun-Link(HDMI CEC), which allows
integrated system control over HDMI and is part of the
HDMI standard.
This function may not work properly on some devices.
HDMI 1080p24 output (BD only)
This unit is equipped with a feature which can provide
smooth movement during playback of film originated
material with the frame rate of 24 frames per second with
progressive scan. (Available only when the TV is connected
by an HDMI cable and compatible with 1080p24 frame
input.) Refer to “HDMI Video Resolution” in “FUNCTION
SETUP” on page 37.
Copyright protection system
To play back the digital video images of a BD / DVD via an
HDMI connection, it is necessary that both the unit and the
TV (or an AV amplifier) support a copyright protection
system called HDCP (high-bandwidth digital content
protection system). HDCP is copy protection technology
that comprises data encryption and authentication of the
connected AV device. This unit supports HDCP. Please read
the operating instructions of your TV (or AV amplifier) for
more information.
Features
Easy and Simple Connection to Your HDTV Via
HDMI
E1T12ED_EN.book Page 7 Tuesday, August 3, 2010 5:13 PM

8EN
INTRODUCTION
(*) The unit can also be turned on by pressing these buttons.
1. STANDBY/ON Qbutton
2. STANDBY/ON indicator
3. Disc tray
4. OPEN/CLOSE Abutton*
5. Infrared sensor window
6. Display
7. VOLUME K/Lbuttons
8. STOP Cbutton
9. PLAY Bbutton*
10. SOURCE button
11. MP3 LINE-IN jack
12. SD CARD slot
1. Mains cable
2. 5.1ch Audio Out jacks
(SPEAKERS (4Ω))
3. LAN terminal
4. HDMI OUT jack
5. AUDIO IN (AUX) jacks
6. FM ANT 75Ωjack
7. DIGITAL AUDIO IN (Coaxial)
jack
8. COMPONENT VIDEO OUT jacks
9. VIDEO OUT jack
(*)The unit can also be turned on by pressing
these buttons.
1. STANDBY/ON Qbutton
2. DISPLAY button
3. SUBTITLE button
4. Number buttons
5. SEARCH button
6. RED / GREEN / YELLOW / BLUE
button
7. TOP MENU button
8. K/L/0/1buttons
9. SETUP button
10. VOL. + / –button
11. E(reverse) button
12. B(play) button*
13. H(skip) button
14. C(stop) button
15. F(pause) button
16. AUDIO button
17. SURROUND button
18. SOUND MODE button
19. MUTE button
20. MODE button
21. G(skip) button
22. D(forward) button
23. SOURCE +/–button
24. RETURN button
25. ENTER button
26. POP MENU / MENU button
27. CLEAR button
28. ANGLE button
29. REPEAT button
30. OPEN/CLOSE Abutton*
31. SLEEP button
Front Panel
OPEN/CLOSE
STANDBY/ON STOPVOLUME PLAY SOURCE
SD CARD MP3 LINE-IN
1 4* 5832
11
12
9* 1076
Rear Panel
243 5 7 86
1
9
Caution
• Do not touch the inner pins of
the jacks on the rear panel.
Electrostatic discharge may
cause permanent damage to the
unit.
• This unit does not have the RF
modulator.
Remote Control
1
5
7
9
11
13
15
16
17 18
3
14
10
8
30*
27
29
26
24
22
21
20
19
23
25
31
2
6
4
28
12*
E1T12ED_EN.book Page 8 Tuesday, August 3, 2010 5:13 PM

9EN
INTRODUCTION
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
Install 2 R6 (1.5V) batteries matching the polarity indicated
inside battery compartment of the remote control.
Make sure to match + and - on the batteries to the marks
indicated in the battery compartment.
Remote Control Usage Guidelines:
• Make sure that there are no obstacles between the
remote control and the infrared sensor window on the
unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the infrared
sensor window of the unit.
• Remote control for different devices can interfere with
each other. Avoid using remote control for other device
located close to the unit.
• Replace the batteries when you notice a fall off in the
operating range of the remote control.
• The maximum operable ranges from the unit are as
follows.
- Line of sight: approx. 7 m
- Either side of the centre: approx. 5 m within 30°
- Above: approx. 5 m within 15°
- Below: approx. 3 m within 30°
In stop mode and “Mode Select” is set to “Network”,
opening screen is displayed.
“vTuner” : To access the menu screen of vTuner.
Installing the Batteries in the Remote Control
Caution
Incorrect use of batteries can result in hazards such
as leakage and bursting. Please observe the
following:
• Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries.
• Do not mix new and old batteries together.
• Do not use different kinds of batteries together.
Although they may look similar, different batteries
may have different voltages.
• Make sure that the + and - ends of each battery
match the indications in the battery compartment.
• Remove batteries from battery compartment that
are not going to be used for a month or more.
• When disposing of used batteries, please comply
with governmental regulations or environmental
public rules that apply in your country or area.
(Refer to page 3.)
• Do not recharge, short-circuit, heat, burn or
disassemble batteries.
Using a Remote Control
2)1) 3)2)1) 3)
1
21
2
OPEN/CLOSE
STANDBY/ON STOPVOLUME PLAY SOURCE
SD CARD MP3 LINE-IN
30˚30˚
5 m 7 m 5 m
Opening Screen
E1T12ED_EN.book Page 9 Tuesday, August 3, 2010 5:13 PM

10 EN
INTRODUCTION
* Brightness of the display can be adjusted. Refer to “Panel Display” in “List of Setup Menus” on page 40.
1. Displays repeat icon. (Appears during repeat playback.)
2. Displays media icon (disc mode or SD card mode).
3. Displays playback status icon. Refer to the table A below.
4. Displays source mode status (refer to table B below) or information such as title number, elapsed playing time,
repeat type, menu type, etc.
<Table A> <Table B>
• When switching the source mode, the following will be
displayed.
Example of Display Message
Front Panel Display
1 2
3 4
Playback
status icon Mode
Playback is in progress
Stop mode
Pause mode
Fast forward mode
Tuning radio station (in FM mode)
Fast reverse mode
Tuning radio station (in FM mode)
Slow forward mode
Loading
Display Mode
“Disc / SD / Network” mode
“Aux” mode
“Coaxial” mode
“MP3 Line-in” mode
“FM” mode
(Frequency of radio station will
be displayed.)
Disc is being played back.
Indicating the current title number and the elapsed time.
Current chapter is in chapter repeat mode during playback of disc.
Loading a disc and the unit is in “Disc / SD / Network” mode.
Dolby Digital audio is being played back during playback of disc.
DTS audio is being played back during playback of disc.
E1T12ED_EN.book Page 10 Tuesday, August 3, 2010 5:13 PM

11EN
CONNECTIONS
Make the following connection to ensure an optimum sound experience.
1Place the main unit near to the TV.
2Place the speakers system at normal listening ear-level and directly parallel to the listening area.
3Place the subwoofer at the corner of the room or at least 1 metre away from the TV.
Choose the appropriate connection, then proceed to the corresponding instruction on the
pages 11-12.
(Supports up to 1080i, 1080p, 1080p/24 resolution.)
Placing the Speakers
Note
• The placement diagram shown here is only a guideline that provides great system performance. You may find other
placement choices that are more suitable for your room layout that provide the sound experience you enjoy.
• To avoid magnetic interference, never position the front speakers too close to your TV.
• The rear speakers are labelled as REAR LEFT or REAR RIGHT.
• The front speakers are labelled as FRONT LEFT or FRONT RIGHT.
• For speaker setup, refer to “Speaker Setup” on pages 39-40.
Connection to the TV
No supplied cables are used in this connection:
Please purchase the necessary cables at your local store.
Use an HDMI cable with the HDMI logo (a certified HDMI cable) for this connection.
High Speed HDMI cable (also known as HDMI category 2 cable) is recommended for better compatibility.
FRONT
RIGHT
FRONT
CENTER
REAR
RIGHT
REAR
LEFT
SUBWOOFER
LEFT
Best
HDMI IN
HDMI OUT
HDMI cable
Your TV
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
E1T12ED_EN.book Page 11 Tuesday, August 3, 2010 5:13 PM

12 EN
CONNECTIONS
(Supports up to 1080i resolution.)
(Supports only 480i/576i resolution.)
• Connect this unit directly to the TV. If the video cables are connected to a VCR, pictures may be distorted due to the
copy right protection system.
You can change the resolution of the video signal being output from the HDMI OUT jack in the setup menu.
For details, refer to “HDMI Video Resolution*” on page 37.
No supplied cables are used in this connection:
Please purchase the necessary cables at your local store.
Supplied cables used in this connection are as follows:
• Video cable x 1
HDMI Mode and Actual Output Signals
Copyright protection system
To play back the digital video images of a BD-video or DVD-video via an HDMI connection, it is necessary that both the
player and the display device (or an AV receiver / amplifier) support a copyright protection system called HDCP (high-
bandwidth digital content protection system). HDCP is copy protection technology that comprises data encryption
and authentication of the connected AV device. This unit supports HDCP. Please read the operating instructions of
your display device (or AV receiver / amplifier) for more information.
Note
• When connected to an HDCP incompatible display device, the picture will not be displayed properly.
• To output the audio signals from the HDMI OUT jack, set “Audio Output” to “HDMI Normal” or “HDMI LPCM” in the
setup menu. (Refer to page 43.)
• The audio signals from the HDMI OUT jack (including the sampling frequency, the number of channels and bit
length) may be limited by the device that is connected.
• Among the display device(s) that support HDMI, some do not support audio output (for example, projectors). While
connected to a device such as a projector, audio will not be output from the HDMI OUT jack.
• When this unit’s HDMI OUT jack is connected to a DVI-D compatible display device(s) (HDCP compatible) with an
HDMI-DVI converter cable, the signals are output in digital RGB.
Better
COMPONENT
VIDEO IN
Y
PB/CB
PR/CR
Component video cable
Your TV
Basic
VIDEO IN
Your TV
Video cable
E1T12ED_EN.book Page 12 Tuesday, August 3, 2010 5:13 PM

13EN
CONNECTIONS
1Connect the speaker cables to the matching colour sockets on the speakers.
2Connect all the speakers and subwoofer to the matching sockets at the rear of the main unit.
Make sure that the colours of the cables and sockets are matched.
This unit provides analogue and digital audio connection. You can connect the audio output from an audio / video
device (e.g. DVD Recorder, VCR, Cable / Satellite Box, game console or TV) to this Blu-ray Disc home theater in order to
enjoy the multi-channel surround sound capabilities.
• Use an audio cable (not supplied) to connect the AUDIO IN (AUX) jacks on the main unit to the audio output jacks on
the connected device.
• Use a digital audio coaxial cable (not supplied) to connect the DIGITAL AUDIO IN (Coaxial) jack on the main unit to the
digital audio coaxial output jack on the connected device.
Connecting Speakers and Subwoofer
Note
• To prevent unwanted noise, never place the speakers too close to the main unit, subwoofer, AC power adapter, TV or
any other radiation sources.
Connecting Audio from Cable Box / Recorder / Game Console or TV
No supplied cables are used in this connection:
Please purchase the necessary cables at your local store.
Note
• To listen to the audio output from these connections, select “Speakers” in “Audio Output” (refer to page 43) and
change the active source mode to the connected input. (Refer to “Switching Active Source Mode” on page 32.)
Front leftFront rightFront centre Rear leftRear rightSubwoofer
DIGITAL OUT
AUDIO OUT
R
L
DVD Recorder / VCR
Cable / Satellite Box
Your TV
Digital audio coaxial cable
Audio cable
or
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
E1T12ED_EN.book Page 13 Tuesday, August 3, 2010 5:13 PM

14 EN
CONNECTIONS
Connect a 3.5mm stereo audio cable(not supplied) to
the MP3 LINE-IN jack on this unit and the headphone
jack on your portable media player.
1Connect the supplied FM wire antenna to the FM
ANT 75Ωjack on this unit.
2Extend the FM antenna and fix its ends to the wall
for optimum reception.
By connecting this unit to the Internet, you can update the
software via the Internet or access the BD-Live and vTuner
service.
Connecting Portable Media Player
No supplied cables are used in this connection:
Please purchase the necessary cables at your local
store.
Note
• To playback the audio from your portable media
player, refer to “Play from Portable Media Player” on
page 32.
Connecting FM Radio Antenna
Note
• For better FM stereo reception, connect an external
FM antenna (not supplied).
• Place the antenna away from your TV, VCR or other
radiation source to prevent any unwanted
interference.
• For FM radio playback, refer to “Radio Operations” on
page 32.
MP3 LINE-IN
OPEN/CLOSE
STANDBY/ON STOPVOLUME PLAY SOURCE
SD CARD MP3 LINE-IN
MP3
FM
ANT
75
Network Connection with LAN
No supplied cables are used in this connection:
Please purchase the necessary cables at your local
store.
Caution
• Do not insert any cable other than a LAN cable to the
LAN terminal to avoid damaging the unit.
Note
• After connecting a LAN cable, set up necessary
network settings. (For the network setup, refer to
“Network Connection” on pages 46-48.)
• For more information about the software update,
refer to “Network Update” on page 49.
• For more information about BD-Live, refer to
“Enjoying BD-Live Discs with Internet” on pages 27.
• For more information about vTuner, refer to “Enjoying
Internet Radio with vTuner” on page 33.
• If your network equipment (modem, etc.) does not
have broadband router functions, connect a
broadband router.
• If your network equipment (modem, etc.) has
broadband router functions but there is no vacant
port, use a hub.
• For a broadband router, use a router which supports
10BASE-T/100BASE-TX.
• Do not connect your PC directly to the LAN terminal
of this unit.
• Please purchase shielded LAN cables at your local
store and use them when you connect to network
equipment.
LAN WAN LAN
12345
LAN cable LAN cable
Networking equipment
(modem, etc.)
Hub or broadband router
Internet
E1T12ED_EN.book Page 14 Tuesday, August 3, 2010 5:13 PM

15EN
CONNECTIONS
After you have com pleted all the conn ections, you mu st find the correc t video chan nel (external in put channel) on your TV.
After you have completed all the connections, you must
find the correct video channel (external input channel) on
your TV.
1After you have made all the necessary
connections, press [STANDBY/ON Q] to turn
on the unit.
2Turn on your TV.
3Press the button on the TV’s remote control
that accesses the external input channel. It
may be labelled “SOURCE”, “AV” or “SELECT”
(refer to your TV’s user manual).
Finding the Video Channel on Your TV
Note
• If the TV is connected by an HDMI cable, it may take a
while for the opening picture to come up.
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
E1T12ED_EN.book Page 15 Tuesday, August 3, 2010 5:13 PM

16 EN
PLAYBACK
Before you start playing back a disc, read the following information.
This unit is compatible to play back the following discs /
files. To play back a disc / file, make sure that it meets the
requirements for region codes and colour systems as
described below. You can play back discs that have the
following logos.
Other disc types are not guaranteed to play back. • ABOUT DIVX VIDEO: DivX®is a digital video format
created by DivX, Inc. This is an official DivX Certified
device that plays DivX video. Visit www.divx.com for
more information and software tools to convert your files
into DivX video.
• ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified®
device must be registered in order to play DivX Video-on-
Demand (VOD) content. To generate the registration
code, locate the DivX VOD section in the device setup
menu. Go to vod.divx.com with this code to complete the
registration process and learn more about DivX VOD.
• DivX Certified®to play DivX®video up to HD 1080p,
including premium content.
• Discs containing the DivX®files with the DivX®GMC
(Global Motion Compensation) playback feature, which is
DivX®supplemental function, cannot be played back on
this unit.
It is recommended that files to be played back in this
unit are recorded under the following specifications:
DivX®
Official DivX®Certified product
MP3/Windows Media™ Audio
JPEG
Information on Playback
Playable Discs and Files
Playable discs Logos
Blu-ray Disc
- BD-video (single / dual layer)
- BD-RE ver. 2.1 (single / dual layer)
(Recorded in BDMV format)
- BD-R ver. 1.1 / 1.2 / 1.3 (single / dual
layer) (Recorded in BDMV format)
(Unclosed discs may not be played
back.)
DVD-video
DVD-RW
DVD-R
CD-DA (audio CD)
CD-RW
CD-R
KODAK Picture CD
DTS-CD -
Playable files Media
AVCHD
DVD-RW/-R
SD Memory Card (including SDHC)
miniSD Card
microSD Card
DivX®BD-RE/-R
DVD-RW/-R
CD-RW/-R
SD Memory Card (including SDHC)
miniSD Card
microSD Card
MP3
Windows Media™ Audio
JPEG
Readable cards Playable files / data
SD Memory Card (8 MB - 2 GB) AVCHD, DivX®, MP3, WMA,
JPEG, picture-in-picture
commentary, subtitles or
other extras for BD-ROM ver. 2
(Profile 2.0 / Profile 1.1)
SDHC Memory Card (4 GB - 8 GB)
miniSD Card (8 MB - 2 GB)
microSD Card (8 MB - 2 GB)
• Playable codec of AVI files : DivX®3.x, DivX®4.x,
DivX®5.x, DivX®6.x
• Maximum size of a video : 1920 x 1080 @ 60 fps
•Samplingfrequencyof
audio
: 16 kHz - 48 kHz
• Audio type : MPEG1 audio layer 3 (MP3),
MPEG1 audio layer 2,
Dolby Digital
• Sampling frequency : 32 kHz, 44.1 kHz or 48 kHz
• Constant bit rate : 112 kbps - 320 kbps (MP3),
48 kbps - 192 kbps
(Windows Media™ Audio)
• Upper limit : 2,560 x 1,900 dots (sub
sampling is 4:4:4)
5,120 x 3,840 dots (sub
sampling is up to 4:2:2)
• Lower limit : 32 x 32 dots
• File size of image
maximum
: 12 MB
E1T12ED_EN.book Page 16 Tuesday, August 3, 2010 5:13 PM

17EN
PLAYBACK
The following discs will not be played back in this unit.
• Unfinalised disc
• BD-RE (ver.1.0)
• BD-RE (ver.2.1) (Recorded in BDAV format)
• BD-R (ver.1.1 / 1.2 / 1.3) (Recorded in BDAV format)
• BD that contains AVCHD files
• BD / DVD hybrid disc (played back as a BD-video only)
• DVD-RW/-R recorded in non compatible recording
format
• Super Audio CD - Only the sound on the CD layer can be
heard. The sound on the high-density Super Audio CD
layer cannot be heard.
• Playability of dual discs are not guaranteed.
• This unit cannot play back the disc contents protected by
Windows Media™ Digital Rights Management (DRM).
BD and DVD are recorded in different colour systems
throughout the world. The most common colour system,
used primarily in the U.K. and other EU countries, is PAL.
This unit uses the PAL system. However, it is also possible
to play back BD and DVD using other colour systems, such
as NTSC.
The contents of BD / DVD / AVCHD are generally divided
into titles. Titles may be further subdivided into chapters.
Audio CD are divided into tracks.
Data discs or SD Memory Cards containing DivX®/ MP3 /
WMA / JPEG are divided into folders, and the folders are
subdivided into files.
Note for SD Memory Cards
• This unit supports SD Memory Card with FAT12/
FAT16 file system, and SDHC Memory Card with FAT32
file system.
• This unit does not support NTFS file system.
• This unit may not read SD Memory Cards formatted
on a computer. If that is the case, please reformat the
SD Memory Cards in this unit and try again.
• This unit does not support miniSDHC and microSDHC
Memory Card.
• For miniSD Card and microSD Card, an adapter is
necessary.
• Portions of this product are protected under
copyright law and are provided under licence by
ARIS / SOLANA / 4C.
• Please keep the SD Memory Cards in their cases when
you are not using them.
• Do not try to open or modify the card.
• Do not touch the terminal surface with your fingers or
any metals.
• Do not attach additional labels or stickers to cards.
• Do not remove the label of the SD Memory Cards.
• This unit recognises up to 8 characters of file name in
the SD Memory Card. Characters after 8th will not be
displayed.
Unplayable Discs and Files
• CD-ROM • CD-I (compact disc-interactive)
•DVD-RAM •VSD(videosingledisc)
•DVD-audio •VideoCD
• HD DVD • SVCD
miniSD Card
adapter
miniSD Card microSD
Card
microSD Card
adapter
Colour Systems
Region Codes
This unit has been designed to play back
BD-video with region “B” and DVD-video
with region “2” or “ALL”. You cannot play
back BD-video or DVD-video that are
labelled for other regions. Look for the
symbols on the right on your BD-video or
DVD-video.
If these region symbols do not appear on
your BD-video or DVD-video, you cannot
play back the disc in this unit. The letter or
number inside the globe refers to region
of the world. A BD-video or DVD-video
labelled for a specific region can only be
played back in the unit with the same
region code.
BD-video
DVD-video
Structure of Disc / SD Memory Card Contents
2
BD / DVD / AVCHD
title 1 title 2
chapter 1 chapter 2 chapter 2chapter 1 chapter 3
audio CD
track 1 track 2 track 3 track 4 track 5
DivX®/ MP3 / WMA / JPEG
folder (group) 1 folder (group) 2
file 1 file 2 file 3 file 4 file 5
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
E1T12ED_EN.book Page 17 Tuesday, August 3, 2010 5:13 PM

18 EN
PLAYBACK
You can check information about the current disc by
pressing [DISPLAY].
To call the on-screen display menu, press [DISPLAY]
during playback. Every time you press [DISPLAY], the
information changes. Depending on the media, available
information varies.
OFF ATitle / Chapter information
ATitle information (elapsed time)
ATitle information (remaining time)
ADecoding format information AOFF
OFF AChapter information (elapsed time)
AChapter information (remaining time)
ATitle information (elapsed time)
ATitle information (remaining time)
ADecoding format information AOFF
OFF (Track information (elapsed time))
ATrack information (remaining time)
ADisc information* (elapsed time)
ADisc information* (remaining time)
AOFF (Track information (elapsed time))
(* not available during programme / random playback)
OFF AFile information (elapsed time)
AFile information (remaining time)
AFile name information AOFF
OFF (File information (elapsed time))
AFile name information
AOFF (File information (elapsed time))
OFF (File information (elapsed time))
AFile name information
ATag information (title name)
ATag information (artist name)
AOFF (File information (elapsed time))
OFF AFile information AFile name information AOFF
Chapter information
<Title / Chapter information for BD / AVCHD>
<Chapter information for DVD>
1. Current title number
2. Current chapter number / Total number of chapters
3. Current repeat setting (Only when repeat setting is
active)
(C:Chapterrepeat,T:Titlerepeat)
4. Indicates that the multi camera angle images are
available on the scene
5. Current playback status
6. Elapsed time (or remaining time) of the current
chapter
Title information
1. Current title number / Total number of titles
2. Elapsed time (or remaining time) of the current title
Track / File information
1. Current track (file) number / Total number of track
(file)
2. Elapsed time (or remaining time) of the current
track / file (except for JPEG files)
3. Indication of SD Memory Card playback
4. Current repeat setting
(Only when repeat setting is active)
(T: Track repeat, G: Group repeat, A: All repeat)
Disc information
1. Current track number / Total number of tracks
2. Elapsed time (or remaining time) of the current disc
On-Screen Display
1 1/10
1 32 4 5
T
3 / 5 0 : 01 : 02
2 6
3 / 5 0 : 01 : 02
1 2
SD1 / 14 0 : 00: 51 G
1 3 42
1 / 14 0 : 00: 51 T
1 2
E1T12ED_EN.book Page 18 Tuesday, August 3, 2010 5:13 PM

19EN
PLAYBACK
File name information
1. Media icon and file name
Tag information
1. Title name based on tag information of current
Windows Media™ Audio file
2. Artist name based on tag information of current
Windows Media™ Audio file
Decoding format information
1. Decoding format
1Press [OPEN/CLOSE A] to open the disc tray.
2Place the disc on the disc tray with its label
side facing up.
• Make sure the disc is compatible with this unit. (Refer to
page 16 for the list of compatible discs.)
3Press [OPEN/CLOSE A] to close the disc tray.
To eject the disc:
Press [OPEN/CLOSE A]to open the disc tray.
Remove the disc.
Press [OPEN/CLOSE A]to close the disc tray.
For the playback media to be read by this unit, the correct
media mode should be selected. You can switch the media
mode by following the steps below.
1In stop mode, press [SETUP].
2Use [K/L] to select , then press [ENTER].
3Use [K/L] to select “Mode Select”, then press
[ENTER].
4Use [K/L] to select the desired media, then
press [ENTER].
5Press [SETUP] to exit.
: DivX®files : MP3 files
: WMA files : JPEG files
File_name_001
1
TITLE
1
ARTIST NAME
2
<Title name information>
<Artist name information>
Dolby Digital
1
How to Insert a Disc
Selecting the Media Mode
Note
• Even if you set the media mode to “SD Card” or
“Network”, the setting will be switched to “Disc” in
following cases :
- If you turn the unit into the standby mode.
- If you change the active source mode to “Aux”,
“Coaxial”, “MP3 Line-in” or “FM” mode.
• “SD Card” can be selected only when an SD Memory
Card is inserted into the SD CARD slot.
Align the disc to the
disc tray guide.
It may take a while to load the disc.
INTRODUCTION CONNECTIONS PLAYBACK FUNCTION SETUP OTHERS
E1T12ED_EN.book Page 19 Tuesday, August 3, 2010 5:13 PM

20 EN
PLAYBACK
1Insert a disc (refer to “How to Insert a Disc” on
page 19 ).
2Playback may start automatically.
If not, press [B(play)].
Some discs may show a title or a disc menu.
In such case, refer to “Using the Title / Disc / Pop-up
Menu” on page 20.
To pause playback:
Press [F(pause)].
To return to the normal playback:
Press [B(play)].
To stop playback:
Press [C(stop)].
Playback will be in Resume-On-Stop mode.
Many of BD-video and DVD-video discs contain title menu
(BD-video / DVD-video / AVCHD), disc menu (DVD-video)
or pop-up menu (BD-video) which guides you through the
available functions in the disc. The contents of the menus
may differ depending on the discs.
Title menu (BD-video / DVD-video / AVCHD)
1Press [TOP MENU].
2Use [K/L/0/1] to select an item, then press
[ENTER].
3Press [TOP MENU] to exit.
Disc menu (DVD-video)
1Press [POP MENU / MENU].
2Use [K/L/0/1] to select an item, then press
[ENTER].
3Press [POP MENU / MENU] to exit.
Pop-up menu (BD-video)
This is a special feature available for some BD-videos.
When you press [POP MENU / MENU], a menu pops out
on the TV screen during play back.
1During the playback of BD-video, press
[POP MENU / MENU].
2Use [K/L/0/1] to select an item, then press
[ENTER].
3Press [POP MENU / MENU] to exit.
Playing Back a BD, DVD or a Disc with
AVCHD Files
Resume-On-Stop mode
If a playback is in Resume-On-Stop mode, when you
press [B(play)] next time, the playback will start from
the point where it has been stopped.
Note
• Resume playback may not be available for the BD that
supports Java applications (BD-Java).
• In the “Disc” mode, the resume information will be
cleared when;
-[C(stop)] is pressed while in the Resume-On-Stop
mode.
- the parental level is changed.
- the disc tray is opened.
• In the “SD Card” mode, the resume information will be
cleared when;
-[C(stop)] is pressed while in the Resume-On-Stop
mode.
- the SD Memory Card is removed.
- the unit is turned into the standby mode.
Note
• may appear at the top-right on the TV screen
when the operation is prohibited by the disc or this
unit.
• During the playback of 2-layered disc, pictures may
stop for a moment. This happens when the 1st layer
switches to the 2nd layer. This is not a malfunction.
• The operation may vary when you play back BD-
video and DVD-video with disc menu. Refer to the
manual accompanying the disc for details.
• Set “Still Mode” setting to “Field” in “Video” menu if
pictures in the pause mode are blurred. Refer to “Still
Mode” on page 38.
Using the Title / Disc / Pop-up Menu
Note
• Contents of menus and corresponding menu
operations may vary among discs. Refer to the
manual accompanying the disc for details.
• Title menu is also available for SD card with AVCHD
files.
E1T12ED_EN.book Page 20 Tuesday, August 3, 2010 5:13 PM
